iRest A710-11 User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
A710-11 MASSAGE CHAIR

01
CONTENTS
Safety and Maintenance
Safety Warning
Name of Components
Function
Touch screen manual controller interface introduction
Method of Usage
I. Turn on the power supply of this product
II. Massage Function Control Operation
III. Introduction to Armrest Shortcut Keys
IV. Voice Control Mode
V. Turn off power, stop massage
VI. Installation Instructions for Armrests
VII. Installation Instructions for Legrest
VIII. Installation Instructions for Legrest
IX. Use of the shawl
X. Pillow Pad and backrest pad's dismounting and use manual
XI. Floor Protection
. Instruction for MovementⅫ
Legal notices
Product Specification
02-03
04-08
09
10-11
12
13
13
13-26
27-28
29
30
30-31
32-33
34
34
35
36
36
37
37
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our company reserves the right to change and explain the design of the
product. If there is some difference between the product function in market
circulation and the description in the manual, it is a normal update of the product,
and our company will not inform you otherwise. The specific product function and
color shall prevail in kind.

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product:
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
Safety Warning Safety Warning
Warning Warning
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
Warning
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
Warning
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.
No downward pressure

0706
Safety Warning Safety Warning
Warning
Before using the massage chair, remove any hard objects in your pocket(s) or any
jewelry carried with you (e.g. key, watch, other similar portable hard objects) to
avoid any damage to this product or physical injury during massage.
Warning
Do not unplug the power cord, or directly turn off the power switch on the back of
the massage chair during massage, in order to avoid any damage to this product or
physical injury.
Warning
Warning
Please do not fall asleep on the massage chair while using to avoid personal injury
caused by unconscious use.
The massage chair should not be used by more than two people at the same time to
avoid product failure or personal injury. In addition, do not let children play on the
massage chair or climb onto the lower leg, seat cushion, foot, backrest or armrest.
Otherwise, accidents or injuries may be caused.

0908
Safety Warning Name of Components
1
2
4
7
15
10
22
24
18
20
21
23
17
14
12
3
16
6
19
9
8
11
13
5
Warning
When adjusting the footrest retractable function or when footrest is declining, please
be sure not to put hard objects (such as keys, mobile phones, Etc.) or put the hand
into the gap of the footrest, and the intersection with the armrest; To avoid product
damage or personal injury caused during the process.
Warning
Before turning on the massage chair, check the surroundings to make sure
that there are no people, pets or other objects around the massage chair
Avoid damage to the product or other objects or personal injury during the
operation of the massage.
25 26
POWER INPUT ON /OF F
1. Head Cushion
2. 3D digital audio (built-in
voice control microphone
at the left side)
3. Negative Ion Generator
(right side)
4. Upper Arm Airbag
Assembly
5. Item Placement Slot
6. Touch Screen Controller
7. Touch Screen Controller
Bracket
8. Arm Airbag Assembly
9. Bump Massage Belt and
Magnetic Therapy
10.Upper Footrest
11. Lower Footrest
12. Shawl Assembly
13. Back Cushion
14. Mobile Phone
Wireless Charger
15. Armrest Shortcut Keys
16. Armrest
17. LED Mood Light
18. Armrest Decorative Part
19. Side Cover
20. Backrest Cover
21. PCB Box Cover
22. Caster
23. Power Cord
24. Power Input
25. Power Switch

