Intel®Server System SR1680MV
Service Guide
A Guide for Technically Qualified Assemblers of Intel® Identified Subassemblies/Products
Intel Order Number E74835-005

ii Intel®Server System SR1680MV Service Guide
Disclaimer
Information in this document is provided in connection with Intel® products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's
Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any
express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining
applications or for any other application in which the failure of the Intel product could create a situation where
personal injury or death may occur. Intel may make changes to specifications and product descriptions at any time,
without notice.
Intel server boards contain a number of high-density VLSI and power delivery components that need adequate
airflow for cooling. Intel's own chassis are designed and tested to meet the intended thermal requirements of these
components when the fully integrated system is used together. It is the responsibility of the system integrator that
chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to
determine the amount of airflow required for their specific application and environmental conditions. Intel Corporation
can not be held responsible if components fail or the server board does not operate correctly when used outside any
of their published operating or non-operating limits.
Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in
the United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2010, Intel Corporation. All Rights Reserved

Intel®Server System SR1680MV Service Guide iii
Preface
About this Manual
Thank you for purchasing and using the Intel®Server System SR1680MV.
This manual is written for system technicians who are responsible for troubleshooting,
upgrading, and repairing this server system. This document provides a brief overview of
the board features, a list of accessories or other components you may need,
troubleshooting information, and instructions on how to add and replace components on
the Intel®Server System SR1680MV. For the latest version of this manual, see
http://support.intel.com/support/motherboards/server/SR1680MV/.
Manual Organization
Chapter 1 provides a brief overview of the Intel®Server System SR1680MV. In this
chapter, you will find a list of the system features, photos of the product, and product
diagrams to help you identify components and their locations.
Chapter 2 provides instructions on adding and replacing components. Use this chapter for
step-by-step instructions and diagrams for installing or replacing components such as the
fans, power supply, drives, and other components.
Chapter 3 provides information on the cable connection. Use this chapter for detailed
information on the cable connections and connector locations.
Chapter 4 provides the description of the functions of all server board jumpers, and
connectors.
Chapter 5 describes the update process and configure features of the system BIOS.
Chapter 6 provides an overview of the embedded SATA RAID options and how to
configure RAID sets.
Chapter 7 provides instructions for installing rail kit to racks.
At the back of this book, you will find an issue report form, troubleshooting information,
regulatory information, and safety information.

iv Intel®Server System SR1680MV Service Guide
Product Contents, Order Options, and Accessories
Your Intel®Server System SR1680MV ships with the following items:
•One 1U chassis
•Two Server Boards
•Two Riser Cards
•Two 2.5-inch SATA HDD backplanes
•One left I/O board
•One right I/O board
•Four Hot-Swap 2.5-inch HDD trays
•Two NIC Boards
•One Power Distribution Board
•Six System Fans
•Four CPU Heatsinks
•One unit Rack Bracket
•Screws for 2.5-inch HDD
•One 1100-W power supply
In addition, you may need or want to purchase one or more of the following accessory
items for your server:
Processor, memory DIMMs, hard drive, and operating system.
For information about which accessories, memory, processors, and third-party hardware
were tested and can be used with your board, and for ordering information for Intel
products, see
http://support.intel.com/support/motherboards/server/SR1680MV/compat.htm.
Additional Information and Software
Documentation and software for this server product are available on the Intel Resource
CD-ROM that shipped with your Intel server product. You can obtain software updates
and additional information at the following Intel website:
http://support.intel.com/support/motherboards/server/SR1680MV/

