iRest A309-8 User manual

Operation Instructions
A309-8 MASSAGE CHAIR
SAVE THESE INSTRUCTIONS

01
02
04
06
07
08
20
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
CONTENTS
Safety and maintenance
Safety warning
Name and function of components
Function
Method of usage
Product specification

0302
Safety and maintenance Safety and maintenance
1.Important Safety Warning.
·Don’t allow children to touch moveable part of this product.
·Please use well-grounding power supply suited to this product.
·Please pull out the plug after use or before cleaning to avoid injury or
Damage to the product.
·Please operate this product according to this manual instruction.
·Don’t use accessories which are not recommended.
·Don’t use this product outdoors.
·Please read this manual instruction carefully before operation.
·Any other usage that is not listed in this manual instruction is forbidden.
·20 minutes of usage each time is recommended.
·Please don’t use it if the leather is broken or damaged.
·Please don’t use it if the cover or leather is damaged.
·Please don’t use it if the radiator hole is covered or blocked.
·Please don’t drop anything into this product.
·Please don’t fall asleep while using this product.
·Please don’t use it if drunk or feel unwell.
·Please don’t use it within one hour after having meal.
·Please don’t make the massage function too strong for avoiding Injury.
·Please do not carry fragile, explosive and combustible materials in your pocket
such as mobile phones, lightersand so on, when using massage chair.
2. Environment for usage.
·Please don’t use it under high temperature and moist environment such as
bathroom.
·Please don’t use it immediately while the environmental temperature
changes sharply.
·Please don’t use it under heavy-dusty or caustic environment.
·Please don’t use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
·People who are suffering from osteoporosis are not suitable to use this product.
·People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
·People who are suffering from fever are not suitable to use this product.
·Pregnant women or women that are in menses period are not suitable to use this
product.
·People who got injured or skin disease are not suitable to use this product.
·Children under 14-year old or people mentally unbalanced without being
Supervised are not allowed to use this machine.
·People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
·People whose bodies are wet are forbidden to use this product.
·The appliance has a heated surface. Persons insensitive to heat must be careful
when using the appliance.
4. Safety.
·Check the voltage if it is suitable to the specification of this product.
·Don’t use wet hand to pull the plug.
·Don’t make water go inside this product to avoid electric shock or cause damage
to this product.
·Don’t damage the wires or change the circuit of this product.
·Don’t use wet cloth to clean the electric parts such as switch and plug.
·Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
·Stop using this product while it works abnormal, and please consult local agent
immediately.
·Stop using this product if you feel unwell, and please consult health care doctor.
·This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
·Children should be supervised to ensure that they do not play with the appliance.
·If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
·This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
·Please don’t forget to cut the power after usage.
·Don’t use this product if the socket looses.
·If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
·Don’t reserve this product under high temperature or near fire and avoid longtime
direct sunshine.
·If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
·Please clean this product by dry cloth. Don’t use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and made, it is
not necessary to be specially maintained.
·Don’t use edged res to thrust this product.
·Don’t roll or pull this product above uneven ground, it should be lifted before
moving.
·Please use it intermittently; don’t make this product work continuously for long.
6. Solution of ordinary malfunctions.
·It is nature movement voice if the motor sounds while in usage.
·If the controller can’t work normally, please check the plug and socket if they are
connected strongly and make sure the switch is turned on.
·If the rated working time is over, the product will automatically activate the power-
off button; If this product works continuously for long, the temperature protector will
make the product automatically power-off, it should be used again after half an
hour's rest.

0504
Safety warning Safety warning
Warning
Warning
Warning
Warning
When the footrest lifting, people should not apply pressure on the footrest to avoid
the massage chair falling forward to damage the product or cause personal injuries.
Prohibit pressing
Before sitting on the massage chair, make sure that the massage hand stays in the
seat cushion position to avoid discomfort to the buttocks during the body pressing
down and damage to the massage hand.
Do not strive to pull out the control cable or power cord during standby or power-on
state to avoid product damaged or electrocution accidents. Advise you unplug the
controller cable and power cord and put away after you use the chair.
When start the zero gravity lying function, be sure to check whether there are
children and pets under the bottom of the footrest and backrest, may cause the
product damaged or personal injuries.

