Invacare®Robin®
Robin®,Robin®Mover
enCeilingHoist
UserManual...................................3
daLøftemotor
Brugsanvisning.................................23
frLève-personnesurrail
Manueld'utilisation............................43
nlPlafondlift
Gebruiksaanwijzing.............................65
noTakmontertløfter
Bruksanvisning.................................85
svTaklyft
Bruksanvisning.................................105
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.

©2019InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibitedwithoutpriorwritten
permissionfromInvacare.Trademarksareidentiedby™and®.AlltrademarksareownedbyorlicensedtoInvacare
Corporationoritssubsidiariesunlessotherwisenoted.
—
Allerettighederforbeholdes.Helellerdelvisgengivelse,kopieringellerændringerforbudtudenforudgåendeskriftlig
tilladelsefraInvacare.Varemærkerermarkeretmed™og®.AllevaremærkerejesafellerergivetilicenstilInvacare
Corporationellerdennevirksomhedslialer,medmindreandetfremgår.
—
Tousdroitsréservés.Larepublication,laduplicationoulamodicationdetoutoupartieduprésentdocumentest
interditesansl'accordécritpréalabled'Invacare.Lesmarquescommercialessontidentiéespar™et®.Toutes
lesmarquescommercialessontdétenuesparoucédéessouslicenceàInvacareCorporationousesliales,sauf
stipulationcontraire.
—
Allerechtenvoorbehouden.Herpublicatie,duplicatieofgeheleofgedeeltelijkewijzigingisverbodenzonder
voorafgaandeschriftelijketoestemmingvanInvacare.Handelsmerkenzijnteherkennenaan™en®.Allehandelsmerken
zijneigendomvanofgelicentieerdaanInvacareCorporationofhaardochterondernemingen,tenzijandersaangegeven.
—
Medenerett.Deterforbudtårepublisere,kopiereellerendreheleellerdeleravdenneveiledningenutenatdetpå
forhånderinnhentetskriftligtillatelsefraInvacare.Varemerkererangittmed™og®.Allevaremerkereiesaveller
lisensierestilInvacareCorporationellertilhørendedatterselskapermedmindreanneterangitt.
—
Medensamrätt.Innehålletfårintegesutpånytt,mångfaldigasellerförändrasheltellerdelvisutanföregående
skriftligttillståndfrånInvacare.Varumärkenbetecknasmed™och®.Samtligavarumärkentillhörellerärlicensierade
tillInvacareCorporationellerdessdotterbolagomingentingannatanges.

Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.
1General.........................................4
1.1Introduction..................................4
1.2Symbolsinthisdocument........................4
1.3Servicelife...................................4
1.4LimitationofLiability............................4
1.5WarrantyInformation...........................4
1.6Compliance...................................4
1.6.1Product-specicstandards.....................4
2Safety..........................................5
2.1Generalsafetyinformation.......................5
2.2Safetyinformationonaccessories..................6
2.3Safetyinformationonelectromagneticinterference.....6
2.4Labelsandsymbolsontheproduct.................6
2.4.1Labellocation..............................6
2.4.2Identicationlabel...........................7
2.4.3Otherlabelsandsymbols......................7
3ProductOverview.................................8
3.1IntendedUse.................................8
3.2Mainpartsoftheceilinghoist.....................8
3.3Accessories...................................8
4Setup...........................................9
4.1Includeditems................................9
4.2BeforeUse...................................9
4.3Installingtheceilinghoist........................9
4.4Insertinghandcontrolplug.......................9
5Usage..........................................10
5.1Generalsafetyinformation.......................10
5.2Generaloperatinginformation.....................10
5.3Operatingtheceilinghoist........................10
5.4Indicatorlightandaudiosignal....................10
5.5ChargingtheBattery............................10
5.6Usingtheexternalback-upbattery.................11
5.7Emergencystop................................11
5.8Emergencylowering............................11
5.9Resettingtheemergencystoporloweringfeature......12
6PatientTransfer...................................13
6.1Generalsafetyinformation.......................13
6.2AttachingtheSling.............................13
6.3LiftingInformation..............................14
6.4Liftingtoandfromaseatedposition................14
6.5Liftingtoandfromalyingposition.................14
7AfterUse........................................15
7.1TransportandStorage...........................15
7.2Dismountingtheceilinghoist......................15
7.3Disposal.....................................15
7.4Reconditioning................................15
8Troubleshooting...................................16
8.1TroubleshootingTable...........................16
9Maintenance.....................................18
9.1Generalmaintenanceinformation..................18
9.2Dailyinspections...............................18
9.3CleaningandDisinfection........................18
9.3.1Generalsafetyinformation.....................18
9.3.2CleaningIntervals............................18
9.3.3Cleaninginstructions.........................18
9.3.4Disinfectioninstructions.......................18
9.4Serviceinterval................................19
9.4.1LOLERStatement............................19
9.5BatteryMaintenance............................19
10TechnicalData...................................20
10.1Dimensionsandweight.........................20
10.2ElectricalSystem..............................20
10.3Environmentalconditions........................20
11Electromagneticcompatibility(EMC)..................21
11.1GeneralEMCinformation.......................21
11.2Electromagneticemission........................21
11.3ElectromagneticImmunity.......................21

Invacare®Robin®
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicpricelists.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexampleproduct
safetynoticesandproductrecalls,contactyourInvacare
representative.Seeaddressesattheendofthisdocument.
Incaseofaseriousincidentwiththeproduct,youshould
informthemanufacturerandthecompetentauthorityin
yourcountry.
1.2Symbolsinthisdocument
Symbolsandsignalwordsareusedinthisdocumentand
applytohazardsorunsafepracticeswhichcouldresultin
personalinjuryorpropertydamage.Seetheinformation
belowfordenitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
1.3Servicelife
Theexpectedservicelifeofthisproductistenyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequencyand
intensityofuse.
1.4LimitationofLiability
Invacareacceptsnoliabilityfordamagearisingfrom:
•Non-compliancewiththeusermanual
•Incorrectuse
•Naturalwearandtear
•Incorrectassemblyorset-upbythepurchaserorathird
party
•Technicalmodications
•Unauthorisedmodicationsand/oruseofunsuitable
spareparts
1.5WarrantyInformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
1.6Compliance
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceRegulation2017/745Class1.Thelaunchdate
ofthisproductisstatedintheCEdeclarationofconformity.
Wearecontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
WeonlyuseREACHcompliantmaterialsandcomponents.
WecomplywiththecurrentenvironmentallegislationsWEEE
andRoHS.
1.6.1Product-specicstandards
TheproducthasbeentestedandconformstoISO10535
(Hoistsforthetransferofdisabledpersons)andallrelated
standards.
Forfurtherinformationaboutlocalstandardsandregulations,
contactyourlocalInvacarerepresentative.Seeaddresses
attheendofthisdocument.
41586745-D