10 11
FunctionFunction
·This product has designed a group of AI massage robots that can walk up and
down, stretch back and forth, and are silent in design.
·It is designed with the function of automatic detection and micro-adjustment of
shoulder position and the automatic detection function of human body curve and
Shiatsu point to automatically adjust the stretch back and forth of the robot
according to the detected human body curve and Shiatsu point, making massage
more humanized and scientific.
·There are four types of automatic massage scenes with different characteristics:
AI intelligent programs (Stress Relieving, Energy, Good-night Sleep, Joint Care,
Neck&shoulder care, Spine Massage), exclusive programs for the wise (Only for
White-collars, Exercise Conditioning, Relaxing Brain, Spine Care, Waist Care,
Legs Care), relaxing and activating programs (Healthy Charge, Meridian
Treatment, Keep Fit, Detox, Restoration Massage, Balance) and overall relaxation
programs (Full-body Stretch, Thai Massage, Chinese Massage, Total Relax,
Psychic Communion), 23 types of automatic massage programs.
·It has three intelligent storage functions: Custom 1, Custom 2 and Custom 3.
·It is provided with five message positions for manual selection, i.e. Full, Partial,
Spot, Upper and Lower.
·It is provided with manual massage functions: including 17 massage techniques
such as Knead (7 modes for switching cyclically), Tap (Tap I, Tap II), Knead &Tap,
Shiatsu (Shiatsu I, Shiatsu II), Grasp, 4D (4D I, 4D II, 4D III, 4D IV) for selection.
·It is provided with massage adjustment functions: including 7 massage adjustment
functions such as five-level back speed adjustment, five-level massage scope
adjustment, five-level massage width adjustment, pneumatic three-level intensity
adjustment, three-level roller speed adjustment and four-level massage time
adjustment.
·It is provided with pneumatic massage function: the arm pneumatic massage
function (8 built-in airbags), upper arm pneumatic massage function (4 built-in
airbags), three-level pneumatic intensity adjustment.
·It is provided with the lower body pneumatic massage function; the leg pneumatic
massage function (4 built-in airbags), foot pneumatic massage function (16 built-in
airbags), three-level pneumatic intensity adjustment.
·It is provided with a unique shawl assembly, with innovative heating functions on
the shoulder, back, waist and abdomen and heating with graphene. Users can
place the shawl at different massage positions according to massage
requirements. When the shawl assembly is placed at the shoulder position, it will
heat the acupoints such as Bingfeng, Tianzong, Yunmen and Qihu around the
shoulders and clavicle by graphene heating, effectively relieving symptoms such
as scapulohumeral periarthritis and coughs and removing cold and moisture from
shoulder joints; when the shawl assembly is placed on the abdomen and back
(dual-purpose), through graphene heating, plays the role of dispelling cold and it
relieving pain, warming channels and removing blood stasis in the back and
abdomen, distributing Qi and blood of the back and abdomen meridian, alleviating
the symptoms such as irregular menstruation and dysmenorrhea for women,
relieving low back pain and kidney discomfort, warming intestines and stomach
and clearing intestinal cold, with a good effect on some people with deficiency of qi
and deficiency of spleen and stomach.
·Slide rail technology is adopted for lying down of the backrest frame to always
make the backrest zero distance from the wall thus saving space to the greatest
extent.
·The guide rail of the backrest frame adopts curved guide rail technology, which
completely conforms to the back of the human body and makes people enjoy a
massage from the head to the thigh.
·It is provided with an intelligent voice control recognition function to control the
massage chair with voice.
·Music playing system, with built-in 3D digital audio in the left and right upper
arms. The Bluetooth function of intelligent devices can be used for wireless
connection to play music.
·Mobile phone wireless charging function is set at the shortcut key of the left
armrest and the mobile phone is placed in a fixed wireless charging position for
charging.
·The left armrest is provided with shortcut keys such as On/Off (Pause) key, 4D
intensity knob key, zero-gravity key, automatic mode key, voice control wake-up key,
foot rest telescopic key, leg rest telescopic key, seat-up key, seat-down key, etc.
·It is provided with adjustment functions between calf-up and calf-down, between
seat-up and seat-down, between zero-gravity 1 and zero-gravity 2.
·It is provided with calf kneading function: kneading and airbag squeezing around
the inside and outside of the calves, which can relieve the stiffness or tension of
the calf muscles caused by long standing.
·It is provided with foot roller massage function to scrape and massage mastoid at
the arch and toes.
·It is provided with ankle stretching function: use the airbag squeezing function of
foot rest and leg rest to fix the calf and feet by airbag tension, and then stretch the
ankle by stretching the foot rest up and down, effectively alleviating muscle
stiffness, leg muscle soreness and ankle strain after long-term walking and
strenuous exercise.
·It is provided with leg traction massage function: the calf and backrest are lifted to
form automatic lying down in a cyclic manner. At the same time, the lower leg air
compression and the back manipulators cooperate together to massage, and the
legs can be stretched for traction massage.
·The foot rest has the function of automatically detecting the plantar position.
When the calf frame rises or falls to a proper angle, the foot rest will automatically
detect the plantar position.
·The foot rest is provided with an electric telescopic adjustment function, which can
adjust the telescopic distance according to the leg length of the user to achieve
the most comfortable massage position and length for the foot.
·It is provided with a bump massage belt and magnetic therapy function in the left
and right palm airbags.
·The left space capsule is provided with a voice control microphone and the right
side of the head is provided with a negative oxygen ion generator.
·It is provided with a 7-inch TFT colored touch screen controller.
·It is provided with LED mood lights at the left and right armrest.
·Automatic sit-up function when the power is off and manipulator automatic reset
function.

