Insta PUT IT ON 101 User manual


FOR USE BY QUALIFIED PERSONNEL ONLY
- 1 -
Safety Summary
WARNING
In case of power cord damage, do not
attempt to repair or replace the power
cord. Contact the manufacturer or the
local distributor.
CAUTION
Hot surface. Avoid contact.
CAUTION
During normal operation, the base of the
machine needs to be installed or placed
above the wall socket.
CAUTION
The machine is to be operated by one
person only.
WARNING
To reduce the risk of electric shock and
injury to persons, disconnect from power
supply before servicing and/or cleaning.
CAUTION
The temperature adjustment knob gets
very hot during operation. Adjust only
when machine is cold.
International Symbols
O
Power Off
I
Power On
Hot Surface
Risk of Electrical Shock
Protective Earth Terminal
Ground
Caution - Warning

FOR USE BY QUALIFIED PERSONNEL ONLY
- 2 -
Congratulations!
Your selection of the Insta Graphic Systems heat seal
machine is a sound business decision. Insta equipment is
the result of the highest quality engineering and time-
tested design. Your new machine combined with Insta’s
reputation of innovation in the heat-seal industry, insures
the continuing capability of delivering the best-decorated
substrates possible.
This manual describes installation, operation, and
maintenance procedures for your new model 101
machine.
Your model 101 machine will have a long
trouble-free life. Read this manual. Keep it with your
machine; it's your key to proper operation and lasting
service.
Installation
DOMESTIC
Use a 15 amp AC circuit. Only industrial
weight extension cords with proper wire
size should be used: size 16/3 wire for
distances up to 25 feet, and size 14/3 for
distances up to 50 feet.
INTERNATIONAL
Only industrial extension cords with
proper wire size (2.5 mm sq.) shall be
used.
IMPORTANT
The appliance must be plugged into a
proper receptacle of the proper size and
rating. Equally important, the line
voltage must be able to accommodate this
appliance as well as other appliances
operating on this circuit.
Specifications
Voltage 120 Volts AC 50/60 Hertz
Model 101 1200 Watts 10.0 Amps
Voltage 230 Volts AC 50/60 Hertz
Model 101 1200 Watts 5.2 Amps
Weight Model 101 29 Pounds (13.2 KG)
Limited Machine Warranty
Insta Graphic Systems warrants this heat seal machine,
when operated under normal conditions, to be free from
manufacturing defects in material and workmanship for a
period of one year on parts (lifetime on the upper heating
element) and 90 days on labor from the invoice date.
This warranty will be effective only when Insta authorizes
the original purchaser to return the product to the factory
in Cerritos, California freight prepaid, and only when the
product upon examination has proven to be defective.
This warranty does not apply to any machine that has
been subjected to misuse, negligence or accident.
Insta shall not be liable for the injury, loss or damage,
direct or consequential, arising out of the use or the
inability to use the product.
No claim of any kind shall be greater in amount than the
sale price of the product or part to which claim is made.
This is the sole warranty given by the company, it is in
lieu of any other warranties, expressed or implied, in law
or in fact, including the warranties of merchantability
and fitness for a particular use, and is accepted as such
by the purchaser in taking delivery of this product.
Operation
1. Push ON/OFF switch to ON position. Set desired
temperature and lift handle so that the upper platen
arm is away from lower platen.
CAUTION
The temperature adjustment knob gets very
hot during operation. Adjust only when
machine is cold.
2. Allow the machine to warm up for approximately 20
minutes. When the selected temperature is reached,
the neon lamp on the power switch will cycle on and
off.
3. Set the desired pressure by adjusting the pressure
adjust knob on the top-center of the machine. To
reduce pressure, turn knob clockwise.
4. Place the substrate on lower platen. Smooth out all
wrinkles.

FOR USE BY QUALIFIED PERSONNEL ONLY
- 3 -
5. Position transfer or lettering on substrate.
6. Close machine by pulling handle down into locked
position.
7. At end of the time cycle. Pull handle up slowly and
move the upper platen handle to its full open
position. This technique will avoid transfer paper
(cover) from being pulled off prematurely due to
suction from the separating platens.
Preventive Maintenance Suggestions
The Insta heat seal machines are relatively maintenance
free. For a long, trouble-free life, the following preventive
maintenance steps should be followed:
1. Do not heat seal items such as buttons, pins, snaps, or
zippers which tend to cut the silicone rubber pad or
scratch the Teflon heat platen.
2. Periodically clean the Teflon-coated heat platen with
a non-abrasive piece of cloth. Stubborn stains may be
cleaned, when platen is cool, with mineral spirits.
3. When the heat platen is hot and not in use, keep in
open position (away from the silicone rubber pad).
4. To prevent soiling of substrate, periodic wiping of
the entire exterior machine, including platens, with a
clean rag is recommended. If necessary, use mineral
spirits for cleaning a cold machine. Since mineral
spirits are flammable, use precautions and keep away
from sparks, flame, or hot heat platen.
5. Occasionally apply a few drops of heavy machine oil
to the moving parts and pressure adjustment screw.
NOTE
Wipe off any excess oil or grease.


