iRest SL-A196-10 User manual

OPERATION INSTRUCTIONS
SL-A196-10MASSAGECHAIR
SAVE THESE INSTRUCTIONS

CONTENTS
01
Safety and maintenance
Safety warning
Name of components
Function
Introduction to the Remote Controller
Method of usage
Legal notices
Product specification
02
04
08
09
10
12
19
19
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our company reserves the right to change and explain the design of the product.
If there is some difference between the product function in market circulation and the
description in the manual, it is a normal update of the product, and our company will
not inform you otherwise. The specific product function and color shall prevail in kind.

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product:
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

04 05
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.
Warning
Warning Warning
Warning
Safe Warning Safe Warning
No downward pressure

0706
Before using the massage chair, remove any hard objects in your pocket(s) or any
jewelry carried with you (e.g. key, watch, other similar portable hard objects) to
avoid any damage to this product or physical injury during massage.
Do not unplug the power cord, or directly turn off the power switch on the back of
the massage chair during massage, in order to avoid any damage to this product or
physical injury.
Please do not fall asleep on the massage chair while using to avoid personal injury
caused by unconscious use.
The massage chair should not be used by more than two people at the same time to
avoid product failure or personal injury. In addition, do not let children play on the
massage chair or climb onto the lower leg, seat cushion, foot, backrest or armrest.
Otherwise, accidents or injuries may be caused.
Warning
Warning Warning
Warning
Safe Warning Safe Warning

Name of Components Function
·This product is designed with a set of four- wheel driven mechanical massage
hands that walk up and down, stretch back and forth, and are silent in design.
·It is designed with the function of automatic detection and micro-adjustment of
shoulder position and the automatic detection function of human body curve and
massage finger pressing point to automatically adjust the stretch back and forth of
the manipulator according to the detected human body curve and massage finger
pressing point, making massage more humanized and scientific
·It has eight characteristic automatic massage functions, i.e. fast massage, comfort
massage, relax massage, full body massage, neck and shoulder massage, back
and waist massage, stretch massage and exercise recovery.
·It is provided with five message scopes for manual selection, i.e. fixed point, upper
back, lower back, local and whole body.
·It is provided with manual massage function: including five massage methods such
as , kneading, tapping, kneading and tapping, shiatsu,knocking . With three level of
speeds for adjustable.
·In the state of tapping, shiatsu and knocking, the width between the two kneading
balls is adjustable with three levels: wide, medium and narrow.
·Equipped with airbag massage function: leg and arm pressure massage function,
with two intensity.
·It is provided with an intelligent voice control recognition function.
·Music playing system, with built-in 3D digital audio in the left and right upper arms.
The bluetooth function of intelligent devices can be used for wireless connection to
play music.
·It is provided with an upper body air compression massage function: shoulder air
compression massage function, arm air compression massage function, and 2-
gear air compression intensity adjustment.
·It is provided with a lower body air compression massage function: lower leg air
compression massage function, and 2-gear air compression intensity adjustment.
·The guide rail of the backrest frame adopts curved guide rail technology, which
completely conforms to the back of the human body and makes people enjoy a
massage from the head to the thigh.
·With back heating functions.
·Automatic sit-up function when the power is off and manipulator automatic reset
function.
0908
1.Head cushion
2.3D digital audio (built-in
voice control microphone)
3. Shoulder air pressure
4.Arm airbag component
5.Controller placement
6.Lower leg frame
7.Back cushion
8.Armrest
9.Side cover
10.Backrest cover
11.Rear cover of power box
12.Movable pulley
13.Power cord and plug
14.Mains input
15.Switch
1
2
3
4
5
7
8
69
10
11
12
13
14 15

