RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
iW-RainboW-G21D
RZ/G1H Qseven Development Platform
Hardware User Guide

REL1.0
Page 2 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Document Revision History
Document Number
iW-PREJD-UM-01-R2.0-REL1.0-Hardware-RZG1H_DevKit
Revision
Date
Change Description
1.0
30th Dec 2016
Official Release Version
PROPRIETARY NOTICE: This document contains proprietary material for the sole use of the intended recipient(s). Do
not read this document if you are not the intended recipient. Any review, use, distribution or disclosure by others is
strictly prohibited. If you are not the intended recipient (or authorized to receive for the recipient), you are hereby
notified that any disclosure, copying distribution or use of any of the information contained within this document is
STRICTLY PROHIBITED. Thank you. “iWave Systems Tech. Pvt. Ltd.”

REL1.0
Page 3 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Disclaimer
iWave Systems reserves the right to change details in this publication including but not limited to any Product
specification without notice.
No warranty of accuracy is given concerning the contents of the information contained in this publication. To the
extent permitted by law no liability (including liability to any person by reason of negligence) will be accepted by iWave
Systems, its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or
inaccuracies in this document.
CPU and other major components used in this product may have several silicon errata associated with it. Under no
circumstances, iWave Systems shall be liable for the silicon errata and associated issues.
Trademarks
All registered trademarks, product names mentioned in this publication are the property of their respective owners
and used for identification purposes only.
Certification
iWave Systems Technologies Pvt. Ltd. is an ISO 9001:2015 Certified Company.
Warranty & RMA
Warranty support for Hardware: 1 Year from iWave or iWave's EMS partner.
For warranty terms, go through the below web link,
http://www.iwavesystems.com/support/warranty.html
For Return Merchandise Authorization (RMA), go through the below web link,
http://www.iwavesystems.com/support/rma.html
Technical Support
iWave Systems technical support team is committed to provide the best possible support for our customers so that
our Hardware and Software can be easily migrated and used.
For assistance, contact our Technical Support team at,
Email : [e-mail]
Website : www.iwavesystems.com
Address : iWave Systems Technologies Pvt. Ltd.
# 7/B, 29th Main, BTM Layout 2nd Stage,
Bangalore, Karnataka,
India –560076

REL1.0
Page 4 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table of Contents
1. INTRODUCTION ............................................................................................................................................9
1.1 Purpose .............................................................................................................................................................9
1.2 Overview ...........................................................................................................................................................9
1.3 List of Acronyms................................................................................................................................................9
1.4 Terminlogy Description...................................................................................................................................11
1.5 References ......................................................................................................................................................11
2. ARCHITECTURE AND DESIGN –QSEVEN CARRIER BOARD ............................................................................. 12
2.1 RZ/G1H Qseven Carrier Board Block Diagram ................................................................................................12
2.2 RZ/G1H Qseven Carrier Board Features .........................................................................................................13
2.3 Qseven MXM Connector.................................................................................................................................15
2.4 On Board Switches ..........................................................................................................................................33
2.4.1 Power ON/OFF Switch.................................................................................................................................33
2.4.2 Board Configuration Switch ........................................................................................................................ 34
2.4.3 Reset Switch ................................................................................................................................................35
2.5 Serial Interface Features .................................................................................................................................36
2.5.1 Debug UART Port ........................................................................................................................................36
2.5.2 Data UART Header ......................................................................................................................................37
2.6 High Speed Interface Features........................................................................................................................38
2.6.1 USB3.0 Port0 (Host).....................................................................................................................................38
2.6.2 PCIe Channel0 Port......................................................................................................................................39
2.6.3 SATA Channel0 Port (Optional) ...................................................................................................................44
2.7 Communication Interface Features ................................................................................................................46
2.7.1 Gigabit Ethernet Port ..................................................................................................................................46
2.7.2 USB2.0 Ports (Host).....................................................................................................................................48
2.7.3 USB2.0 Port1 (OTG).....................................................................................................................................50
2.7.4 SDIO Port.....................................................................................................................................................52
2.7.5 CAN Header.................................................................................................................................................54
2.8 Audio/Video Features .....................................................................................................................................55
2.8.1 Audio IN & OUT ...........................................................................................................................................55
2.8.2 7” LCD with Capacitive Touch .....................................................................................................................57
2.8.3 HDMI Port....................................................................................................................................................60
2.8.4 LVDS Port with Resistive Touch (Optional)..................................................................................................62
2.9 Additional Features.........................................................................................................................................66
2.9.1 SPI Flash ......................................................................................................................................................66
2.9.2 RTC Coin Cell Holder....................................................................................................................................66
2.9.3 Fan Header..................................................................................................................................................67
2.9.4 JTAG Header (Optional)...............................................................................................................................68
2.10 SOM Expansion Connectors............................................................................................................................70
2.11 Carrier Board Expansion Connectors ..............................................................................................................71