Intel®Server System SR1680MV Service Guide v
Unless otherwise indicated in the following table, once on this webpage, type the
document or software name in the search field at the left side of the screen and select the
option to search “This Product.”
Additional Information and Software
For this information or
software Use this Document or Software
For in-depth technical
information about this
product, including BIOS
settings and chipset
information
Intel® Server System SR1680MV Technical Product Specification
If you just received this
product and need to
install it
Intel® Server System SR1680MV Quick Start User's Guide in the
product box
Accessories or other Intel
server products Spares and Configuration Guide
Hardware (peripheral
boards, adapter cards,
and so forth) and
operating systems that
were tested with this
product
Tested Hardware Operating Systems List
Processors that were
tested with this product Supported Processors List
DIMMs that were tested
with this product Supported Memory List
For drivers Driver (for an extensive list of drivers available)
Operating System Driver (for operating system drivers)
For firmware and BIOS
updates Firmware Update Package
To make sure your
system falls within the
allowed power budget
Power Budget Tool

vi Intel®Server System SR1680MV Service Guide

Intel®Server System SR1680MV Service Guide vii
Safety Information
Important Safety Instructions
Read all caution and safety statements in this document before performing any of the
instructions. See also Intel Server Boards and Server Chassis Safety Information on the
Intel®Server Resource CD and/or at http://support.intel.com/support/motherboards/
server/sb/cs-010770.htm.
Wichtige Sicherheitshinweise
Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor
Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu
Intel-Serverplatinen und Servergehäusen auf der Intel®Server Resource CD oder unter
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
Consignes de sécurité
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce
document avant de suivre toute instruction. Consultez Intel Server Boards and Server
Chassis Safety Information sur le Intel®Server Resource CD ou bien rendez-vous sur le
site http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
Instrucciones de seguridad importantes
Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety
Information en el Intel®Server Resource CD y/o en http://support.intel.com/support/
motherboards/server/sb/cs-010770.htm.

viii Intel®Server System SR1680MV Service Guide
䞡㽕ᅝܼᣛᇐ
೼ᠻ㸠ӏԩᣛҸПࠡˈ䇋䯙䇏ᴀ᭛ḷЁⱘ᠔᳝⊼ᛣџ乍ঞᅝܼໄᯢDŽ៪
http://support.intel.com/support/motherboards/server/sb/CS-010770.htmϞⱘ,QWHO
6HUYHU%RDUGVDQG6HUYHU&KDVVLV6DIHW\,QIRUPDWLRQ˄lj,QWHO
᳡ࡵ఼ЏᵓϢ᳡ࡵ఼ᴎㆅᅝֵܼᙃNJ˅DŽ

Intel®Server System SR1680MV Service Guide ix
Warnings
Heed safety instructions: Before working with your server product, whether you are
using this guide or any other resource as a reference, pay close attention to the safety
instructions. You must adhere to the assembly instructions in this guide to ensure and
maintain compliance with existing product certifications and approvals. Use only the
described, regulated components specified in this guide. Use of other products /
components will void the UL listing and other regulatory approvals of the product and
will most likely result in noncompliance with product regulations in the region(s) in which
the product is sold.
System power on/off: The power button DOES NOT turn off the system AC power. To
remove power from system, you must unplug the AC power cord from the wall outlet.
Make sure the AC power cord is unplugged before you open the chassis, add, or remove
any components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be
present on power, telephone, and communication cables. Turn off the server and
disconnect the power cord, telecommunications systems, networks, and modems attached
to the server before opening it. Otherwise, personal injury or equipment damage can
result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage disk drives,
boards, and other parts. We recommend that you perform all procedures in this chapter
only at an ESD workstation. If one is not available, provide some ESD protection by
wearing an antistatic wrist strap attached to chassis ground any unpainted metal surface on
your server when handling parts.
ESD and handling boards: Always handle boards carefully. They can be extremely
sensitive to ESD. Hold boards only by their edges. After removing a board from its
protective wrapper or from the server, place the board component side up on a grounded,
static free surface. Use a conductive foam pad if available but not the board wrapper. Do
not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips
over two jumper pins. Some jumpers have a small tab on top that you can grip with your
fingertips or with a pair of fine needle nosed pliers. If your jumpers do not have such a tab,
take care when using needle nosed pliers to remove or install a jumper; grip the narrow
sides of the jumper with the pliers, never the wide sides. Gripping the wide sides can
damage the contacts inside the jumper, causing intermittent problems with the function
controlled by that jumper. Take care to grip with, but not squeeze, the pliers or other tool
you use to remove a jumper, or you may bend or break the pins on the board.

