iRest A306-48 User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
A306-48 MASSAGE CHAIR

01
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our company reserves the right to change and explain the design of the
product. If there is some difference between the product function in market
circulation and the description in the manual, it is a normal update of the product,
and our company will not inform you otherwise. The specific product function and
color shall prevail in kind.
02
04
07
08
10
12
37
38
TABLE OF CONTENTS
Safety and Maintenance
Safety Warning
Names of Components
Function
Introduction to the Remote Controller
Method of Usage
Legal notices
Product Specification

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
Safety Warning Safety Warning
Warning Warning
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
No downward pressure
Warning
Warning
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator. When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.

06 07
18
19
21
POWER INPUT
ON /OF F
20
Name of Components
1.Head cushion
2.3D digital audio
(left built-in voice-
activated microphone)
3.Upper arm airbag
component
4.Remote controller
5.Arm airbag component
6.Armrest shortcut key
7.Salient massage hand
with magnetic therapy
8.Seat cushion
9.Legrest
10.Footrest
11.Backrest
12.Armrest
13.Waist air bag
14.Remote controller or
mobile phone
placement slot
15.Embedded atmosphere
lamp
16.Armrest decoration
17.Side cover
18.Backrest cover
19.Drive box cover
20.Lockable wheel
21.Power cord and plug
22.Power switch
23.Power input
22 23
1
2
6
8
9
11
10 17
12
3
15
4
16
14
7
5
13
Safety Warning
Warning
When adjusting the footrest retractable function or when footrest is declining, please
be sure not to put hard objects (such as keys, mobile phones, Etc.) or put the hand
into the gap of the footrest, and the intersection with the armrest; To avoid product
damage or personal injury caused during the process.
Warning
Before turning on the massage chair, check the surroundings to make sure
that there are no people, pets or other objects around the massage chair
Avoid damage to the product or other objects or personal injury during the
operation of the massage.

0908
Function
·This product is designed with a set of massage chair manipulators that can move
up and down, drive four wheels and operate in mute mode.
·There are five simulative massage techniques: Shiatsu, Kneading, Tapping,
Knocking , and simultaneous kneading and Tapping.
·This product is equipped with automatic shoulder detection and positioning.
·This product is equipped with 12 automatic massage functions, Comfortable
massage,Easy massage,Stretch massage,Neck& shoulder massage,Full body
massage Back&waist massage,Full air pressure,Chiropracticmassage Fatigue
recovery, .Elderly care,Beautiful buttock,Sleep peacefully
·Manual massage range selection is available for the manipulators: including five
massage ranges for your option (i.e. full range, local, fixed point, upper back and
lower back).
·There are five intelligent memory functions (M1, M2, M3, M4, M5): Remarks on
saved massage functions and techniques are available (e.g. father, mother,
daughter, son, or none).
·Massage adjustment function: 7 massage adjustment functions are available,
including 5 speed levels for back massage adjustment, 5 intensity levels for back
massage adjustment, 5 range levels for massage adjustment, 5 width levels for
massage adjustment, 5 intensity levels for airbag adjustment, 3 speed levels for
roller adjustment, 4 time levels for massage adjustment.
·Airbag massage function for the upper body: airbag massage function for the arms
(8 built-in air bags), airbag massage function for the upper arms (4 built-in air
bags), airbag massage function for the waist (4 built-in air bags), and 5 intensity
levels for airbag adjustment.
·Airbag massage function for the lower body: airbag massage function for the legs
(6 built-in air bags), airbag massage function for the feet (22 built-in air bags), and
5 intensity levels for airbag adjustment.
·The slide rail technology for the backrest ensures zero space between the backrest
and wall, so as to save the space to the greatest extent.
·This product is equipped with the back heat treatment function: carbon fiber is used
as far infrared heat source.
·The backrest guide adopts the curve guide technology, so it completely fits the
curve of human back. The full body can enjoy full massage from the head to the
thighs.
·This product is equipped with the leg kneading massage function: the kneading and
airbag squeezing massage functions are provided on the leg rest to relieve the
stiffness or tension of the leg muscles caused by standing for a long period of time.
·The music player system is available. 3D digital audio systems are built into left
and right upper arms. The Bluetooth function of the smart device can be used to
play music wirelessly.
·This product is equipped with the intelligent voice control and recognition function.
·In the air bags for the left and right palms, there are salient massage bands with
magnetic therapy function.
·The legrest is equipped with a stepless flex adjusting function suitable for users
with different heights.
·This product is equipped with the foot roller massage function.
·At the calf have kneading massage function which can relieve the stiffness and
stress of calf.
·The right armrest is provided with on/off key, linkage adjustment key, pause/run
button, AUTO key, voice control and wake-up button, heat treatment key, air
pressure key, Legrest up/down key, zero gravity key. backrest up/down key.
·The right armrest is equipped with USB charging function.
·The armrests on both sides are equipped with LED atmosphere lamps.
·A LCD color screen Remote controller is available.
·After shutdown the chair , it will automatic sitting up, and the manipulator will reset
as well.
Function