Safety
2Safety
2.1Generalsafetyinformation
Thissectionofthemanualcontainsgeneralsafety
informationaboutyourproduct.Forspecicsafety
information,refertotheappropriatesectionofthemanual
andprocedureswithinthatsection.
WARNING!
Riskofinjuryordamage
–Donotusethisproductoranyavailableoptional
equipmentwithoutrstcompletelyreading
andunderstandingtheseinstructionsandany
additionalinstructionalmaterialsuchasuser
manualsorinstructionsheetssuppliedwith
thisproductoroptionalequipment.Ifyouare
unabletounderstandthewarnings,cautionsor
instructions,contactahealthcareprofessional,
Invacareproviderorqualiedtechnicianbefore
attemptingtousethisproduct.
–Donotmakeanyunauthorizedalterationsor
modicationstotheproduct.
WARNING!
Themaximumsafeworkingloadmustnotbe
exceeded
–Donotexceedthemaximumsafeworkingload
ofthisproductorusedaccessorieslikeslings,
spreaderbarsetc.Seedocumentationorthe
labelingforthestatedmaximumsafeworking
load.
–Thecomponentwiththelowestloadlimit
determinesthemaximumsafeworkingloadof
theentiresystem.
WARNING!
Riskofinjuryordamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Donotattemptanytransferwithoutapproval
ofthepatient’shealthcareprofessional.
–Readtheinstructionsinthisusermanualand
observetrainedpersonnelperformingtransfer
procedures.Thenpracticetransfersunder
supervisionandwithacapablepersonacting
asapatient.
–Specialcaremustbetakenwithpeoplewith
disabilitieswhocannotcooperatewhilebeing
transferred.
–Theceilinghoistisadvisedonlytobeusedto
liftormoveapatient.
–Theredemergencystrapmustbeadjustedto
thecaregiver’sreach,andmustnotberemoved.
–Ifthehoistfails,lowerpatientontoasuitable
surfaceusingtheredemergencystrapbefore
continuingthetransferbyadifferentmethod.
WARNING!
Riskofinjuryordamage
Inappropriatehandlingofcablescancause
electricalshockandproductfailure.
–Donotkink,shearorotherwisedamagethe
cablesoftheproduct.
–Makesurethatnocablesarejammedor
damaged,whentheproductisused.
–Makesurethewiringiscorrectandconnections
areproper.
–Donotuseunauthorizedequipment.
WARNING!
Riskofinjuryordamage
Excessivemoisturewilldamagetheproductand
maycauseelectricalshock.
–Thepatientliftcanbeusedinabathorshower
areabutmustNOTbeusedundertheshower.
Thepatientmustbetransferredtoashower
chairoruseothermeansforshowering.
–Ifthepatientliftisusedinamoisture
environment,ensurethatthepatientliftis
wipedcleanofanymoistureafteruse.
–Donotchargetheproductinamoisture
environmentorwithwethands.
–Donotstoretheproductinadampareaor
dampcondition.
–See10.3Environmentalconditions,page20.
WARNING!
Riskofinjuryordamage
Ignitionsourcescancauseburnsorre.
–Patienttransfermustbeperformedwitha
safetyspacebetweenthehoistandpossible
ignitionsources(heater,stove,replace,etc.)
–Thepatientandassistantsmustnotsmoke
duringtransfer.
–Theslingmustnotbeplacedoverheatsources
(heater,stove,replace,etc.)
WARNING!
Riskofinjuryordamage
Toavoidinjuryordamagewhenoperatingthe
product:
–Closesupervisionisnecessarywhentheproduct
isusednearchildrenorpets.
–Donotletchildrenplaywiththeproduct.
CAUTION!
Riskofinjuryordamage
Theproductcangethotwhenexposedtosunlight
orotherheatsources.
–Donotexposetheproducttodirectsunlightfor
prolongedperiods.
–Keeptheproductawayfromheatsources.
IMPORTANT!
Accumulationoflint,dustandotherdirtcan
impairtheproduct.
–Keeptheproductclean.
IMPORTANT!
Theelectronicsmayonlybeservicedbya
qualiedtechnician.
–Donotremovethetopcover.
1586745-D5

Invacare®Robin®
2.2Safetyinformationonaccessories
CAUTION!
Riskofinjury
Non-originalorincorrectaccessoriesmayaffect
thefunctionandsafetyofthisproduct.
–Duetoregionaldifferences,refertoyour
localInvacarewebsiteorcatalogforavailable
accessoriesorcontactyourInvacareprovider.
–Seethemanualdeliveredwiththeaccessory
forfurtherinformationandinstructions.
–Useonlyoriginalaccessoriesfortheproduct
inuse.Undercertaincircumstances,theuse
slingsfromothermanufacturersispossible.See
additionalinformationinthissection.
–Ariskassessmentisalwaystobecarriedoutby
aprofessionalpriortoissuingliftingequipment.
ItisimportantthattheTask,Individual,Load,
EnvironmentandEquipmentareconsideredin
theriskassessment.
–Alwayschoosetheslingdesignandsize
accordingtothepatient’sweight,sizeand
physicalabilitywhilstconsideringthetypeof
transfertobecarriedout.
CAUTION!
Compatibilityofslingswithattachmentsystem
Invacareusesacommonattachmentsystem
basedonhooksandloops.Loopsontheslings
areattachedtohooksonthelift.Therefore,
suitableslingsofothermanufacturerscanbe
usedonthisliftaswell.
–Useonlyslingswithloopattachmentsthatare
suitableforhooksasattachmentpoints.
–Donotuseslingsdesignedfor"Keyholeor
ClipAttachmentSystems"or"TiltingFrame
Systems".
2.3Safetyinformationon
electromagneticinterference
WARNING!
Riskofmalfunctionduetoelectromagnetic
interference
Electromagneticinterferencebetweenthis
productandotherelectricalequipmentcanoccur
anddisturbtheelectricaladjustmentfunctions
ofthisproduct.Toprevent,reduceoreliminate
suchelectromagneticinterference:
–Onlyuseoriginalcables,accessoriesandspare
parts,tonotincreaseelectromagneticemission
orreduceelectromagneticimmunityofthis
product.
–Donotuseportableradiofrequency(RF)
communicationsequipmentcloserthan30cm
toanypartofthisproduct(includingcables).
–Donotusethisproductnearactive
high-frequencysurgicalequipmentandthe
RFshieldedroomofasystemformagnetic
resonanceimaging,wheretheintensityof
electromagneticdisturbancesishigh.
–Ifdisturbancesoccur,increasethedistance
betweenthisproductandtheotherequipment
orswitchitoff.
–Refertothedetailedinformationandfollow
theguidanceinchapter11Electromagnetic
compatibility(EMC),page21.
WARNING!
Riskofmalfunction
Electromagneticinterferencemaycauseimproper
operation.
–Donotusethisproductadjacenttoorstacked
withotherelectricalequipment.Ifsuchuseis
necessarythisproductandtheotherequipment
mustbecloselyobservedtoverifythatthey
areoperatingnormally.
2.4Labelsandsymbolsontheproduct
2.4.1Labellocation
61586745-D

