Invacare 220 Operation manual

Owner’s Operator and Maintenance Manual
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
HMV™Highly
Maneuverable Vehicle
220

220 2Part No. 1125053
 WARNING
POWERED SCOOTER USERS: DO NOT SERVICE OR OPERATE
THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING THE OWNER’S OPERATOR AND
MAINTENANCE MANUAL. IF YOU ARE UNABLE TO
UNDERSTAND THE WARNINGS, CAUTIONS, AND
INSTRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT
BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS
EQUIPMENT - OTHERWISE INJURY OR DAMAGE MAY RESULT.
PROCEDURES OTHER THAN THOSE DESCRIBED IN THIS
MANUAL MUST BE PERFORMED BY A QUALIFIED TECHNICIAN.
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR
OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING (1 THE OWNER’S OPERATOR AND
MAINTENANCE MANUAL AND (2 THE SERVICE MANUAL (IF
APPLICABLE . IF YOU ARE UNABLE TO UNDERSTAND THE
WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT
INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO
SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE, INJURY
OR DAMAGE MAY RESULT.
NOTE: Updated versions of this manual are available on www.invacare.com.

TABLE OF CONTENTS
Part No. 1125053 3220
TABLE OF CONTENTS
REGISTER YOUR PRODUCT ............................................................... 6
SPECIAL NOTES ................................................................................ 9
TYPICAL PRODUCT PARAMETERS .................................................. 10
LABEL LOCATIONS ......................................................................... 11
SECTION 1—GENERAL GUIDELINES ................................................. 12
Repair or Service Information ...............................................................................................................12
Operation Information............................................................................................................................12
Electrical .....................................................................................................................................................14
Gro nding Instr ctions.......................................................................................................................14
Batteries......................................................................................................................................................15
Rain Test.....................................................................................................................................................15
Weight Training ........................................................................................................................................15
Weight Limitation.....................................................................................................................................15
SECTION 2—EMI INFORMATION ..................................................... 16
SECTION 3—SAFETY/HANDLING OF POWERED SCOOTERS ................ 18
Stability and Balance.................................................................................................................................18
Percentage of Weight Distrib tion ......................................................................................................18
Stairways.....................................................................................................................................................19
Escalators....................................................................................................................................................19
SECTION —SAFETY INSPECTION ................................................... 20
Safety Inspection Checklists...................................................................................................................20
Inspect/Adj st Initially .........................................................................................................................20
Inspect/Adj st Weekly........................................................................................................................21
Inspect/Adj st Monthly.......................................................................................................................21
Inspect/Adj st Periodically.................................................................................................................22
SECTION 5—MAINTENANCE AND TROUBLESHOOTING ................... 23
S ggested Maintenance Proced res .....................................................................................................23
Tro bleshooting........................................................................................................................................24
SECTION 6—OPERATION OF THE POWERED SCOOTER ..................... 25
Control Panel ............................................................................................................................................25
Operating the Scooter ............................................................................................................................26
Engaging/Disengaging the Brake Release Lever .................................................................................27
Resetting the Circ it Breaker................................................................................................................28
SECTION 7—SEAT AND ARMS ......................................................... 29

TABLE OF CONTENTS
Part No. 1125053 4220
TABLE OF CONTENTS
Removing/Installing/Adj sting the Padded Seat .................................................................................29
Removing ...............................................................................................................................................29
Installing/Adj sting Seat Height.........................................................................................................29
Folding/Unfolding the Back - Padded Seat Only................................................................................30
Folding ....................................................................................................................................................30
Unfolding................................................................................................................................................30
Removing/Installing the Del xe Seat....................................................................................................31
Removing ...............................................................................................................................................31
Installing..................................................................................................................................................31
Adj sting Seat Height - Del xe Seat Only..........................................................................................32
Adj sting 90° Seat Swivel - Del xe Seat Only..................................................................................32
Removing/Installing the Arms - Del xe Seat Only ...........................................................................33
Removing ...............................................................................................................................................33
Installing..................................................................................................................................................33
Replacing Armrest Pads - Del xe Seat Only......................................................................................34
SECTION 8—TILLER ADJUSTMENT ................................................... 35
Adj sting the Tiller Angle .......................................................................................................................35
SECTION 9—WHEELS AND CASTERS ................................................ 36
Removing/Installing the Drive Wheels ................................................................................................36
Removing ..............................................................................................................................................36
Installing..................................................................................................................................................36
Removing/Installing the Front Wheel ..................................................................................................37
Removing ...............................................................................................................................................37
Installing .................................................................................................................................................37
Removing/Installing the Fork..................................................................................................................38
Removing ...............................................................................................................................................38
Installing..................................................................................................................................................38
Removing/Installing the Caster Assemblies ........................................................................................39
Removing ...............................................................................................................................................39
Installing..................................................................................................................................................39
SECTION 10—BATTERIES ................................................................ 0
Recommended Battery Type .................................................................................................................40
Removing/Installing the Battery Box ....................................................................................................41
Removing ...............................................................................................................................................41
Installing..................................................................................................................................................41