2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
1110
1.Display:
·TFT color LCD showing the massage functions in the running state.
2.Switch:
·Turn on or off the massage.
3.AUTO key:
·Enter the automatic function mode selection interface. For more information about the
functions, refer to Page 16 of the Operation Instructions.
4.Zero-gravity key:
·Adjust the angle of the massage chair for zero gravity. There are a total of four modes
to choose from (i.e. 1st pressing is Level 1; 2nd pressing is Level 2; 3rd pressing is
Level 3; and 4th pressing makes the massage chair restore to the original state).
5.Up key:
·Up navigation key: select an object upward in the menu, or adjust the massage position
upward.
6.OK:
·Confirm the selected massage function for massage.
7.Left button:
·Left navigation key: return to the previous menu, or select an object leftwards.
8.Down key:
·Down navigation key: select an object downward in the menu, or adjust the massage
position downward.
9.Backrest up button:
·Adjust the backrest upward according to your own massage needs for the most
comfortable massage posture.
10.Legrest Up key:
·Adjust the legrest upward according to your own massage needs for the most
comfortable massage posture.
11.Legrest down key:
·Adjust the leg rest downward according to your own massage needs for the most
comfortable massage posture.
12.Backrest down button:
·Adjust the backrest downward according to your own massage needs for the most
comfortable massage posture.
13.Pause button:
·Pause all the massage functions currently in service. Press this button again to
continue to run all the massage functions before such pause.
14. Menu button:
·Enter the main menu selection interface. For more information about the functions, refer
to Page 15 of the Operation Instructions.
15.Right button:
·Right navigation key: enter the submenu, or select an object rightwards.
16.Linkage sitting key:
·According to the required massage angle, simultaneously adjust the linkage sitting
function of the backrest and the leg rest for the most comfortable linkage sitting
massage posture.
17.Linkage lying key:
·According to the required massage angle, simultaneously adjust the linkage lying
function of the backrest and the leg rest for the most comfortable linkage lying massage
posture.
Introduction to the Remote Controller Introduction to the Remote Controller

Method of Usage
I. Turn on the power supply of this product
Power-on diagram Switch position diagram of power supply
Method of Usage
Shoulder position adjustment
·After detecting the shoulder position, the buzzer will beep. If there is any difference
from the actual shoulder position, adjust it to the appropriate position by pressing
the "UP" or "DOWN" key. The shoulder position has 11 adjustable levels. If there is
no shoulder position adjustment within 10 seconds, the massage function will start
automatically. Press "OK" directly to start massage immediately. If no shoulder
position can be detected, massage will be started according to the shoulder height
by default. Note: During massage, under the information interface, you can press
"Right Button" to select the "Shoulder Adjustment" menu, and press "OK" to enter
the shoulder adjustment interface. You can also use "Up Key" or "Down Key" to
adjust the shoulder position.
30:00
Shoulder position
Please use ▲▼ to adjust the shoulder position and press OK
·High shoulder position
·Suitable shoulder position
·Low shoulder position
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
1312
2.Start to massage (power switch)
·Press “Power” button to start massage, enter the boot screen, backrest maintains
the default position.
·After automatically lying down to the default position, massage chair will
automatically detect the shoulder position and body (note: fast mode only detect
shoulder position, other modes detect whole body and shoulder position), waiting
the detection finish. Or you can press “confirm” button, the massage chair will
directly start to massage in default without shoulder position and body sensing.
Auto lying down
Attention! Ensure that there
are no objects around the
massage chair
Press OK to skip
Body sensing
Just a moment......
Press OK to skip
·If you need to adjust the shoulder position after the massage program is started,
you can directly select "Shoulder Position Adjustment" to enter the shoulder
position adjustment interface; you can press "Up Key" or "Down Key" to adjust the
shoulder position height; you can press "Left Button" to return to the previous
menu, or wait for 10 seconds to automatically return to the information interface
Button Description
Move the massage balls upward to a suitable shoulder position
Move the massage balls downward to a suitable shoulder position
II. Massage function control operation
1.Standby
·After the massage chair is powered on and turned off,
the remote controller is blank in the standby state (i.e.
the LED lamp is off) and cannot perform any operation
(except the key switch).
POWER INPUT
ON/ OFF

