iWave iW-RainboW-G28D User manual

03
Zynq-7000 SoC SODIMM SOM
Development Platform
iW-RainboW-G28D
Quick Start Guide

Quick Start Guide
Disclaimer
iWave Systems reserves the right to change details in this
publication including but not limited to any Product specification
without notice.
No warranty of accuracy is given concerning the contents of the
information contained in this publication. To the extent
permitted by law no liability (including liability to any person by
reason of negligence) will be accepted by iWave Systems, its
subsidiaries or employees for any direct or indirect loss or
damage caused by omissions from or inaccuracies in this
document.
Trademarks
Certification
iWave Systems Technologies Pvt. Ltd. is an ISO 9001:2015
Certified Company.
All registered trademarks, product names mentioned in this
publication are the property of their respective owners and used
for identification purposes only.

Introduction
Quick Start Guide (QSG)
Quick Start Guide
This Quick Start Guide (QSG) is designed for Users to quickly
understand the iW-RainboW-G28D Zynq-7000 SoC SODIMM
Development Board and start the evaluation.It provides the
instructions for setting-up the development board from the
packed box.
Development Platform Description
gCompatible Zynq-7000 SoC- Z-7007S,Z-7014S,Z-7010,Z-7020
Integrated Dual Core ARM Cortex A9 @ up to 866MHz
Up to 85K Logic Elements
The iW-RainboW-G28D Zynq-7000 SoC SODIMM Development
platform incorporates with Zynq-7000 SoC based SODIMM
SOM, SODIMM carrier board with rugged IO connectors and
interface connectors which provides all necessary hardware for
developing an embedded FPGA application based on Xilinx
Zynq-7000 SoC.
gDDR3-512MB (Expandable)
Some Key Features of the Board Include:
gQSPI-2MB (Expandable)
geMMC-8GB (Expandable)
gWi-Fi/BT
gGigabit Ethernet Port
gUSB2.0 OTG Host & Device Port
gFMC Connector
gPmod Connectors
01

This development platform is ESD sensitive. Handle the
product only in accordance with the installation instructions
given in the manual. Therefore ESD precautions should be
taken care during transport and handling. You must use a ESD
ground strap or other grounded source before unpacking or
handling the hardware.
Warning!
iW-RainboW-G28D Zynq-7000 SoC SODIMM Development
board is designed by using RoHS compliant components and
manufactured on lead free production process.
WEEE is Waste Electrical and Electronic Equipment. Check the
local regulations for disposal of electronic products before
disposing.
ESD Sensitive RoHS Compliant
iW-RainboW-G28D
ESD Protection
WEEE Regulations
RoHS Compliance
iW-RainboW-G28D
WEE
02

iW-RainboW-G25D
Step 1 - Unpacking
Remove the Development platform from antistatic cover and
place it above the ESD free area. Use anti-static pad/mat with
proper grounding to place the Development Platform. Don't
touch inside surface of the circuit board.
Quick Start Steps
Quick Start Guide
Avoid using board in extreme dust, humidity and temperature
conditions. Also this development platform is not water proof.
Keep away from wet surface.
Package Box
Zynq-7000 SoC SODIMM SOM
Development Platform
iW-RainboW-G28D
Quick Start Guide
03

Step 2 - What's Inside The Box ?
Make sure that, below deliverables are received without any
physical damage.
iW-RaniboW-G28D
5V,2.5A Power Supply USB OTG Cable QSG
Zynq-7000 DevKit
iW-RaniboW-G28D
Zynq-7000 SoC SODIMM SOM
Development Platform
iW-RainboW-G28D
Quick Start Guide
04

Quick Start Guide
Step 3 - Download FTP Contents
All the technical resources of iW-RainboW-G28D Zynq-7000
SoC- Z-7007S/Z-7014S/Z-7010/Z-7020 SODIMM Development
platform is available in iWave FTP server.
For FTP Credentials, Contact : [email protected]
iW-RainboW-G30D
Hardware
Datasheet-UserGuides
PCB-CAD Files
QuickStartGuide
SOM-HardwareUserGuide
DevKit-HardwareUserGuide
SOM
DevKit
FPGAUserGuide
ReleaseNotes
SoftwareUserGuide
Binaries
Patch
Integrated Design
Heatsink-Datasheet
PCB-CAD Files
Mechanical Files
Compliance Report
MPSoC Name
SOM Part Number
Vivado Version
Software+FPGA
Hardware
iW-RainboW-G28D
FTP Folder Structure
05
Documents
PetaLinux
FPGA-Example-Design
Tools