06 07
Name and function of components Function
1.Head cushion
2.3D digital audio
(left built-in voice-
controlled microphone)
3.Upper arm air
pressure component
4.Arm air pressure
component
5.Manual controller
or mobile phone
placement slot
6.USB charging port
7.Seat cushion
8.Leg rest
9.Foot rest
10.Backrest
11.Armrest
12.Handrail shortcut key
13.Embedded lamp
14.side cover
15.Back cover
16.Manual controller
17.Drive box cover
18.Move pulley
19.Power cord and plug
20.Safety box
21.Power switch
22.Power line socket
15
17
19
16
18
20 21 22
FUSE:
T5AL 250V POWER INPUT
ON/ OFF
·This product has designed a set of massage manipulator that can walk up and down,
four-wheel drive and mute design.
·There are five simulative massage techniques: finger pressing, kneading, tapping,
tapping and kneading at same time.
·Equipped with shoulder automatic positioning detection.
·Automatic massage functions: automatic massage includes 12 kinds of automatic
massage functions, including comfortable massage, relaxing massage, traction
massage, shoulder and neck massage, back and waist massage, whole body
massage, Protection of vertebral massage, fatigue recovery, stretching muscles and
activating collaterals, beautiful buttock shaping, soothing sleep and full air pressure.
·Equipped with upper body manual massage function (the whole body, fixed point and
local three massage parts are selected, and the speed of each massage manipulation
can be adjusted with five speed. In fixed point and local state, the manipulator can
adjust the position up and down; When tapping, pressing and percussion massage, the
width of the massage ball can be wide, medium or narrow.
·It has air pressure massage function: upper arm air pressure massage function (built-in
4 airbags), arm air pressure massage function (built-in 8 airbags), calf air pressure
massage function (built-in 16 airbags), and 3rd air pressure intensity adjustment.
·It has intelligent voice recognition function and intelligent voice control wake-up button
on the left armrest.
·The calf frame is provided with a telescopic adjustment function, and the calf foot is
pulled out with the ankle. The length of the foot extension can be determined according
to the length of the user's leg, and the foot is retracted by the spring force to adapt to
different heights of the person.
·It has a separate lifting and lowering function for the calf frame, a linkage adjustment
function for the backrest frame, zero gravity, and timing adjustment.
·With back heat treatment function: carbon fiber as far infrared heat source.
·Under the backrest frame, the backrest adopts slide rail technology to keep the zero
space against the deviation wall all the time, so as to save the space to the greatest
extent.
·Backrest frame guide adopts curve guide technology, which completely conforms to the
curve of human back, and can enjoy massage from head to thigh.
·Music playback system, 3D digital audio built into left and right upper arms. Use the
Bluetooth function of the smart device to play music wirelessly.
·The foot has a foot roller massage function, and a set of rollers roll the rolling scraping
massage on the arch of the foot.
·The front end of the right armrest is provided with a manual control slot or a mobile
phone slot, and has a USB charging function.
·There are five kinds of handrail shortcut keys on the left handrail, such as the opening
key, the calf frame lifting button, the linkage adjustment button, the automatic mode
button, and the voice wake button.
·The left and right handrails are equipped with LED mood lights.
·LCD Color screen controller.
·Shutdown automatic sitting function, manipulator automatic reset function.
1
2
3
4
8
10
11
712
14
6
5
9
13