REL1.0
Page 5 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
3. ARCHITECTURE AND DESIGN –CAMERA ADD-ON MODULE.......................................................................... 78
3.1 RZ/G1H Camera Add-On Module Block Diagram............................................................................................78
3.2 RZ/G1H Camera Add-On Module Features.....................................................................................................79
3.3 Video Features ................................................................................................................................................80
3.3.1 Camera Selection Switch.............................................................................................................................80
3.3.2 8bit CMOS Cameras ....................................................................................................................................81
3.3.3 16bit CMOS Cameras ..................................................................................................................................86
3.4 Communication Features................................................................................................................................91
3.4.1 CAN Header.................................................................................................................................................91
3.4.2 10/100Mbps Ethernet Header ....................................................................................................................92
3.5 Serial Interface Features .................................................................................................................................93
3.5.1 Data UART Headers (RS232) .......................................................................................................................93
4. TECHNICAL SPECIFICATION.......................................................................................................................... 95
4.1 Electrical Characteristics .................................................................................................................................95
4.1.1 Power Input Requirement ...........................................................................................................................95
4.1.2 Power Output Specification.........................................................................................................................96
4.2 Environmental Characteristics ........................................................................................................................97
4.2.1 Environmental Specification........................................................................................................................97
4.2.2 RoHS Compliance ........................................................................................................................................97
4.2.3 Electrostatic Discharge................................................................................................................................97
4.3 Mechanical Characteristics .............................................................................................................................98
4.3.1 RZ/G1H Qseven Carrier Board Mechanical Dimensions..............................................................................98
4.3.2 RZ/G1H Camera Add-On Module Mechanical Dimensions.........................................................................99
4.3.3 Guidelines to insert the Qseven SOM into Carrier Board............................................................................99
5. ORDERING INFORMATION ........................................................................................................................ 100
6. APPENDIX................................................................................................................................................. 101
6.1 Camera Add-On Module Integration Procedure...........................................................................................101
6.2 8bit CMOS Cameras Connecting Procedure .................................................................................................105

REL1.0
Page 6 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
List of Figures
Figure 1: RZ/G1H Qseven Carrier Board Block Diagram .................................................................................................12
Figure 2: Qseven MXM Connector..................................................................................................................................15
Figure 3: Power ON/OFF Switch......................................................................................................................................33
Figure 4: Board Configuration Switch .............................................................................................................................34
Figure 5: Reset Switch.....................................................................................................................................................35
Figure 6: Debug UART .....................................................................................................................................................36
Figure 7: Data UART Header ...........................................................................................................................................37
Figure 8: USB3.0 Host Port0............................................................................................................................................38
Figure 9: PCIex4 Connector.............................................................................................................................................39
Figure 10: Mini PCIe Connector ......................................................................................................................................42
Figure 11: SATA Connector .............................................................................................................................................44
Figure 12: RJ45 Magjack..................................................................................................................................................46
Figure 13: USB2.0 Port0 (Host) .......................................................................................................................................48
Figure 14: USB2.0 Port3 (Host) .......................................................................................................................................49
Figure 15: USB2.0 Port1 (OTG)........................................................................................................................................51
Figure 16: SD/MMC Connector.......................................................................................................................................52
Figure 17: CAN Header....................................................................................................................................................54
Figure 18: Audio IN/OUT Jack .........................................................................................................................................55
Figure 19: RGB LCD Connector........................................................................................................................................57
Figure 20: RGB LCD Connector........................................................................................................................................59
Figure 21: HDMI Connector ............................................................................................................................................60
Figure 22: LVDS LCD Connector ......................................................................................................................................62
Figure 23: LVDS Backlight Connector..............................................................................................................................64
Figure 24: LVDS Resistive Touch Connector....................................................................................................................65
Figure 25: Coin Cell Holder..............................................................................................................................................66
Figure 26: Fan Header.....................................................................................................................................................67
Figure 27: JTAG Header...................................................................................................................................................68
Figure 28: SOM Expansion Connectors...........................................................................................................................70
Figure 29: Carrier Board Expansion Connectors .............................................................................................................71
Figure 30: RZ/G1H Camera Add-On Module Block Diagram...........................................................................................78
Figure 31: Camera Add-On Module Expansion Connectors ...........................................................................................79
Figure 32 Camera Selection Switch.................................................................................................................................80
Figure 33 8bit CMOS Camera Header.............................................................................................................................81
Figure 34 16bit CMOS Camera Header........................................................................................................................... 86
Figure 35: CAN Header....................................................................................................................................................91
Figure 36 10/100 Ethernet Header .................................................................................................................................92
Figure 37: Data UART 0 Header ......................................................................................................................................93
Figure 38: Power Jack......................................................................................................................................................95
Figure 39: RZ/G1H Qseven carrier board Mechanical dimension –Top View................................................................98
Figure 40: RZ/G1H Qseven carrier board Mechanical dimension - Side View................................................................98
Figure 41: RZ/G1H Camera Add-On Module Mechanical dimension –Bottom View ....................................................99
Figure 42: Qseven SOM Insertion procedure..................................................................................................................99
Figure 43: Insert Pan Head Screw .................................................................................................................................102
Figure 44: Tighten Metallic Hex Spacer ........................................................................................................................102