1312
Method of UsageTouch screen manual controller interface introduction
Touch screen remote controller introduction
Note: The touch screen remote controller displays the color, massage function
and massage function icon layout order, please refer to the physical display!
1.Bluetooth switch and display
2.Time adjustment button and display
3.The status bar
4.The shoulder position can be adjusted up and down
5.Massage status information display
6.Air pressure intensity display
7.Manual, intelligent storage, angle adjustment, settings and other massage function keys
8.The power switch
9.Automatic massage function
10.Massage switch
11.4D massage function keys
12.Operation / pause button
1)、Start to massage
Ⅰ、Switch power supply on
Ⅱ、Massage function control operation
Diagram of plug in Diagram of line
Diagram of the switch
position of power supply
·After the massage chair cannot enter any mode operation in standby mode.
·Press “Power” button to start massage, enter the boot screen, backrest maintains
the default position, calf rest raises slightly, choosing certain auto mode to start
massage (Auto mode or memory function can be selected). The massage chair
will shut down automatically if auto mode is not selected within 5 minutes.
POWER INPUT
ON/ OFF
POWER INPUT
ON/OFF
·VIP Auto Program: Stress Relieving, Energetic Morning, Good-night Sleep, Joint
Care, Neck&shoulder care, Spine Massage.
·Healthcare Auto Program: Office Regimen, Sport Recovery, Brain Refresh, Spine
Care, Waist Care, Legs Care.
·Special Auto Program: Health Recharge, Meridian Treatment, Keep Fit, Bottom
Toning, Restoration Massage, Tiredness Relief.
·Relaxation Auto Program: Full-body Stretch, Thai Massage, Chinese Massage,
Total Relax, Airbag.
2
06
Upper Air Lower Air
Manual Customise
Angle Setting
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
16min
Waist Care
12
1
6
7
8
9
10
11
5
3
2
4
Stress Relieving Energy
Good-night Sleep Joint Care
Neck&shoulder care Spine Massage
VIP
Healthcare
Special
Relaxation
Customise
Select an automatic function to start the massage

1514
Method of usage Method of usage
06
·Upon completion of scan, a beeping sound will emitting from the chair for 10
seconds or press the enter button, the massage heads will gently roll on your
shoulders. During this period, if you would like to further adjust the detected
shoulder region, you can do so by depressing the up or down shoulder button.
There are 11 levels adjust position. If fail to detect, automatically operate the
default massage point.
Please adjust the position of the shoulder......
06
ShoulderPositionAdjust
OK
OK
·Position too low
·Proper position
·Position too high
Buttons Description
Press to adjust the massage heads higher.
Press to adjust the massage heads lower.
2)、The pause button
·While the massage function is operate, press the “Pause” button to temporarily stop
all massage functions; Press the “Pause” button again to continue the massage. If
the pause time exceeds 20 minutes, all massage functions are automatically turned
off.
Pause
Massage function pause Massage function operation
Run/pause Button Functional description
Pause
Operation
In the operation state, press this button to pause all current
massage functions.
In the pause state, press this button to continue the massage
function before the pause
·Under the massage information interface, click the “ ” or “ ” button on the
3D icon to adjust the massage intensity of the upper back muscles, Five levels
intensity.
3)、Upper body massage strength (4D key)
Speed
1 level 2 level 3 level 4 level 5 level
Note:
·Massage strength: 4D massage strength, that is, the massage head is extended
forward or the whole is retracted. The strength of the massage is adjusted to the
strength within a certain massage area. Detect acupressure points, the strength of
each massage point can be tested. You can adjust the strength of a certain
massage point with this button in both automatic and manual conditions.
Auto lying down
Justamoment......
Body sensing progress
16min
Waist Care
2
06
Upper Air Lower Air
Manual Customise
Angle Setting
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
16min
Waist Care
2
06
Upper Air Lower Air
Manual Customise
Angle Setting
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
·When you select any of the automatic modes, the backrest and calf position will
be adjusted to the set angle.
·After adjusting the angle, the massage chair will automatically proceed detection
of your shoulder position and acupressure points (Note: There is only shoulder
position detection when in Frozen Shoulder program, while the others are whole
body detection.). If the scan uncompleted, you press the “ ” button to skip the
detection, automatically operate the default massage mode.