Step 4 - Quick View-SOM
iW-RainboW-G28D
TOP View
BOTTOM View
iW-RainboW-G28D
06
Zynq 7000 SoC
SODIMM Edge
Wi-Fi Module
SODIMM Edge

1. Power Jack (J9)
2. Power On/Off Switch (SW3)
3. PmodConnector2 (J5)
4. SODIMM Connector (J7)
5. Pmod Connector1 (J3)
6. FMC Connector ( J1)
7. Ethernet Jack ( J2)
8. USB OTG MicroAB Port (J4)
9. Reset Switch (SW1)
10.Debug USB MicroAB Port (J6)
11. JTAG Connector (J8)
12. Micro SD Connector (J11)
13. Coin Cell Holder (J12)
Step 5 - Quick View-Carrier Board
TOP View
BOTTOM View
Quick Start Guide
07
1
2
3
4
5
6
7
8
9
10
11
13
12

Quick Start Guide
iW-RainboW-G25DiW-RainboW-G25D
Install the driver for Debug Port in Host PC/Laptop using the
below link.
https://ftdichip.com/products/ft232rq/
Connect TypeA end of USB cable to PC and MicroB end of USB
cable to Development platform's Debug USB MicroAB
Connector (J4) as shown below.
Step 6 - Setting-Up
iW-RainboW-G28D
Debug Port Setting
Setup the Debug Terminal parameters.
Baud Rate : 115200
Data bits : 8
Parity : None
Stop Bits : 1
Flow Control : None
08

03
Connect the 5V power supply to the power jack (J9) of the
Development platform as shown below and slide the Power
ON/OFF button (SW3) as indicted in below image to turn ON the
Development platform.
Warning:
1. Do not try to connect any other power supply other than the
supplied one along with the Development Kit.
2. Do not plug or remove the SOM from carrier board with live
power.
3. Contact iWave If power LEDs are not glowing.
Step 7 - Power-ON the Development Platform
Once Power is applied to the Development platform, the Power
LEDs in the Zynq-7000 SODIMM SOM and carrier board will
glow as shown in the below image.
Quick Start Guide
09
SOM Status LED
Carrier Board Status LED
Power ON/OFF
Switch

Step 8 - Test Environment setup
Once the board power is up, boot messages being displayed in
the debug terminal of PC/Laptop. Press any key in terminal
immediately to see the command prompt of the Boot loader or
wait until Linux OS boots.
After Linux OS boots, Login prompt being displayed in the
debug terminal and enter password as "root" to get the Linux
command prompt as shown below.
CommandPrompt
10
Quick Start Guide
iW-RainboW-G28D

iW-RainboW-G28D
Quick Start Guide
11
The iW-RainboW-G28D Zynq-7000 SoC SODIMM Development
platform Support JTAG interface in Carrier Board for
MPSoC/FPGA Programming and debugging.
JTAG-HS2 Programming Cable
Part Number: 410-249 from Digilent
Example JTAG Cable which is tested with this Platform is
mentioned below.
JTAG
JTAG Connection

iWave’s Other Products
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G28D
Product Name: Zynq US+ MPSoC
(4/5/7-EV/EG/CG) SOM
Processor: Xilinx’s Zynq US+ MPSoC
(4/5/7-EV/EG/CG)
RAM: 4GB PS DDR4*
1GB PL DDR4*
Application: Industrial Motor Control & IoT,
Sensor Fusion, ADAS/Embedded Vision,
Data Centor, Medical Endoscopy
* RAM size is expandable. Contact iWave team for further details
Product Name: Zynq UltraScale+ MPSoC
(ZU5/ZU4/ZU3/ZU2) SBC
Processor: Xilinx’s Zynq US+ MPSoC
(2/3/4/5-EV/EG/CG)
RAM: 8GB PS DDR4* & 4GB PL DDR4*
Application: AI/ML, Industrial IoT, Human
Machine Interface, Advanced Driver
Assistance Systems.
12
Product Name: Zynq US+ MPSoC
(11/17/19-EG) SOM
Processor: Xilinx’s Zynq US+ MPSoC
(11/17/19-EG)
RAM: 4GB PS DDR4*
4GB Dual PL DDR4*
Application: Video Surveillance, Cloud
Computing, Artificial Intelligence/Machine
Learning, 5G Wireless, High Precision Test
Instrument.

Need More Help ?
iWave Systems Provides Technical Support to all Customers
Worldwide.
gEmail
Write your technical queries to [email protected]
gPhone
Call us on : [phone], 26781643, 26786245
gLive Chat
We provide Live Chat technical support to our customers.
Contact iWave to enable Live Chat support.
iW-PRFOZ-UM-01-R4.0-REL1.0-QSG
