1. General
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 2 of 20 poc: SFi
Scape® Lab
Operating Manual
Contents
1. General _____________________________________________________________________________________________________________4
1.1. Safety instructions ___________________________________________________________________________________________________ 4
1.2. Scope of delivery ____________________________________________________________________________________________________ 6
1.3. Cleaning instructions ________________________________________________________________________________________________ 6
1.4. Transportation instructions__________________________________________________________________________________________ 6
2. Specifications and set up___________________________________________________________________________________________ 7
2.1. Specifications_________________________________________________________________________________________________________7
2.2. Connections and controls ___________________________________________________________________________________________ 8
2.2.1. Touch screen_____________________________________________________________________________________________________ 8
2.2.2. Remote Control __________________________________________________________________________________________________ 9
3. Installation ________________________________________________________________________________________________________10
3.1. Notes _______________________________________________________________________________________________________________ 10
3.2. Connection to the power supply____________________________________________________________________________________ 10
4. Switching on ______________________________________________________________________________________________________ 11
5. Display settings – OSD ____________________________________________________________________________________________ 12
5.1. OSD usage ___________________________________________________________________________________________________________12
5.2. Select input source __________________________________________________________________________________________________12
6. Troubleshooting tips ______________________________________________________________________________________________ 13
6.1. Manufacturer – Support _____________________________________________________________________________________________13
6.2. Problems and solutions______________________________________________________________________________________________13
7. Appendix __________________________________________________________________________________________________________ 14
7.1. Technical data _______________________________________________________________________________________________________14
7.1.1. Scape® Lab _______________________________________________________________________________________________________14
7.1.2. Touch screen _____________________________________________________________________________________________________14
7.2. Technical drawings __________________________________________________________________________________________________16
7.2.1. Perspective_______________________________________________________________________________________________________16
7.2.2. Top view _________________________________________________________________________________________________________17
7.2.3. Front view________________________________________________________________________________________________________18
7.2.4. Right view________________________________________________________________________________________________________19
Notes

1. General
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 3 of 20 poc: SFi
This is a class A device according to EN55022.
For more information, please refer to Chapter 1.1 – Radio interference.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003.
This manual is applicable for the following device:
·Scape® Lab 43" (sla43-004 with st43-004 R1.1)
Information in this document is subject to change without notice.
©2019 Interactive Scape GmbH. All rights reserved.
The document or excerpts from the document may not be duplicated without the prior permission of Interactive Scape
GmbH.
Interactive Scape GmbH shall not be liable for any errors contained in this document or any other incidental or
consequential damages resulting from the delivery, use or application of this material.
All product names mentioned in this document are trademarks or registered trademarks of their respective owners.

1. General
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 4 of 20 poc: SFi
1. General
This manual describes the safe installation, configuration and correct operation of the Scape® Lab.
If your device does not have an integrated PC, you can skip the chapters and notes about the integrated PC. All other
notes and instructions continue to apply without restriction.
If necessary, pay attention to the supplementary documents, such as the installation instructions.
1.1. Safety instructions
Before using and operating your Scape® Lab, observe the following safety instructions to prevent you, your
environment or the Scape® Lab from being damaged.
Fire and electric shock
Overloaded sockets, extension cords and power strips can cause fire and electric shock.
·Avoid using power strips and extension cords if possible.
·Do not chain multiple extension cords or power strips together.
Overheating
Heat build-up can overheat the screen and the integrated PC. This can damage the device.
·Ensure there is sufficient air circulation around the Scape® Lab.
·Make sure all the ventilation holes on around the screen and integrated PC are uncovered.
Excess voltage from lightning strikes
In the event of a thunderstorm there is a risk of excess voltage damage from lightning strikes electrical appliances that
are plugged in.
·Do not install the Scape® Lab during a thunderstorm.
·Disconnect the devices from the mains during thunderstorms.
Moisture, liquid and steam
Moisture, liquid and steam inside the Scape® Lab can cause electric shocks or short circuits.
·Only use the Scape® Lab indoors.
·Do not allow liquids to get inside the Scape® Lab.
·Protect your Scape® Lab from steam and moisture.