REL1.0
Page 7 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Figure 45: Insert Camera Add-On Module....................................................................................................................103
Figure 46: Insert Non-Metallic Flat Washer..................................................................................................................103
Figure 47: Tighten the Nut............................................................................................................................................104
Figure 48: Camera Connection......................................................................................................................................105
Figure 49: Camera Lens Cap..........................................................................................................................................105
List of Tables
Table 1: Acronyms & Abbreviations..................................................................................................................................9
Table 2: Terminology ......................................................................................................................................................11
Table 3: Qseven MXM Connector Pin Out ......................................................................................................................16
Table 4: Board Configuration Switch ..............................................................................................................................35
Table 5: Data UART Header Pin Out................................................................................................................................37
Table 6: Dual stack USB 3.0 Connector Pin Out (Bottom port).......................................................................................38
Table 7: PCIex4 Connector Pin Out .................................................................................................................................40
Table 8: Mini-PCIe Connector Pin Out ............................................................................................................................42
Table 9: SATA Connector Pin Out....................................................................................................................................45
Table 10: RJ45 MagJack Pin Out......................................................................................................................................47
Table 11: USB2.0 Port0 (Host) Connector Pin Out..........................................................................................................49
Table 12: Dual stack USB 3.0 Connector Pin Out (Top port)...........................................................................................49
Table 13: USB2.0 Port1 (OTG) Connector Pin Out ..........................................................................................................51
Table 14: SD/MMC Connector Pin Out ...........................................................................................................................53
Table 15: CAN Header Pin Out ........................................................................................................................................54
Table 16: Audio OUT Jack Pin Out...................................................................................................................................56
Table 17: Audio IN Jack Pin Out ......................................................................................................................................56
Table 18: 7” RGB LCD Connector Pin Out .......................................................................................................................58
Table 19: Capacitive Touch Connector Pin Out ..............................................................................................................59
Table 20: HDMI Connector Pin Out.................................................................................................................................61
Table 21 LVDS Connector................................................................................................................................................63
Table 22: LVDS Backlight Connector Pin Out ..................................................................................................................64
Table 23: Resistive Touch Connector Pin Out.................................................................................................................65
Table 24: Fan Header Pin Out .........................................................................................................................................67
Table 25: JTAG Header Pin Out.......................................................................................................................................69
Table 26: Expansion Connector3 Pin Out........................................................................................................................72
Table 27 Camera Selection Switch..................................................................................................................................80
Table 28:8bit Camera Connector1 Pin Out (J13) ............................................................................................................82
Table 29 8bit Camera Connector2 Pin Out (J14).............................................................................................................83
Table 30 8bit Camera Connector3 Pin Out (J12).............................................................................................................84
Table 31 8bit Camera Connector4 Pin Out (J11).............................................................................................................85
Table 32 16bit Camera Connector Pin Out (J1)...............................................................................................................87
Table 33 16bit Camera Connector2 Pin Out (J15)...........................................................................................................89
Table 34: CAN0 Header Pin Out......................................................................................................................................91
Table 35 10/100 Ethernet Header Pin Out .....................................................................................................................92
Table 36: SCIF0 UART Header Pin Out (J9)......................................................................................................................93
Table 37 SCIF1 UART Header Pin Out (J6).......................................................................................................................94