1
3
4
6
7
9
10
11
12
14
15
5
13
8
1110
Note: The specific displays refer to the actual object of this product!
2
Introduction to the Remote Controller Introduction to the Remote Controller
1 LED:.
·Display massage mode and timing etc functions.
2 Panel indicate light:.
·Display all massage functions.
3 Air pressure intensity/ roller key:.
·Turn on/off the air pressure function/Adjustable two air pressure intensity
·Long 3 seconds: Turn on/off roller function.
4 Heat key:.
·Short press：Turn on/off the heating massage function.
·Long press 3 seconds to wake up the voice control function.
5 Massage position key:.
·It is provided with five message scopes for manual selection, i.e. fixed point,
upper body, lower body ,local and whole body.
6 Position downward key:.
·Move the massage balls downward to a suitable position.
7 Auto mode:.
·Automatic cycle switching massage function(for more detail, check page 12)
6.Massage position downward key:
·Move the massage balls downward to a suitable position.
9 Zero-gravity key:.
·Adjust to the zero-gravity Angle of the massage chair.(three setting, Press one for
gear I, press second times for gear II, press third time for gear III).
·Long press 3 seconds: on/off: voice control function(off the function, cannot
indentify voice).
10.Linkage lying key:
·Linkage lying of the massage chair.
11.On/off key:
·Switch on/off massage chair.
12.Massage position upward key:
·Move the massage balls upward to a suitable position.
13.Massage method key:
·Please refer to page 13 of this manual for details.
14 Speed key:.
·Manual adjustment of automatic massage speed.
15.Linkage sitting up key:
·Linkage up of the massage chair sitting button.

Ⅱ.Starttomassage
1312
Method of UsageMethod of Usage
① Press the power button to start the massage and the massage chair will
automatically lie.
② Automatically detect the body shape to keep the fitting between the body and the
massage chair. (you can press the part key to skip the automatic detection and
then enter the default massage program automatically).
③ Make a fine adjustment of shoulder position. If the detected position deviates
from the actual shoulder position, use the speed key and the width key to get to
the appropriate position. (you can press the part key to skip the step).
④ Enter the massage status and experience the massage.
·Automatic massage:
A1
A2
A3
A4
A5
A6
A7
A8
Function Key Description Display
Automatic
massage
Fast massage: experience all massage effects
quickly.
Comfort massage: the most comfortable
massage experience.
Full body massage: deep massage, which can
revive body vitality.
Back and waist massage: focus on the back
and waist.
Stretch massage: the automatic mode is
accompanied by the swing of the electric lever.
Exercise recovery: quick recovery from body
fatigue after exercising.
I. Turn on the power supply of this product:
Plugging-in diagram Product connection
diagram
Power switch diagram
of the product
·Massage part adjustment
H0
H1
H2
H3
H4
·Manual massage
S.1
S.2
S.3
S.4
S.5
P1~P3
d1~d3
Function Key Massage ball adjustment Display
Massage
method
Stop: width.
Kneading: speed.
Tapping: speed and width.
Kneading and Tapping: speed.
Shiatsu: speed and width.
Knocking: speed and width.
Adjust the width in three levels.
Adjust the speed in three levels.
Width
key
Speed
key
Function Key Description Display
Massage
part
Fixed-point: fixed-point massage at a fixed
position.
Local: small-scope local massage.
Upper body: upper body massage.
Lower body: lower body massage.
Whole body: Full body massage back and
forth.
Massage position adjustment (In
fixed point and local modes, the
massage position can be
adjusted).
The manipulator goes
upward
The manipulator goes
downward
S.0
Relax massage: gentle and comfortable deep
massage, which can relieve body fatigue and
relax the body.
Neck and shoulder massage: focus on the
shoulder and neck.

15
14
Press 3 seconds: Turn on/off roller
function.
Foot roller Off：L0
Foot roller On：L1
Short press：Turn on/off the air
pressure function/Adjustable two air
pressure intensity
Method of UsageMethod of Usage
Ⅲ. Voice Control Mode
·When the massage chair is turned on or in standby mode, the sound "Hi Alice" or
"Hey Alice"will be produced to enable the voice control function.
·After such function is enabled successfully, the massage chair will reply "I am here."
At this moment, once a corresponding voice control entry to be implemented is
given within six seconds, the corresponding voice control function can be performed
after a reply is received from the massage chair; if no correct voice control entry is
given within six seconds, the voice control function automatically will be off
automatically and needs to be enabled again.
·Note: When waking up the voice control function, please use English, the speech
rate is moderate, Voice commands should be follow up the Voice entry.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No.
Voice control entry
Massage on
Massage close
Comfort massage
Relax massage
Full body massage
Neck and shoulder massage
Back and waist massage
Stretch massage
Fixed massage
Change the other mode
Go little down
Go little up
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Stop adjustment
Answer entry
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok, full body massage
Answer: Ok, neck and shoulder massage
Answer: Ok, back and waist massage
Answer: Ok, stretch massage
Answer: ok,fixed massage
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Answer: OK, Open the air pressure
Answer: OK, , Close the air pressure
Answer: Ok, Up the seat position
Answer: Ok, Down the seat position
Answer: Ok, stop adjustment
Voice Control Entry
Entry: “Hi Alice” or “Hey Alice”. Answer: I am here.
16
17
·Rest frame adjustment
·Air compression massage
·Massage while heating
·Zero-gravity key
Zero-
gravity
Function Key Description Display
Air
pressure
Mode
Heat
Refer to indicators
on the panel for
display
Function Key Description
Each time you press this key, the product will change to one
automatic lying mode. There are three modes in total which
can be cyclically switched.
Long press 3 seconds: on/off: voice control function(off the
function, cannot indentify voice)
Function Key Description
Sit-up
key
Lying
key
Press and hold this key to slowly rise the backrest frame
while slowly lowering the calf frame and release it to stop the
rising or lowering. If you get up to the top, rising stops.
Press and hold this key to slowly lower the backrest frame
while slowly rising the calf frame and release it to stop the
lowering or rising. If you get to the lowest, lowing stops.
Function Key Description
Heat Short press：Turn on/off the heating massage function.
Long press 3 seconds to wake up the voice control function.

