iRest SL-A385 User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
Massage Chair
Future Foresee
SL-A385
Products refer to the actual product, without prior notice.

02
04
05
06
13
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
01
CONTENTS
Safety and maintenance
Name and functionof components
Function
Method of usage
Product specification

0302
1.Important Safety Warning.
Don t allow children to touch moveable part of this product.
Please use well-grounding power supply suited to this product.
Please pull out the plug after use or before cleaning to avoid injury or
Damage to the product.
Please operate this product according to this manual instruction.
Don t use accessories which are not recommended.
Don t use this product outdoors.
Please read this manual instruction carefully before operation.
Any other usage that is not listed in this manual instruction is forbidden.
20 minutes of usage each time is recommended.
Please don t use it if the leather is broken or damaged.
Please don t use it if the cover or leather is damaged.
Please don t use it if the radiator hole is covered or blocked.
Please don t drop anything into this product.
Please don t fall asleep while using this product.
Please don t use it if drunk or feel unwell.
Please don t use it within one hour after having meal.
Please don t make the massage function too strong for avoiding Injury.
2. Environment for usage.
Please don t use it under high temperature and moist environment such as
bathroom.
Please don t use it immediately while the environmental temperature
changes sharply.
Please don t use it under heavy-dusty or caustic environment.
Please don t use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
People who are suffering from osteoporosis are not suitable to use this product.
People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
People who are suffering from fever are not suitable to use this product.
Pregnant women or women that are in menses period are not suitable to use this
product.
People who got injured or skin disease are not suitable to use this product.
Children under 14-year old or people mentally unbalanced without being
Supervised are not allowed to use this machine.
People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
People whose bodies are wet are forbidden to use this product.
The appliance has a heated surface.persons insensitive to Heat must be careful
when using the appliance.
4. Safety.
Check the voltage if it is suitable to the specification of this product.
Don t use wet hand to pull the plug.
Don t make water go inside this product to avoid electric shock or cause
damage to this product.
Don t damage the wires or change the circuit of this product.
Don t use wet cloth to clean the electric parts such as switch and plug.
Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
Stop using this product while it works abnormal, and please consult local agent
immediately.
Stop using this product if you feel unwell, and please consult health care doctor.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
Please don t forget to cut the power after usage.
Don t use this product if the socket looses.
If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
Don t reserve this product under high temperature or near fire and avoid longtime
direct sunshine.
Please clean this product by dry cloth. Don t use thinner, benzene or alcohol.
The mechanical components of this product are specially designed and made, it is
not necessary to be specially maintained.
Don t use edged res to thrust this product.
Don t roll or pull this product above uneven ground, it should be lifted before
moving.
Please use it intermittently; don t make this product work continuously for long.
6. Solution of ordinary malfunctions.
It is nature movement voice if the motor sounds while in usage.
If the controller can t work normally, please check the plug and socket if they are
connected strongly and make sure the switch is turned on.
If the rated working time is over, the product will automatically activate the power-
off button; If this product works continuously for long, the temperature protector will
make the product automatically power-off, it should be used again after half an
hour s rest.
If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
Safety and maintenance Safety and maintenance