1716
4)、Automatic function
Method of usage Method of usage
·There are four different automatic massage scenes in Auto mode:
·VIP Auto Program: Stress Relieving, Energetic Morning, Good-night Sleep, Joint
Care, Neck&shoulder care, Spine Massage.
·Healthcare Auto Program: Office Regimen, Sport Recovery, Brain Refresh,
Spine Care, Waist Care, Legs Care.
·Special Auto Program: Health Recharge, Meridian Treatment, Keep Fit,
Bottom Toning, Restoration Massage, Tiredness Relief.
·Relaxation Auto Program: Full-body Stretch, Thai Massage, Chinese
Massage, Total Relax, Airbag. There are 23 automatic massage functions
in total. Click the “auto” icon to select the automatic massage, when in
automatic massage, the speed and width can not be adjusted.
·Press “more" icon to select the corresponding automatic massage function.
Function Description
Auto mode
VIP
Special
Relaxation
Relieve fatigue and relax muscle, improve microcircu-
lation of back & limbs and quickly relieve stress.
Stress
Relieving
Energy
Good-night
Sleep
Joint Care
Spine
Massage
The body gets rest after one night sleeping. Quickly
wakeup all the body functions by massaging whole
muscle to start a fresh day.
It helps balance your body, quickly improve sleep
quality by massaging the 12 health acupoints.
Care for the health of all joints by pushing, pulling,
stretching and other massage modes
Massage each spine to protect its health, alleviate
slipped disc.
Legs Care
Healthcare
Office
Regimen
Sport
Recovery
Brain
Refresh
Spine Care
Waist Care
Increase physical exercise by massage, improve the
body functions of Office Sedentary.
Restoring physical fatigue quickly of after-exercise-body.
Relieve neck and shoulder pain, promote blood supply
to the brain by massaging YUZHEN and DAZHU points.
Care for the health of spine and improve the lack of
exercise.
Focus on improving spine health and relieving stiffness
in the waist muscles.
Quickly relieve the soreness and muscle fatigue in
lower body.
Improve the quality of nap and work efficiency.
Health
Recharge
Meridian
Treatment
Keep Fit
Bottom
Toning
Restoration
Massage
Tiredness
Relief
Dredge the meridians, improve the body's microcirculation
and immunity quickly。
Effectively massage buttocks and legs to shaping the
body, reduce the accumulation of body fat.
Improve overall blood circulation of body to enhance
vitality and immunity.
Wake up all body functions quickly, replenish physical
strength and restore fatigue by massaging the 12
health acupoints.
Relieve fatigue, restore vitality, clean the blood lactic
acid produced after exercise.
Full-body
Stretch
Thai
Massage
Chinese
Massage
Total Relax
Airbag
Stretch the body to increasing its flexibility by Thai
massage.
Comprehensively relieve fatigue and soreness through
a deep massage for whole body.
According to the traditional Chinese medicine theory,
balance the body function to achieve physical fitness
and remove the disease.
Total Relax, soothing massage the whole body by
kneading and tapping to relieve fatigue.
Focusing on body pressure massage, it can fully relax
the body, restore fatigue, and calm the nerves.
16min
Waist Care
206
Upper Air Lower Air
Manual Customise
Angle Setting
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
Neck&
shoulder
care
The unique massage mode for neck and shoulder,
relieve neck and shoulder pain and improve blood
supply in the brain.
16min
Waist Care
2
06
Upper Air Lower Air
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
VIP Auto Program
VIP
Healthcare
Special
Relaxation

1918
·Under the manual massage function interface, select the manual massage
technique, back stretch, speed and width adjustment.
·Manual (manipulation): includes six different massage techniques: knead, tap,
knead & tap, shiatsu, 4D, and shoulder. In the state of tap and shiatsu massage,
the width of the massage ball of the robot is adjustable. The massage speed can
be adjusted in other massage techniques except for stopping. You can also close
the manual massage interface by clicking the " " icon.
5)、Manual
01)、Manual - manipulation
02)、Manual - back stretching
Method of usage Method of usage
·Click the “ ” icon to enter the manual massage function selection interface,
including manual, manual strength and width, back stretch, upper airbag massage,
lower air bag massage, calf squeeze, foot rollers, Negative oxygen ions, heat and
other massage functions.
·Click the “ ” icon to close the manual massage interface.
Manual massage function selected interface Manual massage function interface
Speed
Width
Manual massage function - manual interface
Speed- Speed+
Width- Width+
1 level 2 level 3 level 4 level 5 level
1 level 2 level 3 level 4 level 5 level
·Manual (massage area): includes massage functions such as fixed, partial, overall,
upper back, and lower back.
·Click on the corresponding stretch mode icon to select the personalized massage
function. You can also close the manual massage interface by clicking the " " icon.
Manual massage function - back stretching interface
Manual
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Lower
Air
Foot
Roller
Spe ed+
Width+
Upper
Air
Full Upper Lower
Calf
Knead
06
Upper Air Lower Air
16min
Waist Care
Tap
Knead&Tap
Spot
开启 O FFON
-Ion Heat
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Lower
Air
Foot
Roller
Upper
Air
Full Upper Lower
Calf
Knead
Speed+
Width+
06
Upper Air Lower Air
16min
Waist Care
Tap Knead&Tap
Spot
开启 O FFON
-Ion Heat
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Lower
Air
Foot
Roller
Spe ed+
Width+
Upper
Air
Full Upper Lower
Calf
Knead
06
Upper Air Lower Air
16min
Waist Care
Tap
Knead&Tap
Spot
开启 O FFON
-Ion Heat
Note: In 4D massage technique mode, the width of 4DⅠ and 4DⅡ cannot be
adjusted; the width of 4DⅢ and 4DⅣ can be adjusted.
Kneading(Seven modes of
kneading can be switched cyclically)
Tapping(Tapping I, Tapping II)
Function
Description
Shiatsu(Shiatsu I, Shiatsu II)
Simultaneous kneading and tapping
Shoulder lifting
4D(4D I, 4D II, 4D III, 4D IV)
Speed, Intensity
Speed, Width, Intensity
Speed, Intensity
Speed, Width, Intensity
Speed, Intensity
Speed, Width, Intensity
·5 Speed levels
adjustable
·5 Width levels
adjustable
·5 Intensity levels
adjustable
16min
Waist Care
206
Upper Air Lower Air
Manual Customise
Angle Setting
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More