xIntel®Server System SR1680MV Service Guide

Intel®Server System SR1680MV Service Guide xi
Table of Contents
Preface ........................................................................................................................iii
About this Manual ................................................................................................................. iii
Manual Organization ............................................................................................................. iii
Product Contents, Order Options, and Accessories ............................................................. iv
Additional Information and Software .....................................................................................iv
Safety Information ....................................................................................................vii
Important Safety Instructions ............................................................................................... vii
Wichtige Sicherheitshinweise .............................................................................................. vii
Consignes de sécurité ......................................................................................................... vii
Instrucciones de seguridad importantes .............................................................................. vii
Warnings ............................................................................................................................... ix
Chapter 1: Server System Features ..........................................................................1
System Overview ...................................................................................................................3
Server Chassis Layout ..................................................................................................3
Front View Components ................................................................................................4
Back View Components ................................................................................................4
Buttons and System LEDs .....................................................................................................5
Front Panel Buttons and LEDs ......................................................................................5
Rear Panel Button and LEDs ........................................................................................6
LED Information .............................................................................................................6
Chapter 2: Hardware Installations and Upgrades ...................................................9
Before You Begin ...................................................................................................................9
Tools and Supplies Needed ..........................................................................................9
System References .....................................................................................................10
Power Off .....................................................................................................................10
Mid-Top Cover .....................................................................................................................11
Removing the Mid-Top Cover ......................................................................................11
Central Processing Unit (CPU) ....................................................................................12
Removing the Processor .............................................................................................13
Installing the Processor ...............................................................................................15
Removing the Heatsink ...............................................................................................16
Installing the Heatsink .................................................................................................17
System Memory ...........................................................................................................17
System Memory Channel Population Requirements for Memory RAS Modes ....................19
Independent Channel Mode ........................................................................................19
Mirrored Channel Mode ...............................................................................................19
Lockstep Channel Mode ..............................................................................................19

xii Intel®Server System SR1680MV Service Guide
Removing a DIMM ......................................................................................................21
Installing a DIMM ........................................................................................................21
Server Board Cage Module .........................................................................................23
Left and Right I/O Board Cage Modules .............................................................................25
Removing the Left I/O Board Cage Module ................................................................26
Power Supply Module .........................................................................................................27
Removing the Power Supply Module ..........................................................................27
Installing the Power Supply Module ............................................................................28
Power Distribution Board ..................................................................................................... 28
Removing the Power Distribution Board ..................................................................... 29
Installing the Power Distribution Board .......................................................................29
Pluggable SATA Drive .........................................................................................................30
2.5-inch Pluggable SATA HDD ...........................................................................................30
Removing a 2.5-inch Pluggable SATA HDD ...............................................................30
Installing a 2.5-inch Pluggable SATA HDD .................................................................32
2.5-inch Pluggable HDD Backplane ....................................................................................32
Removing an HDD Backplane ....................................................................................33
Installing a 2.5-inch Pluggable SATA HDD Backplane ...............................................33
System Fans .......................................................................................................................33
Removing a System Fan .............................................................................................34
Installing a System Fan ...............................................................................................35
Air Duct ................................................................................................................................35
Removing the IOB Air Duct .........................................................................................35
Installing Air Ducts ......................................................................................................36
PCI-E Cage .........................................................................................................................36
Removing a PCI-E Cage .............................................................................................36
Installing a PCI-E Cage ...............................................................................................38
Daughter Cards (Optional) ..........................................................................................38
Removing the IO Expansion Module ...........................................................................39
Installing the IO Expansion Module .............................................................................41
Chapter 3: Cable Connections .................................................................................43
Connectors and Pin 1 Locations .................................................................................43
Cable Connections ......................................................................................................44
Chapter 4: Connectors, Jumpers, and LEDs ..........................................................47
Connector and Component Locations of Server Board .......................................................47
Connector and Component Locations of IO Board .............................................................49
Connector and Component Locations of NIC Board ...........................................................50
Connectors and Components of Front Panel ......................................................................51
10 GB IO Card (Optional Daughter Card) ...........................................................................52
InfiniBand Card (Optional Daughter Card) ..........................................................................53
Connector and Component Locations of HDD Backplane ..................................................54
Connectors and Component Locations of PDB ...................................................................55