Note: you can't adjust the massage position when it is in auto program.
MainMenu
Auto program
30:00
·After entering the massage program, if you need to adjust the massage position,
you can press the "Menu" button on the remote controller to select "Manual
Function" to enter; you can select any one of the manual functions, and then press
"Left Button" to return to the information interface (i.e. The information interface will
switch to the manual function interface)
·In the manual function interface, if the massage range shows a fixed point or local
area, you can directly press "Up Key" or "Down Key" to adjust the manipulator
upward and downward
·In the manual function interface, if the massage range displays neither fixed point
nor local area, you need to select "Massage Adjustment" to enter, and then select
"Massage area", and a fixed point or local area, and press "Left Button" to return to
the information interface. Next, you need to press "Up Key" or "Down Key" to
adjust the manipulator upward and downward
3.Pause button
·While the massage function is in service, press "Pause" button to temporarily stop
all the massage functions; press "Pause" button again to continue the massage
function before pause. If the pause time exceeds 20 minutes, all the massage
functions will be automatically turned off.
Massage position adjustment
4.Menu button
·Press "Menu Button" to enter the massage function selection interface of the main
menu, including automatic, manual, and other functions, intelligent storage, angle
adjustment, settings and other function interfaces.
·Enter the menu interface. Press "Up Key" or "Down Key" to select the function.
Confirm via "OK" to enter the next level of selection; press "Left Button" to return to
the previous menu interface.
Method of UsageMethod of Usage
30:00
Shoulder position
Please use ▲▼ to adjust the shoulder position and press OK
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Pause
Pressthepausebuttonagain
toresumeusing
1514
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
00:00
Manual Mode
Mode:Tap
Area:Spot
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
ues to adjust the massage posit

·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the automatic programs. Press "OK" (or press “Auto”button on the
hand controller.) to enter the selection of automatic programs.
· 21 special automatic massage programs are available: Comfortable
massage,Easy massage,Stretch massage,Neck& shoulder massage,Full body
massage Back&waist massage,Full air pressure,Chiropracticmassage Fatigue
recovery, .Elderly care,Beautiful buttock,Sleep peacefully
· Enter the automatic program interface. Press "Up Key" or "Down Key" to select
any automatic function massage program. It will automatically return to the
information interface, which will be displayed as the automatic program information
interface.
1) Automatic program (main menu - Auto program)
Method of Usage
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Method of Usage
Program
The most comfortable massage experience.
Gentle and comfortable deep massage to relieve your body fatigue
and relax the body.
Stretch your legs and waist through the leg rest and the backrest to
effectively remove fatigue,relieve joint pain and restore vitality.
Deep massage to rejuvenate your body.
Comfortable
massage
Easy
massage
Stretch
massage
Full body
massage
Description
Neck&
shoulder
massage
With the unique massage technique for the neck and shoulder, the
effective massage for the cervical spine and scapula can be
performed to relieve the neck and shoulder pain and reduce fatigue
on the neck and shoulder.
Focus on spine massage and fully relieve the fatigue and pain from
your body.
Chiropractic
massage
Focus on the back and waist massage to relieve the pain on the
back and waist.
Back&waist
massage
Note: All automatic programs that have been selected to run will be displayed in the
massage function status bar.
Focus on whole body air pressure massage to achieve total
relaxation of the body, deep massage of the body, and overall
relief of body fatigue and ache.
Full air
pressure
30:00
Auto program
Comfort massage
Select the object with ▲▼ and press OK
Easy massage
Stretch massage
Neck & Shoulder massage
Back & waist massage
Full Body massage
Restore the full body from fatigue and pain; achieve relaxation,
improve microcirculation, and quickly relieve fatigue for the back
and limbs.
Fatigue
recovery
Stimulate the circulation of the blood and cause the muscles and
joints to relax; quickly improve the body's microcirculation and
enhance your immunity.
Elderly care
Effective massage on the buttocks and thighs to shape the body
and reduce the accumulation of excess body fat.
Through the massage for the twelve major acupoints for healthcare,
it helps the body to adjust balance, quickly improve your sleep and
sleep quality.
Beautiful
buttock
Sleep
peacefully
1716

