Iwata Full Finish G-Series G6 Instruction Manual

取扱説明書 | Operating Instruction Manual

When airbrush projects call for larger coverage, look no further than the Iwata G-Series airbrush-guns. They spray with
the ne atomization and air pressure of an airbrush. For full nishes, ANEST IWATA spray guns oer superior atomization
for a reliable and consistent nish.
FULL FINISH™
本格塗装
Bottle Set

ANEST IWATA-MEDEA, INC.
Portland, Oregon U.S.A.
[phone] (M-F)
[email protected]om
www.iwata-airbrush.com
ANEST IWATA AUSTRALIA PTY LTD.
Mt. Druitt, NSW
[phone]
www.anest-iwata.com.au
ANEST IWATA STRATEGIC CENTER
Cardano al Campo, Italy
[phone]
www.anest-iwataeu.com
ANEST IWATA SOUTH-EAST ASIA CO., LTD.
Bangkok, Thailand
[phone]
www.anest-iwatasoutheastasia.com
ANEST IWATA SHANGHAI
Shanghai, China
[phone] / 15 / 16
www.anest-iwata-sh.com
ANEST IWATA RUS LLC
Moscow, Russia
[phone]
www.anestiwata.ru
ANEST IWATA CORPORATION
Yokohama, Japan
[phone]
www.anest-iwata.co.jp
ANEST IWATA (U.K.) LTD.
Neots Cambs, England
[phone]
www.anest-iwata.co.uk
ANEST IWATA MOTHERSON LTD.
Uttar Pradesh, India
[phone] / 14 / 17
www.aircompressors.com
ANEST IWATA SOUTH AFRICA (PTY) LTD.
Johannesburg, Republic of South Africa
[phone]/2265/2223
www.anest-iwata.co.za
CENTURY TRADING CO., LTD.
Seoul, Korea
82-2-2163-0300
www.centrading.co.kr
If you have any issues or warranty service questions, contact your
local ANEST IWATA aliate before returning to your place of purchase.
NEED ASSISTANCE

4
FEATURES
Iwata G-Series G6
• MAC Valve for precise control of air
and spray
• G6 head system
• Spray width: 5/8” up to 2.5”+
• Long tapered needle for smooth
transition between medium to
extra wide spray
• Dual-purpose air cap and fan
adjustment valve to spray round
or oval patterns
• Interchangeable with side feed
bottles and cups

Iwata G-Series G5
• True center-post gravity-feed airbrush
• MAC Valve for precise control of air
and spray
• G5 head system
• Spray width: 5/8” up to 2.5”+
• Twilight-chrome nish
Iwata G-Series G3
• True center-post gravity-feed airbrush
• MAC Valve for precise control of air
and spray
• G3 head system
• Spray width - 5/8” up to 2.5”
• Twilight-chrome nish
5

FOR G-SERIES G6
Pattern Adjustment Set (#14)
This adjustment creates a circular- or oval-shaped spray pattern.
When the valve is fully closed, twisted fully clockwise, the spray
pattern will be a round shape. The round pattern is best for doing
graphics in small areas. When the valve is fully opened, twisted
fully counter-clockwise, the spray pattern will be an oval shape,
also known as a fan pattern. The oval fan pattern provides a smooth
background spray.
When using the Power Jet compressor, the pattern adjustment
valve should only be opened a maximum of ½ turn. Using a com-
pressor with power greater than 1 HP allows the valve to be fully
opened, creating the fan pattern shape.
Air Cap (#1)
The air cap produces a round or an oval fan-shaped pattern
depending on how the pattern adjustment valve is set. Refer to the
Pattern Adjustment Set Instructions if necessary.
Orientation of the oval varies based on where the nger-like
protrusions on the air cap are oriented. The nger-like protrusions
dictate where the fat part of the oval will be. Spray with the fat part
of the oval. If the oval is vertical, spray up and down. If the oval is
horizontal, spray side to side.
Change the orientation by simply twisting the air cap. (Remember
to loosen air cap cover ring rst.)
Fluid Adjustment Knob (#22)
The uid adjustment knob limits how much uid will be sprayed
when the trigger is pulled all the way back. After setting the spray
pattern (see #14 description), the uid adjustment knob sets the
amount of spray delivered to an object’s surface. This feature proves
invaluable each time the trigger is pulled back while spraying large
areas that need precise, repeatable spray output. It’s cruise control
for the long haul.
1. Start spraying with the knob fully opened, but don’t screw it
entirely o the airbrush!
2. Find the best trigger position for the best spray.
3. Screw the knob clockwise until the trigger pull is limited to the
desired position.
Don’t forget! Unscrew the knob when you can’t gure out why you
don’t get as much spray as you used to.
Air Adjusting Set (#23)
The air adjustment knob sets the amount of air owing through the
airbrush. It’s a convenient way to adjust the pressure on the y. It
functions like a MAC Valve*. Start with the knob set at the full open
position by twisting it counterclockwise until it stops. After you’re
familiar with the airbrush, adjust the air pressure to achieve the best
spray pattern as necessary.
*The MAC (Micro Air Control) Valve controls airow to the airbrush-gun.
6