1. General
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 5 of 20 poc: SFi
Improper cleaning
Improper cleaning with harsh detergents and solvents or soaking wet cloths can damage the Scape® Lab.
·Observe the information on cleaning your Scape® Lab (see Chapter 1.3 - Cleaning instructions).
Improper opening and repair
Improper opening and improper repairs may be dangerous to users of the device.
·Do not open the housing of the device.
·In case of repair contact the manufacturer or a specialist dealer.
Radio interference
Radio interference can be generated by any device that emits electromagnetic signals. Due to the large number of
devices that transmit and receive radio waves, interference from overlapping radio waves can occur.
·Do not use the Scape® Lab in locations where the use of radio equipment is prohibited.
·Always follow the instructions and instructions of authorized persons to switch off radio equipment, especially in
hospitals, outpatient health centers, medical practices and other medical facilities, to avoid interference with sensitive
medical equipment.
·Check with your doctor or the manufacturer of your medical device (pacemaker, hearing aid, implant with electronic
control, etc.) to see if it can work your Scape® Lab without interference.
·If necessary, maintain the minimum distance of 15 cm recommended by medical device manufacturers to avoid
interference with your medical device.
Hazardous environments
Under unfavorable conditions, radio waves near explosive atmospheres may lead to fire or explosions.
·Do not install and operate the Scape® Lab near explosive gases, flammable gases, areas where the air contains
chemicals or particles such as grain, dust or metal powders, and near detonation zones.
·In places with potentially explosive gases and near detonation zones, follow the instructions for switching off the
electronic devices to avoid disruption of the blasting and ignition systems.
Load and damage to the surface
Rough, hard or sharp-edged materials and heavy objects can damage the screen surface of the Scape® Lab.
·Do not place heavy objects on the screen.
·Use only objects with smooth or soft bottom surfaces on the screen.
·Clean the undersides of the objects before and after each use.

1. General
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 6 of 20 poc: SFi
1.2. Scope of delivery
The following accessories are included with your Scape® Lab:
·Multi socket adapter with Schuko plug for mains power
·Network cable for connection to LAN network
·Wireless keyboard with trackpad
·Screen cleaning kit
·Remote control
·Operating manual (possibly by email)
1.3. Cleaning instructions
The touch sensor of the Scape® Lab does not usually need to be serviced. Nevertheless, it is recommended to clean the
glass surface of the screen regularly.
·Disconnect the device from the mains before cleaning.
·Typically, a solution of isopropyl alcohol and water (50:50 blend ratio) or the included screen cleaning kit are best for
cleaning the touch sensor.
·Apply the solution to a soft, lint-free cloth. Avoid using rough cloths.
·Use the cloth to clean the glass surface. Apply the liquid only to the cloth and never directly to the device. This will
prevent liquid from entering the inside of the device or causing marks on the frame.
1.4. Transportation instructions
The safest way to transport your device is in a Scape® Lab flight case (sold separately).
·The device is very heavy. Make sure that at least two people lift and carry the device.
·Do not transport the device upside-down
·Apply the brakes on the castors of the frame during transportation.
·Secure the device or flightcase against slipping and tipping.

2. Specifications and set up
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 7 of 20 poc: SFi
2. Specifications and set up
2.1. Specifications
Touch screen
Display
3840 x 2160 (UHD) 60 Hz
16
.7 million colors
8 ms response time
Connections
2x HDMI (1x HDMI 2.0, 1x
HDMI 1.4)
1x DisplayPort
Touch sensor
3M – PCAP (80 touches)
(optional) integrated Capore® Touch & Object Recognition

2. Specifications and set up
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 8 of 20 poc: SFi
2.2. Connections and controls
2.2.1. Touch screen
The screen of the Scape® Lab comes preinstalled and connected to the integrated PC ready for operation.
*analogous to button on remote control
1
IR sensor for remote control
2
Switch between Touch TUIO / USB Touch
3
RJ-45 Lan interface – to use the Capore® Touch & Object Assistant
4
USB connection type B – for direct connection of touch and PC
5
DisplayPort input
6
HDMI 2.0 input (UHD 60 Hz)
7
HDMI
input
8
DVI input
9
Stand
-by *(17)
10
Status LED
11
Close OSD / back / show input selection
*(21)
12
Plus / right
*(23)
13
Minus /
left *(22)
14
Open OSD / confirm selection
*(20)
15
IEC socket for connection to 230V 50Hz
16
Main power switch
15
16

2. Specifications and set up
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 9 of 20 poc: SFi
2.2.2. Remote Control
*analogous to button on the screen
All keys on the remote control which are not explained above are not required for operation of Scape® Lab and do not
have any function.
1
Stand
-by *(9)
2
Display mode selection
3
Show input
selection
4
Show OSD / confirm selection
*(14)
5
Close OSD
*(11)
6
Left
/ minus *(13)
7
Right / plus
*(12)
1
2
3
4
5
6
7

3. Installation
—
Scape® Lab Technical specifications are subject
spr43-004 to change without notice.
Operating Manual Version 1.6 – Status: 12/2019
Page 10 of 20 poc: SFi
3. Installation
The Scape® Lab is delivered ready for operation. All units are fully assembled and wired.
Place the device in a suitable location and connect it to the power supply.
3.1. Notes
Observe the following points when setting up the device:
·Give the Scape® Lab sufficient time to adapt to the ambient temperature. Otherwise the device may be damaged or
destroyed by condensation inside the device.
·Only operate the Scape® Lab indoors.
·Do not expose the Scape® Lab to direct sunlight.
3.2. Connection to the power supply
Connect the Scape® Lab to the mains supply using a suitable socket on the power distributor's power cord. Then set
the main switch on the centre bar to "I".
When disconnecting the appliance from the mains, always pull the plug and do not pull the cable.
Do not touch the plug with wet hands.