·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the manual program, and press "OK" to enter the manual program
interface.
·5 manual massage techniques/functions: OFF, kneading, Tapping, simultaneous
kneading and tapping, Shiatsu, knocking, etc.
·After entering the manual program interface, press “Up Key” or “Down Key” to
select the required manual massage technique. Press “OK” to confirm. Press "Left
Button" to return to the previous interface. After returning to the information
interface, you will find that you have entered the information interface of the
manual function.
2) Manual function (main menu - manual function)
Manual mode 30:00
Tap
Knead & Tap
Shiatsu
Knock
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Stop
Knead
Select the object with ▲▼ and press OK
Kneading
Tapping
Technique
Description
Shiatsu
Simultaneous
kneading and
tapping
Knocking
Speed
Speed, width
Speed
Speed, width
Speed, width
·5 speed levels
adjustable
·3 width levels
adjustable
Method of Usage Method of Usage
3) Other functions (main menu key - other functions)
·Press the "Menu key" to enter the main menu interface, press the "Up key" or
"Down key" to select other functions icon, and press the "OK key" to enter other
functions interfaces.
·Other functions include: upper body air pressure, lower body air pressure, back
heating, calf kneading.
·After entering the other function interface, press the "Up key" or "Down key" to
select the desired massage function, after selecting one of the functions, use the
"right key" to turn on or off the function, and then press "OK key" to confirm. Press
"left key" to return to the previous menu interface.
01) Other functions - airbag massage for the upper body
·Upper air massage: including upper arm air pressure, waist air pressure, arm air
pressure.
·Enter the other function interface, press the "Up key" or "Down key" to select the
upper body air pressure massage function, press the "right key" to enter the upper
body air pressure to select on or off, and then press the "OK key" to confirm. Press
"left key” to return to the previous menu interface.
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
1918
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK

Method of Usage
02) Other functions - airbag massage for the lower body
·Lower body air pressure: including leg air pressure and foot air pressure.
· Enter the other function interface, press the"Up key" or "Down key" to select the
lower body air pressure massage function, press the "right key" to select on or off,
and then press the "OK key" to confirm. Press "left key" to return to the previous
menu interface.
03) Other functions - back heating
·Back heating: Turn on or off the back heating function, turn it on for 3 minutes to
warm up.
·Enter the other functions interface, press the"Up key" or "Down key" to select the
back heating function, enter the "on or off" selection by "right key", and then press
the "OK key" to confirm. Press "left key" to return to the previous menu interface.
Otherfunctions 19:59
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Otherfunctions 19:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Method of Usage
04) Other functions - calf kneading
·Calf kneading: Turn on or off the calf rub function.
· Enter the other functions interface, press the "Up key" or "Down key" to select the
calf kneading function, enter the "on or off" selection by "right key", and then press
the "OK key" to confirm. Press "left key" to return to the previous menu interface.
4) Intelligent storage (main menu - Customise)
19:59
Otherfunctions
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
·Press the "Menu key" to enter the menu interface, press the "Up key" or "Down
key" to select the customise icon, and press the "OK key" to enter the customise
interface, including: Memory use, Memory Save, Cancel.
·Smart Memory use include: M1, M2, M3, M4, M5.
·Smart Memory Save includes: M1, M2, M3, M4, M5.Use function: Recall
previously saved massage programs, including massage mode, massage
technique, air pressure mode and intensity, legrest and backrest position,
angle.Save: Save the currently running massage program, including massage
technique, air pressure mode and intensity, position and angle of the legrest and
backrest.
·Cancel is an exit option.Note: When saving the massage mode, you can make
notes on the saved massage programs(eg: father, mother, son, daughter, none).
2120
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK

Method of Usage
19
MemoryUse
MemorySave
Cancel
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Method of Usage
Note: Make notes on the saved massage functions and techniques (eg: father,
mother, daughter, son, none).
Memory Save 19:59
M1
M2
M3
M4
M5
Adderuser
Dad
Mom
Son
·After entering the memory save interface, press the"Up key" or "Down key" to
select the memory save function. Press "OK key" to save or cancel.
·Enter the memory save interface, press the "Up key" or "Down key" to select any
one of the M1-M5 saving programs you want, and press the "OK key" to select and
confirm, and make remarks for saving the massage function ; Press "left key" to
return to the previous menu interface.
Daughter
None
01) Customise -Memory save or cancel
02) Customise -Memory use or cancel
·After entering the memory use interface, press the "Up key" or "Down key" to
select the memory use function. Press "OK key" to enter memory use or cancel.
·Enter the memory use interface, press the "Up key" or "Down key" to select the
desired use program from M1-M5 to recall the saved massage program; press the
"left key" to return to the previous menu interface.
MemoryUse
MemorySave
Cancel
Select the object with ▲▼ and press OK
Memory Use19:59
M1
M2
M3
M4
M5
MemoryUse
MemorySave
Cancel
Select the object with ▲▼ and press OK
Angleadjustment 19:59
Wholebodyangle
Calfangle
Backangle
Zero-g
5) Angle adjustment (main menu - angle adjustment)
·Press "Menu" to enter the main menu interface, press "Up key" or "Down key" to
select the angle adjustment icon, and press "OK key"to enter the angle adjustment
interface.
·Angle adjustment includes: whole body angle, calf angle, back angle, zero-gravity.
·After entering the angle adjustment interface, press the "Up key" or "Down key" to
select the desired angle adjustment function, and then press the "OK key" to adjust
the selected angle to confirm. Press "left key" to return to the previous menu
interface.
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
2322

Method of Usage
Wholebodyangle
19:59
Use the ▲▼ to adjust the whole body angle
Angleadjustment 19:59
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK
Method of Usage
01) Angle adjustment - whole body angle
·Whole body angle adjustment: Adjust the angle of the backrest frame and the small
leg frame at the same time.
·Enter the angle adjustment interface, press the"Up key" or "Down key" to select
the whole body angle, and then press the "Up key" or "Down key" to adjust thee
whole body angle to the desired angle degree; press "left key" to return to the
previous menu interface.
02) Angle adjustment - calf angle
·Calf angle adjustment: Adjust thee legrest up and down.
·Enter the angle adjustment interface, press the"Up key" or "Down key" to select
the calf angle function, and then press the"Up key" or "Down key" to adjust the
legrest frame to the desired massage position degree; press "left key" to return to
the previous menu interface.
Calfangle 19:59 Angleadjustment 19:59
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK Use the ▲▼ to adjust the calf angle
03) Angle adjustment - back angle
·Back angle adjustment: Adjust the backrest frame to lie down.
·Enter the angle adjustment interface, press the"Up key" or "Down key" to select
the back angle function, and then press the"Up key" or "Down key" to adjust the
backrest frame to the desired massage position degree; press "left key" to return to
the previous menu interface.
04) Angle adjustment - zero gravity
·Zero-gravity adjustment: There are three angles of zero-gravity adjustment and
zero-gravity-off function, a total of four modes can be selected.
·Enter the angle adjustment interface, press the "Up key" or "Down key" to select
the zero gravity function; press the"OK key" to enter the zero gravity interface, and
then press the "Up key" or "Down key"to select zero gravity angle function among
Off, 1st, 2nd or 3rd angle and then press the "OK key"to confirm; press the "left
key" to return to the previous menu interface.
Zero-g19:5 9
OFF
1
2
3
19:59
Angleadjustment
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
Backangle 19:5919:59 Angleadjustment
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK
Use the ▲▼ to adjust the Back angle
2524