2120
·Manual (air pressure): includes upper body airbag pressure and lower body air pressure
massage function. Click the air pressure function icon to turn the air pressure massage
function on or off. Adjust the intensity by clicking the " " or " "button. You can also
close the manual massage interface by clicking the " " icon.
Function Description
Point
Local
Upper back
Lower back
overall
Upper adjust
Lower adjust
Press button once, a single dot appears in the display. Massage
apparatus will stay stationary.
Press button again, two arrows appear. Massage apparatus will
move in an approximately 3 inch range.
Round back massage.
Round back massage.
Full back massage.
Press and hold to move the range of the massage area up in the
Fixed or Partial Position.
Press and hold to move the range of the massage area up in the
Fixed or Partial Position.
03)、Manual - air pressure massage
Manual massage function - air pressure
selection interface
In the upper body air pressure or lower body air
pressure open state, you can adjust the air
pressure massage three level strength.
Speed
1level 2level 3level
Function Description
Upper Air
Lower Air
Turn the upper body air pressure massage function on or off.
Turns the lower body air pressure massage function on or off.
04)、 Manual - calf squeeze
ModeⅠModeⅡModeⅢ
Calf squeeze massage mode
Forward Reverse Positive
inversion
After opening calf squeeze massage
function, adjust positive and negative
rotation massage function.
Manual massage function – the calf
squeeze interface
Function Description
Press the switch on or off the calf squeeze massage function.
05)、Manual - foot rollers
Speed
Manual massage function - foot rollers
selection interface
1level 2level 3level
Function Description
Press the switch on or off the foot rollers massage function.
Foot
Roller
· Select to turn the calf massage function on or off by pressing the “ ” button;
There are three different calf massage modes. Adjust the calf massage mode by
clicking the " " or " " button.
·Click the “ ” icon to close the manual massage interface.
Calf
Knead
Calf
Knead
· By Pressing “ ” to select switch on or off the foot rollers massage function. Click
“ ” or “ ” to adjust the speed of the roller. The speed can be adjusted in three
levels. You can also click “ ” icon to close the manual massage interface.
Foot
Roller
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Foot
Roller
Spe ed+
Width+
Full Upper Lower
Calf
Knead
Upper
Air
Lower
Air
06
Upper Air Lower Air
16min
Waist Care
Tap Knead&Tap
Spot
开启 O FFON
-Ion Heat
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Lower
Air
Foot
Roller
Spe ed+
Width+
Upper
Air
Full Upper Lower
Calf
Knead
06
Upper Air Lower Air
16min
Waist Care
Tap
Knead&Tap
Spot
开启 O FFON
-Ion Heat
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Full Back Upper Back Lower Back Partial
Lower
Air
Spe ed+
Width+
Upper
Air
Foot
Roller
Calf
Knead
06
Upper Air Lower Air
16min
Waist Care
Tap Knead&Tap
Spot
开启 O FFON
-Ion Heat
Method of usage Method of usage

2322
06)、Manual-negativeoxygenion
·Click the “Negative Ions ” button to select switch on or off the negative
oxygen ion massage function. You can also click the “ ” icon to close the manual
massage interface.
ON
Manual massage function -
Negative Ions selection interface
Function Description
Press this button switch on or off the negative oxygen ion function.
Negative oxygen ion
ON
07)、Manual-backheating
·Click the “Heat ” button to turn on or off the heating function of the cape
(graphene heating) . it will be warm 3 minutes after the heating function is turned on
·Click the “ ” icon to close the manual massage interface.
ON
Manual massage function -
heating selection interface
Function Description
ON
2
06
Upper Air Lower Air
16min
Waist Care
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Lower
Air
Foot
Roller
Spe ed+
Width+
Upper
Air
Full Upper Lower
Calf
Knead
开启 O FFON
-Ion Heat
Tap
Knead&Tap
Spot
4D
Ⅳ
Ⅱ Ⅱ
Manual Mode
Knead Shiatsu Grasp
Speed-
Width-
Partial
Lower
Air
Foot
Roller
Spe ed+
Width+
Upper
Air
Full Upper Lower
Calf
Knead
06
Upper Air Lower Air
16min
Waist Care
Tap
Knead&Tap
Spot
开启 O FFON
-Ion Heat
· Click the “ ” button icon to enter the program memory massage function
selection interface, including program memory I, program memory II, program
memory III and other storage or recall functions.
·Select to the storage or recall massage function by clicking on it.
·Storage: Store all current massage methods, air pressure, angle, and other
massage functions.
·Call: Call the previously stored technique, air pressure, angle, and other massage
functions.
·Click the “ ” icon to close the program memory massage interface.
6)、Customise
Customise
Program memory selection interface Program memory interface
7)、Angularadjustment
Angle
Angle adjustment selected interface Angle adjustment interface
2
06
Upper Air Lower Air
Ⅱ
Ⅰ
Ⅲ
Ⅰ
ⅡⅢ
Customise
Save
Use
16min
Waist Care
·Click the “ ” button icon to enter adjustment interface, including massage
function of linkage sitting, linkage lying, calf rise, leg down, zero gravity, leg
stretch, and foot stretch.
·Click the “ ” icon to close the angle adjustment interface.
Method of usage Method of usage
Ang le adju stmen t
Foot Adjust
Seat-Up
Seat-Down
Calf-UP
Calf-Down
Press this button to turn on or off the heating function.
206
Customise
Angle Setting
Upper Air Lower Air
16min
Waist Care
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
Manual
206
Customise
Angle Setting
Upper Air Lower Air
16min
Waist Care
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
Manual