REL1.0
Page 8 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table 38 SCIF2 UART Header Pin Out (J8).......................................................................................................................94
Table 39 SCIFB1 UART Header Pin Out (J3).....................................................................................................................94
Table 40: HSCIF0 UART Header Pin Out (J2) ...................................................................................................................94
Table 41: Power Jack Pin Out..........................................................................................................................................95
Table 42: Power Input Requirement............................................................................................................................... 96
Table 43: Power Output Specification ............................................................................................................................ 96
Table 44: Environmental Specification ...........................................................................................................................97
Table 45: Orderable Product Part Numbers .................................................................................................................100
Table 46: Camera Add-On Module Accessories............................................................................................................101

REL1.0
Page 9 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1. INTRODUCTION
1.1 Purpose
The RZ/G1H Qseven Development platform incorporates RZ/G1H CPU based Qseven SOM and Qseven Carrier board
for complete validation of RZ/G1H CPU functionality. This document is the Hardware User Guide for the RZ/G1H
Qseven Carrier Board. This Guide provides detailed information on the overall design and usage of the Qseven Carrier
Board from a Hardware Systems perspective. Complete information about the RZ/G1H Qseven SOM hardware is
explained in another document named “iW-RainboW-G21M-RZG1H_QsevenSOM-HardwareUserGuide-RELx.y”.
1.2 Overview
iWave's RZ/G1H Qseven Development platform incorporates RZ/G1H Qseven SOM which is based on Renesas’s high
performance RZ/G1H Quad ARM Cortex A15 + Quad ARM Cortex A7 processor and the Qseven carrier board with 7"
Capacitive Touch LCD. The development board can be used for quick prototyping of various applications targeted by
the RZ/G1H processor. With the 120mmx120mm Nano ITX size, Qseven carrier board is highly packed with all the
necessary on-board connectors to validate the Qseven features of RZ/G1H Qseven SOM. iWave also supports Camera
Add-On Module for RZ/G1H Qseven Development platform to validate Expansion connector interfaces of RZ/G1H
Qseven SOM.
1.3 List of Acronyms
The following acronyms will be used throughout this document.
Table 1: Acronyms & Abbreviations
Acronyms
Abbreviations
ARM
Advanced RISC Machine
BPP
Bits Per Pixel
CAN
Controller Area Network
CMOS
Complementary Metal-Oxide Semiconductor
CPU
Central Processing Unit
GPIO
General Purpose Input Output
HSCIF
High Speed Serial Communication Interface with FIFO
I2C
Inter-Integrated Circuit
IC
Integrated Circuit
JTAG
Joint Test Action Group
LCD
Liquid Crystal Display
Mbps
Megabits per sec
MHz
Mega Hertz
MSIOF
Clock-Synchronized Serial Interface with FIFO
NC
No Connect
NPTH
Non Plated Through hole

REL1.0
Page 10 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Acronyms
Abbreviations
PCB
Printed Circuit Board
PCIe
Peripheral Component Interconnect Express
PTH
Plated Through hole
PWM
Pulse Width Modulation
RTC
Real Time Clock
SATA
Serial AT Attachment
SCIF
Serial Communication Interface with FIFO
SDIO
Secure Digital Input Output
SDHI
SD Card Host Interface
SSI
Serial Sound Interface
SOM
System On Module
UART
Universal Asynchronous Receiver/Transmitter
USB
Universal Serial Bus
USB OTG
USB On The Go

REL1.0
Page 11 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1.4 Terminlogy Description
In this document, wherever Signal Type is mentioned, below terminology is used.
Table 2: Terminology
Terminology
Description
I
Input Signal
O
Output Signal
IO
Bidirectional Input/output Signal
CMOS
Complementary Metal Oxide Semiconductor Signal
DIFF
Differential Signal
TMDS
Transition-Minimized Differential Signalling
OD
Open Drain Signal
OC
Open Collector Signal
Analog
Analog Signal
Power
Power Pin
PU
Pull Up
PD
Pull Down
NA
Not Applicable
NC
Not Connected
Note: Signal Type does not include internal pull-ups or pull-downs implemented by the chip vendors and only includes
the pull-ups or pull-downs implemented on board.
1.5 References
RZ/G1H Qseven SOM Hardware User Guide
Renesas’ RZ/G1H CPU Hardware User Manual
Qseven® Specification Version 2.0
Qseven® Design Guide

