iRest SL-A08-1 User manual

SAVE THESE INSTRUCTIONS
SL-A08-1 massage chair
Operation Instructions

01
02
04
05
16
16
Thanks for purchasing this product. Please read this manual instruction
carefully in order to know how to use this product correctly before operation.
Please pay more attention to some important safety warning and keep this
manual book properly for future use.
Note: Our Company reserves the right to revise the design and description
of this product without any further notice. Please refer to the actual color of
this product.
Safety and maintenance
Name and function of components
Function & Efficacy
Method of usage
Product specification
CONTENTS

0302
1. IMPORTANT SAFETY WARNING.
·Don’t allow children to touch moveable part of this product.
·Please use well-grounding power supply suited to this product.
·Please pull out the plug after use or before cleaning to
avoid injury or damage to the product.
·Please operate this product according to this manual instruction.
·Don’t use accessories which are not recommended.
·Don’t use this product outdoors.
·Please read this manual instruction carefully before operation.
·Any other usage that is not listed in this manual instruction is
forbidden.
·15 minutes of usage each time is recommended.
·Please don’t use it if the leather is broken or damaged.
·Please don’t use it if the cover or leather is damaged.
·Please don’t use it if the radiator hole is covered or blocked.
·Please don’t drop anything into this product.
·Please don’t fall asleep while using this product.
·Please don’t use it if drunk or feel unwell.
·Please don’t use it within one hour after having meal.
·Please don’t make the massage function too strong for
avoiding injury.
2. Environment for usage.
·Please don’t use it under high temperature and moist environment such as
bathroom.
·Please don’t use it immediately while the environmental temperature
changes sharply.
·Please don’t use it under heavy-dusty or caustic environment.
·Please don’t use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
·People who are suffering from osteoporosis are not suitable to use this product.
·People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
·People who are suffering from fever are not suitable to use this product.
·Pregnant women or women that are in menses period are not suitable to use
this product.
·People who got injured or skin disease are not suitable to use this product.
·Children under twelve or people who are not able to operate this product are
not suitable to use this product.
·People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
·People whose bodies are wet are forbidden to use this product.
·People who is sensitive to heat.
4. Safety.
·Check the voltage if it is suitable to the specification of this product.
·Don’t use wet hand to pull the plug.
·Don’t make water go inside this product to avoid electric shock or cause
damage to this product.
·Don’t damage the wires or change the circuit of this product.
·Don’t use wet cloth to clean the electric parts such as switch and plug.
·Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
·Stop using this product while it works abnormal, and please consult local agent
immediately.
·Stop using this product if you feel unwell, and please consult health care
doctor.
5. Maintenance.
·This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
·Please don’t forget to cut the power after usage.
·Don’t use this product if the socket looses.
·If this product will be left unused for long, please curl up the wires and reserve
this product in dry and dustless environment.
·Don’t reserve this product under high temperature or near fire and avoid
longtime direct sunshine.
·Please clean this product by dry cloth. Don’t use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and
made, it is not necessary to be specially maintained.
·Don’t use edged res to thrust this product.
·Don’t roll or pull this product above uneven ground, it should be lifted before
moving.
·Please use it intermittently; don’t make this product work continuously for long.
6. Solution of ordinary malfunctions.
·It is nature movement voice if the motor sounds while in usage.
·If the controller can’t work normally, please check the plug and socket if they
are connected strongly and make sure the switch is turned on.
·If the rated working time is over, the product will automatically activate the
power-off button; If this product works continuously for long, the temperature
protector will make the product automatically power-off, it should be used again
after half an hour’s rest.
Safety and maintenance Safety and maintenance

10
11
12
13
14
15
16
0504
1
2
3
6
5
4
7
17 18 19 20
8
9
Function
·
·
·
·
·
·
·
·
·
·
·
·
·
·
Efficacy
·Dispel fatigue.
·Accelerate blood circulation.
·Alleviate muscle fatigue.
·Relax tense muscle.
·Alleviate ner ve aches.
·Alleviate muscle aches.
This product is equipped with a muted four wheel driven massage
mechanism which can move up and down.
It is designed with four characteristic automatic massage function: relax,
pressure-relieving, healthcare and comfortable.
It is designed with upper body automatic massage function (Neck
&shoulder auto and back &waist auto).
It is designed with upper body manual massage functions, there are three
massage area available: overall, partial and fixed. There are five massage
methods of shiatsu, kneading, flapping, knocking and synchronous
kneading &flapping, each method has five speeds for choice. When it is
operating under shiatsu, flapping and knocking separately, the massage
wide can be adjusted among wide, medium and narrow.
Arms airbag massage function (there are 36 airbags inside) with two
strengths available.
The lower body airbag massage function (there are 47 airbags inside) with
three position choices (lower body, feet and buttock) and two strengths
available.
It is designed with buttock vibration and feet vibration massage function
with two strengths available.
It is designed with handed heater. Five Helium-Neon lamps use five Xiu
jade as infrared emitter, the temperature can be adjusted from 40℃ to 70
℃.
It is designed with backrest heating function which uses carbon fiber as
infrared source.
It is designed with three massage function memories.
The foot rest frame can be extended, the foot rest and backrest can bed
reclined and declined.
It is designed with automatic sit-up function and mechanism recovery
function when shutting off the machine .
It is equipped with VFD colorful display.
It is equipped with MP3 player and earphone.
ON/OF F FUSE
Name and function of components Function & Efficacy
1.Pillow Pad
2.Remote
Controller
3.Earphone
4.Armrest
5.Cushion
6.Calfrest
7.Footrest
8.Backcushion
9.arms airbag
groupware
10.Backrest Cover
11.Fan Hole
12.Remote
Controller Stand
13.Player(MP3)
14.Back Wheel
15.Earphone Line
16.Cable&Plug
17.Earphone Jack
18.Plug Jack
19.Switch
20.Fuse box