Intel®Server System SR1680MV Service Guide xiii
Chapter 5: BIOS Setup and Configuration .............................................................59
BIOS Setup Utility ........................................................................................................59
Entering the BIOS Setup Utility ...................................................................................60
Main Menu ...................................................................................................................63
Advanced Menu ...........................................................................................................64
SATA Configuration Submenu ....................................................................................67
Super IO Chipset Submenu .........................................................................................74
USB Configuration Submenu ......................................................................................76
USB Mass Storage Device Configuration Submenu ...................................................78
PCI Express* Configuration Submenu ........................................................................80
IPMI Configuration Submenu ......................................................................................81
View BMC System Event Log Submenu .....................................................................83
Remote Access Configuration Submenu .....................................................................84
Boot Menu ...................................................................................................................85
Boot Setting Configuration Submenu ..........................................................................86
Boot Device Priority Submenu .....................................................................................88
Removable Drives Submenu .......................................................................................89
CD/DVD Drives Submenu ...........................................................................................90
Security Menu ..............................................................................................................91
Trusted Computing Submenu ......................................................................................93
Exit Menu .....................................................................................................................95
BIOS Updates ..............................................................................................................96
ROM Flash ..................................................................................................................96
Chapter 6: Embedded SATA RAID ..........................................................................99
Enabling RAID in the BIOS Setup ...............................................................................99
Chapter 7: Installing the Rackmount Rail Kits .....................................................101
Procedure to install the rail kit ............................................................................................102
Appendix A: Intel®Server Issue Report Form .....................................................105
Appendix B: Troubleshooting ...............................................................................111
Resetting the System .........................................................................................................111
Problems following Initial System Installation ....................................................................111
First Steps Checklist ..................................................................................................111
Hardware Diagnostic Testing .............................................................................................112
Verifying Proper Operation of Key System Lights .....................................................113
Confirming Loading of the Operating System ............................................................113
Specific Problems and Corrective Actions .........................................................................113
Power Light Does Not Light .......................................................................................113
No Characters Appear on Screen .............................................................................114
Characters Are Distorted or Incorrect ........................................................................114
System Cooling Fans Do Not Rotate Properly ..........................................................115
Cannot Connect to a Server ......................................................................................115
LED Information .........................................................................................................116