Method of Usage
01) Setting - Language
·Language setting: including Chinese and English(this function has a memory, and
it will still be the last selected state after power off and restart).
·Enter the setting interface, press the"Up key" or "Down key" to select the language
setting, and enter the language setting by "right key",Press"OK key" to select the
desired Chinese Simplified or English; press "Left key" to return to the previous
menu interface.
Method of Usage
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 19:59
Language
Bluetooth
Voice control
ID CODE
Select the object with ▲▼ and press OK
中⽂简
English
6) Setting(Main menu-Setting)
·Press the "Menu button" to enter the main menu interface, press the "Up key" or
"Down key" to select the setting icon, and press the "OK key" to enter the setting
interface.
·Settings include: language settings, bluetooth settings, smart voice control, device
ID code.
·After entering the setting interface, press the "Up key" or "Down key" to select the
desired setting function, and then press the "right key" to set the selected setting
function, and then press "OK key"to confirm; press "Left key" to return to the
previous menu interface.
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 19 :59
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
02) Settings - Bluetooth
·Bluetooth setting (this function is disabled by default): After enabling the Bluetooth
function of the massage chair, you can connect a Bluetooth-enabled sound source
device (such as a mobile phone, MID tablet, etc.) The music played by the music
source device is wirelessly transmitted to the massage chair audio system for
music playback.
·Enter the setting interface, press the"Up key" or "Down key" to select the Bluetooth
setting, enter the Bluetooth function through the "right key" to enable or disable it,
and press the"OK key" to select the desired enable or disable; press the "Left key"
to return to the previous menu interface.
03) Setting - intelligent voice control
·Smart voice control: Turn on or off the smart voice control function (this function
has a memory, and the last selected state is retained after power off and restart);
Note: When the smart voice control is turned off, the voice wake-up cannot be
performed.
·Enter the setting interface, press the"Up key" or "Down key" to select the intelligent
voice control function, enter the intelligent voice control setting through the "right
key", press the"OK key" to select the desired enable or disable; press the "Left
key" to return Go to the previous menu interface.
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 19 :59
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 19 :59
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
2726

Method of Usage
Adjustment 19:59
Back speed
Massagearea
Massagewidth
Airintensity
Rollerspeed
Timing
1
2
3
4
5
7) Massage adjustment
·In the information interface state, press the "Left key" or "right key" to select the
massage adjustment button, and press the "OK key" to enter the massage
adjustment interface.
·Massage adjustment includes: back speed, massage area, massage width, air
intensity, roller speed, timing.
·After entering the massage adjustment interface, press the "Up key" or "Down
key"to select the desired massage adjustment function, after selecting any
massage adjustment function, enter the massage gear selection through the "right
key", and then press " OK key" to confirm the selected gear. Press "left key" to
return to the previous menu interface.
Select the object with ▲▼ and press OK
04) Equipment ID
·Equipment ID: Display the current device ID number.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the equipment
ID and check the equipment number of the current device.
MainMenu
Auto program
19:59
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 19:59
Language
Bluetooth
Voice control
ID CODE
Select the object with ▲▼ and press OK
2003140001
Method of Usage
Function
Description
Back massage speed 5 speed levels adjustable
Massage range There are 5 modes for your choice: fixed point, local area,
full back, upper back, and lower back
Massage width 3 width levels adjustable
Airbag intensity 5 intensity levels adjustable
Roller speed Choose from 4 modes including OFF and Level 1-3
Massage time Choose from 4 modes: +10min, +5min, -5min, -10min
Notice:
·Depending on the remaining massage time, when the displayed time is not enough
to add or subtract a certain time, the operation will not be displayed (the upper limit
of the time display is 40 minutes). For example: the display time of the hand
controller is 39 minutes, the range of massage time adjustment is: -5 minutes, -10
minutes (cannot display +10 minutes, +5 minutes).
·The adjustment of the air pressure can only be used when the air pressure
function or automatic function is turned on (please refer to page 18 of this manual
for details on how to turn on the air pressure function).
5.Zero-gravity key
·Press "Zero-gravity Key" to adjust the position of zero gravity. You can choose
different angle positions for zero gravity according to your own needs (i.e. 1st
pressing is Level 1; 2nd pressing is Level 2; 3rd pressing is Level 3; and 4th
pressing makes the massage chair restore to the original state).
2928
30:00
00:00
Auto program
Easy massage>
Mode:Tap
Width:Middle
Back speed
Massage width
Air intensity Roller speed
Adjustment Shoulder
Select the object with ◀▶ and press OK