Safety
2.4.2Identicationlabel
Product Name
YYYY-MM
= xxx kg
Invacare Portugal, Lda
Rua Estrada Velha 949
4465-784 Leça do Balio, Portugal
XXXXXX XXXXX_XX
XXXXXXXXXXXXX
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
ISO 10535
Theidenticationlabelcontainsthemainproduct
information,includingtechnicaldata.
Symbols
SerialNumber
ReferenceNumber
ManufacturerAddress
ManufacturingDate
Max.SafeWorkingLoad
CLASSIIequipment
TypeBAppliedPart
WEEEconform
Europeanconformity
Abbreviationsfortechnicaldata:
•Iin=IncomingCurrent
•Uin=IncomingVoltage
•Int.=Intermittence
•AC=AlternatingCurrent
•Max=maximum
•min=minute
Formoreinformationabouttechnicaldata,see10Technical
Data,page20.
2.4.3Otherlabelsandsymbols
RefertoUserManual
1586745-D7

Invacare®Robin®
3ProductOverview
3.1IntendedUse
Aceilinghoistisabattery-poweredtransferdevice,designed
tobeusedindoorinnormaltemperatureandhumidity.
Ifcontinuouslyexposedtohighhumidity,highcondensation
andcorrosives(e.g.chlorineorammoniagases)theproduct
maybeimpairedandareductioninlifetimemustbe
expected.
Commonliftingsituationsare:
•Betweenthebedandawheelchair
•Toandfromthetoilet
•Loweringandraisingpatientsto/fromtheoor
Themaximumsafeworkingloadisstatedin10Technical
Data,page20
Theceilinghoistcanbeusedtotransferandposition
completelyorpartiallyimmobilepatientsinthe
recommendedtracksystem.Allpositionchangesarepossible
withoutassistanceofthepatient.
Ahealthcareprofessionalorprivatepersonwhohasreceived
propertrainingistheintendedoperatorofthisproduct.
Therearenoknowncontraindicationsforthisproduct.
3.2Mainpartsoftheceilinghoist
Robin®Robin®Mover
AConnectionforhandcontrol
BControlbuttonUP
CDirectionalarrowsonRobin®Mover
DControlbuttonDOWN
EConnectionforexternalback-upbattery
FIndicatorlight
GLiftingstraps
HRedemergencystrap
IStraphooks
JRetainerforhandcontrol(accessory)
KHandcontrol
3.3Accessories
Duetoregionaldifferences,refertoyourlocal
Invacarewebsiteorcatalogfordetailsaboutavailable
accessoriesorcontactyourInvacareprovider.
•2-and4-pointspreaderbarincludingexiscopeversion
•Stretcherforhorizontallift
•Scaleincludingspreaderbar
•Holderforhandcontrol
•Batterycharger
•Chargerset(chargerandholderforhandcontrol)
•Extensionstrapsandextensioncablesforhandcontrol
•Externalback-upbattery
•Chargerforexternalback-upbattery
•Slingmodelsfor“LoopandCoatHangerSpreaderBar
System”:
–Fullbodysupportslings–withoutheadsupport
–Fullbodysupportslings–withheadsupport
–Slingsfordress/toileting–withorwithouthead
support
–Slingsforamputee
–Slingsforwalkingtraining
81586745-D

Setup
4Setup
4.1Includeditems
Robin®Robin®Mover
•ACeilinghoist
includingtwoliftingstrapswithhooksandanemergency
strap.Robin®Moveralsoincludesthetrolley.
•BHandcontrol
•CUsermanual
4.2BeforeUse
CAUTION!
–Theceilinghoistisnotintendedtobe
usedtogetherwithMEDICALELECTRICAL
EQUIPMENT.
Beforerstuse,allfeaturesofthehoistsystemmustbe
inspectedbyspecializedservicetechnicians.
Performavisualinspectionoftheceilinghoist.Ifthe
packagingisdamageduponarrival,theceilinghoistparts
mustbethoroughlyexaminedforvisibledamageordefects.
Ifthereisanysuspicionofdamage,theceilinghoistmust
notbeusedbeforespecializedservicetechnicianshave
approvedit.
Theemergencystopisactivatedduringshipment.Reset
theemergencystopbeforerstuse.See5.9Resettingthe
emergencystoporloweringfeature,page12.
Itispossiblethatthehoist´sbatteryisdischargedonaccount
ofself-discharge.Chargethehoist´sbatterybeforerstuse.
See5.5ChargingtheBattery,page10.
4.3Installingtheceilinghoist
Theceilinghoisthastobemountedtoarailsystemforuse.
Therailsystemhastobeinstalledandapprovedaccording
toEN10535byaspecializeddealerorspecializedservice
technician.
InstallingRobin®
TheRobin®requiresatrolley,holdingtheceilinghoistin
therailsystem.Thetrolleyhastobepre-installedbya
specializeddealerorservicetechnician.
Tomounttheceilinghoisttothetrolley,dothefollowing:
1.LocatethehoisttrolleyattheØ32mmroundrecess
intherail.
2.Liftthehoistandpushthesuspensionpinthroughthe
trolleyopening.
3.Turnthehoistby90degreestoxitinthetrolley.
4.Adjustthelengthoftheemergencystop/loweringcord
towithintheuser’sreach.
InstallingRobin®Mover
Robin®Moverisaceilinghoistwiththetrolleyalready
attached.Thetrolleycanthereforenotbepre-installedin
therailsystem.
Theceilinghoisthastobeinstalledbyaspecializeddealer
orservicetechnician.
4.4Insertinghandcontrolplug
1.SlideandholdlockingleverAawayfromtheaperture
C.
Agateintheaperturewillopen.
2.MakesuretheplugBisinthecorrectorientationwith
theslotupwards(seeimage).Insertplugintoaperture.
3.Releaselever,sothatthegateclosesandholdtheplug
intheaperture.
Removingthehandcontrolplug
1.SlideandholdlockingleverAawayfromtheaperture
C.
2.PulltheplugBoutoftheaperture.
3.Releaselever.
1586745-D9