0706
ON/ OFF F US E
Method of usage Method of usage
Backrest angle adjustment:
Press this button and the backrest will raise
slowly, loose the button and it will stop.
Backr est raise
Press this button and the backrest will fall slowly,
loose the button and it will stop.
Backrest fall
Foot rest angle adjustment:
Foot re st ra ise
press this button and the foot rest will raise,
loose the button and it will stop.
Foot rest fall
press this button and the foot rest will fall,
loose it and it will stop.
Ⅲ.Start massage.
①Press the red button to start massage.
②Detect your upper body massage point, and then automatically detect
your shoulder position. When finish, you can hear [di.di] sound. Now you can
adjust should position. Press the functional massage button to start
massage.
Under shoulder position adjustment state, the memor y function buttons
A, B, C will glitter. Auto massage function buttons can be comfort,ease
bodycare,activate.Upper body auto massage function buttons and lower
body airbag massage button will keep on lighting .If press anyone of them
and it will do massage as stored before.。
③If the massage mechanism of shoulder position does not fit well with the
actual one, you can adjust through the up and down button. There are 5
grades of shoulder position.
Ⅰ.Plug in.
Ⅱ.Change the angle of backrest and foot rest as required. (Please don't
Operate while massaging).
extend
button
calf rest adjust:
move the mechanism upward to reach the shoulder.
mov e the mech anism down war d to reac h the sho ul der .
·switch position sketch map Plug in sketch map·
keep pressing this for extending
the calf rest
button
withdraw
button keep oressing this for withdrawingbutton

0908
Method of usage Method of usage
Shoulder
adjust
轻松
酸痛
改善
疲劳
恢复
01
02
03
04
Lower body
C）upper body manual massage ：
Suitable shoulder position
Hig h should er posit ion
suit able should er posit io n
Low should er positio n
Press the functional massage button to start massage.
A)Memor y function massage:
Under shoulder position adjustment state, the memor y function buttons
A, B, C will glitter. Press anyone of them and it will do massage as stored
before. The memor y function button will keep on lighting.
B)Characteristic auto massage, auto upper body massage, auto lower
body massage:：
Name Button Massage feature Display status
Characteristic auto massage
Comfort
Massage
Relax
Massage
Fitness
Massage
Press ure relieving
Mass age
activ ate the blo od circula tion
Relax the whole body
Deep massage of th e point,
relax th e ache muscle
Impro ve th e body's fa tig ue,
make th e body activ e
F1
F2
Auto massage
neck shoulder
massage
back waist
massage
Mainly massage the
neck, shoulder area
mainly massage the
back waist area
Name Button Massage feature Display status
Auto massage
Lower body pressure
massage
Intensity can
be adjust
Mass age fu ncti on
Massage function
Mainly massage
the feet, calf, leg
and buttock
Function Button Description, display stutas Massage balls
adjustment
Measure
Knocking
Shiatsu
Kneading
Flapping
Kneading
&flapping
Speed , wid th
Speed ,wid th
Speed
Speed, wid th
Speed
Speed
Width
5 speed options available
3 width options available
Backrest stretch
Fixed position (fixed) massage
Small area(partial) trip massage
Upper body(overall) trip massage
Display status
Adju st massage ball s
Button
Function:
adjusted under fixed and partial modes)
Massage position adjustment (the massage position can be
Mechanism up
Mechanism down
BACK STRETCH
④
air pressure on arms mainly massage
left and right arms Arm

