jbc JT-T1A User manual

INSTRUCTION MANUAL
JTT
Heater Hose Set

TC
Suction
OK
17:14
20
ºC
Power
45%
120ºCSelected
TC
Temp.
4m 38s
400
ºC
80
%
400ºCSelected
Protection
HotAir Temp. AirFlow Selec.
TC
Suction
OK
JTT
TET
JT
TE
Use only with a 250V fuse
Employer uniquement avec
un fusible de 250V
TC
Suction
OK
Manual ................... 1 unit
Ref. 0029044
Handle for JTT ... 1 unit
Ref. JT-A
JTH
Heating Element for JTT ...... 1 unit
according to purchased reference incuded
either JTH1 Ref. 0014105 (100V/120V)
or JTH2 Ref. 0014107 (230V)
Packing List
The following items are included:
This manual corresponds to the following references:
JT-T1A (110V/120V)
JT-T2A (230V)
Changing JTT Heater Hose Set
Note: Only perform this operation when
the station is turned off.
Use a spanner to unscrew the nut (1) and
remove the tool hose (2).
Insert the new hose, make
sure it is pushed all the way
into the connector (2), and
tighten the nut (1).
1
2
2
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

TC
Suction
OK
TC
Suction
OK
Features
JTT Heater Hose Set allows to repair medium and large SMDs. It
works with JTU Control Unit and JT Nozzles.
Replacing the Heating Element
Note: Only perform this operation when the heating element is cold
and the unit is disconnected from the mains.
Loosen the screw (1) and pull the worn heating element out of the
handle (2).
Insert the new heating element, make sure its pushed all the way in
(2) and tighten the screw (1).
JTH
Heating Element for JTT
Ref. 0014105 (100V and 120V)
Ref. 0014107 (230V)
JTT
Heater Hose Set
Ref. JT-T1A (110V, 120V)
Ref. JT-T2A (230V)
2
1
JT Nozzle*
Tool Button:
Start/stop blowing hot air
* not included, sold separately
Handle for JTT
Ref. JT-A
(100V / 120V / 230V)
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic
equipment at the end of its life must be collected and returned to an
authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against all manufacturing defects,
including the replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must be returned, postage paid, to
the dealer where it was purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
0029044-0522
JTT
Heater Hose Set
Ref.: JT-T1A (110V/120V)
Ref.: JT-T2A (230V)
- Hose Length: 1100 mm / 43.31 in
- Total Net Weight: 370.5 g / 0.817 lb
- Package Dimensions/Weight: 382 x 159 x 81 mm / 508.8 g
(L x W x H) 15.04 x 6.26 x 3.19 in / 1.122 lb
Complies with CE standards.
ESD safe.
Specifications
