JDS Uniphase Portable Optical Network Tester MTS-8000 User manual

ACTERNA TEST & MEASUREMENT SOLUTIONS
WEBSITE: www.jdsu.com/fiberoptictest
Transport Module
• All in one module for
Full PDH/T-Carrier & SDH/SONET test-
ing up to 10 Gb/s
Ethernet testing 10/100/1GigE/
10GigE LAN & WAN up to the IP layer
Dispersion Modules
• PMD – Polarization Mode Dispersion
• CD – Chromatic Dispersion
MTS-8000 Portable Optical Network Tester
All your optical network testing needs covered in a single platform
The power of one, performing
the work of many
A powerful unit
• Flexible scalable platform
• Industry-leading size and weight, e.g. plat-
form + transport module < 7 kg
• Interchangeable modules
• Generates test results in seconds
• Fully automatic testing
• Combination of several tests
• Remotely controlled (via Ethernet, Fiber)
Fiber Characterization Testing
• Optical Time Domain Reflectometer
(OTDR)
• Chromatic Dispersion (CD)
• Polarization Mode Dispersion (PMD)
• Attenuation Profile (AP)
• Loss testing
CWDM/DWDM Testing
• OSA with frequency range from 1250 nm to
1650 nm
• DWDM parameters OSNR, optical channel
power, wavelength deviation
• Application for EDFA and DFB testing
• Channel isolation for BER analysis
• Single or dual port analyzer
Amplified DWDM system analysis
Pass/Fail OTDR analysis
OTDR Module
• More than 20 OTDR modules
• Combined wavelengths MM: 850/1300
SM: 1310/1383/1550/1625 nm
• Dynamic range 30 dB up to 50 dB

MTS-8000 Tester
2
Automatic bi-directional
measurement function
• Automate the acquisition process
• Check fiber continuity
• File transfer through the fiber
• True splice loss with both end analysis
• Optical talkset option needed
Bi-directional OTDR analysis


1
1
1
1
1
2
3
4
Pulse delay method complies with TIA/EIA FOTP-168
DUT
Polarized
Broadband
Source
Analyzer OSA
PMD test results with Pass/Fail analysis
Local
Remote
MTS-8000 00286
UHD 1310/1550/1625 nm
MTS-8000 00439
UHD 1310/1550/1625 nm
Tested fiber
Data
PC software solution for report generation
OFS-100 Results Analysis
• OTDR, CD, PMD, AP, and OSA results
analysis
• Batch processing capability via automation
process
• Pass/Fail function
• Customized printouts
OFS-200 FiberCable Acceptance
Report Generation
• Complete fiber characterization reporting
capability including bi-directional OTDR,
CD, PMD, AP, IL and ORL results
• Advanced OTDR evaluation for loop back
and mid-point management
• Powerful report preview
• Direct access keys for easy process and
efficiency
Single menu for chromatic dispersion trace and table
display
Fiber Characterization
CD Module
• Pulse delay method complies with TIA/EIA
FOTP-168
• Fast single-end measurement with sectional
analysis capability
• CD analyzer and four-wavelength OTDR
(1310/1480/1550/1625 nm) with one module
Physical Fiber Testing
Key features OTDR
• Fast data acquisition enables VHD plug-in
to reach 40 dB aer 10 s with a maximum
performance up to 45 dB
• Highest dynamic range with 50 dB at
1550 nm, UHD module
• New VLR module with outstanding dead
zone of 0.8 m EDZ and 4 m ADZ, 43 dB
dynamic
• Fastest scan speed at 0.1 s in real-time mode
• Up to 128000 acquisition points with sam-
pling resolution down to 4 cm
Built-in Optical Talkset
• Data transfer capability: file exchange or
remote control
• Used also for fully automatic bi-directional
measurements
• OTS-55 handheld for far end communica-
tion
PMD Module
• Fixed analyzer method standardized by
ITU-T, IEC and TIA/EIA
• Fast measurement time – from just
6 seconds
• Measure through multiple EDFAs