Invacare®Robin®
5Usage
5.1Generalsafetyinformation
WARNING!
Riskofinjuryordamage
Beforeusingtheliftwithapatient,refertothe
followingsafetyinformationandinstructions:
–2Safety,page5
–6PatientTransfer,page13
5.2Generaloperatinginformation
CAUTION!
Iftheliftingstrapsareguidedincorrectlyinthe
hoist(e.g.thestrapsbecometwisted),theceiling
hoistwillautomaticallyturnoff.
–Keepthestrapsstraighttoensuretheyfeed
intothehoistcorrectly.Thestrapsareheld
taughtbytheweightofthehooks.
–Keepthestrapsfreelysuspendedwhenthe
unloadedhoistislifting/lowering.
Ifauserunintentionallytrapsthehand
intheliftingstrapduringlifting,thehoist
willautomaticallyturnoff.Thehoiststops
immediatelywhenahandgetsincontactwith
thestrapinlet.
–Keepyourhandsawayfromthestrapinlet
duringlifting.
CAUTION!
Thehandcontrolisprotectedagainstsplashed
water(IPX4).Extendedcontactwithwaterwill
damagethehandcontrol.
–Donotimmersethehandcontrolinliquids,
evenforashorttime.
–Avoidanycontactwithwaterorotherliquids.
5.3Operatingtheceilinghoist
Theceilinghoistisinoperationmodeassoonasabutton
onthehandcontrolispressed.
Robin®Robin®Mover
D
A
B
C
A
B
Liftingandloweringthestraps
Whentheceilinghoistisnotloaded,itwilllift/lower
athighspeed.Whenloadedwithmorethan10kg,
thelifting/loweringspeedisautomaticallyreduced
toasafelevel.
1.Toliftthestraps,presstheUPbuttonAonthehand
control.
2.Tolowerthestraps,presstheDOWNbuttonBonthe
handcontrol.
Theceilinghoistcanalsobeoperatedbypressingthe
UPandDOWNbuttonsontheundersideofthehoist.
TraverseRobin®alongthetrack
1.Usethetwoliftingstrapstopulltheceilinghoistalong
thetrack.
DONOTusetheredemergencystraptotraverse
theceilinghoist.
TraverseRobin®Moveralongthetrack
1.Performoneofthefollowing:
•Hoistisloaded:PressbuttonLEFTCorRIGHTD
onthehandcontroltotraversetheceilinghoist
alongthetrack.
•Hoistisnotloaded:Usethetwoliftingstrapsto
pullthehoistalongthetrack.
DONOTusetheredemergencystraptotraverse
theceilinghoist.
Itisnotpossibletoactivatebothtraversingand
lifting/loweringfunctionsimultaneously.Whenthetraversing
functionisactivated,theblueindicatorlightonthebottom
ofthehoistisoff.See5.4Indicatorlightandaudiosignal,
page10.
5.4Indicatorlightandaudiosignal
Hoist
StatusIndicatorlightAudiosignal
Off/Standby
Hoisttraversing
(Robin®Moveronly)
OffNo
Hoistinuse
(Up/Down)
BlueNo
LowbatteryBlueFlashingYes
Theblueindicatorlightontheundersideofthehoistturns
offautomaticallyafter30seconds.
WallMountedCharger
StatusIndicatorlightDuration
Batterynot
connected
Yellown/a
Initializingand
analysisofbattery
Yellow12–14seconds
FastchargeRed5min—3hours
Charged(trickle
charge)
Greenn/a
Faultcondition
(batterydefect)
Alternatingred
andgreen
n/a
5.5ChargingtheBattery
Ifthechargestatusbecomeslow,anaudibleindicator
soundsandtheindicatorlamponthebottomoftheceiling
101586745-D

