iRest A200-1 User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
A200-1 MASSAGE CHAIR

01
TABLE OF CONTENTS
Safety and Maintenance
Safety Warning
Name of Components
Function
Introduction to the Remote Controller
Method of Usage
I. Turn on the power supply of this product
II. Massage Function Control Operation
III. Voice Control Mode
IV. End massage
V. Operation Instructions for Bluetooth Speaker Play
Calf Installation Instruction 
VI. Instructionsforinstallationoflowerleg
 VII. Instructions for Removal and Use of Head Cushion and Backrest
VIII. Floor Protection
 IX. Instruction for Movement
Legal notices
Product Specification
02-03
04-07
08
09
10-11
12-30
12
12-30
31
32
32
33
34
34
35
35
36
36
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our company reserves the right to change and explain the design of the product.
If there is some difference between the product function in market circulation and the
description in the manual, it is a normal update of the product, and our company will
not inform you otherwise. The specific product function and color shall prevail in kind.

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product:
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.
No downward pressure
Safety Warning Safety Warning
Warning Warning
Warning Warning

0706
Before using the massage chair, remove any hard objects in your pocket(s) or any
jewelry carried with you (e.g. key, watch, other similar portable hard objects) to
avoid any damage to this product or physical injury during massage.
Do not unplug the power cord, or directly turn off the power switch on the back of
the massage chair during massage, in order to avoid any damage to this product or
physical injury.
Please do not fall asleep on the massage chair while using to avoid personal injury
caused by unconscious use.
Safety Warning Safety Warning
Warning Warning
Warning
Warning
The massage chair should not be used by more than one person at a time to avoid
product failure or personal injury. In addition, do not let children play on the massage
chair or climb onto the lower leg, seat cushion, foot, backrest or armrest. Otherwise,
accidents or injuries may be caused.

08 09
16 17
1
2
3
4
7
8
9
6
11
5
12
13
14
15
10
Name of Components Function
1.Head cushion
2.3D digital audio (built-in
voice control microphone)
3.Shoulder air pressure
4.Arm airbag component
5.Controller
6.Controller placement slot
7.Lower leg frame
8.Backrest cushion
9.Armrest
10.Armrest decoration
11.Side cover
12.Backrest cover
13.Rear cover of power box
14.Movable pulley
15.Power cord and plug
16.Mains input
17.Switch
·This product has designed a group of AI intelligent core massage manipulators that can
walk up and down, stretch back and forth, and are silent in design.
·It is designed with the function of automatic detection and micro-adjustment of shoulder
position and the automatic detection function of human body curve and massage finger
pressing point to automatically adjust the stretch back and forth of the manipulator
according to the detected human body curve and massage finger pressing point, making
massage more humanized and scientific.
·With characteristic automatic massage function: Comfort massage, Relax massage,
Stretch Massage, Neck&shoulder Massage, Back&Waist Massage, Full body Massage,
Ancient Beauty Care, Leg&hip Care, Sedentary Release, Spine Care, President Cosy,
Relieve Soreness, Good-night Sleep,Sport Recovery, and Meridian Treatment 15 kinds of
automatic massage functions.
·It has three intelligent storage functions: storage I, storage II and storage III.
·It is provided with five message scopes for manual selection, i.e. fixed point, upper back,
lower back, local and whole body.
·sevenIt is provided with manual massage function: including massage methods such as
stopping, kneading, slapping, kneading and slapping, finger pressing, tapping and 3D (3D
I and 3D II).
·It is provided with massage adjustment function: including 3D intensity 3-gear adjustment,
air compression intensity 3-gear adjustment and time adjustment 4-gear adjustment.
·It is provided with an upper body air compression massage function: palm air
compression massage function (built-in 4 airbags), shoulder air compression massage
function (built-in 2 airbags), arm air compression massage function (built-in 4 airbags),
and 3-gear air compression intensity adjustment.
·It is provided with a lower body air compression massage function: lower leg air
compression massage function (built-in 12 airbags) and 3-gear air compression intensity
adjustment.
·Slide rail technology is adopted for lying down of the backrest frame to make the backrest
8cm from the wall, thus saving space to the greatest extent.
·The guide rail of the backrest frame adopts curved guide rail technology, which
completely conforms to the back of the human body and makes people enjoy a massage
from the head to the thigh.
·It is provided with an intelligent voice control recognition function.
·Music playing system, with built-in 3D digital audio in the left and right upper arms. The
Bluetooth function of intelligent devices can be used for wireless connection to play
music.
·It is provided with leg traction massage function: the lower leg and backrest are lifted to
form automatic lying down in a cyclic manner. At the same time, the lower leg air
compression and the back manipulators cooperate together to massage, and the legs can
be stretched for traction massage.
·It is provided with a separate lifting adjustment function for the lower leg frame, linkage
lifting adjustment function for the backrest frame, and zero-gravity automatic lying angle
adjustment function.
·It is provided with a foot and sole roller massage function. Three groups of rollers roll to
scrape and massage toes and roots of feet, and roll to scrape and massage the arch of
feet. The speed is adjustable in three gears.
·The lower leg frame is provided with a spring retractable adjustment function. The length
for the user to stretch out his/her feet is dependent on his/her feet, and the user stretches
back his/her feet by spring force.
·With bumps and magnet therapy massage functions in palm massage area
·Automatic sit-up function when the power is off and manipulator automatic reset function.
·With back heating and leg heating functions: Heat use far infrared heat source.
·Equipped with TFT color screen manual controller.