17
16
1
1.Enter the smart device main menu. Open "Settings" and select the "Bluetooth"
option. Open "Bluetooth", and Bluetooth will automatically "Search for a New
Bluetooth Device".
2.The smart device will search for the corresponding Bluetooth model (IMCM-
XXXX). Click the "Match" button. If you are asked whether to match with the
device, you just select "Match" to complete matching.
3.Turn on "Music Player" in the smart device and select the song to play.
Ⅳ.Operation Instructions for Bluetooth Speaker Play
Method of UsageMethod of Usage
Ⅶ.InstructionsforRemovalandUseofHeadCushionandBackrest
·The use of the head cushion can reduce the intensity of kneading massage on the
neck and shoulders. You can decide whether to use the head cushion according
to your own needs (the head cushion is recommended). The backrest and the
back cushion are connected by a zipper (1). The head cushion and the backrest
are connected by a (2).Zipper
Zipper
2
Zipper
3.Hang the lower leg sleeved with the fixing block on the hook of the massage chair
seat frame (Fig. 3).
4.Fasten the lower leg on the massage chair with 4 M4 screws (2 on the left and 2
on the right). Check whether there is any abnormality in the up-and-down turning
and whether the pipeline is folded. Then the lower leg installation is completed
(Fig. 4).
3 4
1.After connecting the lower leg and the air tube on the massage chair with the wire
harness, untie the fixed pipeline belt and insert the connecting part into the seat
frame (Fig. 1).
2.Sleeve the lower leg fixing block on the round tubes on the left and right sides of
the lower leg (Fig. 2).
Ⅵ.Instructionsforinstallationoflowerleg
1 2
·During the massage process, press the power on/off key to immediately turn off all
massage functions, reset the backrest frame and the lower leg frame, or when the
massage timing time arrives, all massage functions will be automatically turned off,
with the backrest frame and the lower leg frame not reset.
V.End massage
·Shut off the power supply of this product, as shown in the attached figure (Power
Shut-off Diagram of the Product).
Power Shut-off Diagram of the Product
Disconnection Diagram
Unplugging Diagram

18
Product Specification
Material description: PVC, PA, steel parts, electric and electron components
MATERIAL PU LEATHER CLOTH WOOD
Model: SL-A196-10
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
Rated power: 90W
Rated time: 20min
Safety structure: Class I
19
Note
Warning
Method of Usage
Ⅷ.FloorProtection
·The prolonged heavy pressure on the massage chair may cause scratches on the
floor. Thus, put a carpet or cushion on the floor where the massage chair is placed
to avoid this damage.
Do not move the massage chair with its wheels on the rough
ground or in a narrow space. At least two persons are required to
lift it. During lifting, take the legrest sealing plate and backrest cover
grooves as the acting points. (Do not lift the armrest directly.)
·Make sure that all the wires are pulled away from the massage chair surface; then
press the backrest down to a certain angle (with the center of gravity resting on
the wheels), you can push the massage chair forward with hands, move it to a
suitable position and gently restore it to the normal angle. (Note: During
movement, you must turn off the power button first and then unplug the power
cord and the remote controller connection wire.)
Ⅸ. Instruction for movement
The rear moving wheels of the massage chair are only suitable for short-distance
and slow movement. For long-distance transportation, please use other auxiliary
moving tools to move this massage chair!
Legal notices
FCC Information
·Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
·This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
·This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