Usage
hoistashes(seealso5.4Indicatorlightandaudiosignal,
page10).Whenthishappens,thereisusuallysufcient
powertolowerthepatient.
Itisnotpossibletousethehoistwhilethebattery
ischarging.
1.Finishthecurrentliftinprogress
Ifthecurrentliftinprocessdischargesthebattery
completely,anexternalbackupbatterymaybeusedto
temporarilypowerthelift.See5.6Usingtheexternal
back-upbattery,page11.
2.Movetheceilinghoisttothechargingstation.
3.Assurethatthehandcontrolandchargingstationare
cleananddrybeforecharging
4.Placethehandcontrolintothechargingstation.
Ayellowindicatorlamponthechargerindicates
thehandcontrolisconnected.Theindicatorlamp
illuminatesredwhilecharging.
5.Whenfullycharged,theindicatorlamponthecharger
turnsgreen.
Aslongastheceilinghoistisnotinuse,leavethehand
controlinthechargingstation.
6.Tousetheceilinghoist,removethehandcontrolfrom
thecharger.
Keepingthebatterieschargedguaranteeshoist
functionalityandmaintainsthebatterytoensurea
longlifetime.
Iftheaudibleindicatorbeepsandtheblueindicator
onthehoistashesafterthehoisthasbeenfully
chargedandonlybeeninuseforashortperiodof
time,thebatterymayneedexerciseorreplacement.
See9.5BatteryMaintenance,page19.
Iftheceilinghoistwillnotbeusedformorethan
4weeks,Invacarerecommendsdisconnectingthe
chargerandpullingtheemergencystop.
Thechargerisconnectedtothemainswithamains
plug.Makesurethatthemainsplugisaccessible
andcanbeunpluggedifrequired.
5.6Usingtheexternalback-upbattery
Iftheceilinghoisthastobeusedimmediatelywithits
batterydischarged,anexternalback-upbatterycanbeused.
Usetheexternalback-upbatteryonlyasanexception
andwhenabsolutelynecessary.Theexternalback-up
batteryisavailableasanaccessory.
1.Inserttheplugoftheexternalback-upbatteryAinto
apertureBundersideofthehoist.Theexternalback-up
batteryshouldhangfreelyduringpatienttransfer.
2.Operatetheceilinghoistasdescribedinchapter5.3
Operatingtheceilinghoist,page10.
3.Rechargetheexternalback-upbatteryinordertohave
itfullychargedforthenextusage.
Chargingtheexternalbattery:
1.Placethepluginthechargersocket(aspecialadapter
isnecessary).
2.TheLEDlightturnsgreentoindicatetheunitisfully
charged(approx.chargingtime2hours).
5.7Emergencystop
Theemergencystopfunctionisusedtostopthepatient
fromloweringorliftingiftheceilinghoistdoesnotstop
orreacttothehandcontrol.
1.PullandreleasetheredemergencystrapAunderside
ofthehoistBtoactivatetheemergencystop.
Theceilinghoiststopsanyliftingorloweringmovement
immediately.
IMPORTANT!
Whentheredemergencystraphasbeenpulled,
thehoistfunctions,includingtheendstop,are
deactivated.Theblueindicatorlightturnsoff.
–Toactivatethehoistfunctionsagain,reset
theemergencystop.See5.9Resettingthe
emergencystoporloweringfeature,page12.
5.8Emergencylowering
Theemergencyloweringfunctionisusedtolowerthe
patientonlyifthehoisthasstoppedworking.
1586745-D11

Invacare®Robin®
1.PullandholdtheredemergencystrapAundersideof
thehoistBtolowerthepatient.
Keeponpulling,untilthepatientisloweredtoasafe
position.
2.Releasetheredemergencystraptostoploweringthe
patient.
IMPORTANT!
Whentheredemergencystraphasbeenpulled,
thehoistfunctions,includingtheendstop,are
deactivated.Theblueindicatorlightturnsoff.
Withtheendstopfunctiondeactivated,thelifting
strapswillnotstopautomaticallywhenlowered
totheirfulllength.Continuedloweringcould
resultinrollinguptheliftingstrapsunevenlyand
inthewrongway.
–Pulltheredemergencystraponlyuntilthe
patientisloweredtoasafeposition.
–DONOTlowertheliftingstrapstotheirfull
lengthormore.
–Toactivatethehoistfunctionsagain,reset
theemergencystop.See5.9Resettingthe
emergencystoporloweringfeature,page12.
5.9Resettingtheemergencystopor
loweringfeature
WARNING!
–Iftheemergencystoporemergencylowering
mustbeused,thereisaproblemwiththe
system.ContactyourdealerorInvacare
representativeforservicebeforeusingthe
systemagain.
WhentheredemergencystrapBhasbeenpulled,the
resetbuttonApopsoutsothataredringisvisible.The
hoistwillnotfunctionuntiltheemergencystoporlowering
featureisreset.
1.PresstheresetbuttonAtoresettheemergencystop
orloweringfeature.
2.Activatethehandcontroltoresumeuseofthehoist.
121586745-D

PatientTransfer
6PatientTransfer
6.1Generalsafetyinformation
WARNING!
RiskofInjuryorDamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Beforetransferringtoastationaryobject
(wheelchair,bed,commodeorothersurface)
checkthatitsweightcapacitycanwithstand
thepatient’sweight.
–Ifapplicablethebrakesofthestationaryobject
(wheelchair,bedetc.)mustbeappliedbefore
loweringthepatientontoorliftingthepatient
off.
WARNING!
RiskofInjuryorDamage
Damagetopartsoftheliftcausedbyimpactwith
theoor,wallsorotherstationaryobjectsmay
causedamagetotheproductandleadtoinjury.
–Donotallowpartsofthelifttoimpactthe
oor,wallsorotherstationaryobjects.
–Alwaysstorethehandcontrolproperlywhen
notinuse.
WARNING!
Riskofinjury
Thereisariskofinjurytothepatientand
caregivercausedbydanglinghooksorthehand
control.
–Alwaysbeawareofthepositionofthehooks
andhandcontrolduringliftingprocedures.
WARNING!
RiskofEntrapmentorStrangulation
Itemsinthepatient’ssurroundingscancause
entrapmentstrangulationduringlifting.Toavoid
entrapmentorstrangulation:
–Beforelifting,checkthatthepatientis
completelyfreeofhis/hersurroundings.
–Donotallowthehandcontrolcordorthe
liftingstrapstobecomeentangledaroundthe
patientandcaregivers.
WARNING!
RiskofEntrapment
Thereisariskofentrapmentbetweenthehooks
andtheslingaswellasbetweenthehooksand
thehookhousing.
–Usecautionwhenlifting.
–Neverputhandsorngersonornearthe
hookswhenlifting.
–Ensurethepatient’shandsandngersareaway
fromthehooksbeforelifting.
IMPORTANT!
Alltransferproceduresdescribedinthefollowing
canbeperformedbyone(1)assistant.However,
Invacarerecommendsthattheproceduresare
performedbytwo(2)assistantswhenever
possible.
6.2AttachingtheSling
WARNING!
RiskofInjury
Usageofwrongordamagedslingscancausethe
patienttofallorcauseinjurytoassistants.
–UseanInvacareapprovedslingthatis
recommendedbytheindividual’sdoctor,nurse
ormedicalassistantforthecomfortandsafety
oftheindividualbeinglifted.
–Invacareslingsandpatientliftaccessoriesare
specicallydesignedtobeusedinconjunction
withInvacarepatientlifts.
–Aftereachlaundering(inaccordancewith
instructionsonthesling),inspectsling(s)for
wear,tear,andloosestitching.
–Bleached,torn,cut,frayed,ordamagedslings
areunsafeandcouldresultininjury.Discard
immediately.
–DONOTalterslings.
WARNING!
RiskofInjury
Improperlyattachedoradjustedslingscancause
thepatienttofallorcauseinjurytoassistants.
–Besuretochecktheslingattachmentseach
timetheslingisremovedandreplaced,to
ensurethatitisproperlyattachedbeforethe
patientisremovedfromastationaryobject
(bed,chairorcommode).
–DONOTuseanykindofplasticback
incontinencepadorseatingcushionbetween
patientandslingmaterialthatmaycausethe
patienttoslideoutoftheslingduringtransfer.
–Positionthepatientintheslingasdirectedby
theinstructionsprovidedwiththesling.
–Adjustmentsforpatientsafetyandcomfort
shouldbemadebeforemovingthepatient.
Theinformationinthissectionisonlyageneralguideline.
Refertotheslingusermanualformoredetailsaboutthe
slings.
Aslingwithfourtosixstrapsdesignedformountingon
hooksshouldbeusedwhenusingtheceilinghoist.
Theloopsoftheslingmaybeequippedwithcolorcoded
strapsprovidingdifferentlength,toplacethepatientin
variouspositions.Matchthecorrespondingcolorsoneach
sideoftheslingforanevenliftofthepatient.
Theslingstrapsaretobehookedinpairs(onefromtheback
andonefromtheleg)ontheirownsuspensionhook.
Whenattachingtheslingtothehooks,andthestraps
aretwisted,thestrapswillrotateandstretchout,
thusensuringtrouble-freeoperation.
1586745-D13