1110
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
Introduction to the Remote Controller Introduction to the Remote Controller
Display screen section of manual controller 1.Display screen:
·TFT color liquid crystal display screen displays the massage function in the
running state.
2.On/off key:
·Turn on or off the massage chair.
3.Automatic key:
·Enter the automatic function mode selection interface. Please refer to page 15 of
this manual for detailed function description.
4.Zero-gravity key:
·Adjust the zero-gravity angle of the massage chair, and there are four modes for
selection (pressing for the first time enters the first gear, pressing for the second
time enters the second gear, pressing for the third time enters the third gear, and
pressing for the fourth time restores to the initial state).
5.Up key:
·Navigate the Up key, select the object upward in the menu, or adjust the massage
position upward.
6.OK key:
·Confirm the selected massage function to perform confirmed massage.
7.Left key:
·Navigate the Left key, return to the previous menu, or select the object to the left.
8.Down key:
·Navigate the Down key, select the object downward in the menu, or adjust the
massage position downward.
9.Lower leg frame ascending key:
·According to the user’s own massage requirement, the lower leg frame is
ascended to the most comfortable massage posture.
10.Lower leg frame descending key:
·According to the user’s own massage requirement, the lower leg frame is
descended to the most comfortable massage posture.
11.Pause key:
·Pause all currently running massage functions, and press this key again to
continue running all massage functions before the pause.
12.Menu key
·Enter the main menu selection interface. Please refer to page 15 of this manual
for detailed function descriptions
13.Right key
·Navigate the Right key to enter the sub-menu, or select the object to the right.
14.Linkage sit-up key:
·According to the desired massage angle, the backrest frame and the lower leg
frame are adjusted for linkage sit-up at the same time to the most comfortable
linkage sit-up massage posture.
15.Linkage lying key
·According to the desired massage angle, the backrest frame and the lower leg
frame are adjusted for linkage lying at the same time to the most comfortable
linkage lying massage posture.

1312
·After detecting the shoulder position, the buzzer prompts with a "beep." If there is
any difference from the actual shoulder position, adjust to the appropriate position
by pressing "Up" or "Down." Shoulder position is adjustable in 11 gears. If there is
no shoulder position adjustment within 10 seconds, it will automatically enter the
massage function. If you press the "OK” key directly, you will enter the massage
immediately. If the shoulder position cannot be detected, massage is performed at
the default shoulder position height.
1).Shoulder position adjustment
1.Standby
·When the massage chair power cord connected, and the chair in standby state,
you can turn on the chair by power on/off key, rise up and lying down the chair, and
use the voice control wake up key.
2.Start massage (on/off key)
·Press the on/off key to start the massage, and the backrest frame and lower leg
frame will automatically lie down to the set angle.
·After lying in place automatically, the massage chair automatically detects the
shoulder position and body shape waiting for the detection to be completed. Or
press the "OK" key to directly skip the shoulder position and body shape detection,
then turn on the default value to start massage.
·After entering the massage program, if it is necessary to adjust the shoulder, from
the operation status information interface, you can directly select the shoulder
adjustment button to enter the whole shoulder adjustment interface, and adjust the
shoulder position and height through the "Up" or "Down" key; press the "Left" key
to return to the previous menu interface.
Method of UsageMethod of Usage
I. Turn on the power supply of this product:
Plugging-in diagram Product connection
diagram
Power switch diagram
of the product
II. Massage Function Control Operation:
Button Description
Move the massage balls upward to a suitable shoulder position
Move the massage balls downward to a suitable shoulder position
OK
Auto lying down......
Attention, please! Make sure there is no body
Body detection
Please wait...
“OK” to skip
16:00
Comfort massage
Roll Str Air Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK
20:00
Shoulder Adj
Please use “up” or “down” key to select and press OK
06
Shoulder Adj
Please use “up” or “down” key to select and press OK
20:00
06
·High shoulder position
·Suitable shoulder position
·Low shoulder position