2524
02. Lying angle adjustment
Function Description
Calf-Up
Calf-Down
Leg up key: Press and hold to raise the calf unit independently of the
backrest, release to stop; After the calf rest up is completed, the calf
frame will automatically detect the length of the foot.
Leg down key: Press and hold to lower the calf unit independently of
the backrest, release to stop; After the calf rest down is completed, the
calf frame will automatically detect the length of the foot.
Seat-down
Seat-up
01). Zero gravity adjustment
Function Description
Zero gravityⅠ: Automatically adjust the calf and backrest position to
zero gravityⅠposition.
Zero gravityⅡ: Automatically adjust the calf and backrest position to
zero gravityⅡposition.
8)、Settings
· Click the “ ” button icon to enter the setting selection interface, including backlight
brightness adjustment, sleep time adjustment, button volume switch, serial number,
language selection and other settings.
·Click the “ ” icon to close the settings interface.
Setting
Setting selection interface Setting interface
201804150001
English
1Min 3Min 10M in 3 0M in
Setting
Brightness
Sound
Language
S/N
Chine se
Auto-Lock
02)、Auto-Lock
03)、Sound
04)、Language
05)、S/N
·Select brightness slider and slide left and right to adjust the backlight brightness.
·Select lock screen button and make choice with 1 minute, 3 minutes, 10 minutes or
30 minutes.
·Click the “ ” icon to turn off the button volume, and click “ ” to turn on the
button volume.
·Language selection
·Displays information such as current equipment.
01)、Brightness
Method of usage Method of usage
Seat-up key: press and hold this key to slowly rise the backrest frame
while slowly lowering the calf frame, and release it to stop rising of the
backrest frame or lowering of the calf frame; after the seat-up action is
completed, the calf frame will automatically detect the foot length.
Seat-down key: press and hold this key to slowly lower the backrest
frame while slowly rising the calf frame, and release it to stop lowering
of the backrest frame or rising of the calf frame; after the seat-down
action is completed, the calf frame will automatically detect the foot
length.
Function Description
Foot rest shortening key: manually adjust shortening of the foot rest;
press and hold this key to move the foot rest up slowly and stop when
released.
Foot rest extension key: manually adjust extension of the foot rest;
press and hold this key to move the foot rest down slowly and stop
when released.
03). Footrest Stretch adjust
Manual Customise
Ang le Setting
206
Upper Air Lower Air
16min
Waist Care
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More

·Click the “ ” icon to adjust the massage time function. Each time you press it,
it will add 5 minutes. It cannot exceed 40 minutes. If it exceeds 40 minutes, it will
return to 5 minutes.
·Click the “ ” icon to switch on or off Blue tooth. “ ” is to switch off the Blue
tooth status, and “ ” is to switch on the Blue tooth status.
·After the Blue tooth-enabled audio source device (such as mobile phone, MID
tablet, etc.) is paired with the massage chair Blue tooth module, the music played
by the audio source device can be wirelessly transmitted to the massage chair
audio system for music playback via Blue tooth.
9)、Bluetooth
10)、Timeadjustment
16 min
Method of usage
Blue tooth switch
Blue tooth
off state
Blue tooth
on state
Blue tooth interface not enabled
Attentions: When controlling the Blue tooth switch, you should return to the main
information control interface. If you are in the manual, angle adjustment or custom
storage control interface, Blue tooth can't be controlled.
Time Setting
Time adjustment interface
Attentions: When adjusting the time, you should return to the main information
control interface. If you are in manual, angle adjustment or custom storage control
interface, the time cannot be controlled.
16min
Ease Ache
16min
Ease Ache
16min
Ease Ache
Method of usage
1
2
3
4
5
6
7
8
9
10
4D
III.Introduction to Armrest Shortcut Keys
1. 4D Intensity rotation button: adjust the massage intensity of the 4D manipulator.
2. On/Off key: Turn on (short press to pause) or off the massage chair.
3. Zero Gravity key: adjust massage chair to the zero gravity angle.
4. Extension adjustment of the foot rest: extend the foot rest by adjustment.
5. Shortening adjustment of the foot rest: shorten the foot rest by adjustment.
6. Wireless Charging: Mobile Phone Wireless Charger.
7. Auto key: Adjust the automatic massage function, and cyclically switch the automatic
function every time you press it.
8. Voice Control Wake-up key: Short press this key to wake up the voice control, long
press for 3 seconds to turn on/off the voice control function.
9. Linkage Lying key: adjust the linkage lying angle.
10. Linkage Up key: adjust the linkage up angle.
2726
Manual Customise
Angle Setting
206
Upper Air Lower Air
16min
Waist Care
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More
Manual Customise
Angle Setting
206
Upper Air Lower Air
16min
Waist Care
Stress Relieving
Energy
Good-night Sleep
Joint Care
Neck&shoulder care
Spine Massage
Thai Massage
More