Invacare®Robin®
6.3LiftingInformation
WARNING!
Onlypersonnelwhohavereceivedtraining
regardingtheuseofliftingequipmentandtting
ofslingsshouldusethehoist.
–Planthemove.Avoidleavingtheclientinthe
slingunattended.
–Theceilinghoistliftsquickly.Beforelifting,
checkthattheclientiscompletelyfreeof
his/hersurroundings.
–Thepatient’sbodypartsmustnotbeindanger
ofbecomingtrapped.
–Checkthattheredemergencystrap,hand
controlandhandcontrolcablearefreeofthe
liftingstraps,clientandotherobjectsbefore
theceilinghoistisactivatedandmovedupor
down.
–Whentheceilinghoistisusedcorrectly,the
clientshouldonlybeliftedtotheextentthat
she/heisclearofthesurfaceandshouldbe
movedatthisheight.
6.4Liftingtoandfromaseatedposition
Followthisprocedurewhenliftingapatientfromaseated
position(wheelchair,commode,etc.).
1.Traversetheceilinghoistalongthetracktowardsthe
patienttobelifted.
2.Positionthesuspensionhooksatthesameheightasthe
patient’schestandnocloserthanmid-thigh.
3.Positionthesuspensionhookssotheyareparalleltothe
patient’sshoulders.
4.Positionthepatientinthesling.Refertotheslinguser
manual.
5.Attachtheslingtothesuspensionhooks.Referto6.2
AttachingtheSling,page13.
6.5Liftingtoandfromalyingposition
Followthisprocedurewhenliftingapatientfromalying
position.
1.Traversetheceilinghoistalongthetracktowardsthe
patienttobelifted.
2.Positionthesuspensionhooksabovethepatienttobe
lifted.
3.Alignthesuspensionhookswiththepatient’sshoulders.
4.Positionthepatientinthesling.Refertotheslinguser
manual.
5.Elevatetheheadofthebed,sothattheuserissitting
up.
6.Attachtheslingtothesuspensionhooks.Referto6.2
AttachingtheSling,page13.
141586745-D

AfterUse
7AfterUse
7.1TransportandStorage
Invacarerecommendsthattheceilinghoistisalways
transportedandstoredintheoriginalpackaging.Placethe
ceilinghoistonasoftsurface,suchasaclothorfoam
rubbermat.
Forlongtermstorage,theemergencystopmustbeactivated.
Thiswillreducethedischargeofthebattery.Referto5.7
Emergencystop,page11.
Fortransportandstorageconditionsoftheceilinghoist,
referto10.3Environmentalconditions,page20.
7.2Dismountingtheceilinghoist
Theceilinghoistcanbedismountedfortransportorstorage.
Robin®
1.Liftthehoistslightlyandpushthesuspensionpinout
ofitsholderinthetrolley.
2.Turnthehoistby90degreesandpullitoutofthetrolley.
Robin®Mover
ContactyourInvacarerepresentativeorspecializeddealerto
havetheceilinghoistdismountedbyaspecializedservice
technician.
7.3Disposal
WARNING!
EnvironmentalHazard
Devicecontainsbatteries.
Thisproductmaycontainsubstancesthatcould
beharmfultotheenvironmentifdisposedof
inplaces(landlls)thatarenotappropriate
accordingtolegislation.
–DONOTdisposeofbatteriesinnormal
householdwaste.
–BatteriesMUSTbetakentoaproperdisposal
site.Thereturnisrequiredbylawandfreeof
charge.
–Doonlydisposedischargedbatteries.
–Coverterminalsoflithiumbatteriespriorto
disposal.
–Forinformationonthebatterytypeseebattery
labelorchapter10TechnicalData,page20.
Beenvironmentallyresponsibleandrecyclethisproduct
throughyourrecyclingfacilityatitsendoflife.
Disassembletheproductanditscomponents,sothedifferent
materialscanbeseparatedandrecycledindividually.
Thedisposalandrecyclingofusedproductsandpackaging
mustcomplywiththelawsandregulationsforwaste
handlingineachcountry.Contactyourlocalwaste
managementcompanyforinformation.
7.4Reconditioning
Thisproductissuitableforreuse.Toreconditiontheproduct
foranewuser,carryoutthefollowingactions:
•Cleaninganddisinfection
•Inspectionaccordingtoserviceplan
Fordetailedinformationaboutinspection,cleaningand
disinfection,consulttheusermanualandservicemanual
forthisproduct.
1586745-D15