1514
2).Massage position adjustment
·After entering the massage program, if it is necessary to adjust the massage position,
press the "Menu" key on the manual controller to select the manual program to enter,
select the manual program, and then press the "Left" key to return to the information
interface (the information interface is changed to the manual program interface).
·From the manual program interface, if the massage position displays fixed points or
local, you can directly press the "Up" or "Down" key to move the manipulator up and
down.
·From the manual program interface, if the massage position is not fixed point or local,
you need to select massage adjustment to enter, then select the massage part, select
fixed point or local, then press the "Left" key to return to the information interface, and
then press the "Up" or "Down" key to move and adjust the manipulator up and down.
Method of UsageMethod of Usage
Note: In auto mode, the manipulator cannot be moved up and down through the "up
key" or "down key".
3.Pause key
·When the massage function is running, press the "Pause" key to temporarily stop
all massage functions; press the "Pause" key again to continue the massage
function before the pause. If the pause lasts for more than 20 minutes, all massage
functions will be automatically turned off.
4.Menu key
1).Automatic program (menu - automatic program, or you can also enter the
automatic program interface through the "Automatic" key)
·Press the "Menu" key to enter the menu massage function selection interface,
including automatic program, manual program, air compression massage, auxiliary
function, memory storage, setting function, etc.
·After entering the menu interface, press the "Up" or "Down" key to select the
desired massage function, select any function, and then press the "OK" key to
confirm. Press the "Left" key to return to the previous menu interface.
·Press the "Menu" key to enter the menu interface, press the "Up" or "Down" key to
select the automatic function, and press the "OK" key (or directly press the "Automatic"
key in the information interface) to enter the selection of the automatic function.
·Automatic functions include 15 automatic massage modes, i.e. Comfort massage, Relax
massage, Stretch Massage, Neck&shoulder Massage, Back&Waist Massage, Full body
Massage, Ancient Beauty Care, Leg&hip Care, Sedentary Release, Spine Care,
President Cosy, Relieve Soreness, Good-night Sleep,Sport Recovery, and Meridian
Treatment.
·Enter the automatic function interface, press the "Up" or "Down" key to select any
automatic function massage program, and then press the "OK" key to confirm. It will
automatically return to the information interface, and the information interface will be
displayed as an information interface with automatic functions.
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
暂停中
再次点击暂停按键
恢复使⽤
Pause!
Click pause button
to restore use
Manual Mode
Wise
Area
Width
Speed
Spot
Partial
Upper
Lower
Full
Please use “navigation” key to select and press OK
16:00
16:00
Comfort massage
Roll Str Air Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
16:00
Auto Mode
Comfort Massage
Relax Massage
Stretch Massage
Neck&shoulder Massage
Back&Waist Massage
Full body Massage
Please use “up” or “down” key to select and press OK
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK

1716
Method of UsageMethod of Usage
Function Description
The most comfortable massage experience.
Gentle and comfortable deep massage, which can relieve body
fatigue and relax the body.
According to the unique neck and shoulder massage method,
through effective massage of cervical spine and scapula, neck and
shoulder pain can be relieved and neck and shoulder fatigue can be
improved.
Focus on the back and waist to relieve back and waist soreness.
The lower leg frame and the backrest frame are lifted and lowered
for stretching and traction of the leg and waist, effectively relieving
tiredness, relieving joint soreness and restoring vitality.
Deep massage, which can revive body vitality.
Massage manipulator combine with shoulder airbags, kneading
massage focus on neck and shoulder, kneading and tapping
massage on back and waist, kneading massage on buttocks,
kneading and tapping massage on laps, foot rollers, legs airbags
and arm airbags massage started at same time.
Ancient
Beauty
Care
The foot roller function started, air bags inflate and deflate, and the
massage manipulator move from legs to buttock with kneading and
flapping massage technique.
Leg&
hip Care
Aim to office sedentary group, increase the amount of physical
exercise by massage, improve the body function.
Sedentary
Release
Protect the health of the whole spine, and improve the lack of
exercise.
Spine
Care
The massage manipulator, combine with airbags, rollers and the
music played by bluetooth connecting, relax the physical and mental
pressure of business groups.
President
Cosy
Relieve
Soreness
Soothe fatigue and pain on the human body, relax the limbs
and improve micro-circulation, relieve joint pain and restore
vitality.
Good-night
Sleep
Sport
Recovery
By pressing and rubbing with the air bag and rolling with the
wheel, it can relieve the swelling of the shoulders, arms,
knees, calves and other key parts after exercise, and quickly
recover the fatigue after exercise.
Meridian
Treatment
Dredge the channels and collaterals, quickly improve the
body's micro-circulation, and enhance immunity.
2).Manual program (menu - manual program)
·Press the “Menu” key to enter the menu interface, press the “Up” or “Down” key to
select the manual program, and press the "OK" key to enter the manual function
interface.
·Manual program: including method, position, width, speed and other massage
functions.
·After entering the manual program interface, press the “Up” or “Down” key to select
any manual program, then select the function sub-menu using the “Right” key, and
then press the "OK" key to confirm. Press the "Left" key to return to the previous
menu interface.
With kneading, shiatsu massage techniques, combined with
low-intensity air pressure massage and function, through the
12 health acupoints massage, help to regulate and balance on
human body;At the same time, the massage chair
automatically swings back and forth to form a zero-gravity cradle
massage state, so that people can fall
asleep more quickly, improve sleep quality.
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Manual Mode
Wise
Area
Width
Speed
OFF
Knead
Tap
Knead&Tap
Shiatsu
Knock
Please use “navigation” key to select and press OK
16:00

1918
Method of UsageMethod of Usage
Function Massage ball adjustment
OFF
Knead
Tap
Knead&Tap
Shiatsu
Knock
3DⅠ
3DⅡ
Width.
Speed.
Speed and width.
Speed
Width.
Speed and width.
Speed.
Speed and width.
Adjustable speed in
three gears
Adjustable width in
three gears
02).Manual program - position
·Position: including fixed point, local, upper body, lower body and whole body.
·After entering the manual program interface, press the "Up" or "Down" key to select
the massage position function, enter the massage position function sub-menu using
the "Right" key to select, then press the "Up" or "Down" key to select any massage
position, and press the "OK" key to confirm; press the "Left" key to return to the
previous menu interface.
Function Description
Spot
Partial
Upper
Lower
Full
Fixed-point massage at
fixed-point position.
Small-scope local massage
back and forth.
Upper back massage back and forth.
Lower back massage back and forth.
Full back massage back and forth.
When selecting fixed-point and local
massage methods, the massage
area can be adjusted using the "Up"
or "Down" key in the information
interface.
01).Manual program - method
·Method: including 7 different massage methods such as kneading, tapping,
kneading and Tapping, shiatsu, knocking and 3D (3DⅠ and 3DⅡ). The width of the
manipulator massage ball can be adjusted under the massage methods including
tapping, shiatsu, knocking and 3D Ⅱ. Except for stopping, the massage speed can
be adjusted under other massage methods.
·After entering the manual program interface, press the "Up" or "Down" key to select
the massage method function, enter the massage method sub-menu using the
"Right" key to select, then press the "Up" or "Down" key to select any massage
method, and press the "OK" key to confirm; press the "Left" key to return to the
previous menu interface. 16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Manual Mode
Wise
Area
Width
Speed
Spot
Partial
Upper
Lower
Full
Please use “navigation” key to select and press OK
16:00 Manual Mode
Wise
Area
Width
Speed
Spot
Partial
Upper
Lower
Full
Please use “navigation” key to select and press OK
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Manual Mode
Wise
Area
Width
Speed
OFF
Knead
Tap
Knead&Tap
Shiatsu
Knock
Please use “navigation” key to select and press OK
16:00 Manual Mode
Wise
Area
Width
Speed
OFF
Knead
Tap
Knead&Tap
Shiatsu
Knock
Please use “navigation” key to select and press OK
16:00

