iver IV007 Configuration guide

*Image used for illustration purposes only.
Install
Instructions
Backplate
Passage Set
Standard
—
Australia
14 - 16 Stepney Street,
Stepney, South Australia 5069
P: [phone]
[e-mail]
iver.com.au
SDG Trading Pty Ltd
trading as Iver
ACN 008 154 041 | ABN 18 008 154 041
Contact Us
Southern Design Group
New Zealand
P: [phone]
[e-mail]
iver.co.nz
Scan for
Product &
Finish Care
Information
Scan for NZ
Warranty
Scan for AU
Warranty

1.1. Mark the edge of
your door at the
desired height
of your lever.
1.2. We recommend
around 900mm –
1100mm from
oor level, or at the
centre of a lock rail
on a panel door.
(Figure 1)
1. Marking
the Door
Preferred product height
Figure 1.
3.1. If required, shorten tie bolts to suit door thickness.
3.2. Ensure to cut so that the screw does not protrude
from the opposite plate once installed. (Figure 3)
3. Prepare Tie Bolts
— if using face x timber screws, proceed to step 4
2. Install Latch & Striker Plate
As per supplier instructions, resources available
at iver.com.au/resources.
Figure 2.
1.3. Using a spirit level, mark
the door at the desired
lever height, continuing the
line from the front of the
door, around the edge and
onto the back of the door.
(Figure 2)
1.4. We recommend extending
the line 100mm onto each
face of the door.
4.1. Place the split spindles into the lock body from
either side of the door*.
4.2. Install the halves on either side of the door,
ensuring the levers function in the correct direction.
4.3. Insert male tie bolts through top and bottom of
back plate, OR
4.4. Ax wood screws at all xing points.
4.5. Place the female sections in the opposite holes,
lining them up with the male thread.
4.6. Secure loosely by hand, then use a screwdriver
to hold the female section while tightening the
male section with a second screwdriver. (Figure 4)
—
* Regular spindle also provided
Figure 3.
(2)
4. Install Levers
Wood Screws
Figure 4.
(1)
(2)
(4)
(3)

Included: Not Included:
PLEASE NOTE:
The screws provided with Iver
products are made from solid
brass. This allows nishes to be
matched as closely as possible
and prevents the possibility of
screws rusting in coastal areas.
Please note that screws require
pre-drilling.
Please take extra care
when tting.
1.
2. (or 3.)
4.
Backplate Passage
Set Standard
1. Backplate
Passage
Lever Set
2. Tie Bolts
3. Wood Screws
4. Split Spindle
5. Standard
Spindle
IMPORTANT:
Please install this door
hardware in the following
order to ensure its warranty
is not voided.
1. Install the door hardware
on raw / unnished door
using the instructions
provided.
2. Remove door hardware
and store safely. Do not
place painters tape or
masking tape over the
product. The tape will
damage the nish.
3. Paint / nish door.
4. Reinstall hardware.
Please recycle
me after use
