jbc T6057 User manual

T6057 / T1528 / T1530
Grips for T245 /
T245G / T245P Handles
INSTRUCTION MANUAL

Manual ........................... 1 unit
Ref. 0016121
Fitters ............................... 4 units
Packing List
The following items are included*:
This manual corresponds to the following references:
0016057 green 0021528 blue 0021530 black
Grips for T245 / T245G / T245P Handles .......................... 4 units
* According to product reference, either green, blue or black grips are
included.
2

CD-Q:
OK
CD-Q:
OK
CD-Q:
OK
Hold this way
so the fitters
can slide
Insert the fitters into the new
grip.
To remove the fitters, hold the
grip and pull the fitters out. Use
pliers if necessary.
Fitter
New Grip
1. Inserting Fitters
2. Assemble Grip
3. Removing Fitters
Push the grip with the fitters
onto the handle.
Changing Grips
Replace the grips easily using the included fitters like shown in the
following pictures.
3
www.jbctools.com

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic
equipment at the end of its life must be collected and returned to an
authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against all manufacturing defects,
including the replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must be returned, postage paid, to
the dealer where it was purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
0016121-1021
T6057 / T1528 / T1530
Grips for T245 / T245G / T245P Handles
Ref.: 0016057 green Ref.: 0021528 blue Ref.:0021530 black
- Grip Dimensions: 62 x ø15.8 mm / 2.44 x ø0.62 in
- Total Net Weight: 8 g / 0.018 lb
- Package Dimensions/Weight: 90 x 55 x 40 mm / 19.5 g
(L x W x H) 3.54 x 2.17 x 1.57 in / 0.043 lb
Complies with CE standards.
ESD safe.
Specifications