REL1.0
Page 12 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2. ARCHITECTURE AND DESIGN –QSEVEN CARRIER BOARD
This section provides detailed information about the RZ/G1H Qseven Development Platform carrier board features
with high level block diagram and detailed information about each block.
2.1 RZ/G1H Qseven Carrier Board Block Diagram
iW-RainboW-G21D-RZ/G1H Qseven Carrier Board Block Diagram
Qseven MXM Connector
MFG
USB to UART
Converter
Debug MicroAB
Conn.
UART Header(6Pin) UART0
100/1000
ENET3
RJ45 & USB Stack
Dual USB 3.0 Port
OTG µUSB Port
USB_P0
SDIO
SD/MMC Conn.
CAN
CAN Header (6Pin)
USB_P1
22-Pin Conn.¹ SATA¹
PCIe x 4 Slot
Mini PCIe Conn.
I2S/HDA
Audio IN Jack
Audio OUT Jack
I2S CODEC
Capacitive TP Conn.
RTC Battery Holder
VCC-RTC
SPI Flash
SPI
80 pin Carrier
Expansion
Connector - 3
MSIOF0(SYNC)
GPPWM
x2
80 pin SOM Expansion
Connector - 1
80 pin SOM Expansion
Connector -2
VIN0 (8bit/16bit)4, VIN1 (8bit/16bit)5, VIN2 (8bit), VIN3(8bit), GPIO x 3
USB0
SDHI2
USB2
SCIF2/JTAG
SCIFB2
CAN1
+3V
7” RGB Capacitive
LCD Conn.
LVDS0 LVDS
Receiver
RGB-24bit
LVDS-DU0
PCIe
EtherAVB3
USB1_HUB_1
SATA0/SATA1
Control
Signals
SMBUS/
GP1_I2C
Port2
(Top)
Ethernet
(Top)
USB 2.0
(Bottom)
TPU0TO1,
TPU0TO2
I2C0
I2C2
I2C2
GP0_I2C
To Other Peripherals
I2C0, I2C2. I2C3
LED’s
PCIe Clock
Buffer Push Button
CAN
Transceiver
Switch
+5V
RSVD MSIOF0 (CS1#)
RST_BTN#
Q7_GPIOs
Control Signals
80 pin Carrier
Expansion
Connector - 1
80 pin Carrier
Expansion
Connector - 2
Output Control Signals (SUS_STAT#, SUS_S3#, SUS_S5# , THRMTRIP#)
Input Control Signal (RST_BTN#)
12V DC Input Power Jack
On Board
Regulators
To On Board
Peripherals
FAN Header
ON/OFF
Switch
PCIe
¹ SATA connector is supported in carrier board but RZ/G1H SOM doesn’t support SATA in edge connector by default.
² JTAG connector is supported in carrier board but RZ/G1H SOM doesn’t support JTAG in edge connector by default.
³ EtherAVB & VI0 is multiplexed ins same pins and so either one interface only can be used at a time.
4 VI0 & VI3 can be used in 8bit mode. If VI0 is used in 16bit, then VI3 cannot be used
5 VI1 & VI2 can be used in 8bit mode. If VI1 is used in 16bit, then VI2 cannot be used.
To connect
Add On Module
USB_P2
USB_P6
USB_P7
USB3.0_RX
USB3.0_TX
Port1
(Bottom)
VCC-5V
JTAG Header2
I2S
Reserved Pins
7” LCD Backlight
Conn.
LCD Backlight
controller
LVDS_BLEN
USB1_HUB_2 USB_P3
10/100Mpbs Ethernet, VGA x1, CAN0, SSI0, MSIOF3/I2C1, SCIFB1,HSCIF0,
SCIF0,1,3, PWM x 3, TPU x 1
LVDS LCD Conn with
BL Conn..
LVDS1
Resistive TP Conn.
LVDS-CH1
Touch
controller
I2C2
HDMI Conn.
TMDS
HDMI
I2C3
GP2_I2C
TPU0TO2
TPU0TO1
Figure 1: RZ/G1H Qseven Carrier Board Block Diagram

REL1.0
Page 13 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.2 RZ/G1H Qseven Carrier Board Features
The RZ/G1H Qseven carrier board supports the following features to validate RZ/G1H Qseven SOM Edge connector
Interfaces.
On Board Switches
Power ON/OFF Switch
Board Configuration Switch
Reset Switch
Serial Interface Features
Debug UART through USB Micro AB Connector
Data UART (SCIFB2) x 1 Port through Header
High Speed Interface Features
USB 3.0/USB 2.0 Host x 1 Port through Dual stack USB 3.0 Type A Connector (Bottom)
PCIe x 1 Port through x4 connector or Mini-PCIe connector
SATA x 1 Port through 22pin Serial ATA Connector (Optional)1
Communication Features
100/1000Mbps Ethernet through RJ45MagJack
USB 2.0 Host x 1 Port through Type A Connector (Dual stack USB 3.0 - Top)
USB 2.0 Host x 1 Port through Type A Connector
USB 2.0 OTG x 1 Port through Micro AB Connector
SDHI (4bit) x 1 Port through Standard SD Connector
CAN x 1 Port through Header
Audio/Video Features
I2S Audio Codec with 3.5mm Audio IN and OUT jack
7”RGB LCD Connector through LVDS to RGB transmitter with Capacitive Touch
2nd LVDS port display connector
Additional Features
SPI Flash (MSIOF0 with SS#0)
RTC Coin Cell holder
Fan Header
20-Pin JTAG Header (Optional)2

