jbc JNA Series User manual

Station
More Information at the
product web page
Video Guide
Watch the
product video
JNA
High-Precision Hot Air Station
This Plug & Play Guide corresponds to the following references:
Ref.
JNA-9B (100 V)
JNA-1B (120 V)
JNA-2B (230 V)

2
Stand for NH ....................................... 1 unit
Ref. NA-SB
High-Precision Hot Air Control Unit .... 1 unit
Ref. JNA-9UB (100 V)
Ref. JNA-1UB (120 V)
Ref. JNA-2UB (230 V)
Power Cord
Included in JNA Control Unit
JNA
High-Precision Hot Air
Control Unit
Packing List
The following items are included according to purchased station reference:
High-Precision Heater Hose Set ... 1 unit
Ref. NH-A
Installation
J125 / J325 Cartridge Range ....... 2 units
Ref. J125410 (Ø 1 mm, bent) ............................1x
Ref. J325410 (Ø 3 mm, bent) ............................1x
Pick & Place Handle ........................ 1 unit
Ref. T260-A
NBC260 Bent Needles & Cups
for T260 ................................................ 1 unit
Ref. 0026490
Pedal ................................................... 1 unit
Ref. P-405

3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Installation
JNA
High-Precision Hot Air Control Unit
JNA
High-Precision Hot Air Control Unit
NAS
Stand for NH
High-Precision Heater Hose Set
P405
Pedal
T260
Pick & Place Handle
NH
High-Precision
Heater Hose Set
J125010 *
Cartridge
Stand Cable
Ref.: 0023953
* Not included, sold separately.

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must be collected and returned to an authorized
recycling facility.
Warranty
Get 2 year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
JNA
High-Precision Hot Air Station
Ref. JNA-9B (100 V)
Ref. JNA-1B (120 V)
Ref. JNA-2B (230 V)
- Net Weight: 4.06 kg / 8.94 lb
- Package Dimensions / Weight: 425 x 295 x 495 mm / 5.75 kg
(L x H x W) 16.73 x 11.61 x 19.49 in / 12.68 lb
Complies with CE standards.
ESD safe.
00 31524-131223
Specifications
