jbc NA101 User manual

NA101/NA102
NANE Updating Kit C115/
NASE Updating Kit C115
INSTRUCTION MANUAL

Adjustable Nano Tweezers .................... 1 unit
Ref. A N115 - A
Splashguard .................................... 2 units
Nano Handle ............................................ 2 units
Ref. N T115 - A
Soft Foam Grip
(Ref. see page 5)
Manual .................................................. 1 unit
Ref. 0029833
Packing List
The following items are included in
Ref. 0 021101:
This manual corresponds to the following references:
0021101 - NA101 0021102 - NA102
NANE Updating Kit C115 NASE Updating Kit C115
The following items are included in
Ref. 0 021102:
The following items are included for Ref. 0021101 and Ref. 0021102:
Nano Handle ............................................... 1 unit
Ref. N T115 - A
Soft Foam Grip
(Ref. see page 5)
2