REL1.0
Page 14 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Carrier board Expansion Connectors
Carrier board Expansion Connector13
Carrier board Expansion Connector24
Carrier board Expansion Connector3
SPI (MSIOF0 with SS1#) x 1 Port
I2C x 3 Ports
GPIOs & Power
General Specification
Power Supply : 12V, 2A Power Input Jack
Form Factor : 120mm X 120mm Nano ITX
1SATA connector is supported always in Qseven carrier board hardware. If Qseven SOM supports SATA interface on
Qseven Edge connector, then SATA can be tested in Qseven carrier board. In RZ/G1H CPU based Qseven SOM, SATA is
not supported in Qseven Edge connector by default.
2JTAG connector is supported always in Qseven carrier board hardware. If Qseven SOM supports JTAG interface on
Qseven Edge connector, then JTAG can be tested in Qseven carrier board. In RZ/G1H CPU based Qseven SOM, JTAG is
not supported in Qseven Edge connector by default.
3 The RZ/G1H Qseven SOM Expansion conenctor1 interfaces are one to one directly connected to Qseven carrier board
expansion connector1 in Qseven carrier board. Please check the RZ/G1H SOM user guide for the detailed interface
availability on this connector.
4 The RZ/G1H Qseven SOM Expansion conenctor2 interfaces are one to one directly connected to Qseven carrier board
expansion connector2 in Qseven carrier board. Please check the RZ/G1H SOM user guide for the detailed interface
availability on this connector.

REL1.0
Page 15 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.3 Qseven MXM Connector
The RZ/G1H Qseven carrier board supports 230Pin Qseven MXM Edge mating connector for Qseven SOM attachment.
This standard 230-pin robust connector is capable of handling high-speed serialized signals and can be used for size
constrained embedded applications. This Qseven MXM Edge mating connector (J11) is physically located at the top of
the board as shown below.
Figure 2: Qseven MXM Connector

REL1.0
Page 16 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table 3: Qseven MXM Connector Pin Out
Pin
No.
Qseven MXM
Connector Pin
Name
Signal Name
Signal Type/
Termination
Description
1
GND
GND
Power
Ground.
2
GND
GND
Power
Ground.
3
GBE_MDI3-
GPHY_DTXRXM
IO, DIFF
Gigabit Ethernet MDI differential pair 3
negative.
This pin is connected to RJ45 Magjack J22.
4
GBE_MDI2-
GPHY_CTXRXM
IO, DIFF
Gigabit Ethernet MDI differential pair 2
negative.
This pin is connected to RJ45 Magjack J22.
5
GBE_MDI3+
GPHY_DTXRXP
IO, DIFF
Gigabit Ethernet MDI differential pair 3
positive.
This pin is connected to RJ45 Magjack J22.
6
GBE_MDI2+
GPHY_CTXRXP
IO, DIFF
Gigabit Ethernet MDI differential pair 2
positive.
This pin is connected to RJ45 Magjack J22.
7
GBE_LINK100#
GPHY_LINK_LED2
-
100Mbps Ethernet link status LED.
This pin is connected to D15 Green LED.
8
GBE_LINK1000#
GPHY_LINK_LED2
-
Gigabit Ethernet link status LED.
This pin is connected to D16 Green LED.
9
GBE_MDI1-
GPHY_BTXRXM
IO, DIFF
Gigabit Ethernet MDI differential pair 1
negative.
This pin is connected to RJ45 Magjack J22.
10
GBE_MDI0-
GPHY_ATXRXM
IO, DIFF
Gigabit Ethernet MDI differential pair 0
negative.
This pin is connected to RJ45 Magjack J22.
11
GBE_MDI1+
GPHY_BTXRXP
IO, DIFF
Gigabit Ethernet MDI differential pair 1
positive.
This pin is connected to RJ45 Magjack J22.
12
GBE_MDI0+
GPHY_ATXRXP
IO, DIFF
Gigabit Ethernet MDI differential pair 0
positive.
This pin is connected to RJ45 Magjack J22.
13
GBE_LINK#
GPHY_LINK_LED2
-
Gigabit Ethernet link status LED.
This pin is connected to RJ45 Magjack J22.
14
GBE_ACT#
GPHY_ACTIVITY_LED
1
-
Gigabit Ethernet Activity status LED.
This pin is connected to RJ45 Magjack J22.
15
GBE_CTREF
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to RJ45 Magjack J22
centre tap pins through resistor and default
populated in carrier board.