xiv Intel®Server System SR1680MV Service Guide
BIOS POST Beep Codes ..........................................................................................116
Appendix C: Installation/Assembly Safety Instructions .....................................119
English ...............................................................................................................................119
Deutsch ............................................................................................................................. 121
Français .............................................................................................................................123
Español .............................................................................................................................125
Italiano ...............................................................................................................................127
Appendix D: Safety Information ............................................................................131
English ...............................................................................................................................131
Server Safety Information .........................................................................................131
Safety Warnings and Cautions ..................................................................................131
Intended Application Uses ........................................................................................132
Site Selection ............................................................................................................132
Equipment Handling Practices ..................................................................................132
Power and Electrical Warnings .................................................................................133
Access Warnings ......................................................................................................133
Electrostatic Discharge (ESD) ................................................................................... 134
Other Hazards ...........................................................................................................134
Deutsch ............................................................................................................................. 135
Sicherheitshinweise für den Server ...........................................................................135
Sicherheitshinweise und Vorsichtsmaßnahmen .......................................................136
Zielbenutzer der Anwendung .................................................................................... 136
Standortauswahl .......................................................................................................136
Handhabung von Geräten .........................................................................................137
Warnungen zu Netzspannung und Elektrizität ..........................................................138
Warnhinweise für den Systemzugang .......................................................................138
Elektrostatische Entladungen (ESD) .........................................................................139
Andere Gefahren .......................................................................................................140
Français ............................................................................................................................. 141
Consignes de sécurité sur le serveur ........................................................................ 141
Sécurité: avertissements et mises en garde ............................................................. 141
Domaines d’utilisation prévus ...................................................................................142
Sélection d’un emplacement .....................................................................................142
Pratiques de manipulation de l’équipement ..............................................................142
Alimentation et avertissements en matière d’électricité ............................................143
Avertissements sur l’accès au système ....................................................................143
Décharges électrostatiques (ESD) ............................................................................144
Autres risques ...........................................................................................................144
Español ............................................................................................................................. 145
Información de seguridad del servidor ......................................................................145
Advertencias y precauciones sobre seguridad ......................................................... 145
Aplicaciones y usos previstos ...................................................................................146
Selección de la ubicación ..........................................................................................146

Intel®Server System SR1680MV Service Guide xv
Manipulación del equipo ............................................................................................147
Advertencias de alimentación y eléctricas .................................................................147
Advertencias el acceso al sistema ............................................................................148
Descarga electrostática (ESD) ..................................................................................149
Otros peligros ............................................................................................................149
简体中文 .....................................................................151
Appendix E: Regulatory and Certification Information .......................................157
Product Regulatory Compliance ........................................................................................157
Product Safety Compliance .......................................................................................158
Product EMC Compliance - Class A Compliance ......................................................158
Product Ecology Compliance ....................................................................................159
Certifications / Registrations / Declarations ...............................................................159
Product Regulatory Compliance Markings ................................................................160
Rack Mount Installation Guidelines ...................................................................................165
Power Cord Usage Guidelines ..........................................................................................166
Electromagnetic Compatibility Notices ..............................................................................168
FCC Verification Statement (USA) ............................................................................168
ICES-003 (Canada) ...................................................................................................169
CE Declaration of Conformity (Europe) .....................................................................169
VCCI (Japan) .............................................................................................................169
BSMI (Taiwan) ...........................................................................................................170
KCC (Korea) ..............................................................................................................170
Regulated Specified Components .....................................................................................170
Appendix F: Warranty ............................................................................................173
Appendix G: Getting Help ......................................................................................175