TABLE OF CONTENTS
220 5Part No. 1125053
TABLE OF CONTENTS
Removing/Installing the Batteries..........................................................................................................42
Removing ...............................................................................................................................................42
Installing..................................................................................................................................................42
Charging the Batteries.............................................................................................................................43
SECTION 11—TRANSPORTING ........................................................ 5
Transporting the Scooter .......................................................................................................................45
Disassembling........................................................................................................................................45
Assembling.............................................................................................................................................45
SECTION 12—SCOOTER ACCESSORIES ............................................. 7
Installing/Removing the Cr tch/Cane Holder....................................................................................47
Installing..................................................................................................................................................47
Removing ...............................................................................................................................................47
Installing/Removing the Safety Flag .......................................................................................................48
Installing..................................................................................................................................................48
Removing ...............................................................................................................................................48
Installing/Removing/Using the Walker Holder .................................................................................49
Installing/Removing the Walker Holder .........................................................................................49
Using the Walker Holder...................................................................................................................49
Installing/Removing the Rear Mo nted Basket ..................................................................................50
Installing..................................................................................................................................................50
Removing ...............................................................................................................................................50
LIMITED WARRANTY ..................................................................... 51

REGISTER YOUR PRODUCT
220 6Part No. 1125053
REGISTER YOUR PRODUCT
The benefits of registering:
1. Safeg ard yo r investment.
2. Ens re long term maintenance and servicing of yo r p rchase.
3. Receive pdates with prod ct information, maintenance tips, and ind stry news.
4. Invacare can contact yo or yo r provider, if servicing is needed on yo r prod ct.
5. It will enable Invacare to improve prod ct designs based on yo r inp t and needs.
Register ONLINE at www.invacare.com
- or -
Complete and mail the form on the next page
Any registration information yo s bmit will be sed by Invacare Corporation only, and
protected as req ired by applicable laws and reg lations.

Name_______________________________________________________________
Address _____________________________________________________________
City ___________________State/Province __________
Zip/Postal Code ________
Email ___________________________________Phone No. _________________
Invacare Model No. ______________________Serial No. __________________
Purchased From _________________________Date of Purchase:___________
1. Method of purchase: (check all that apply)
❏ Medicare ❏ Insurance ❏Medicaid ❏ Other __________________________
2. This product was purchased for use by: (check one)
❏ Self ❏ Parent ❏ Spouse ❏ Other
3. Product was purchased for use at:
❏ Home ❏ Facility ❏ Other
4. I purchased an Invacare product because:
❏ Price ❏ Features (list features) _________________________________________
5. Who referred you to Invacare products? (check all that apply)
❏Doctor ❏ Therapist ❏ Friend ❏Relative ❏Dealer/Provider ❏Other_________
❏ Advertisement (circle one): TV, Radio, Magazine, Newspaper ❏ No Referral_____
6. What additional features, if any, would you like to see on this product?
__________________________________________________________________________
7. Would you like information sent to you about Invacare products that may be available for a
particular medical condition? ❏Yes ❏No
If yes, please list any condition(s) here and we will send you information by email and/or mail about
any available Invacare products that may help treat, care for or manage such condition(s):
__________________________________________________________________________
8. Would you like to receive updated information via email or regular mail about the Invacare
home medical products sold by Invacare's dealers? ❏Yes ❏No
9. What would you like to see on the Invacare website?
__________________________________________________________________________
10. Would you like to be part of future online surveys for Invacare products? ❏ Yes ❏ No
11. User's Year of birth: ______________________________________________________
If at any time you wish not to receive future mailings from us, please contact us at Invacare Corporation,
CRM Department, 39400 Taylor Parkway, Elyria, OH 44035, or fax to 877-619-7996 and we will remove
you from our mailing list.
To find more information about our products, visit www.invacare.com.
PRODUCT REGISTRATION FORM
Register ONLINE at www.invacare.com - or -
Complete and mail this form
Cut Along Line
Fold
here
Fold
here