zero
0908
Method of usageMethod of usage
LCD: display all massage functions.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1.Power switch:
·Turn on or off all massage functions.
2.Pause \ run button:
·Pause or run all massage functions.
3.Timing key:
·Timing time adjustment
4.Automatic reclining key:
·There are three automatic reclining modes, which can automatically switch
according to your own needs.
5.Footrest up key:
·Adjust footrest up.
6.Automatic massage button:
·Please refer to page 10 of this manual for details.
7.Air pressure mode key:
·Turn on/off air pressure massage function (please refer to page 11 of this manual
for details).
8.Manual massage key:
·Please refer to page 11 of this manual for details.
9.Foot roller key:
·Please refer to page 11 of this manual for details.
10.Shoulder adjustment key:
·Manual adjustment of human shoulder position massage finger pressure point.
11.Up key:
·Adjust backrest frame rise and calf frame drop.
12.Calf frame down key:
·Adjust calf frame down.
13.Lie down key:
·Adjust backrest frame to drop and crus frame to rise.
14.Air pressure intensity key:
·Adjust air pressure intensity function.
15.Heating key:
·On/off heating massage function.

11
①、Press the power button to start the massage.
②、leg frame and back frame will automatically lie down Angle, waiting for the
selection of massage function (select an automatic function), sitting posture
adjustment more than 3 minutes without operation, automatic shutdown and
sitting.
③、After selecting the function of automatic mode, the automatic detection of
human shoulder position and massage finger pressure point shall be carried
out first, and wait for the completion of the detection.
④、If the detected shoulder position is deviated from the actual shoulder position,
adjust the upper and lower keys of the shoulder position to the appropriate
position.The shoulder position has 10 positions.No shoulder position
adjustment within 10 seconds, then automatically enter the massage function.
Method of usageMethod of usage
1.Switch power supply on
Diagram of plug in Diagram of the switch position of power supply
2.Start to massage
Button Description Display
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
10
Shoulder
adjust
High shoulder position
suitable shoulder position
Low shoulder position
Place in a shoulder massage and acupressure point detection process, (manual
device screen display shoulder position adjust icon and hear manual device "click"
sound, and then key shoulder position which can adjust the position of shoulder),
now has 12 can be automatically massage function keys (comfortable massage,
massage, traction massage easily, massage neck, back, waist massage whole body
massage, protecting vertebral massage, fatigue recovery, relaxes the muscles and
stimulate blood circulation, shaping beautiful buttock, Ann god sleeps, full pressure)
in any key and enter the massage function (skip step 5).
⑤、Select the massage function, massage.
F1 Auto
F2 Auto
F3 Auto
F4 Auto
F5 Auto
A1 Auto
A2 Auto
A3 Auto
A4 Auto
A5 Auto
A6 Auto
A7 Auto
·Automatic massage
Function Button Description Display
Comfort
Relax
Stretch
Shoulder&neck
Back&waist
More
Automatic
massage
Comfort: The most comfortable massage experience.
Easy: the depth of the soft and comfortable massage,
relieve body fatigue
Frame and backrest frame rise and fall, and air
pressure massage, and stretch or traction on the leg,
remove fatigue, restore vitality.
Shoulder & neck: focus on shoulder and neck massage.
Back &waist: to back waist massage focus.
Full body massage: deep massage to rejuvenate
the body.
chiropractic massage: focus on chiropractic massage,
relax body and mind.
Fatigue recovery: improve the whole body fatigue pain,
for the back, limbs to achieve relaxation and improve
microcirculation, quickly relieve fatigue.
Meridians massage: dredge meridians, quickly improve
the body's microcirculation, enhance immunity.
Beautiful buttock model: be aimed at buttock and thigh
effective massage, beautify body shape, reduce the
accumulation of redundant adipose body.
Sleep peacefully massage: through the twelve major
health acupoints massage to help the body recuperate
balance, quickly improve sleep, improve sleep quality.
All pressure:, focusing on the whole body pressure
massage to fully relax the body, to the depth of the
body massage, fully relieve fatigue and pain of the body.
FUSE:
T5AL 250V POWER INPUT
ON/OF F