Method of Usage
Button
Description
Zero-gravity Key: Once it is pressed, the positions of the leg rest and
the backrest can be automatically adjusted to the positions for zero
gravity.There are three zero-gravity modes and the lying OFF mode,
which can be switched.
6.Lying angle adjustment button
Button
Description
Leg rest up button: Hold down the button to make the leg rest rise
slowly. Release it to stop such action.
Leg rest down button: Hold down the button to make the leg rest
move downward slowly. Release it to stop such action.
Backrest up button: Hold down the button to make the backrest rise
slowly. Release it to stop such action.
Backrest down button: Hold down the button to make the backrest
move downward slowly. Release it to stop such action.
Linkage sitting key: By holding down this key, the backrest will rise
slowly and the leg rest will move downward slowly; by releasing it,
such UP/DOWN action of the backrest and the leg rest will be
stopped.
Linkage lying key: By holding down this key, the backrest will move
downward slowly and the leg rest will rise slowly; by releasing it, such
DOWN/UP action of the backrest and the Leg rest will be stopped.
1
3
7
8
10
I
II
2
4
5
6
9
1.Linkage adjustment key: press it to perform linkage adjustment on the backrest
for upward/downward movement.
2.ON/OFF key: press it to start the massage chair.
3.AUTO key: press it to enable the automatic massage function. Press and hold the
button for three seconds to turn off the armrest lamp; operate it again to turn it on
4.Pause/run button: pause or run all massage functions.
5.Heat treatment key: click the key to enable or disable the heat treatment function.
6.Air pressure key: turn on/off air pressure massage function.
7.Legrest up/down key: press it to make the legrest move upward/downward.
8.Voice control and wake-up button: Short press to enable the voice control function,
long press 3 seconds to turn on or off the voice control function.
9.Backrest up/down key: press it to make the backrest move upward/downward.
10.Zero-gravity key: press it to adjust the massage chair to the angle for zero gravity.
III. Introduction to Armrest Shortcut Keys
Method of Usage
3130

I
II
Power button: Short press this button to pause the operation; if it is
hold down for 3 seconds, power will be ON/OFF. If the pause time
during massage exceeds 20 minutes, all the massage functions will
be automatically turned off.
Linkage lying knob: By rotating this knob clockwise, the backrest will
move downward slowly and the legrest will rise slowly; by releasing it,
such DOWN/UP action of the backrest and the legrest will be stopped.
Linkage sitting knob: By rotating this knob counterclockwise, the
backrest will rise slowly and the legrest will move downward slowly;
by releasing it, such UP/DOWN action of the backrest and the legrest
will be stopped.
Automatic mode key: Press it to switch among those automatic
massage functions. Press and hold the button for three seconds to turn
off the armrest lamp; operate it again to turn it on
Heat treatment key: Click the key to enable or disable the heat
treatment function.
Air pressure key: Turn on/off air pressure massage function.
Legrest down button: Press the button to make the legrest move
downward slowly. Release it to stop such action.
Legrest up button: Pull the button to make the legrest rise slowly.
Release it to stop such action.
Zero-gravity key : the positions of the legrest and the backrest can I
be automatically adjusted to the positions for zero gravity.I
Backrest up button: the back rest keeping lifting when pressing this
button, and black rest stopped lifting once release the button.
Backrest down button: the back rest keeping reclining when
pressing this button, and black rest stopped reclining once release
the button
Method of Usage
Function
Description
Zero-gravity key : the positions of the legrest and the backrest can II
be automatically adjusted to the positions for zero gravity.II
Press this button during massage, and all the massage actions will be
suspended at once. (i.e. the massage chair will turn off after 20min).
Then press this button again to restore all the previous massage actions.
Voice control and wake-up button: Short press to enable the voice
control function, long press 3 seconds to turn on or off the voice
control function.
Method of Usage
3332
·When the massage chair is turned on or in standby mode, the sound "Hi Alice" or "Hey
Alice"will be produced to enable the voice control function. Alternatively, you can press
the voice control button on the right armrest to enable the voice control function.
·Long press 3 seconds to turn on or off the voice control function.
·After such function is enabled successfully, the massage chair will reply, "I am here."
Please enter your desired action within 6 seconds. After the massage chair responds,
you can achieve the massage mode you want; if not, the voice control function will
automatically turn off.
·Note: Please use English when the voice control function wakes up. The speech rate is
moderate; Voice commands should follow up the Voice entry.
IV. Voice Control Instruction
Note: commands 14 and 15 can only be used after command 13.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No.
Massage on
Massage close
Comfort Massage
Relax massage
Full body massage
Neck and shoulder massage
Back and waist massage
Stretch massage
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Change the other mode
Go little down
Go little up
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok, full body massage
Answer: Ok, neck and shoulder massage
Answer: Ok, back and waist massage
Answer: Ok, stretch massage
Answer: Ok, open the air pressure
Answer: Ok, close the air pressure
Answer: Ok, up the seat position
Answer: Ok, down the seat position
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Voice Control Entry
Entry: “Hi Alice” or “Hey Alice”. Answer: I am here.
Voice control entry Answer entry