04 05
Function
Designed with a set of vertically movable, four wheel driven muted intelligent
massage hands.
Designed with emulation massage methods of shiatsu, kneading, flapping,
knocking, simultaneous kneading and flapping.
Set with the shoulder automatic detection and location.
Set with memory set on function M1 and M2
Manual massage for the upper body with three options, fixed, partial and overall
massage, with five levels of speed adjustable. in the state of flapping, shiatsu and
knocking, the width between the two kneading balls is adjustable with three
Levels: wide, medium and narrow. On partial and fixed point, the massage hands
can move up and down to adjust the massage point accurately.
Air pressure massage function with three modes: full body air pressure, arms
(upper arm set with 4 airbags, arm set with 8 airbags), leg set with 16 airbags,
three intensity optional.
Leg designed with roller massage function at the bottom of foot, two pairs of
papillae on toe root rotating massage; on the arch and heel mastoid skin scraping
massage.
Back heating function: carbon fi ber far infrared heat source.
The footrest use stepless extended to suit for different body heights.
Backrest frame down slides used technology to deviate from the wall by keeping
zero space, reach the maximum space saving.
Leg lifting adjusting, the backrest frame lifting adjusting and automatic lay down
mode adjustment function.
L shape back track fitting curves of the body, can realize the zero gravity when
back down.
Intelligent automatic massage function: express, wholesome, oriental, swedish ,
classic, chiro.
On upper arm has two grades width adjustment function When you adjust to the
last grade, to push into the arm about a gear distance then lose your hand and
arm device will automatically reset, and so on in order to adapt to the different
shoulder breadth of users.
3D stereo sound speaker installed into armrest.
Fast-pair blue tooth to play music.
Easy control key board on right armrest for on/off, decline/recline.
Name and function of components Function
1
2
3
4
5
8
10
6
15
14
18
20
11
21 22 23
7
16
17
19
9
12
13
1.Head cushion
2.
3.Upper arm air bag components
4.Arm air bag components
5.
6.Seat cushion
7.Leg rest frame
8.Foot rest frame
9.Calf stop sealing plate
10.Back rest pad
11.Armrest decoration
12.Armrest
13.Side cover
14.Back cover
15.Manual controller
16.Drive box cover
17.Safety switch
18.Base caster
19.Power line and power plug
20.Power socket
21.Fuse box
22.Power switch
23Manual controller socket
3D stereo speaker
Easy control key board

0706
Method of usage Method of usage
Note: The specific displays referto
the actual object of this product!
1.Switch power supply on
Diagram of plug in Diagram of the switch position of power supply
2.Start to massage
1). Press power button, massage chair automatically reclining, and start massage.
2). Automatic shoulder position and massage acupressure point detection, waiting
for the completion of testing.
3). If there is difference with the massage balls and the actual shoulder position,
youcan adjust the up and down button to a suitable position. Shoulder position
has 10 grades adjustable.It will run automatic massage if there is noadjustment
on shoulder position within 10 seconds
Button Description Display
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
Shoulder
adjust
High shoulder position
suitable shoulder position
Low shoulder position
AUTO MODE
MANUAL
EXPRESSWHOLESOME
ORIENTAL/M1
SWEDISHCLASSIC CHIRO/M2
Menory
Menory
4) Choose massage function to massage
Memory function massage
Function Button Display
Memory
massage
Press button ORIENTAL/ M1 or CHIRO /M2 for 3 seconds, then
enter into memory massage function M1 or M2 , it will revert to the
previous memory massage mode.
ORIENTAL/M1
CHIRO/M2

0908
Air pressure function massage
Massage point adjust (in fixed
point, partial modes you can
adjust the massage position)
Other manual function
Method of usage Method of usage
Function Button Description Display
Back
Stretch
Massage hand
move up
Massage hand
move down
Function Button Description Display
Air pressure
mode
Intensity
Three air pressure modes(full body, arm and leg )
for Lower body
With three grades adjustable
Function Button Description Display
Roller
Heating
Sole roller: sole roller switch, with 3 speed levels
available
Far infrared back heating, has warm feeling when
it start to work 3 minutes later
H0
H1
H2
H3
H4
Fixed position (fixed point) massage back and forth
Small area (partial area) massage back and forth
Overall massage back and forth
Upper body massage back and forth
Lower body massage back and forth
Other manual function
Function Button Description
Calf rise
and drop
Backrest rise
and drop
Auto lay
down mode
Calf rest lifting button, press this button, calf restlifting slowly,
stop when release it
Calf rest decline button, press this button, calf rest decline
slowly, stop when release it
Backrest lifting button, press this button, backrest lifting slowly,
stop when release it
Backrest decline button, press this button, backrest decline
slowly, stop when release it
with three modes circulation function, when press the button,
turn into auto lay downmode.
Auto F0
Auto F1
Auto F2
Auto F3
Auto F4
Auto F5
Function Button Adjust Massage Ball Display
Speed
Width
SPEED
WIDTH
Three Grades Speed Adjustable
Three Grades Widths Adjustable
EXPRESS
WHOLESOME
SWEDISH
CLASSIC
MODE
MASSAGE AREA
MASSAGE AREA
MASSAGE AREA
MASSAGE AREA
MASSAGE AREA
AIR MODE
AIR POWER
FOOT ROLLER
HEAT
Upper body manual massage, lower body manual massage
1)Upper body manual massage
Characterized auto massage
Function Button Description Display
Mode: One button cycle
the five manual massage
modes, kneading, flap,
flap & kneading, shiatsu,
tap, and off.
Knead & flap:Speed
Flap: Speed And Width
Knead: Speed
Shiatsu: SpeedAnd Width
Knock: SpeedAnd Width
Quick fix massage for those who are in the rush.
A full body massage with rolling massage on the
neck area.
Rolling massage on the neck with fast moving
massage on the back.
Kneading massage with scrubbing.
Emphasizes on massage along the spinal area
plus stretching action.
Characterized
auto massage
ORIENTAL/M1
CHIRO/M2
Decline and recline the back rest and foot rest to
enforce lying automatically, and it is auto-cycle
mode, to improve the stretch for waist, meanwhile,
the foot airbag, back mechanism massage waist.