12 13
Method of usageMethod of usage
H0
H1
H2
Function Button Display
·Upper body manual massage
Massage ball adjustment
Technique
Speed
Width
Back
stretch
Shiatsu: speed, width.
Knead: speed.
Beat: speed, width.
Knead pat: speed.
Knock: speed, width.
5 speed adjustable.
The width of the third gear can be adjusted.
Fixed position and spot massage.
Small area local round trip massage.
A round trip massage.
Massage position adjustment
(in fixed point and local mode,
massage position can
be adjusted).
Manipulator uplink
Manipulator descending
·Pneumatic massage
Function Button Description Display
Air
pressure
Mode
intensity
Full pressure: air pressure massage on arms,
legs and feet.
Arm: air pressure massage with the arm as the
focus.
Leg: barometric massage for leg, foot.
Adjustable in three levels.
·Foot roller massage
Function Button Description Display
Foot
roller
Press this button to turn on or off the foot roller
massage, and has a weak, medium, strong three
levels of intensity can be adjusted to close the
four states of cycle switching. min
·Heated massage
Function Button Description Display
Heat
Press this button to turn on or off the back far
infrared hyperthermia. Turn on 3 minutes later
Have a warm.
·Pause/start massage button
Function Button Description Display
Pause/start
Press this button in the process of massage, and
all massage movements will be suspended
urgently when time continues to countdown), and
then press this key to resume all before suspension
massage.
·Adjust lying Angle
Function Button Description
Set up
Lay
down key
Calf
Rise up
Calf
Go down
Lie down
automatically
Press this button, backrest frame slowly rise, calf frame
slowly fall, and issued "di...di..."until it reached the top.
Press this button again in the process of sitting, then stop
sitting immediately.
Press this key, backrest frame slowly down, calf frame
slowly up, and issued "di...di..."until it stops. Press this key
again in lying down process, stop lying down immediately.
Press and hold this button, the calf frame slowly rises, and
issue "di...di...""until it reaches the top and stops. Release it
and stop adjusting.press this button, lower leg frame slowly,
and issue "di...di..."until the end of the stop, release will stop
adjustment.
Press this button, lower leg frame slowly, and issue "di...di..."
until the end of the stop, release will stop adjustment.
Press the button every time to switch one automatic lying
mode. There are three modes in total.
·Other manual functions
Function Button Description Display
Timing
Time adjustment, every time to press will add 5
minutes, can not exceed 30 minutes, if more than
30 minutes return to the minimum time value.

14 15
Method of usageMethod of usage
3.Introduction of handrail shortcut keys
The left arm
Function
Description
Right arm
USB
AUTO
1
2
3
4
5
6
7
Left armrest shortcut:
1.Power button: Turn the massage chair on or off.
2.linkage adjustment button: linkage adjustment of the backrest lifting adjustment.
3.calf frame lifting button: adjust the calf frame to rise or fall.
4.automatic button: turn on the automatic massage function.
5.voice control wake-up button: wake up voice control function.
Right armrest shortcut:
6.Place the slot: the hand controller and the mobile phone can placed in the slot.
7.USB charging port: smart device charging.
Power button: Press this button to turn the massage function on or off.
The calf riser button: pushes the button up and raises the calf frame
slowly, and releases it to stop the calf frame from rising.
Lower leg lowering button: Press the button down slowly to lower the
calf frame, and release to stop the lower leg frame.
Link up button: push the button up the back frame slowly, while the calf
frame slowly descends, release the backrest frame and the calf frame
are stopped.
Linking lying button: Press the button down slowly to lower the backrest
frame, while the calf frame rises slowly, releasing then the backrest
frame and the calf frame are stopped.
Auto mode button: Each time you press it, the auto massage function
switches.
USB jack: USB charging port, you can charge smart devices (such as
mobile phones).
Voice control wake-up button: press this button to wake up the voice
control function.