4D
Method of usage Method of usage
Function Description
On/Off key: short press this key to suspend operations and press it for
3 seconds to turn it on and off. If the pause lasts for more than 20
minutes during massage, all massage functions will be automatically
turned off.
4D intensity knob key: Adjust the massage intensity of 4D manipulator
(weakened when rotating counterclockwise, enhanced when rotating
clockwise), and the intensity ranges from Level 1 to Level 5.
Zero-gravity key: each time the key is pressed, the position of the calf
frame and backrest frame will be automatically adjusted to the
zero-gravity position. There are two zero-gravity lying modes, which can
be switched in cycles.
Footrest shortening key: manually adjust the Footrest shortening;
Press this key to slowly shorten the movement of the Footrest up,
release to stop.
Footrest elongation key: manually adjust the Footrest elongation;
Press this key to slowly extend down the Footrest to move, release
to stop.
Auto Mode key: Switch the automatic massage function every time
you press it.
Voice Control Wake-up key: Short press this key to wake up the voice
control, long press for 3 seconds to turn on/off this function.
Seat-up key: Press and hold this key to slowly rise the backrest frame
while slowly lowering the calf frame, and release it to stop rising of the
backrest frame or lowering of the calf frame; after the seat-up action is
completed, the calf frame will automatically detect the foot length.
Seat-down key: press and hold this key to slowly lower the backrest
frame while slowly rising the calf frame, and release it to stop lowering
of the backrest frame or rising of the calf frame; after the seat-down
action is completed, the calf frame will automatically detect the foot
length.
2928
IV. Voice Control Mode
·When the massage chair is turned on or in standby mode, the sound “Hi Alice” or “Hey
Alice” will be produced to enable the voice control function.
·Long press zero gravity button of remote controller for 3 seconds to turn on or off this
function.
·After such function is enabled successfully, the massage chair will reply "I am here". At
this moment, once a corresponding voice control entry to be implemented is given within
six seconds, the corresponding voice control function can be performed after
a reply is received from the massage chair; if no correct voice control entry is given
within six seconds, the voice control function automatically will be off automatically and
needs to be enabled again.
·Note: When the voice control function is enabled, . The speaking please use English
speed cannot be too fast. The speech instruction should be issued according to the
voice control entry.
Note: commands 14 and 15 can only be used after command 13.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No.
Massage on
Massage close
Comfort Massage
Relax massage
Full body massage
Neck and shoulder massage
Back and waist massage
Stretch massage
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Change the other mode
Go little down
Go little up
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok, full body massage
Answer: Ok, neck and shoulder massage
Answer: Ok, back and waist massage
Answer: Ok, stretch massage
Answer: Ok, open the air pressure
Answer: Ok, close the air pressure
Answer: Ok, up the seat position
Answer: Ok, down the seat position
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Voice Control Entry
Entry: “Hi Alice” or “Hey Alice”. Answer: I am here.
Voice control entry Answer entry

3130
Method of usage Method of usage
·In the process of massage, press the power switch key to immediately turn off all
massage functions, the backrest and the calf are reset, the massage time is up,
and all massage functions are immediately turned off, and the backrest and the
calf are not reset.
·Cut off the power supply of the whole machine, the figure (schematic diagram of
the whole machine power cut).
Schematic diagram of the whole machine power turning off.
Schematic diagram of unplugging the whole machine wiring.
Schematic diagram of unplugging the power plug.
1. Find out the connector and air tube from the bottom of the seat frame and pass
out from the middle of the seat frame (Figure 1).
2. Take out the armrest from the package and make the connector and air tube on
the armrest correspond to the connector and air tube at the bottom of the seat
frame one by one (butt joint according to the mark on the physical butt joint line)
(Figure 2).
Figure 1 Figure 2
Figure 3 Figure 4
3. The connector and air tube on the armrest are inserted into the connector and air
tube at the bottom of the seat frame, which should be in place and firm (Figure 3).
4. After the air tube and connector are docked, insert them into the bottom of the
seat frame and take care to avoid the air tube from being folded (Figure 4).
5. Hold the armrest with both hands, first hook the front end of the armrest, hang it
in the seat frame steel and press down the front end of the armrest. (Figure 5)
6. Then, align the male buckle on the rear end of the armrest with the female buckle
on the capsule, insert the rear end of the armrest into the female buckle of the
capsule and snap it tightly (note that the fit gap of the armrest capsule should be
even). (Figure 6)
Figure 5 Figure 6
7.Fix the rear end of the armrest tightly with a M6*20 screw (Figure 7).
8.Pull the upper arm holster away and fix it with a M6*20 screw (Figure 8);
Figure 7 Figure 8
9. Align the mounting holes that fix the steel frame at the front end of the armrest,
and then use the provided 4# Allen wrench to fix and tighten the armrest and the
seat frame steel piece with two M5×14 black zinc environmental friendly hexagon
socket head cap screws and a 6×12×1.5 black zinc environmental friendly flat pad
(Figure 9).
10. Install the screw hole plug at the back end of armrest (Figure 10).
Figure 9 Figure 10
V. Turn off power, stop massage
VI. Installation Instructions for Armrests
POWER INPUT
ON/ OFF
POWER INPUT
ON/OF F