1 2
1.Enter the smart device main menu. Open "Settings" and select the "Bluetooth"
option. Open "Bluetooth", and Bluetooth will automatically "Search for a New
Bluetooth Device".
2.The smart device will search for the corresponding Bluetooth model (e.g. IMCM-
XXXX). Click the "Match" button. If you are asked whether to match with the
device, you just select "Match" to complete matching.
3.Turn on "Music Player" in the smart device and select the song to play.
V. Operation Instructions for Bluetooth Speaker Play
VI. Turn off the power and stop massage
·If the power button is pressed during massage, it will stop all the massage
functions immediately, and the backrest, the legrest and massage chair
manipulators will go back to the default positions. When the preset massage time
is up, all the massage functions will be OFF. The backrest and the legrest will not
go back to the default positions.
·Shut off the power supply of this product, as shown in the attached figure (Power
Shut-off Diagram of the Product).
Method of Usage
Switch position diagram of power supply Unplug the power cord
VII. Installation Instructions for Legrest
·After connecting the wires and the air hose between the legrest and the massage
chair, remove the cable ties and insert the connecting part into the seat (Figure 1).
·Place the round tubes on the left and right sides of the legrest onto the legrest
support (Figure 2).
3 4
Method of Usage
12
Zipper Zipper
·Next, flip the leg rest cover over to cover the round tubes on either side of the leg
rest (Picture 3).
·Secure the leg rest to the massage chair with two M4 screws (one on each
side).Check for bends in pipes, cables, wires, or other abnormalities when turning
up and down. If all is well, install the leg rests (Figure 4).
VIII. Instructions for Removal and Use of Head Cushion and Backrest
·The headrest reduces the intensity of the neck and shoulder kneading massage.
You can decide whether to use a headrest (recommended) according to your own
needs. The backrest and the cushion are connected by a zipper (1). The headrest
and backrest are connected by a zipper (2).
3534
POWER INPUT
ON/ OFF

Method of Usage
·The prolonged heavy pressure on the massage chair may cause scratches on the
floor. Thus, put a carpet or cushion on the floor where the massage chair is placed
to avoid this damage.
Note: Do not move the massage chair with its wheels on the rough ground or in a
narrow space. At least two persons are required to lift it. During lifting, take the
legrest sealing plate and backrest cover grooves as the acting points. (Do not lift the
armrest directly.)
IX. Floor Protection
X. Instruction for Movement
Warning: The rear moving wheels of the massage chair are only suitable for a
shortdistance and slow movement. Please use other auxiliary moving tools for long-
distance transportation to move this massage chair!
·Make sure all wires are pulled away from the surface of the massage chair and
press down the backrest to an angle (center of gravity on the wheels); you can
push the chair forward, move it to the position you want and then return to
standard pitch. (Note: During movement, you must turn off the power button first
and then unplug the power cord and the remote controller connection wire.)
3736
Legal notices
FCC Information
·Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
·This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
·This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20cm between the radiator & your body. This transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter.