17
47
8
46
26
1
10
23
18
42
24
34
13
27
14
23
40
38
29
25
5
9
2
22
41
30
32
28
21
30
35
3
30
20
6
35
7
29
15
16
19
36
30
11
4
37
44
41
43
45
A2
39
31
33
A1
MODEL 101
MODEL 101 0410

MODEL 101 0410
MODEL MODEL
MS101 MS101
NO PART NAME QTY 120V 230V
1 MS101 BASE 1 MPB90161 MPB90161
2 MS101 ARM 1 MPA90162 MPA90162
3 REAR SPRING PIN 1 MPP90252 MPP90252
4 OVERCENTER LEVER 1 MPL90253 MPL90253
5 PHILLIPS SCREW PAN HEAD 8-32x5/16 1 SP832516 SP832516
6 OVER CENTER SPRING PIN 1 MPP90254 MPP90254
7 OVER CENTER LOCK ASSEMBLY 1 MPL90255 MPL90255
8 GROMMET 1 1004542116 1004542116
9 SWITCH POWER WITH CLIP 1 MPPS230 MPPS230
10 13 X 13 RUBBER PAD 1 MPP90163 MPP90163
11 SLEEVE, 101 TEMP. CONTROL 1 MPS90293 MPS90293
13 GUIDE PIN 1 MPP90256 MPP90256
14 UPPER PLATEN SHROUD 1 MPSS101 MPSS101
15 PRESSURE ADJUSTMENT SCREW 1 MPS90257 MPS90257
16 ADJUST KNOB 1 MPPK018 MPPK018
17 TEMPERATURE CONTROLLER W/KNOB 1MPPT032 MPPT032
18 INLET POWER CONNECTOR 1 MPC90258 MPC90258
19 SINGLE PIN HANDLE 1 MPP90259 MPP90259
20 RETURN SPRING 2 MPS90260 MPS90260
21 PRESSURE HANDLE 1 MPH90261 MPH90261
22 RUBBER GRIP 1 MPSH168 MPSH168
23 PHILLIPS SCREW PAN HEAD 10-32x3/16 6 SP103212 SP103212
24 REAR COVER PLATE 1 MPP90262 MPP90262
25 ADJUST COLLAR 1 MPSP247 MPSP247
26 RUBBER FOOT 6 MPF90004 MPF90004
27 INSULATION SHROUD 13X13 1 MPI90263 MPI90263
28 HANDLE PIN 1 MPP90264 MPP90264
29 SET SCREW 2 SST1032316 SST1032316
30 E-CLIP FOR ½ PIN 8 MPSC240 MPSC240
31 CENTER LOCK PIN 1 MPP90265 MPP90265
32 BOTTOM PIN 1 MPP90266 MPP90266
33 LOCK WASHER #8 1 WL8 WL8
34 PHILLIPS SCREW PAN HEAD 6-32x1/4 2 SP63214 SP63214
35 E-CLIP FOR 3/8 PIN 4 MPSC241 MPSC241
36 OVER CENTER LEVER MECHANISM PIN 1 MPP90267 MPP90267
37 NUT 1/4-20 1 MPNH1420 MPNH1420
38 TEMPERATURE DECAL 1 100454221 100454221
39 TEMPERATURE LIMITER 1 MPPT045 MPPT045
40 POWER CORD 1 MPP90250 MPP90251
41 TEFLON BUSHING 4 MPS90285 MPS90285
42 WIRE HARNESS 1 MPW90180 MPW90180
43 WIRE CLAMP 1 CC14 CC14
44 WASHER #8 1 WSAE8 WSAE8
45 DECAL 1 MPL90176 MPL90176
46 PHILLIPS SCREW PAN HEAD 8-32x1/4 1 SP83214 SP83214
47 INTERNAL LOCK WASHER #8 1 WLIT8 WLIT8
A1 PLATEN HEAT ASSY COMPLETE 1 MPP1011-A MPP1012-A
A2 PLATEN HEAT WITH WIRING 1 MPP101W MPP1012W