xvi Intel®Server System SR1680MV Service Guide

Intel®Server System SR1680MV Service Guide xvii
List of Figures
Figure 1. Intel® Server System SR1680MV with 2.5-inch Pluggable HDDs.............................. 1
Figure 2. Layout of Server Chassis with 2.5-inch Pluggable HDDs.......................................... 3
Figure 3. Front View of Server with 2.5-inch Pluggable HDDs.................................................. 4
Figure 4. Back View .................................................................................................................. 5
Figure 5. Front Panel Buttons and LEDs of Server................................................................... 5
Figure 6. Back View LEDs and Buttons of Two I/O Boards ...................................................... 6
Figure 7. Pressing the Power Button....................................................................................... 10
Figure 8. Unplugging the Power Cord..................................................................................... 11
Figure 9. Removing the Mid-Top Cover.................................................................................. 12
Figure 10. Location of Processors........................................................................................... 12
Figure 11. Opening the Load Plate ......................................................................................... 13
Figure 12. Lifting the Processor Out of the Socket.................................................................. 14
Figure 13. Placing on the PnP Cap......................................................................................... 14
Figure 14. Closing the Load Plate........................................................................................... 15
Figure 15. Pointing the Golden Corner Toward the Socket..................................................... 16
Figure 16. Removing the Heatsink.......................................................................................... 17
Figure 17. Location of System Memories................................................................................ 18
Figure 18. DIMM Socket Location........................................................................................... 18
Figure 19. Lifting the DIMM Out of the Socket........................................................................ 21
Figure 20. Pressing the Retaining Clips Outward ................................................................... 22
Figure 21. Inserting the DIMM into the Socket........................................................................ 22
Figure 22. Server Board Cage Module with 2.5-inch Pluggable SATA HDD Location............ 23
Figure 23. Releasing the Locking Latch.................................................................................. 23
Figure 24. Pull the Locking Lever to Remove the Server Board Cage Module....................... 24
Figure 25. Left I/O Board Cage Module Location.................................................................... 25
Figure 26. Right I/O Board Cage Module Location................................................................. 25
Figure 27. Slide the Locking Latch.......................................................................................... 26
Figure 28. Pull the Locking Lever to Remove the Left I/O Board Cage Module...................... 26
Figure 29. Power Supply Location.......................................................................................... 27
Figure 30. Removing the Power Supply Module..................................................................... 28
Figure 31. Power Distribution Board ....................................................................................... 28
Figure 32. Removing the Power Distribution Board................................................................ 29
Figure 33. 2.5-inch Pluggable SATA HDD Location................................................................ 30
Figure 34. Release the Locking Lever..................................................................................... 31
Figure 35. Pull the Locking Lever to Remove the HDD Carrier............................................... 31
Figure 36. Release Screws and Lift the HDD Up.................................................................... 32
Figure 37. 2.5-inch Pluggable HDD Backplane Location........................................................ 32
Figure 38. Remove the Screws and Lift the Backplane Up..................................................... 33
Figure 39. System Fans Location............................................................................................ 34
Figure 40. Lift a System Fan Up from I/O Board Cage Module............................................... 34
Figure 41. Lift Air Duct Up....................................................................................................... 35
Figure 42. PCI-E Cage Location ............................................................................................. 36

xviii Intel®Server System SR1680MV Service Guide
Figure 43. Lifting the PCI Cage from the I/O Board Module................................................... 37
Figure 44. Removing the Expansion Card.............................................................................. 37
Figure 45. Securing the Slot Cover......................................................................................... 38
Figure 46. Removing the Riser Card ...................................................................................... 38
Figure 47. 10 GB IO Card Location ........................................................................................ 39
Figure 48. InfiniBand Card Location ....................................................................................... 39
Figure 49. Lifting the Module Upward from the IO Board ....................................................... 40
Figure 50. Removing the Module Upward from the IO Board................................................. 40
Figure 51. Locations of Connectors and Pin 1 on Server Board............................................. 43
Figure 52. Locations of Connectors and Pin 1 on I/O Board .................................................. 44
Figure 53. Connecting the System Fan Cables...................................................................... 45
Figure 54. Connectors and Component Locations of Server Board....................................... 47
Figure 55. Connectors and Component Locations of IO Boards............................................ 49
Figure 56. Connectors and Component Locations of NIC Board............................................ 50
Figure 57. Connectors and Component Locations of Front Panel.......................................... 51
Figure 58. Connectors and Components of 10 GB IO Card................................................... 52
Figure 59. Connectors and Components of InfiniBand Card.................................................. 53
Figure 60. Connectors and Components of 2.5-inch Pluggable HDD Backplane................... 54
Figure 61. Connectors and Component Locations of PDB..................................................... 55
Figure 62. Location of MISC Jumper...................................................................................... 56
Figure 63. Location of ICH Function Jumper.......................................................................... 57
Figure 64. Overview of Rail Kit ............................................................................................. 101
Figure 65. Location Of Spring Screw Holes.......................................................................... 102
Figure 66. Secure screw into the rail hole............................................................................. 103
Figure 67. Secure the Rail to Racks..................................................................................... 103
Figure 68. Slide The Server Into Racks................................................................................ 103
Figure 69. Push The Server To The End Of Racks.............................................................. 104
Figure 70. Secure The Server Ears To Racks...................................................................... 104

