1Intermec EasyCoder 501 LL Cutter Guide – Installation Instructions Ed.1
EasyCoder 501 LinerLess Cutter
Cutter Guide Installation
1-960410-02
EasyCoder 501 LinerLess
Cutter Guide
Installation Instructions
Edition 1, October 2001
The guide plate is intended to be fitted at the front
of the cutter of an EasyCoder 501 LinerLess. It
prevents labels to fall off after cutting and for
example stick to the front of the cutter or to the
table where the printer stands. It is not necessary
to fit the guide plate, but we recommend to fit it
unless some other means of taking care of the label
are provided, for example an applicator.
The guide plate has a special coating that prevents
labels from sticking to it.
The guide plate is not fitted at delivery to prevent
damage during transportation, but is easy to fit
using a #T10 Torx key:
•Loosen the two #T10 Torx screws, that hold
the plate beneath the cutter’s outfeed slot, a few
turns.
•Slip the guide plate onto the screws from
above.
•Make sure to press the guide plate down as
far as the U-shaped indents at the bottom edge
allow.
EasyCoder is a registered trademark of Intermec Technologies
Corp.
Torx is a registered trademark of Camcar Division of Textron Inc.
LinerLess Cutter Unit
Guide Plate
Outfeed Slot
#T10Torx Key
Torx Screws