Fold
here
Fold
here
Cut Along Line
Invacare Product Registration Form
Please Seal with
Tape Before Mailing

SPECIAL NOTES
Part No. 1125053 9220
SPECIAL NOTES
WARNING/CAUTION notices as used in this manual apply to hazards or unsafe
practices which could result in personal in ury or property damage.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO
CHANGE WITHOUT NOTICE.
As a manufacturer of owered scooters, Invacare endeavors to su ly a wide
variety of owered scooters to meet many needs of the end user. However, final
selection of the ty e of owered scooter to be used by an individual rests solely with
the user and his/her healthcare rofessional ca able of making such a selection.
TIE-DOWN RESTRAINTS AND SEAT RESTRAINTS
Powered scooter users should NOT be trans orted in vehicles of any kind while in
the owered scooter. As of this date, the De artment of Trans ortation has not
a roved any tie-down systems for trans ortation of a user while in a owered
scooter, in a moving vehicle of any ty e.
It is Invacare’s osition that users of owered scooters should be transferred into
a ro riate seating in vehicles for trans ortation and use be made of the restraints
made available by the auto industry. Invacare cannot and does not recommend any
owered scooter trans ortation systems.
SEAT POSITIONING STRAP
It is the obligation of the Dealers, Thera ists and other Healthcare Professionals to
determine if a seating ositioning stra is required to ensure the safe o eration of
this equi ment by the user. Serious injury can occur in the event of a fall from a
owered scooter.
 WARNING
The seat ositioning stra is a ositioning belt only. It is not designed for use as a
safety device withstanding high stress loads such as auto or aircraft safety belts. If
signs of wear a ear, belt MUST be re laced immediately.
Invacare roducts are s ecifically designed and manufactured for use in conjunction
with Invacare accessories. Accessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare roducts.

TYPICAL PRODUCT PARAMETERS
220 10 Part No. 1125053
TYPICAL PRODUCT PARAMETERS
220
OVERALL DIMENSIONS
BASE LENGTH:
BASE WIDTH:
STEP HEIGHT (Floor Pan to Ground):
SEAT HEIGHT (Floor Pan to Seat Cushion)
Delu e Seat:
Padded Seat:
39 inches
19.5 inches
3.25 inches
16-18 inches
15-17 inches
SEAT DIMENSIONS
WIDTH:
DEPTH:
BACK HEIGHT:
15 inches
15 inches
13 inches
ARM DIMENSIONS
LENGTH:
HEIGHT BETWEEN SEAT AND ARMS:
WIDTH BETWEEN ARMS:
11 inches
8 inches
16.75 inches
SPEED RANGE 0 - 4.1 m.p.h.
(Factory setting - 3.8 m.p.h.)
MAXIMUM INCLINE CAPABILITY 8° Grade
WHEELS
FRONT WHEEL:
DRIVE WHEEL:
8 inches 2 inches
8 inches 2 inches
TURNING RADIUS: 27 inches
WEIGHT OF PRODUCT
FRONT BASE SECTION:
REAR BASE SECTION:
PADDED SEAT:
DELUXE SEAT:
BATTERY BOX:
OFF BOARD CHARGER:
23 lbs
44 lbs
12 lbs
23 lbs
21 lbs
1 lbs
TOTAL WEIGHT OF PRODUCT
With Padded Seat:
With Delu e Seat:
100 lbs
111 lbs
MAXIMUM WEIGHT LIMITATION 220 lbs