REL1.0
Page 17 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Pin
No.
Qseven MXM
Connector Pin
Name
Signal Name
Signal Type/
Termination
Description
16
SUS_S5#
SUS_S5_Q7
I, 3.3V CMOS
S5 State.
This pin is connected to indication LED D9.
Note: This pin is optionally connected to
Expansion Connector3 (J14) 8th Pin.
17
WAKE#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to Push button (SW5)
in carrier board.
18
SUS_S3#
SUS_S3_Q7
I, 3.3V CMOS
S3 state.
This pin is connected to indication LED D12.
Note: This pin is optionally connected to
Expansion Connector3 (J14) 7th Pin.
19
SUS_STAT#
SUS_STAT_Q7
I, 3.3V CMOS
Suspend Status.
This pin is connected to indication LED D10.
Note: This pin is optionally connected to
Expansion Connector3 (J14) 10th Pin.
20
PWRBTN#
PWRBTN#
-
Power Button output.
This pin is connected to Push button (SW3)
in the carrier board used for SOM On/Off
control.
21
SLP_BTN#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to Push button (SW7)
in carrier board.
22
LID_BTN#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected from 8bit DIP switch
(SW2) 3rd position in carrier board.
23
GND
GND
Power
Ground.
24
GND
GND
Power
Ground.
25
GND
GND
Power
Ground.
26
PWGIN
PWGIN
O, 5V CMOS/
10K PU
Power Good Output.
27
BATLOW#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected from 8bit DIP switch
(SW2) 2nd position in carrier board.
28
RSTBTN#
RSTBN
O, 3.3V CMOS
Active low Reset button Output.
This pin is connected to Push button SW4 in
carrier board for reset generation.
Note: This pin is optionally connected to
Expansion Connector3 (J14) 12th Pin.
29
SATA0_TX+
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to 22pin SATA
Connector (J25) for SATA Channel0
Transmit differential pair positive.

REL1.0
Page 18 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Pin
No.
Qseven MXM
Connector Pin
Name
Signal Name
Signal Type/
Termination
Description
30
SATA1_TX+
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 7pin SATA Connector
(J21) in carrier board.
31
SATA0_TX-
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 22pin SATA
Connector (J25) for SATA Channel0
Transmit differential pair negative.
32
SATA1_TX-
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 7pin SATA Connector
(J21) in carrier board.
33
SATA_ACT#
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected from 22pin SATA
Connector (J25) for SATA Channel0
command Activity line.
34
GND
GND
Power
Ground.
35
SATA0_RX+
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 22pin SATA
Connector (J25) for SATA Channel0 Receive
differential pair positive.
36
SATA1_RX+
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 7pin SATA Connector
(J21) in carrier board.
37
SATA0_RX-
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 22pin SATA
Connector (J25) for SATA Channel0 Receive
differential pair negative.
38
SATA1_RX-
NC
-
NC in RZ/G1H Qseven SOM.
This pin connected to 7pin SATA Connector
(J21) in carrier board.
39
GND
GND
Power
Ground.
40
GND
GND
Power
Ground.
41
BIOS_DISABLE#/
BOOT_ALT#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected from 8bit DIP switch
(SW2) 1st position in carrier board.
42
SDIO_CLK#
SD2_CLK(GP3_16)
I, 3.3V CMOS
SDHI2 Clock.
This pin is connected to SD/MMC connector
(J30).
43
SDIO_CD#
SD2_CD(GP3_22)
O, 3.3V CMOS/
10K PU
SDHI2 Card Detect.
This pin is connected from SD/MMC
connector (J30).
44
SDIO_LED
GPIO_SD1_LED(GP5_
22)
I, 3.3V CMOS
SDIO LED.
This pin is connected to D8 Green LED.