Invacare®Robin®
8Troubleshooting
8.1TroubleshootingTable
SYMPTOMSPROBLEMSOLUTION
EmergencystopactivatedCheckthattheemergencystopisnot
activated.Referto5.9Resettingthe
emergencystoporloweringfeature,page
12.
Systemdoesnothavepowerorbattery
isdischarged
Chargethebatteryoruseemergency
battery.Referto5.5Chargingthe
Battery,page10.
Ceilinghoistdoesnotrespondtothe
handcontrol’sbuttonsandup/down
buttonsontheceilinghoistarenot
responding.
FuseisblownThefuseneedstobereplaced.Contact
anInvacarerepresentativeorspecialized
dealerforservice.
HandcontrolnotconnectedproperlyCheckthehandcontrolplug.Referto4.4
Insertinghandcontrolplug,page9.
Ceilinghoistdoesnotrespondtothehand
control’sbuttons,butup/downbuttons
ontheceilinghoistareresponding.HandcontroldefectiveReplacethehandcontrol.
BatterynearlydischargedChargethebatteryoruseemergency
battery.Referto5.5Chargingthe
Battery,page10.
Liftingstrapswillonlymovedownand
notup.
LoadistoohighReducetheload.Thehoistisequipped
withanover-currentsafetysystem.
HandcontroldefectiveReplacethehandcontrol. Liftingstrapswillonlymoveupandnot
down.LoosestrapfunctionactivatedContactanInvacarerepresentativeor
specializeddealerforservice.
Ceilinghoistspeedisthesamewithand
withoutload.
Non-loadquickmovementfunction
activatedpermanently
ContactanInvacarerepresentativeor
specializeddealerforservice.
LiftinghooksdonotturnfreelyenoughCleanorreplacethehooks.Contactan
Invacarerepresentativeorspecialized
dealerforservice.
Liftingstrapsaretwistedanddonot
straightenout.
StrapsarefrayedContactanInvacarerepresentativeor
specializeddealertoreplacethestraps.
RailsrequireserviceorcleaningContactanInvacarerepresentativeor
specializeddealerforservice.
Trolleywornordamaged(Robin®only)Trolleymustbereplaced.Contactan
Invacarerepresentativeorspecialized
dealerforservice.
Drivingwheelswornordamaged(Robin®
Moveronly)
Drivingwheelsmustbeadjusted.Contact
anInvacarerepresentativeorspecialized
dealerforservice.
Ceilinghoistdoesnottraversetherails.
Handcontroldefective(Robin®Mover
only)
Replacethehandcontrol.
Ceilinghoistemitsexcessivenoisewhen
activated.
Bearings,gearwheelsormotordefectiveThehoistmustbereplaced.Contactan
Invacarerepresentativeorspecialized
dealerforservice.
Checkthatthepowersupplyisswitched
onandconnectedtothechargingstation.
CeilinghoistwillnotchargeSystemhasnopower
ContactanInvacarerepresentativeor
specializeddealerforservice.
Checkthattheceilinghoisthaspower
supplyandthatthebatteryisrecharged.
NoindicatorlightonhoistSystemhasnopowerorbatteryis
discharged
Placethehandcontrolinthecharging
stationandrechargetheceilinghoist.
Theemergencystrapdoesnotturn
ceilinghoistoff
Ceilinghoistrequiresservice.ContactanInvacarerepresentativeor
specializeddealerforservice.
Theemergencystrapdoesnotlowerthe
ceilinghoist.
Ceilinghoistrequiresservice.ContactanInvacarerepresentativeor
specializeddealerforservice.
161586745-D

Troubleshooting
Ifproblemsarenotremediedbythesuggestedmeans,contactanInvacarerepresentativeorspecializeddealerfor
service.
1586745-D17

Invacare®Robin®
9Maintenance
9.1Generalmaintenanceinformation
CAUTION!
Riskofinjuryordamage
–Donotperformanymaintenanceorservice
procedureswhiletheproductisinuse.
Followthemaintenanceproceduresdescribedinthismanual
tokeepyourproductincontinuousservice.
9.2Dailyinspections
WARNING!
Riskofinjuryordamage
Damagedorwornpartscanaffectthesafetyof
thelift.
–Thepatientliftshouldbecheckedeachtime
itisused.
–Donotusetheliftifdamageisfoundoryou
questionthesafetyofanypartofthelift.
ContactyourInvacareproviderimmediately
andensuretheliftisnotuseduntilrepairsare
made.
DailyInspectionChecklist
qVisuallyinspectslings,spreaderbar(optional),lifting
strapsandstraphooks.Checkallpartsfordamageor
wear.
qChecktheemergencystopandemergencylowering
function.Checkallpartsforexternaldamageorwear.
qCheckthatallhardwareandattachmentpointsfor
damageorwear.Checkallpartsforexternaldamage
orwear.
qVerifythatthehandcontrolisfunctional.
qCheckthebatterycharger.
qChargethebatteryeverydaytheliftisused.
9.3CleaningandDisinfection
9.3.1Generalsafetyinformation
CAUTION!
Riskofcontamination
–Takeprecautionsforyourselfanduse
appropriateprotectiveequipment.
CAUTION!
Riskofelectricshockandproductdamage
–Switchoffthedeviceanddisconnectfrom
mains,ifapplicable.
–Whencleaningelectroniccomponentsconsider
theirprotectionclassregardingwateringress.
–Makesurethatnowatersplashestotheplug
orthewalloutlet.
–Donottouchthepowersocketwithwethands.
IMPORTANT!
Wronguidsormethodscanharmordamage
theproduct.
–Allcleaningagentsanddisinfectantsusedmust
beeffective,compatiblewithoneanotherand
mustprotectthematerialstheyareusedto
clean.
–Neverusecorrosiveuids(alkalines,acidetc.)
orabrasivecleaningagents.Werecommend
anordinaryhouseholdcleaningagentsuchas
dishwashingliquid,ifnotspeciedotherwisein
thecleaninginstructions.
–Neveruseasolvent(cellulosethinner,acetone
etc.)thatchangesthestructureoftheplastic
ordissolvestheattachedlabels.
–Alwaysmakesurethattheproductiscompletely
driedbeforetakingintouseagain.
Forcleaninganddisinfectioninclinicalorlong-term
careenvironments,followyourin-houseprocedures.
9.3.2CleaningIntervals
IMPORTANT!
Regularcleaninganddisinfectionenhances
smoothoperation,increasestheservicelifeand
preventscontamination.
Cleananddisinfecttheproduct
–regularlywhileitisinuse,
–beforeandafteranyserviceprocedure,
–whenithasbeenincontactwithanybody
uids,
–beforeusingitforanewuser.
9.3.3Cleaninginstructions
IMPORTANT!
–Theproductdoesnottoleratecleaningin
automaticwashingsystems,withhigh-pressure
cleaningequipmentorsteam.
Cleaningthelift
Method:Wipeoffwithawetclothorsoftbrush.
Max.temperature:40°C
Solvent/chemicals:Ordinaryhouseholdcleaningagentand
water.
Drying:Wipedrywithasoftcloth.
Cleaningthesling
Refertothewashinginstructionsontheslingandtothe
slingmanualforcleaningdetails.
9.3.4Disinfectioninstructions
Informationonrecommendeddisinfectants
andmethodscanbefoundonhttps://vah-
online.de/en/for-users.
Indomesticcare
Method:Followtheapplicationnotesfortheused
disinfectantandwipedisinfectallaccessiblesurfaces.
Disinfectant:Ordinaryhouseholddisinfectant.
181586745-D