16 17
·When the massage chair is open or in standby mode, say "hi, Alice" or press the
voice control wake-up button on the right armrest to wake up the voice control
function.
·After the successful wake-up, the massage chair will reply “I am here”. At this time,
the voice control entry corresponding to the function is realized within 6 seconds.
After the massage chair is respond, the corresponding voice control function can be
realized; if did not correctly say any voice entry for more than 6 seconds, the voice
control function automatically turns off and needs to be reawakened.
·Note: When waking up the voice control function, please use Mandarin, the speech
rate is moderate, Voice commands should be follow up the Voice entry.
4.Voice control operation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Voice control enter
Awakening words: “hi Alice”. Answer: I am here.
Serial No Voice control entry
Massage on
Massage close
Comfort Massage.
Relax massage.
Full body massage.
Neck and shoulder massage.
Back and waist massage.
Stretch massage.
Fixed massage.
Change the other mode.
Go little down.
Go little up.
Open the air pressure.
Close the air pressure.
Up the seat position.
Down the seat position.
Stop adjustment.
Answer entry
Answer: Ok, massage on.
Answer: Ok, massage close
Answer: ok, comfort massage
Answer: ok, relax massage
Answer: ok,full body massage
Answer: ok,Neck and shoulder massage
Answer: Ok,back and waist massage
Answer: ok,stretch massage
Answer: ok,fixed massage
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Answer: OK, Open the air pressure
Answer: OK , Close the air pressure
Answer: Ok, Up the seat position
Answer: Ok, Down the seat position
Answer: Ok, stop adjustment
Method of usageMethod of usage
1.Enter the smart device manual and open the Bluetooth function to search the new
Bluetooth devices .
2.Will find the bluetooth named like (IMCM-XXXX),choose it to pair with the chair .
3.Turn on the Music Player in the smart device .
5.Bluetooth Player Operation
6.Turn off the power and stop massage.
·When pressing the power button during the massage, it will stop all the massage
functions immediately, the backrest and footrest will go back to the default posit
on.And when the massage time up, the massage hand will go back to the default
position, all the massage function will stop, the backrest and footrest will not go
back to the default position.
·Cut off the power of the whole machine. Figure (switch power off)
Diagram of the power switch position Unplug the power cord
1. After connecting the air hose and the wire harness on the calf and the massage
chair, untie the fixed line belt and insert the connecting part into the frame. (Figure 1).
2. Place the calf fixing block on the two sides of the round tubes of the calf (Figure 2).
7.The calf installation.
FUSE:
T5AL 250V POWER INPUT
ON/OF F
1 2

12
18 19
3. Hang the calf of the fixed block on the massage chair frame hook (Figure 3).
4.Then use 4 (each side two pcs) M4 screws to fasten the calf to the massage chair,
check whether there is any abnormality, whether the pipeline is folded or not, and
finish the installation (Figure 4).
8.Head cushions and backrest pad's dismounting and use manual
·The head cushion allows you to contr ol the intensity of the neck and shoulder
massage, You can decide whether to use the head cushion (Recommend to use).
The backrest cushion and the backrest is connected by zipper (1), head cushion
and the backrest cushion connected by the Velcro as show in the illustration (2).
Zipper Thread gluing
Method of usageMethod of usage
·Put the heavy massage chairs on the wood floor for a may damage the floor,
so please place a carpet or other object to avoid this damage.
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in
a narrow space. Two people are required to lift the chair. During the lifting period,
take the calf rest end sealing plate and backrest cover grooves as the force-bearing
point(Please do not lift armrest directly.)
9.Floor Protection
10.Method of movement
·Make sure that all wires are far above the ground, tilt the backrest backward to
a certain degree (with the gravity center resting on the wheels), push the chair
forward or backward with your hands and finally resume the chair to the normal
position in a slow and gentle manner.
Note: During movement you must turn off the power first and then unplug the
power cord and the controller cord.
3 4

20
Product specification
Model: SL-A309
Configure: 8
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power input:120W
Rated time: 20Min
Safety structure: Class I
Material introduction: PVC, PA, steel parts and electric & electron parts
MATERIAL PU LEATHER CLOTH WOOD