Pre-Check The Settings
1. Close the pattern adjustment knob (#14) fully by gently twisting
it clockwise until it stops. It doesn’t need to be tight.
2. Open the uid-adjustment knob (#22) fully by gently twisting it
counterclockwise. NOTE: You might unscrew the uid adjustment
knob o of the airbrush. Don’t worry. Screw it back on one or
two full turns.
3. Open the air adjustment knob (#23) fully by twisting it counter
clockwise until it stops. It doesn’t need to be tight.
4. Loosen air cap cover ring (#3) to adjust the air cap (#1), specically
the little nger-like projections until they are horizontal to the
ground. Then tighten air cap cover ring (#3).
Assembly
1. Screw the air hose rmly onto the air source outlet.
NOTE: In many cases the air source is a compressor.
2. Screw the air hose rmly onto the G-Series’air inlet beneath
the handle.
G6 Bottle Set Spraying
1. Fill a bottle at least 1/2 of the way full of properly prepared paint.
2. Screw the lid (bottle cap set) onto the bottle.
3. Screw the bottle onto the airbrush-gun.
4. Adjust the air source pressure to 35-55 psi and spray.
G3, G5 and G6 Spraying
1. Screw the metal cup onto the airbrush-gun.
2. Fill cup at least 1/2 of the way full of properly prepared paint.
3. Attach lid to cup.
4. Adjust the air source to 35-55 psi and spray.
General Spraying
1. Pull the trigger back slightly and only the air will come out.
2. Pull the trigger back more until paint starts to spray in small
amounts.
3. Pulling the trigger back further releases even more paint until
the trigger is pulled as far as it can go.
GETTING STARTED
7

GENERAL OPERATION
Fine-Line Spray
1. Pull the trigger back slightly to start the air.
2. Position the airbrush close to the surface. About 1 inch
or 2.5 cm.
3. Pull the trigger back a little more to start the ow of paint.
Control line thickness by adjusting the distance between the
airbrush and the surface, and also by adjusting the paint ow
amount.
Background Spraying
1. Position the airbrush further from the surface – 4-6 inches or
10-16 cm is common.
2. Pull the trigger back a lot to release a large amount of paint.
Control spray width by adjusting the distance between the
airbrush and the surface and by opening the pattern adjustment
knob (#14). Opening the pattern adjustment knob changes the
spray pattern shape from a circle to an oval.
Control spray consistency over large areas by setting
the uid adjustment knob (#22) to limit the amount of paint
volume sprayed.
1. Pull the trigger back to the desired amount of spray.
2. Screw the uid-adjustment knob in until it pushes the trigger.
• Always spray in a well-ventilated area.
• Do not spray solvent-based (ammable) paints around open
ames.
• Use the appropriate respirator to safely lter out the paint
vapors particular to the to the kind of paint you are using.
• Wear eye protection to prevent paint contact with eyes.
• Never use air pressure that exceeds the airbrush-gun’s limit.
(6.8 bar, 10.68 MPa, 98 psi)
CAUTION
WARNING
8

Cleaning
Cleaning Between Colors
1. Replace the color bottle with a bottle containing the appropriate
cleaning solution (when using the G6 Bottle Set). Rinse out metal
cup and ll with cleaning solution.
2. Spray until the solution sprays clear and clean.
3. Remove the bottle of cleaning solution (when using the G6
Bottle Set). Dump out remaining solution from metal cup.
4. Spray air until it sprays dry.
5. Fit a color bottle with the new color and spray or add new color
to metal cup.
6. Repeat the procedure when nished.
Before Each Session
Spray water, or appropriate solvent, through the airbrush-gun to
ensure it is in proper working order.
NEVER soak your entire airbrush in any liquid. NEVER
store your airbrush with spray medium or cleaning
agents in the uid cup.
After Each Session
Or any time the airbrush-gun becomes clogged:
1. Increase the air pressure.
2. Spray cleaning solution through the airbrush-gun for a short
time.
3. Unscrew the uid adjustment knob (#22).
4. Remove the spring (#21).
5. Pull out the needle (#5).
6. Wipe down the needle.
7. Gently reinsert the needle. NOTE: The needle is delicate and
sharp. Be careful not to bend the tip of the needle or hurt
yourself while reinserting it.
8. Place the spring on the needle.
9. Screw the uid adjustment knob onto the airbrush-gun.
The higher air pressure will help to thoroughly clean out the paint.
MAINTENANCE
9
CAUTION
WARNING