Maintenance
Drying:Allowtheproducttoair-dry.
Inclinicalandlongtermcare
Followyourin-housedisinfectionproceduresandonlyuse
thedisinfectantsandmethodsspeciedtherein.
9.4Serviceinterval
WARNING!
Riskofinjuryordamage
Servicemustbeperformedonlybyaqualied
technician.
–ContactyourInvacareproviderforservice.
Servicemustbeperformedatleastevery12monthsunless
otherwisestatedinlocalrequirements.
Thefrequencyofinspectionmustbeincreased,ifthe
productiscontinuouslyexposedtohighhumidity,high
condensationandcorrosives(e.g.chlorineorammonia
gases),topreventproductimpairment.
9.4.1LOLERStatement
TheUKHealthandSafetyExecutive’sLiftingOperationsand
LiftingEquipmentRegulations1998,requireanyequipment
thatisusedintheworkplacetoliftaloadbesubjectto
safetyinspectiononasixmonthlybasis.Pleaserefertothe
HSEwebsiteforguidancewww.hse.gov.uk.
Thepersonresponsiblefortheequipmentmustensure
adherencetoLOLERregulations.
9.5BatteryMaintenance
Iftheaudibleindicatorbeepsandtheblueindicatoronthe
hoistashesafterthehoisthasbeenfullychargedandonly
beeninuseforashortperiodoftime,thebatterymayneed
tobeexercised.
Toenablethebatterytochargefully,thebatteryshouldbe
exercisedfromtimetotime.
Followingalongperiodofstorage,itcouldalsobenecessary
toexercisethebattery.
Itisalsosuggestedthatthebatteryisexercisedinsituations
wherethehoistisusedinfrequently,and/orwherethehand
controlisplacedinthechargerforlongperiodsoftime.In
thissituation,therewillalwaysbecapacityenoughforafew
lifts,butwerecommendtoexercisethebatteryassoon
aspossibleafterwards.
Exerciseofthebatterycanbedonebychargingand
dischargingthehoistcompletelyseveraltimes.
1.ChargethebatteryuntiltheLEDturnsgreen.
2.Removethehandcontrolfromthecharger.
3.Raiseandlowerthestrapswithaloadforoneminute.
4.Waittenminutes.
5.RepeatSteps3–4untilthebatteryiscompletely
discharged.
Continuethisprocessaftertheaudiblealert
soundsandthebluelightashes,indicatingthe
batteryislow.
6.RepeatSteps1–5twotothreetimes.
1586745-D19

Invacare®Robin®
10TechnicalData
10.1Dimensionsandweight
Dimensions
Robin®Robin®
Mover
Hoistlength(A)470mm470mm
Hoistwidth(B)250mm250mm
Hoistheight(C)203mm266mm
Maximumliftingrange(D)2.5m2.5m
Weights
Robin®
Robin®
Mover
Maximumliftingcapacity(Safe
WorkingLoad)
200kg200kg
Totalweightwithoutsling7.3kg10kg
10.2ElectricalSystem
Robin®Robin®Mover
Maximumcurrent
input0.9A
Protectionclass1Entiredevice:IPx4
(ceilinghoist:IP24;handcontrol:IP44)
InsulationclassClassIIequipment
TypeBappliedpart
Appliedpartcomplyingwiththe
speciedrequirementsforprotection
againstelectricalshockaccording
toIEC60601-1.
Soundlevel50–55dB(A)
Numberoflifts
percharge65liftsof0.5mwith80kg
Robin®Robin®Mover
Intermittent
(periodicmotor
operation)
10%,max.2min./18min.
BatteryNiMHBattery24V/1.9Ah
ChargingtimeUpto3hoursat20°C
Liftingspeedwith
200kgload2.1cm/s2.1cm/s
Traversespeedin
thetracksn/a14cm/s
Charger
VoltageoutputDuringcharging:25–36VDC
No-load:41VDC
Voltagesupply100–240VAC,50–60Hz
Protectionclass1IP41orIP67(dependingonversion)
1Seeproductlabelandlabeloneachelectricdevicefor
correctprotectionclass.ThelowestIPclassicationdecides
theoverallclassicationofthedevice.
•IPx4:Protectedagainstwatersplashedfromany
direction.
•IP24:Protectedagainstobjectslargerthan12.5mmand
protectedagainstwatersplashedfromanydirection.
•IP44:Protectedagainstobjectslargerthan1mmand
protectedagainstwatersplashedfromanydirection.
•IP41:Protectedagainstobjectslargerthan1mmand
protectedagainstverticallydrippingwater.
•IP67:Dust-tightandprotectedagainsttemporary
immersionintowater.
10.3Environmentalconditions
Storageand
transportationOperation
Temperature-30°Cto+50°C+5°Cto+40°C
Relativehumidity10%to70%20%to90%at30
°C,notcondensing
Atmospheric
pressure700hPato1060hPa
Allowtheproducttoreachoperationtemperature
beforeusage:
•Warmingupfromminimumstoragetemperature
mighttakeupto24hours.
•Coolingdownfrommaximumstorage
temperaturemighttakeupto24hours.
201586745-D
