Interchange SHB100-A User manual

NOTE: Please read and fully understand the instructions in this manual before
operating the stapler. Carefully read through this OPERATOR’S MANUAL to ensure efficient, safe
operation. It is recommended that the MANUAL be kept readily available as an important reference
when using this tool.
!
Operator’s Manual
Manual Carton Closing Staplers
SHB100-A
Item No. 64300
1-3/8" Crown Carton Closing Stapler
5/8" and 3/4"
(15mm and 18mm)
SHB150-C
Item No. 64310
1-1/4" Crown Carton Closing Stapler
5/8"and 3/4"
(15mm and 18mm)
Ask for
Genuine
INTERCHANGE®
A58 and A34
Staples
Ask for
Genuine
INTERCHANGE®
C58 and C34
Staples

2Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
Index
Information Page
Tool and fastener specifications ........................2
Safety instructions ..................................3
Loading the tool ....................................4
Check staple leg length...............................4
Clinch adjustment ...................................5
Depth adjustment ...................................5
Operating the tool ...................................6
Troubleshooting.....................................6
Clearing a jam from the tool ...........................7
Teeth replacement ..................................7
Driver replacement ..................................8
Pusher spring replacement............................9
Parts list .........................................10
Parts Drawing .....................................11
Stapler Specications: SHB100-A & SHB150-C
Tool Dimensions -
Length x Width x Height
15.75" x 4.53 x 11.22"
﹙400mm x 115mm x 285mm﹚
Weight ﹙without fasteners﹚ 5.16 lbs. ﹙2.34 kgs.﹚
Magazine Capacity 100 Staples
A Staple Specications:
Crown 1-3/8" ﹙35mm﹚
Length 5/8" and 3/4" ﹙15mm and 18mm﹚
C Staple Specications:
Crown 1-1/4" ﹙32mm﹚
Length 5/8" and 3/4" ﹙15mm and 18mm﹚
Applications
Carton Closing
Tool & Fastener Information

3
Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
SAVE THIS MANUAL
FOR FUTURE REFERENCE!
WARNING: The warnings, cautions and instructions discussed in this instruction
manual can not cover all possible conditions and situations that may
occur. It must be understood by the operator that common sense and
caution are factors which can not be built into this product, but must
be supplied by the operator.
When using the tool, basic safety precautions should always
be followed to reduce the risk of personal injury and damage to
equipment.
1. Read this manual and understand all safety instructions before operating the tool.
If you have any questions, please contact our authorized representatives.
2. Do not place your hand or any part of your body in the staple clinching area.
3. Never point any operational driving tool at yourself or at any other person.
Do not pull the trigger when carrying or holding the tool.
4. At the workplace, always wear protective equipment such as safety glasses,
hearing protection and head protection.
OPERATE THE STAPLER ACCORDING TO THIS MANUAL.
WARNING!
■Always follow the tool manufacturer’s safety and
maintenance instructions.
■Always wear safety glasses with side shields when operating
or servicing tools.
Important Information

4Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
Operating Instructions
Loading the Tool
Check Staple Leg Length
1. Pull pusher back until it stops on pusher pivots then rotate
pusher to position for loading staplers.
2. Insert 2 strips of the appropriate staples into the magazine
from the back. Let the strips slide forward to the front of the
magazine.
3. Pull pusher back to upright position and gently let the pusher
slide forward against the staples. Do not let the pusher slide
forward and strike the staples at high speed for this may
deform the staples or damage the tool.
1. Loosen set screw with 3mm hexagon wrench key.
2. Turn adjusting rod 180° with a screw driver to the desired
adjustment.
3. If you want to shoot long leg staples, position the “L” on
the adjusting rod facing up.
4. If you want to shoot short leg staples, position the “S” on
the adjusting rod facing up.
5. Tighten set screw.
STAPLE
LENGTHS
ROD
POSITION
2
3 & 4
1
2
1
3

5
Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
Operating Instructions
Clinch Adjustment
Depth Adjustment
1. Loosen adjustment nut by turning adjustment screw
clockwise ﹙in﹚ to loosen clinch.
2. Tighten adjustment nut by turning adjustment screw
counter-clockwise ﹙out﹚ to tighten clinch.
3. After adjusting, tighten adjustment nut.
1. Loosen front screw with 4mm hexagon wrench key.
2. Push the body up and adjust to desired depth.
2
1

6Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
PROBLEM CAUSE REMEDY
Excessive Jams Teeth screws loose.
Staple size is wrong.
Tighten screws.
Use the proper size staple.
Uneven Clinch Wrong staple size Check for proper length
adjustment and clincher size.
Unclinched staple Teeth are loose.
Teeth are broken.
Tighten teeth.
Replace teeth.
Can’t clinch staples well Adjustment screw is
at wrong position.
See and check “Clinch Adjustment”
(page 5).
Operating Instructions
Operating the Tool
1. Insert staples into your tool following the instructions on
page 4 of this manual.
2. Position the box in line with the desired staple location,
using the small projections on either side of the magazine
seat to aid in locating the position of the staple.
3. Hold the handle with your hand and press the handle
all the way down until it stops by the other hand.
Release the handle and move the stapler to the next
location.
4. To achieve the strongest closure, place staples near the end
of box, but check the packing requirements to find optimal
staple placement.
5. Test staple clinching in samples of the box board being
used. Make adjustments for depth of penetration and
tightness of clinch as needed.
WARNING: To prevent accidental injuries: never place a hand or any other part of body in
staple clinching area or adjustment window. Never point tool toward anyone else. Do not engage
in horseplay. Always handle the tool with care. Never press handle unless tool is in positioned over
carton. Protect your eyes and ears. Wear safety glasses with side shields. Wear hearing protection.
Employers and users are responsible for ensuring the user or anyone near the tool wears this safety
protection.
NOTE: Check and replace any damaged or worn components on the tool. The safety warning
labels on the tool must also be replaced if they are not legible.
WARNING: Stop using the tool immediately if any of the following problems occur. Serious
personal injury could occur. A qualified person or an authorized service center must do any repairs or
replacements.
Trouble Shooting
3
1
4

7
Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
Clearing a Jam from the Tool
1. Pull pusher back and rotate to locked position.
2. Remove staples from the magazine.
3. Remove the magazine unit with flat head screw driver,
then clear jam.
4. Reassemble the magazine unit.
Trouble Shooting
Teeth Replacement
1. Remove the magazine unit with flat head screw driver.
2. Loosen screw with 4mm hexagon wrench key.
3. Remove the magazine seat.
4. Loosen screws with 3mm hexagon wrench key.
5. Change teeth one at a time to prevent reversing the
direction of the teeth. Reassemble the tool.
Tool Maintenance
3
1
4
3
1
4
2

8Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
Tool Maintenance
Driver Replacement
1. Remove the magazine unit with flat head screw driver.
2. Loosen screws with 4mm hexagon wrench key.
3. Remove the magazine seat.
4. Loosen set screw with 3mm hexagon wrench key to unlock
adjustment rod.
5. Loosen pivot screw with flat screw driver. Remove handle
and linkage mechanism.
6. Remove spring pin with hammer and 5mm straight rod.
7. Loosen screws with 3mm hexagon wrench key. Take off the
spring pin with hammer and 6mm straight rod.
8. Reassemble the tool.
3
1
4
2
7
5
6

9
Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
Tool Maintenance
Pusher Spring Replacement
1. Remove the magazine unit with flat head screw driver.
2. Loosen screw and nut with 2.5mm hexagon wrench key and
7mm socket wrench.
3. Loosen rod with 6mm offset wrench remove pusher guides.
Remove pusher.
4. Remove spring pin with hammer and 4mm diameter
straight rod.
5. Reassemble the tool.
3
1
4
2