2120
Method of UsageMethod of Usage
04).Manual program - speed
·Speed: Manipulator massage speed adjustment, with a total of 3 gears.
·Enter the manual program interface, press the "Up" or "Down" key to select the
speed, enter the speed function sub-menu using the "Right" key to select, then press
the "Up” or "Down" key to select any massage speed, and press the "OK" key to
confirm. Press the "Left" key to return to the previous menu interface.
Note:
Width: the width can be adjusted under the massage methods including slapping,
finger pressing , tapping and 3D II, with a total of 3 gears.
3).Air compression massage (menu - air compression massage)
·Press the "Menu" key to enter the menu interface, press the "Up" or "Down" key to
select air compression massage, and press the "OK" key to enter the air
compression massage interface.
·Air compression massage: including upper body air compression, lower body air
compression, air compression intensity and other massage functions.
·After entering the air compression massage interface, press the "Up" or "Down"
key to select any air compression function, then select the sub-menu of this
function using the "Right" key, and then press the "OK" key to confirm. Press the
"Left" key to return to the previous menu interface.
01).Air compression massage - upper body air compression
·Upper body air compression: including plam air pressure, arm air pressure,
shoulder air pressure, and other air compression massage functions.
·Enter the air compression massage interface, press the "Up" or "Down" key to
select the upper body air compression massage function, enter the upper body air
compression sub-menu using the "Right" key to select, then press the "Up” or
"Down" key to select to turn on or off the upper body air compression function, and
press the "OK" key to confirm. Press the "Left" key to return to the previous menu
interface.
·Width: Manipulator massage width adjustment, with a total of 3 gears.
·Enter the manual program interface, press the "Up" or "Down" key to select the width
function, enter the width function sub-menu using the "Right" key to select, then
press "Up" key or "Down" key to select any massage width, and press the "OK" key
to confirm; press the "Left" key to return to the previous menu interface.
03).Manual program - width
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Air Massage
Up Body
Low Body
Air Str
OFF
ON
Please use “navigation” key to select and press OK
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Air Massage
Up Body
Low Body
Air Str
OFF
ON
Please use “navigation” key to select and press OK
16:00
3
2
1
Manual Mode
Wise
Area
Width
Speed
Please use “navigation” key to select and press OK
16:00
3
2
1
Manual Mode
Wise
Area
Width
Speed
Please use “navigation” key to select and press OK
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Manual Mode
Wise
Area
Width
Speed
Narrow
Middle
Wide
Please use “navigation” key to select and press OK
16:00 Manual Mode
Wise
Area
Width
Speed
Narrow
Middle
Wide
Please use “navigation” key to select and press OK
16:00
16:00
Comfort Massage
Roll speed Air power
Adjustment Shoulder
Select the object with“left” or “right” key and press OK

22
Method of UsageMethod of Usage
·Air compression intensity: the intensity can be adjusted in three gears.
·Enter the air compression massage interface, press the "Up" or "Down" key to
select the air compression intensity, enter the air compression intensity sub-menu
using the "Right" key to select, then press the "Up” or "Down" key to select any air
compression intensity gear, and press the "OK" key to confirm. Press the "Left" key
to return to the previous menu interface.
03).Air compression massage - air compression intensity
02).Air compression massage - lower body air compression
·Lower body air compression: including leg air compression, foot air compression
and other air compression massage functions.
·Enter the air compression massage interface, press the "Up" or "Down" key to
select the air compression intensity, enter the air compression intensity sub-menu
using the "Right" key to select, then press the "Up” or "Down" key to select any air
compression intensity gear, and press the "OK" key to confirm. Press the "Left" key
to return to the previous menu interface.
23
4).Other function (menu - other function)
01).Other function-foot roller function
·Press the "Menu" key to enter the menu interface, press the "Up" or "Down" key to
select other functions, and press the "OK" key to enter the other function interface.
·Other functions: Include , back heating and calfrest heating.Foot roller
·Enter the other function interface, press the "Up" or "Down" key to select one type
function , enter the other function sub-menu using the "Right" key to select, then
press the "OK" key to confirm. Press the "Left" key to return to the previous menu
interface.
·Foot roller: with four modes: OFF/Gear 1/Gear 2/Gear 3, The default mode is Gear 2.
·After entering the interface of other functions, press "up" or "down" to select the
foot roller massage function, enter the sub-menu of the foot roller by "right " to
select, and then press "up" or "down" to select any type of roller strength and
switch, and press "OK" to confirm. Press the "left " to return to the menu interface
of the previous level.
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
1
2
3
Air Massage
Please use “navigation” key to select and press OK
Up Body
Low Body
Air Str
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
1
2
3
Please use “navigation” key to select and press OK
Other Func
Roll OFF
16:00
BackHeat
LegHeat
Air Massage
Please use “navigation” key to select and press OK
OFF
ON
Up Body
Low Body
Air Str
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
16:00
Menu
Auto Mode
Manual Mode
Air Massage
Other Func
Customise
Setting
Please use “up” or “down” key to select and press OK
1
2
3
Please use “navigation” key to select and press OK
Other Func
Roll OFF
16:00
BackHeat
LegHeat
16:00
Comfort massage
Roll Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK
Air Str
16:00
Comfort massage
Roll Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK
Air Str
16:00
Comfort massage
Roll Str Air Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK

2524
Method of UsageMethod of Usage
5).Memory storage (menu - memory storage)
·Press the "Menu" key to enter the menu interface, press the "Up" or "Down" key to
select the memory storage function, and press the "OK" key to enter the memory
storage interface, including storage functions such as storage call and storage
save.
·Memory storage includes three functions: storage 1, storage 2 and storage 3.
·After entering the memory storage interface, press the "Up” or "Down" key to
select any of storage 1, storage 2 and storage 3, enter the storage or call sub-
menu using the "Right" key, then press the "Up” or "Down" key to select, and press
the "OK" key to confirm. Press the "Left" key to return to the previous menu
interface.
·Storage: Storing the currently running massage program, including massage
method, air compression mode and intensity, position and angle of lower leg frame
and backrest frame, and other massage functions.
·Call: Calling the previously saved massage program, including massage mode,
massage method, air compression mode and strength, position and angle of lower
leg frame and backrest frame, and other massage functions.
03).Other function--calfrest heating function
·Calfrest heating function: You will feel warm after start heating function 3 mins.
·When you enter the auxiliary function interface, press "upper" or "lower" button to
choose the calfrest heating function. Through "right" button enter to the submenue,
then choose "upper" or "lower" button to turn on or off, press "ok" to confirm. Press
"left" button to back to the previous menue.
02).Other function--back heating function
·Back heating function: You will feel warm after start heating function 3 mins.
·When you enter the auxiliary function interface, press "upper" or "lower"
button to choose the back heating function. Through "right" button enter to
the submenue, then choose "upper" or "lower" button to turn on or off, press
"ok" to confirm. Press "left" button to back to the previous menue.
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Other Func
Please use “navigation” key to select and press OK
OFF
ON
16:00
Roll
BackHeat
LegHeat
16:00
Comfort massage
Roll Str Air Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Other Func
Please use “navigation” key to select and press OK
Roll
BackHeat
LegHeat
OFF
ON
16:00
16:00
Comfort massage
Roll Str Air Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK
23
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Customise
Save 1
Save 2
Save 3
Please use “navigation” key to select and press OK
Save
Use
16:00

2726
Method of UsageMethod of Usage
01).Setting function - Bluetooth
·Bluetooth: Turn on the Bluetooth function of the massage chair to connect the
sound source device with Bluetooth function (such as mobile phone, MID tablet,
etc.). After pairing and connecting with the Bluetooth module of the massage chair,
the music played by the sound source device can be wirelessly transmitted to the
sound system of the massage chair through Bluetooth for music playing.
·After entering the setting function interface, press the "Up" or "Down" key to select
the Bluetooth function, enter the Bluetooth function sub-menu using the "Right" key
to select, then press the "Up" or "Down" key to select to turn on or off the Bluetooth
function, and press the "OK" key to confirm; press the “Left” key to return to the
previous menu interface.
02).Setting function - voice control
·Voice control: intelligent voice control function (this function has memory, i.e. if
selected, it is still the function selected when the product is restart after power
failure); Note: When the intelligent voice control is turned off, voice wake-up cannot
be performed.
·After entering the setting function interface, press the "Up" or "Down" key to select
the voice control function, enter the voice control function sub-menu using the
"Right" key to select, then press the "Up" or "Down" key to select to turn on or off
the voice control function, and press the "OK" key to confirm; press the “Left” key
to return to the previous menu interface.
6).Setting function (menu - setting function)
·Press the "Menu" key to enter the menu interface, press the "Up" or "Down" key to
select the setting function, and press the "OK" key to enter the setting function
interface.
·Setting functions: including Bluetooth, voice control, language, serial number and
other setting functions.
·After entering the setting function interface, press the "Up" or "Down" key to select
any setting function, then select the sub-menu of this function using the "Right"
key, and then press the "OK" key to confirm. Press the "Left" key to return to the
previous menu interface.
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
OFF
ON
16:00
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
16:00
OFF
ON
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
16:00
OFF
ON
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
OFF
ON
16:00
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
OFF
ON
16:0016:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK

Function Description
·Depending on the remaining massage time, when the displayed time is not
enough to add or subtract a certain time, the operation will not be displayed (the
upper limit of time display is 40 minutes). For example, if the displayed time of the
manual controller is 39 minutes, the adjustment range of massage time is -5
minutes or -10 minutes (+10 minutes and +5 minutes cannot be displayed).
·Among them, the adjustment of air compression intensity can only be used when
the air compression function or the automatic function is turned on (please refer to
page 21 of this manual for details on the mode for turning on the air compression
function).
3D Str
Time Adj
Neck, back, waist, hip massage intensity adjustment, with a total of
3 gears.
The strength can be adjusted in 3 gears.
4 modes are available, i.e. +10 minutes, +5 minutes,-5 minutes
and -10 minutes.
Note:
04).Setting function - serial number
·Serial number: displaying current device information
·After entering the setting function interface, press the "Up" or "Down" key to select
the serial number, and press the "Left" key to return to the previous menu interface.
7).Massage adjustment
·In the information interface, press the "Left" or "Right" key to select the massage
adjustment button, and press the "OK" key to enter the massage adjustment
interface.
·Massage adjustment includes three massage adjustment functions for selection,
i.e. 3D intensity, air compression intensity and time adjustment.
·After entering the massage adjustment interface, press the "Up" or "Down" key to
select any massage adjustment function, then enter the massage adjustment sub-
menu using the "Right" key to select, then press the "Up" or "Down" key to select
the desired massage adjustment gear, and press the "OK" key to confirm. Press
the "Left" key to return to the previous menu interface.
2928
Method of UsageMethod of Usage
Air Str
03).Setting function - language
·Language: including Simplified Chinese and English.
·After entering the setting function interface, press the "Up" or "Down" key to select
the language function, enter the language function sub-menu using the "Right" key
to select, then press the "Up" or "Down" key to select any language function, and
then press the "OK" key to confirm; press the “Left” key to return to the previous
menu interface.
2
1
3
Massage Adj
Please use “navigation” key to select and press OK
3D Str
Air Str
Time Adj
00000000000
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
16:00
Comfort massage
Roll Str Air Str
Shoulder Adj
Select the object with“left” or “right” key and press OK
Massage Adj
中⽂
English
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
16:00
16:00
Menu
Auto Mode
Manual Mode
Air Massage
OtherFunc
Customise
Setting
Please use “up” or “down” key to select and press OK
中⽂
English
Setting
Please use “navigation” key to select and press OK
Bluetooth
Voice
Language
SN:
16:00

3130
Method of UsageMethod of Usage
6.Lying angle adjustment key
Function Description
Lower leg frame ascending key: press and hold this key to slowly rise
the lower leg frame, and release it to stop rising.
Lower leg frame descending key: press and hold this key to slowly
lower the lower leg frame, and release it to stop lowering.
Linkage sit-up key: press and hold this key to slowly rise the backrest
frame while slowly lowering the lower leg frame, and release it to stop
rising of the backrest frame or lowering of the lower leg frame.
Linkage lying key: press and hold this key to slowly lower the backrest
frame while slowly rising the lower leg frame, and release it to stop
lowering of the backrest frame or rising of the lower leg frame.
III. Voice Control Mode
·When the massage chair is turned on or in standby mode, the sound "Hi Alice" or
"Hey Alice"will be produced to enable the voice control function.
·After such function is enabled successfully, the massage chair will reply "I am here."
At this moment, once a corresponding voice control entry to be implemented is
given within six seconds, the corresponding voice control function can be performed
after a reply is received from the massage chair; if no correct voice control entry is
given within six seconds, the voice control function automatically will be off
automatically and needs to be enabled again.
·Note: When waking up the voice control function, please use English, the speech
rate is moderate, Voice commands should be follow up the Voice entry.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No.
Voice control entry
Massage on
Massage close
Comfort massage
Relax massage
Full body massage
Neck and shoulder massage
Back and waist massage
Stretch massage
Fixed massage
Change the other mode
Go little down
Go little up
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Stop adjustment
Answer entry
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok, full body massage
Answer: Ok, neck and shoulder massage
Answer: Ok, back and waist massage
Answer: Ok, stretch massage
Answer: ok,fixed massage
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Answer: OK, Open the air pressure
Answer: OK, , Close the air pressure
Answer: Ok, Up the seat position
Answer: Ok, Down the seat position
Answer: Ok, stop adjustment
Voice Control Entry
Entry: “Hi Alice” or “Hey Alice”. Answer: I am here.
16
17
5.Zero-gravity key
·Zero-gravity key: each time the key is pressed, the position of the lower leg frame and
backrest frame will be automatically adjusted to the zero-gravity position, with a total
of three zero-gravity lying modes in cyclic switching.
Function Description
Zero-gravity key: each time the key is pressed, the position of the lower
leg frame and backrest frame will be automatically adjusted to the
zero-gravity position, with a total of three zero-gravity lying modes in
cyclic switching.
16:00
Comfort massage
Roll Str Air Str
Massage Adj Shoulder Adj
Select the object with“left” or “right” key and press OK