20
7-1
14
5
14
12 15
10
13
16
16-1
17
18
19
6
4
11
23
7-2
24
8
9
1
2
3
6-1
6-2
7
21
22
22
16
16-2
10

11
PRICE ITEM ALSO
# ITEM DESCRIPTION CODE # G3 G5 G6 FITS
15 Air Valve Shaft C I2023 nnnRG-3/LPH-50
16 Air Valve Seat Set F I2052 xxnRG-3/LPH-50
16-1 Gasket Air Valve Seat I2171 x x n
16-2 O-ring A I6601 nnx
17 Air Valve Seat Screw A I2053 nnnRG-3/LPH-50
18 Air Valve C I2022 nnnRG-3/LPH-50
19 Air Valve Spring A I2062 nnnRG-3/LPH-50
20 Fluid Adjustment Guide Set F I2082 nnnRG-3/LPH-50
21 Needle Spring B I2252 nnnRG-3/LPH-50
22 Fluid Adjusting Knob C I2091 xxnRG-3
I6701 nn x
23 Air Adjusting Set D I6261 xxn
I6262 nnx
24 Air Hose Adapter (1/4”-1/8”) D I6241 nnnRG-3/LPH-50
3 oz Jar With G6 Bottle Set I4803G6 xx opt/ n
Fluid Cup With Lid 4.4 oz / 130 ml I210G3 n opt x
7.5 oz / 220 ml I210G5 optn x
Spanner I2301 xxopt
Fluid Cup 150 ml (PC 61) I2101 xxopt
220 ml (PC 51) I2102 xxopt
250 ml (PC 5) I2103 xxopt
Fluid Cup Lid 150 ml (PC 61) I2111 xxopt
220 ml (PC 51) I2112 xxopt
250 ml (PC 5) I2113 xxopt
PRICE ITEM ALSO
# ITEM DESCRIPTION CODE # G3 G5 G6 FITS
1 Air Cap G6 H I6001 opt opt n
G3 J I6004 nopt opt
G5 J I6005 opt nopt
2 Air Cap Packing A I6002 nnn
3 Air Cap Cover Ring C I6003 nnn
4 Fluid Head G6 I I6044 opt opt n
Nozzle G3 I I6045 nopt opt*
G5 I I6046 opt n opt*
5 Fluid Needle G6 F I6174 xxn
Duplex Needle G3/G5 I6175 nn x
6 Airbrush Body Set (G6) O I3071 xxnLPH-50
6-1 Fluid Cup Joint D I2122 xxnRG-3/LPH-50
6-2 Bottle Joint Adapter F I6231 xxnRG-3/LPH-50
7 Airbrush Body Set (G3/G5) O I3072 nnx
7-1 Fluid Nipple D I6501 nnx
7-2 Air Nipple B I6801 nnx
8 Fluid Needle Packing D I2152 xxnRG-3/LPH-50
9 Needle Packing Seat A I2192 xxnRG-3/LPH-50
10 Needle Packing Set D I6401 nnx
11 Trigger C I2331 nnnRG-3/LPH-50
12 E Stopper 2 pcs/pk A I3321 nnnLPH-50
13 Trigger Stud A I2341 nnnRG-3/LPH-50
14 Pattern Adjustment Set H I6252 nnx
G I6251 xxn
n= yes x= no opt = optional
*You must change the aircap and needle to use optional nozzle sizes.
CA PROP
65
CA PROP
65
CA PROP
65
CA PROP
65
CA PROP
65
CA PROP
65
CALIFORNIA PROP 65 WARNING: Certain products identied with this symbol and oered for sale in this catalog contain lead,
a chemical known to the State of California to cause cancer, birth defects and other reproductive harm.
CA PROP
65

12
©2018 Anest Iwata-Medea, Inc. All rights reserved.
All Iwata airbrushes are warranted against all manufacturing defects of material and manufacture or workmanship for a
period of FIVE years from date of purchase. This warranty does not cover needles, nozzles, o-rings and internal packings
since these parts need to be replaced occasionally due to normal wear. Any other parts or materials that are or become
defective so as not to be usable within this period will be repaired or replaced. This warranty does not cover damage
caused by negligence or airbrushes which have been altered or abused in any way.

4

3
エアーブラシ全体を液体に浸さないで下さい。 カップに塗料、洗浄液、
などを入れたままエアーブラシを保管しないで下さい。
CAUTION
WARNING

2

1
ECL903-IM-KMA
G3
G5
G6
ヘッドシステム