1110
Memory set on
10
ON/ OFF F US E
Method of usage Method of usage
Intensity
d)other manual functions
Function Button Description, display stutas Speciality
Buttocks Two intensity
options adjustment
Function Button Description, display stutas Speciality
70
40
55
Handed
heater
Handed heater switch
Increase the temperature,
the highest is 70 degrees
Decrease the temperature,
the lowest is 40 degrees
Increase in
5 degrees
Decrease in
5 degrees
Function Button Description, display stutas Speciality
Musi c paly
Music on/off figure
Previous song
Next song
Volume increase
Volume decrease
Music play under boot-
strap or awaiting work
Function Button Description, display stutas Speciality
Backrest
Heating
Lower body air pressure manual massage
Function Button Description, display stutas Speciality
Lower body
Feet
buttock
Intensity
Low e rbo d y
Lower body air
pres sur e massage
Foo t &Ca l f
only foot&calf area air
pressure massage
But t ock s
only buttocks air
pressure massage
Lower body air pressure
massage intensity adjustment
Two intensity
options adjustment
Two intensity
options adjustment
Two intensity
options adjustment
Far-infrared heating therapy in the back,
you can feel dampheat when you turn it on
3 mins late
Two intensity
options adjustment
Buttocks
Vibration
Sole
Vibration Sole
IV、Turn off the power, and stop the massage.
①During massage, press the red power button to stop all massage
functions, the backrest and foot rest will automatically return to the original
state.
②Memo buttons A, B, C flushing, press any of the memo buttons to save
the massage start before it finishes. The VFD control will display Memory Set
On. Or you can turn off the red button to cut the power, the massage
mechanism can restore. Or you can wait 10 min, it can be turned off
automatically and the massage mechanism can restore.
③Cut off the power
·sketch map of cutting off the power
·ske tch map of metho ds to cut off the power
NOTE：There is a backrest heater faucet inside of left armrest.

Method of usage
How to download mp3 music :
1. Turn off the power of massage chair .
2. Pull out the u-disk from the MP3 player .
3. Insert the u-disk into USB port of PC (Windows Xp、Windows
2000、WindowsNT.)
4. Download your favorite MP3 format music into U-disk .if fails ,
please firstly format the disk.
5. Delete the USB Mass Storage Device on the PC after complete
download .
6. Pull out the U-disk from PC
7. Insert U-disk to the USB port of MP3 player
8. Now MP3 music was renewed . you may turn on the power of
massage chair .
Note :
1. If fails to play MP3 music ,please firstly format the U-disk on PC
before download.Then follow the instruction to insert the U-disk into
USB port of MP3 player.
2. Except the U-disk , do not remove or loose the MP3 player .
USB
（1）
（3）
Method of usage
1312

1514
（1） （2）
（1） （2）
3. T HE PADDI N G AND BACK CUSHIO N A SSEMBLI N G AND OPERATION
Us i n g the cushion wh i c h can reduce the n e c k & shoulder kne a ding
ma s s age of the pillo w, c an de t ermine accord i ng to your deman d s
wh e ther to use the pil l o w cushion or not ( r e commend usin g t h e pillow
cu s h ion).
ba c ks of cushions co n nect back throu g h zipper(1)pi l low cushion and
ba c k through is it spi ke joining t o g lue cushion(2 )
Warn: C a n't raise the bac k c ushion to use , in ca s e that cause the in j ur y t o
yo u.
4. I N STALLATION AND USE OF T H E CONTROLLER AN D T EA TA BLE TRAY
In s t all the contro l ler shelf on the ma s s age chair(1) I n sert the contro l ler
sh e l f in thecontro l l er shelf(2) Th e c o ntrol can rota t e freely and
ve r tically(3) Th e c ontrol can rota t e freely and hori z ontally(4)
Method of usage
（3） （4）
（1） （2）
5.Prohibited proceeding:
1)、When the arms airbag groupware connect with the armrest, the spindle
can't be added with lube.
2)、It is forbidden to stab the airbag by needle or other sharp things.
3)、It is forbidden to wobble the airbag groupware in case to destroy
relevant components.
Usage:
1)、When the airbag groupware spindle is inserted into the hole half length
and the chair is turned on, the induction equipment in the hole receive
signal and will start feeding the air; when the groupware spindle is inserted
into the hole completely, there will be no air coming out of the joint and the
airbag will start working.
2)、When the airbag groupware is taken off but not completely, it is
common that there will be air coming out of the joint.
3)、The hand-wheel will be loose if turned to left side, and be tight if turned
to right side; it can be taken off by turning to the left side continuously.
4)、When take off the groupware, please check if it moves forward and
backward freely.
5)、In order to avoid colliding with the airbag groupware, the controller
should be put for ward by 20° as shown in picture (1) and (2).
Method of usage

16
6. F LO O R PROTECTION
Put the heavy ma s sage chairs on t h e w ood floor for a lo n gtime may
da m age the floor, so pleas e p lace a carpet or ot h er object to avoi d t his
da m age.
Ca u tion: Do not move t h e c hairs with its w h e els on wood floo r, r oug h
gr o u nd or in a narrow sp a ce. Two peo p le are required t o l ift the chair.
Model: SL-A08-1
Description: Massage chair
Voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Power:300W
Safety design: Class I
Rated working time: 15 minutes
Product specification
Method of usage
Material introduction: PVC, PA, steel parts and electric &ele
-ctron parts
MATERIAL PU LEATHER CLOTH WOOD