3332
Method of UsageMethod of Usage
·During the massage process, press the power on/off key to immediately turn off all
massage functions, reset the backrest frame and the lower leg frame, or when the
massage timing time arrives, all massage functions will be automatically turned off,
with the backrest frame and the lower leg frame not reset.
IV.End massage
·Shut off the power supply of this product, as shown in the attached figure (Power
Shut-off Diagram of the Product).
Power Shut-off Diagram of the Product
Disconnection Diagram
Unplugging Diagram
1.Enter the smart device main menu. Open "Settings" and select the "Bluetooth"
option. Open "Bluetooth", and Bluetooth will automatically "Search for a New
Bluetooth Device".
2.The smart device will search for the corresponding Bluetooth model (e.g. IMCM-
XXXX). Click the "Match" button. If you are asked whether to match with the
device, you just select "Match" to complete matching.
3.Turn on "Music Player" in the smart device and select the song to play.
V.Operation Instructions for Bluetooth Speaker Play
1.After connecting the lower leg and the air tube on the massage chair with the wire
harness, untie the fixed pipeline belt and insert the connecting part into the seat
frame (Fig. 1).
2.Sleeve the lower leg fixing block on the round tubes on the left and right sides of
the lower leg (Fig. 2).
1 2
3.Hang the lower leg sleeved with the fixing block on the hook of the massage chair
seat frame (Fig. 3).
4.Fasten the lower leg on the massage chair with 4 M4 screws (2 on the left and 2
on the right). Check whether there is any abnormality in the up-and-down turning
and whether the pipeline is folded. Then the lower leg installation is completed
(Fig. 4).
3 4
Massage chair reset... Please wait for the
massage chair to stop.around the massage chair.

3534
Method of Usage
Warning : The rear moving wheels of the massage chair are only suitable for short-
distance and slow movement. For long-distance transportation, please use other
auxiliary moving tools to move this massage chair!
·Make sure that all the wires are pulled away from the massage chair surface; then
press the backrest down to a certain angle (with the center of gravity resting on
the wheels), you can push the massage chair forward with hands, move it to a
suitable position and gently restore it to the normal angle. (Note: During
movement, you must turn off the power button first and then unplug the power
cord and the remote controller connection wire.)
IX. Instruction for movement
Method of Usage
12
VII. Instructions for Removal and Use of Head Cushion and Backrest
·The use of the head cushion can reduce the intensity of kneading massage on the
neck and shoulders. You can decide whether to use the head cushion according
to your own needs (the head cushion is recommended). The backrest and the
back cushion are connected by a zipper (1). The head cushion and the backrest
are connected by a (2).Zipper
VIII. Floor Protection
·The prolonged heavy pressure on the massage chair may cause scratches on the
floor. Thus, put a carpet or cushion on the floor where the massage chair is placed
to avoid this damage.
Note: Do not move the massage chair with its wheels on the rough ground or in a
narrow space. At least two persons are required to lift it. During lifting, take the
legrest sealing plate and backrest cover grooves as the acting points. (Do not lift the
armrest directly.)
Zipper Zipper

36
Material description: PVC, PA, steel parts, electric and electron components
MATERIAL PU LEATHER CLOTH WOOD
Product Specification
Model: SL-A200-1
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power:90W
Rated time: 20min
Safety structure: Class I
Legal notices
FCC Information
·Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
·This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
·This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
–This equipment should be installed and operated with minimum distance 20cm between
the radiator&your body.