Intel®Server System SR1680MV Service Guide xix
List of Tables
Table 1. Intel®Server System SR1680MV Feature Summary ..................................................2
Table 2. LED Information ..........................................................................................................6
Table 3. Ideal DIMM Installation Options for A-C Channels of Processor 1 ............................20
Table 4. Ideal DIMM Installation Options for D-F Channels of Processor 2 ............................20
Table 5. BIOS Setup Utility Screen Descriptions ....................................................................59
Table 6. Keyboard Command Bar Description ........................................................................60
Table 7. Main Menu of BIOS Setup Utility ...............................................................................63
Table 8. Main Menu Fields ......................................................................................................63
Table 9. Advanced Menu of BIOS Setup Utility .......................................................................64
Table 10. CPU Configuration Submenu ..................................................................................65
Table 11. CPU Configuration Submenu Fields .......................................................................65
Table 12. SATA Configuration Submenu1 ..............................................................................67
Table 13. SATA Configuration Submenu2 ..............................................................................68
Table 14. SATA Configuration Submenu3 ..............................................................................69
Table 15. SATA Configuration Submenu4 ..............................................................................70
Table 16. SATA Configuration Submenu Fields ......................................................................71
Table 17. Primary/Secondary IDE Master/Slave .....................................................................72
Table 18. Primary/Secondary IDE Master/Slave Submenu Field ............................................73
Table 19. Super IO Chipset Submenu ....................................................................................74
Table 20. SATA Configuration Submenu Fields ......................................................................75
Table 21. USB Configuration Submenu ..................................................................................76
Table 22. USB Configuration Submenu Fields ........................................................................76
Table 23. USB Mass Storage Device Configuration Submenu ...............................................78
Table 24. USB Mass Storage Device Configuration Submenu Fields ....................................79
Table 25. PCI Express* Configuration Submenu ....................................................................80
Table 26. PCI Express* Configuration Submenu Fields ..........................................................80
Table 27. IPMI Configuration Submenu ..................................................................................81
Table 28. IPMI Configuration Submenu Fields ........................................................................82
Table 29. View BMC System Event Log Submenu .................................................................83
Table 30. Remote Access Configuration Submenu ................................................................84
Table 31. Remote Access Configuration Submenu Fields ......................................................84
Table 32. Boot Menu of BIOS Setup Utility .............................................................................85
Table 33. Boot Setting Configuration Submenu of BIOS Setup Utility ....................................86
Table 34. Boot Setting Configuration Submenu Fields ...........................................................86
Table 35. Boot Device Priority Submenu ................................................................................88
Table 36. Removable Drives Submenu ...................................................................................89
Table 37. CD/DVD Drives Submenu .......................................................................................90
Table 38. Security Menu of BIOS Setup Utility ........................................................................91
Table 39. Security Menu Fields ...............................................................................................92
Table 40. Trusted Computing Submenu .................................................................................93
Table 41. Trusted Computing Submenu Fields .......................................................................94
Table 42. Exit Menu of BIOS Setup Utility ...............................................................................95

xx Intel®Server System SR1680MV Service Guide
Table 43. BIOS Requirements Description .............................................................................96
Table 44. Recommended screwdrivers ................................................................................101
Table 45. Location and Adapt Depth for Racks .................................................................... 102
Table 46. Resetting the System ............................................................................................111
Table 47. LED Information .................................................................................................... 116
Table 48. POST Error Beep Codes ......................................................................................116
Table 49. Error Beep Codes Generated by Intel®Management Module ..............................117
Table 50. Product Regulatory Compliance Markings ............................................................ 160
