EasyCoder 401/501/601
Label-Taken Sensor Kit
P/N 1-960350-06
Edition 5
September 1998
Installation Instructions

EasyCoder 401/501/601 – Installation Instructions
1
This booklet contains instructions on how to install the Label-
Taken Sensor Kit (LTS) on EasyCoder 401, EasyCoder 401
Linerless,EasyCoder 501, and EasyCoder 601 printers. Installa-
tion should preferably be performed by an authorized service
technician.
For information on how to use the label-taken sensor, please refer
to the Technical Manual for EasyCoder 401, EasyCoder 401
Linerless, EasyCoder 501, or EasyCoder 601 respectively.
The Label-Taken Sensor Kit consists of:
• One Reflecting Sensor assy. with cable and connector
• One Sensor Bracket
• One Screw
• This Installation Instructions booklet
Theonlytoolsneededare#T10and#T20Torxscrewdriversanda
small non-conductive flat-tipped screwdriver.
❑MakeasimpleFingerprintprogramthatchecksthestatusofthe
LTS, e.g.:
10 BREAK 1,88
20 BREAK 1 ON
30 FORMFEED
40 IF (PRSTAT AND 2) THEN BEEP
50 GOT0 40
60 END
RUN
You can break this program by transmitting the character X
(ASCII 88) decimal on the standard serial interface "uart1:".
LABEL-TAKEN SENSOR KIT
General Information
Information in this manual is subject to change without prior notice and does
not represent a commitment on the part of Intermec Printer AB.
©CopyrightIntermecPTCAB,1998.Allrightsreserved.PublishedinSweden.
EasyCoder and Fingerprint are registered trademarks of Intermec Technolo-
gies Corp.
Torx is a registered trademark of Camcar Division of Textron Inc.
Preparation Before
Installation
Note:
Illustrationsshow an EasyCoder 501.
The principles for fitting this optional
equipment in an EasyCoder 401,
EasyCoder 401 Linerless, or Easy-
Coder 601 printer are similar.
The label-taken sensor excludes the
fittingofapapercutterandviceversa.
EasyCoder 401/501/601
Label-Taken Sensor Kit
Installation Instructions
Edition 5, September 1998
Part No. 1-960350-06

EasyCoder 401/501/601 – Installation Instructions
2
❑Turnoffthepower.Fordoublesecurity,pullthepowercordout
of the mains receptacle at the rear plate of the printer.
❑Open the right-hand door.
❑Open the front hatch.
❑Usinga #T10 Torx screwdriver,remove the six oreight screws
that hold the left-hand cover (see illustration).
❑Remove the cover.
❑Pressthereflectingsensorassemblyintothebracketasillustrated
below.
LABEL-TAKEN SENSOR KIT, cont'd.
Step-by-Step Installation
Instructions
Continued!
Screws
Screws
Sensor Assy.
Bracket

EasyCoder 401/501/601 – Installation Instructions
3
❑Using the screw included in the kit, fit the sensor/bracket
assemblytotheinnerwalloftheprinterunitasshownbythetwo
illustrations below. Fit the cable underneath the top part of the
bracket, as illustrated in the second picture.
LABEL-TAKEN SENSOR KIT, cont'd.
Step-by-Step Installation
Instructions, cont'd.
Continued!
Screw
LTS assy.
Fit LTS here
Cable held by bracket

EasyCoder 401/501/601 – Installation Instructions
4
Step-by-Step Installation
Instructions, cont'd.
LABEL-TAKEN SENSOR KIT, cont'd.
❑Slip the cable of the label-taken sensor through the hole in the
centre-linewallof the printerintotheelectronicscompartment.
❑ConnectthecabletoP-606ontheCPUboard,seebelow.Incase
ofanEasyCoder401Linerlessprinter,firstremovethecableto
thecutterinterfaceconnectoralreadyfittedonP-606.Becareful
so the cables do not interfere with any moving parts.
❑Check that a strap is fitted on both pins of P-6071.
❑Insert the power cord and turn on the power.
❑Adjust the sensitivity of the label-taken sensor by means of the
potentiometer WR-602 on the CPU board:
•StartupFingerprintandruntheprogramdescribedonpage1.
Leave the label in the outfeed slot to create a label-not-taken
condition.
•The printer should start to beep continuously. If not, turn the
potentiometer back and forth until the beeping starts.
•Adjust the potentiometer so the beeping does not stop when
the screw is turned a quarter of a turn in either direction.
•Remove the label. The beeping should cease immediately.
•If necessary, readjust the potentiometer2.
•Break the program by typing Xon the host.
❑When the label-taken sensor works properly, put back the left-
hand cover and close the front hatch and right-hand door. Then
the printer is ready for operation.
1/.InEasyCoder401Linerlessprinters,
the strap is usually fitted on just one of
the pins of P-607. Move the strap so
both pins become interconnected.
2/.Ifadjustmentbymeansofthepotentio-
meter is not sufficient, a strap on P-607
on the CPU board allows the intensity
of the LTS light-emitter to be changed:
Strap fitted: High intensity (default)
No strap: Low intensity
CAUTION!
High Voltage
The LTS must be adjusted with the
poweron.Toavoidtheriskofelectrical
shock or short-circuits, use non-
conductive tools only. Keep your
fingersawayfromtheareabehindthe
CPUboard,wherethemainsinletand
switch are situated.
POWER ON
040700.10040700.10
FLASHEPROM
232
CL
422
LTS
+-
WR-602
P-606
P-607
CPU-board Label-taken sensor
adjustment
Strap
Connect
here!