3332
Method of usage Method of usage
3
3. Firstly, insert the rotating inner sleeve and the rotating outer sleeve into the left
and right rotation shafts of the legrest (Note: The large step must face inward)
(Figure 3).
4. Then remove the rotation shaft cover supporting the legrest on the left and right
frames of the massage chair (Figure 4).
4
1.First of all, cut the connection wire and the air pipe tie fixed on the steel pipe
(Figure 1).
2.Connect the connection wire and the air pipe leading from the lower end of the
backrest to the legrest connectors. Confirm whether butt connection is OK. Then
insert the butt connection wire and air pipe into the bottom of the frame from the
lower hole of the backrest. Pay attention to avoiding any air pipe bending during
insertion (Figure 2).
1 2
56
5.Next, hang the legrest (left and right rotation shafts) into the rotation shaft cover
supporting such frames simultaneously (Figure 5).
6.Place the rotation shaft cover. Press the rotating outer sleeve of the legrest. Then
tighten the rotation shaft cover supporting the legrest with two M5×14 black zinc
environmentally-friendly hexagonal socket head screws and a 6×12×1.5 black
zinc environmentally-friendly flat pad by the supplied 4# hex wrench (Figure 6).
7. After the screws are tightened, hook the groove at the back end of the legrest
cover to the hinge pin. Then press down the front end of the legrest cover to make
it completely parallel to the rotation shaft cover. Hook the convex point at the side
of the legrest cover to the hole at the side of the legrest hook. Finally, the legrest
is installed (Figure 7)
7
VII. Installation Instructions for Legrest

3534
1. Align the positioning column of the bracket assembly with the positioning hole of
the armrest bracket support plate and lock it with 3 cross-recessed screws
(Figure 1).
2. Then fasten the decorative cover of the support (Figure 2).
Heating area
Heating area
Magnet area (only for fixing)
Method of usage Method of usage
Figure 1 Figure 2
Schematic diagram of back
and waist
Schematic diagram of shoulder
and abdomen
12
Zipper Zipper
VIII. Installation Instructions for Legrest
IX. Use of the shawl
X. Pillow Pad and backrest pad's dismounting and use manual
·It is provided with a unique shawl assembly, with innovative heating functions on
the shoulder, back, waist and abdomen and heating with graphene. Users can
place the shawl at different massage positions according to massage
requirements. When the shawl assembly is placed at the shoulder position, it will
heat the acupoints such as Bingfeng, Tianzong, Yunmen and Qihu around the
shoulder and clavicle by graphene heating, effectively relieving symptoms such
as scapulohumeral periarthritis and cough, and removing cold and moisture from
shoulder joints.
·When the shawl assembly is placed on the abdomen and back (dual-purpose),
through graphene heating, it plays the role of dispelling cold and relieving pain,
warming channels and removing blood stasis in the back and abdomen,
distributing Qi and blood of the back and abdomen meridian, alleviating the
symptoms such as irregular menstruation and dysmenorrhea for women, relieving
low back pain and kidney discomfort, warming intestines and stomach and
clearing intestinal cold, with a good effect on some people with deficiency of qi and
deficiency of spleen and stomach.
·Using head cushions can reduce the kneading massage intensity on neck
andshoulder, according to your needs to decide whether the head cushions
isneeded (recommend head cushions). Backrest cushion and backrest connected
by zipper (1), head cushions and backrest pad connected by zipper (2).

3736
Method of usage
Product specifications
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in
a narrow space. Two people are required to lift the chair. During the lifting period,
take the calf rest end sealing plate and backrest cover grooves as the force-bearing
point(Please do not lift armrest directly.)
·Put the heavy massage chairs on the wood floor for a may damage the floor, so
please place a carpet or other object to avoid this damage.
·Make sure that all the wires are pulled away from the massage chair surface;
then press the backrest down to a certain angle (with the center of gravity resting
on the wheels), you can push the massage chair forward with hands, move it to a
suitable position and gently restore it to the normal angle. (Note: During
movement, you must turn off the power button first and then unplug the power
cord and the remote controller connection wire).
Warning : The rear moving wheels of the massage chair are only suitable for short-
distance and slow movement. For long-distance transportation, please use other
auxiliary moving tools to move this massage chair!
Model: SL-A710
Configure: 11
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power:220W
Rated time: 20min
Safety structure: Class I
Material description: PVC, PA, steel parts, electric and electron components
MATERIAL PU LEATHER CLOTH WOOD
XI. Floor Protection
Ⅻ. Instruction for Movement
Legal notices
FCC Information
·Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
·This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
·This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20cm between the radiator & your body. This transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter.