10 Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
NO. CODE QTY Description NO. CODE QTY Description
001 HAH-P22 1 BODY UNIT 026 A00103710A 1 PUSHER UNIT (19-32)
002 A01102701 1 HANDLE 027 A00103501 1 ROLLER
003 A00300301 1 HANDLE SLEEVE 028 A00103401 1 SPRING
004 A01103001 1 LINK 029 A00607101 2 ROD UNIT
005 A00300501 1 PIVOT PIN 030 A00103903A 1 RIGHT PUSHER GUIDE
006 A00300601 1 PIVOT SCREW 031 A00103203 2 ROD UNIT
007 A01102801 1 COVER 032 A00103904A 1 LEFT PUSHER GUIDE
008 A01102901 1 SPRING 033 A00607501 1 BRACKET
009 A02100501 1 HANDLE 034 A00105001 2 WASHER
010 A00301001 1 ADJUSTMENT SCREW 501 BAA050020 2 SPRING PIN (5-20)
011 A00301101 1 ADJUSTMENT NUT 502 BAC0404062 2 HEX. SOC. HEAD BOLT (M4 X 0.7-6)
012 A00101801 1 ADJUSTING ROD 503 A00104701 2 ROD (4.9-17.5)
014 A01102502 1 FRONT PLATE 504 BAC0306142 1 HEX. SOC. HDLESS. BOLT (M6 X
1-14)
015 A00102102 1 RIGHT TEETH (19MM) 505 BAC0605142 2 HEX. SOC. HEAD BOLT (M5 X 0.8-14)
016 A00102202 1 LEFT TEETH (19MM) 506 BAC0605122 4 HEX. SOC. HEAD BOLT (M5 X 0.8-12)
017 A00102301 2 TEETH SEAT 508 BAC0605142 6 HEX. SOC. HEAD BOLT (M5 X 0.8-14)
018 A00102401 2 PLATE 510 A00106201 2 HEX. SOC. FLAT COUNTER SUNK HD
SCREW (M5 X 0.8-12)
019 A00301902 1 BLOCK 511 A00104501 4 PIN (3.97-13)
020 A00102605 1 DRIVER (19-35) 512 A00104602 2 PIN (6.06-8)
020 A01201706 1 DRIVER (19-32) 513 BAC0604102 2 HEX. SOC. HD BOLT (M4 X 0.7-10)
021 A00102702A 1 COVER UNIT 515 BAA060016-R 2 SPRING PIN (6-16)
022 A02100407A 1 MAGAZINE SEAT 516 BAD01041 1 LOCK NUT (M4 X 0.7)
023 HAA-19-35-
P7-SD 1 MAGAZINE (19-35) 517 BAC0404202 1 HEX. SOC. HEAD BOLT (M4 X 0.7-20)
023 HAA-19-32-
P7-SD 1 MAGAZINE (19-32) 520 BAA040016 1 SPRING PIN (4-16)
024 A01102403 2 SPRING 521 BAC0204062 1 HEX. SOC. FLAT COUNTER SUNK HD
SCREW (M4 X 0.7-6)
025 A01102201 1 BRACKET
026 A00103709A 1 PUSHER UNIT (19-35)
Rev. 2013/06/19
NOTICE: The parts listed in this manual are for service assembly and for reference.
Changes to the tool and drawing may be made without notification.
Most parts are available. Contact your local dealer for more information.
WARNING: When the tool needs repairing or servicing, it is strongly recommended
that you contact your local dealer. Do not disassemble the tool yourself, which might
waive your right for product guarantee.
Parts List

11
Interchange Brands, LLC
Manual Carton Closing Staplers Model No. SHB100-A
& SHB150-C
SHB100-A, SHB150-C Parts Drawing ﹙09-30-14﹚
Parts Drawing

Interchange Brands
Operator’s Manual
Models: SHB100-A,
SHB150-C
(11-10-14) Made In Taiwan DN
Limited One (1) Year Warranty for Staplers
Our products are designed and constructed using the highest standards of both material and workmanship. We
warrant to the original retail purchaser that their tools will be free from defects in material or workmanship for the
warranty period of one year.
During the warranty period (which begins on the purchase date), we will repair or replace, at our option and
expense, any product or part that is defective in materials or workmanship after examination by an Authorized
Warranty Service Center, subject to the exceptions, exclusions and limitations described below. Any replacement
product or part will carry a warranty for the balance of the warranty period applicable to the replaced product
or part. A DATED SALES RECEIPT OR PROOF OF PURCHASE FROM THE ORIGINAL RETAIL PURCHASER IS
REQUIRED TO MAKE A WARRANTY CLAIM. To make a warranty claim, you must return the product, with proper
receipt/proof of purchase and return transportation charges prepaid, to us (your dealer) or an Authorized Warranty
Service Center. We will perform our obligations under this warranty within a reasonable time after approval of the
warranty claim.
WARRANTY EXCLUSIONS
The following warranty exclusions apply:
1. Normal wear parts are not covered under this warranty.
2. This warranty does not cover parts damaged due to normal wear, misapplication, misuse, accidents,
improper storage, or damage resulting during shipping.
3. Products used in production/industrial applications are excluded from this warranty.
4. Labor charges, maintenance, or loss, damage and repairs resulting from improper operation are not covered
by this warranty.
GENERAL WARRANTY CONDITIONS
This warranty will be honored, only if:
1. No evidence of abuse, abnormal conditions, accident, neglect, misuse or improper modifications or storage
of the product exists; and
2. No deviations from following recommended operating instructions, specifications, and maintenance
schedules exist. (Read Operator Manual for use, specifications, and maintenance instructions).
This warranty is the only warranty for the product and we disclaim all other warranties. Any implied warranties
will be limited in duration to the applicable warranty period specified above. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you. Your remedies are solely and
exclusively as stated above. We shall in no event be liable for incidental, consequential, indirect or special dam-
ages. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. In no event, whether as a result of a breach of contract, warranty,
tort (including negligence) or otherwise, shall our liability exceed the price of the product that has given rise to
the claim or liability. Any liability connected with the use of this product shall terminate upon the expiration of the
warranty period specified above. No employee or representative of any distributor or dealer is authorized to make
any change or modification to this warranty.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to
state.