REL1.0
Page 19 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Pin
No.
Qseven MXM
Connector Pin
Name
Signal Name
Signal Type/
Termination
Description
45
SDIO_CMD
SD2_CMD(GP3_17)
IO,3.3VCMOS/
10K PU
SDHI2 command.
This pin is connected to SD/MMC connector
(J30).
46
SDIO_WP
SD2_WP(GP3_23)
O, 3.3V CMOS/
10K PU
SDHI2 Write Protect.
This pin is connected to SD/MMC connector
(J30).
47
SDIO_PWR#
GPIO_SD1_PWR(GP1
_27)
I, 3.3V CMOS/
10K PD
SD/MMC Interface Power Enable.
This pin is used control the power input to
the SD/MMC connector.
48
SDIO_DAT1
SD2_DAT1(GP3_19)
IO, 3.3V CMOS
SD2 Data1.
This pin is connected to SD/MMC connector
(J30).
49
SDIO_DAT0
SD2_DAT0(GP3_18)
IO, 3.3V CMOS
SD2 Data0.
This pin is connected to SD/MMC connector
(J30).
50
SDIO_DAT3
SD2_DAT3(GP3_21)
IO, 3.3V CMOS
SD2 Data3.
This pin is connected to SD/MMC connector
(J30).
51
SDIO_DAT2
SD2_DAT2(GP3_20)
IO, 3.3V CMOS
SD2 Data2.
This pin is connected to SD/MMC connector
(J30).
52
SDIO_DAT5
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to SD/MMC connector
(J30) in carrier board.
53
SDIO_DAT4
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to SD/MMC connector
(J30) in carrier board.
54
SDIO_DAT7
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to SD/MMC connector
(J30) in carrier board.
55
SDIO_DAT6
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to SD/MMC connector
(J30) in carrier board.
56
USB_DRIVE_VBUS
USB0_PWEN(GP5_18
)
I, 3.3V CMOS
USB OTG Power enable.
57
GND
GND
Power
Ground.
58
GND
GND
Power
Ground.
59
HDA_SYNC/
I2S_WS
SSI_WS34(GP4_9)
I, 3.3V CMOS
SSI Audio transmit frame synchronization.
This pin is connected to I2S audio codec.

REL1.0
Page 20 of 106
RZ/G1H Qseven Development Platform Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Pin
No.
Qseven MXM
Connector Pin
Name
Signal Name
Signal Type/
Termination
Description
60
SMB_CLK/
GP1_I2C_CLK
I2C0_SCL
I, 3.3V OD
I2C0 clock.
This pin is connected to PCIe Clock buffer,
PCIex4 connector, Mini PCIe connector and
Expansion Connector3 (J14) 77th Pin.
61
HDA_RST#/
I2S_RST#
GPIO_SSI_RST(GP1_2
9)
I, 3.3V CMOS/
10K PU
Audio Codec Reset.
This pin is connected to Capacitive Touch
Connector for touch reset & Expansion
connector3 (J14) 42nd Pin.
62
SMB_DAT/
GP1_I2C_DAT
I2C0_SDA
IO, 3.3V OD
I2C0 Data.
This pin is connected to PCIe Clock buffer,
PCIex4 connector, Mini PCIe connector and
Expansion Connector3 (J14) 79th Pin.
63
HDA_BCLK/
I2S_CLK
SSI_SCK34(GP4_8)
O, 3.3V CMOS
SSI Audio transmit clock.
This pin is connected from I2S audio codec.
64
SMB_ALERT#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to Expansion
connector3 (J14) 11th Pin in carrier board.
65
HDA_SDI/ I2S_SDI
SSI_SDATA3(GP4_10)
I, 3.3V CMOS
SSI Audio Transmit Data.
This pin is connected to I2S audio codec.
66
GP0_I2C_CLK
I2C2_SCL(GP4_0)
I, 3.3V OD
I2C2 clock.
This pin is connected to I2S Audio Codec,
Capacitive touch connector, Resistive touch
connector, and Expansion Connector3 (J14)
78th Pin.
67
HDA_SDO/
I2S_SDO
SSI_SDATA4(GP4_13)
O, 3.3V CMOS
SSI Audio Receive Data.
This pin is connected from I2S audio codec.
68
GP0_I2C_DAT
I2C2_SDA(GP4_1)
IO, 3.3V OD
I2C2 Data.
This pin is connected to I2S Audio Codec,
Capacitive touch connector, Resistive touch
connector, and Expansion Connector3 (J14)
80th Pin.
69
THRM#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected from Push button
(SW6) in carrier board.
70
WDTRIG#
NC
-
NC in RZ/G1H Qseven SOM.
This pin is connected to Expansion
connector3 (J14) 17th Pin in carrier board.
71
THRMTRIP#
GPIO_THRMTRIP_Q7
(GP4_11)
O, 3.3V CMOS
Thermal trip.
This pin is connected to indication LED D11
and Expansion connector3 (J14) 53rd Pin.
