jbc HDE-9E User manual

Station
More Information at the
product web page
Video Guide
Watch the
product video
HDE
Heavy Duty Soldering Station
This Plug & Play Guide corresponds to the following references:
Ref.
HDE-9E (100 V)
HDE-1E (120 V)
HDE-2E (230 V)

2
T470F
Thermal Insulator Grip HD Handle ...................... 1 unit
Ref. T470-FA (cartridge not included)
HDE
Heavy Duty Control Unit .................................. 1 unit
Ref. HDE-9UD (100 V)
Ref. HDE-1UD (120 V)
Ref. HDE-2UD (230 V)
Power Cord
Included in HDE Control Unit
HDE
Heavy Duty
Control Unit
Packing List
The following items are included according purchased station reference:
HDS
Stand for T470 Heavy Duty Handles .................... 1 unit
Ref. HD-SF
SCH
Cartridge Holder ...................................................... 1 unit
Ref. SCH-A
Installation

3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Installation
HDS
Stand for T470 Heavy
Duty Handles
T470F
Thermal Insulator Grip HD
Handle
C470 *
Cartridge Range
Stand Cable **
Ref. 0024227
HDE
Heavy Duty Control Unit
* Not included, sold separately
SCH
Cartridge Holder
** Included in HDS Stand for T470

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must be collected and returned to an authorized
recycling facility.
Warranty
Get 2 year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
HDE
Heavy Duty Soldering Station
Ref. HDE-9E (100 V)
Ref. HDE-1E (120 V)
Ref. HDE-2E (230 V)
- Package Dimensions / Weight: 450 x 345 x 243 mm / 6.82 kg
(L x H x W) 17.72 x 13.58 x 9.57 in / 15.04 lb
Complies with CE standards.
ESD safe.
0031507-190523
Specifications
