iver IV013 Configuration guide

*Image used for illustration purposes only.
Install
Instructions
Rose Inbuilt
Privacy Set
Australia
14 - 16 Stepney Street,
Stepney, South Australia 5069
P: [phone]
[e-mail]
iver.com.au
SDG Trading Pty Ltd
trading as Iver
ACN 008 154 041 | ABN 18 008 154 041
Contact Us
Southern Design Group
New Zealand
P: [phone]
[e-mail]
iver.co.nz
Scan for
Product &
Finish Care
Information
Scan for NZ
Warranty
Scan for AU
Warranty

1.1. Mark the edge of
our door at the
desired height of
your lever.
(Figure 1)
1.2. We recommend
around 900mm –
100mm from
oor level, or at the
centre of a lock rail
on a panel door.
1. Marking
the Door
Preferred product height
Figure 1.
2. Preparing the Door
2.1 Ax supplied tube latch privacy template to your
door in the location marked in step 1.1
2.2 As per template drill an 18mm hole to accommodate
spindle, ensure to drill from either side of the door to
avoid splitting the timber.
2.3 As per template, using your preferred method
drill mortice hole of H25 x W23 x D77mm on edge
of the door.
Figure 2.
1.3. Using a spirit level, mark
the door at the desired
lever height, continuing
the line from the front of
the door, around the edge
and onto the back of
the door. (Figure 2)
1.4. We recommend extending
the line 100mm onto
each face of the door.
3.1. Insert the tube latch privacy with face plate and
mark around the edges with a stanley knife.
3.2 Using your preferred method create a 4mm recess
to accommodate the privacy latch and faceplate.
3.3 Insert the tube latch privacy and face plate unit and
pre-drill 2mm pilot holes at 6 and 12 o’clock.
3.4 Install tube latch privacy and face plate with
provided screws.
3.5 Please note to change tongue direction pull out and
rotate 180 and release.
3. Install Tube Latch Privacy & Face Plate
4.1. Using preferred method create a W22 x H32mm
cavity to a minimum depth of 12mm on the door edge.
4.2 Remove dust and insert dust box.
4.3 Place striker plate over cavity and mark around the
edges with a stanley knife.
4.4 Using your preferred method create a 4mm recess
to accommodate the striker plate.
4.5 Insert dust box and striker plate.
4.6 Drill two 2mm holes for striker plate screws at
6 and 12 o’clock and install screws.
4.7 Tighten manually with a screwdriver.
4. Install Dust Box & Tube Latch Privacy
Striker Plate
Figure 3.
(6)
5.1. If required, shorten cut-o screws to suit door
thickness.
5.2. Ensure to cut so that the screw does not protrude
from the opposite rose once installed. (Figure 3)
5. Prepare Cut-o Screws
if using face x timber screws, proceed to step 6
6. Install Tube Latch Privacy Spindle
6.1. Place the tube latch privacy spindle (provided with
the tube latch) through the latch follower. (Figure 4)
6.2 Roll rubber stopper over opposite end until it locates
within the groove. (Figure 5)
7.
Figure 4.
Figure 5.
7.1 . Remove the outer roses from the door lever set and
install the halves on either side of the door, ensuring
the levers function in the correct direction.†
7. 2 Insert two of the cut-o screws through non-
threaded holes of the inner rose at 12 and
6 o’clock, screwing them into the opposite rose.
Repeat at 3 or 9 o’clock, depending on location
of privacy pin, OR (Figure 6)
7. Install Levers
1. 7.
6. (or 5.)
Figure 6.
† For Helsinki lever unscrew end cap to remove and t rose.

Included:
Not Included:
PLEASE NOTE:
The screws provided with Iver
products are made from solid brass.
This allows nishes to be matched
as closely as possible and prevents
the possibility of screws rusting
in coastal areas. Please note that
screws require pre-drilling.
Please take extra care
when tting.
8. Privacy Turn
Wood Screws
7. Install Levers (cont.)
7. 3 . Ax wood screws at 3 xing points, leaving the
3 or 9 o’clock holes for the privacy pin and
emergency release.
7.4 Replace outer roses, ensuring the privacy pin hole
lines up with the 3 or 9 o’clock bolt-through hole
on the inner rose (for pin) and outer rose
(for emergency release). (Figure 7)
Figure 7.
8.
8.1 Place privacy pin into hole in rose on inside of
door, align with female thread in latch and screw
to secure. (Figure 8)
8. Install Privacy Pin
Figure 8.
1.
2.
8.
7.7.
6. (or 5.)
Rose Privacy Set Built-in
1. Rose Privacy Lever Set
2. Outer Rose Covers
3. Hex Key
4. Grub
Screws
5. Wood Screws
6. Cut-o Screws
7. Tube Latch
Privacy Spindle
IMPORTANT:
Please install this door
hardware in the following
order to ensure its warranty
is not voided.
1. Install the door hardware
on raw / unnished door
using the instructions
provided.
2. Remove door hardware
and store safely. Do not
place painters tape or
masking tape over the
product. The tape will
damage the nish.
3. Paint / nish door.
4. Reinstall hardware.
Please recycle
me after use

Drilling
Template
Rose Inbuilt
Privacy Set
—
CUT ALONG DOTTED LINE
35mm 38mm 40mm
A
BCD
Fold and align along door edge
60mm
42mm
DOOR THICKNESS
Drill Ø25mm hole
57mm deep at centre
of door edge