11
10
Set with safety switch in a power supply
box, if there is heavy pressure on power
supply box, then forced stop back lying
function, prevent hurts peoplewhen lying.
Method of usage Method of usage
3) Cut off the power of the whole machine.
Figure (Switch power off)
Diagram of the switch position of power supply Power switch method map
WARNING
4.Calf installation
Install the rotating shaft incalf fixed axis first, noticed the hole should be aligned, so
that the R shape pin assembly (chart 1)
After calf is connected with the fixed axis aligned, then insert (chart 2)
chart 1 chart 2
Plug R pin, then moved to the other side of the calf, and the plug R pin (chart 3)
Finished (chart 4)
chart3 chart4
When the machine under the working state, with lying and calf rest lifting, you
could not apply gravity on the calf, to prevent the massage chair does harm to
peoplebefore dumping(chart1).
chart2).
Ensure the mechanism hands not in the seat part ,otherwise will cause
uncomfortable in the Buttock when you seating in the chair(
Note
chart1 chart2
Shortcut keys
Button Description
Calf rest lifting button, press this button, calf restlifting slowly,
stop when release it.
Calf rest decline button, press this button, calf rest decline
slowly, stop when release it.
Backrest lifting button, press this button, backrest lifting slowly,
stop when release it.
Backrest decline button, press this button, backrest decline
slowly, stop when release it.
1)Press power button during massage progress, all massage function will be stop
immediately, the backrest and footrest will return to original position automatically,
meanwhile you can set up memory function. After rated working time, all massage
functions will be finished, meanwhile you can set up memory function, but
backrest and footrest won't return to original position.
2)Memory store function: After rated working time or switch off, the hand controller
displays "Memory" and glitter, remind the users whether need to store the
massage mode before turn off, you can press the memory function buttons
M1 or M2 as you like, store the massage mode.
3.Turn off power, stop massage
Pause and run button: to stop massage function you need to press
on/off button, if it stops more than 20 minutes, the massage chair will
shut down all the massage function

12 13
Method of usage
Product specification
Put the heavy massage chairs on the wood floor for a longtime may damage the floor,
so please place a carpet or other object to avoid this damage.
Model: SL-A385
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power input:150W
Rated time: 20Min
Safety structure: Class
Material introduction: PVC, PA, steel parts and electric &ele
-ctron parts
MATERIAL PU LEATHER CLOTH WOOD
Method of usage
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in
a narrow space. Two people are required to lift the chair. During the lifting period,
take the calf sealing board and backrest cover grooves as the focal point(Please do
not lift armrest Directly.)
7.Method of movement
Make sure that all wires are far above the ground, tilt the backrest backward to
a certain degree (with the gravity center resting on the wheels), push the chair
forward or backward with your hands and finally resume the chair to the normal
position in a slow and gentle manner.
Note:During movement you must turn off the power switch first and then unplug the
power line and hand controller connecting line.
6.Floor Protection
Foldable pillow pad. The users can choice the number of layer to find the best
intensity of back massage.
Separate the head pillow to fall down to the back to reduce the intensity of back
massage.
Backrest cushion and backrest connected byzipper (1), head cushion and
backrest pad connected by thread gluing (2)
Zipper Thread gluing
5. Head cushions and backrest pad's dismounting and use manual