MTS-8000 Tester
3
Transport Confi guration
Primary Port Bank
• 2.5 Gb/s, 622 Mb/s, and 155 Mb/s SDH/SONET
Tx/RX (1310 nm, 1550 nm)
• 10/100/1000 Mb/s Ethernet
• 1 GigE Tx/Rx (850 nm, 1310 nm, 1550 nm)
Secondary Port Bank
• 10/100/1000 Mb/s Ethernet
• 1 GigE Tx/Rx (850 nm, 1310 nm, 1550 nm)
10 Gb/s Port Bank
• 10 Gb/s SDH/SONET (1310 nm, 1550 nm)
• 10 GigE LAN & WAN (850 nm, 1310 nm, 1550 nm)
Optical Connection Check Interfaces
• High accuracy power meter
• Continuous wave power source
• Visual fault locator
Port Bank #4
• T1 and E1 balanced and
unbalanced Tx/Rx
Port Bank #5
• E3, DS3, STS-1, E4 Tx/Rx
• STM-1 (e) Tx/Rx
Transport Module
• Contained in one 5 cm module
– PDH / T-carrier interfaces include
DS1, E1, E3, DS3, E4, STS-1 and STM-1e
– SDH/SONET interfaces (1310 nm, 1550 nm) include
155 Mb/s, 622 Mb/s, 2.5 Gb/s, 10 Gb/s
– Ethernet interfaces (850 nm, 1310 nm and 1550 nm)
include
10/100/1000 Mb/s electrical and 1 GigE Optical
– 10 GigE LAN + WAN
• Only 2.5 kg fully populated, total weight < 7 kg
• Fully scalable to meet your current and future needs
• Optical and electrical signal level measurements
• Up to 2.5 hours at 10 Gb/s rates with one battery
(2 batteries possible)
• Field exchangeable connectors for all standard connector
types
• SDH/SONET testing
– Mixed payload generation and analysis
– Concatenated signals
– Automatic Protection Switching (APS)
– Overhead byte manipulation and analysis
– Round Trip Delay (RTD)
• Ethernet testing
– Single and dual port Ethernet confi guration
– Testing on Layer 1, 2 and 3 (IP)
– VLAN support
– Constant, burst and ramp traffi c generation
– Traffi c fi lter capabilities
– Automated RFC2544 testing
– Loop-up /loop-down of far end device

All statements, technical information and recommendations related to the products herein are based upon in-
formation believed to be reliable or accurate. However, the accuracy or completeness thereof is not guaranteed,
and no responsibility is assumed for any inaccuracies. e user assumes all risks and liability whatsoever in con-
nection with the use of a product or its applications. JDSU reserves the right to change at any time without notice
the design, specifications, function, fit or form of its products described herein, including withdrawal at any time
of a product offered for sale herein. JDSU makes no representations that the products herein are free from any
intellectual property claims of others. Please contact JDSU for more information. JDSU and the JDSU logo are
trademarks of JDS Uniphase Corporation. Other trademarks are the property of their respective holders.
© 2006 JDS Uniphase Corporation. All rights reserved.
Test & Measurement Regional Sales
NORTH AMERICA
TOLL FREE: 1 866 228 3762
FAX: [phone]
LATIN AMERICA
TEL:[phone]
FAX:[phone]
ASIA PACIFIC
TEL:[phone]
FAX:[phone]
EMEA
TEL:[phone]
FAX:[phone]
WEBSITE:
www.jdsu.com/fiberoptictest
MTS-8000 Tester
EFSCOPE250, EFSCOPE400: Optical video inspection probe
Accessories
E80HCase5: Hard carrying case for
single module configuration
E80SCase3: Soft carrying case for
single module platform
E80keyB: USB keyboard
Connector Inspection Scope
• Fiber Connector Inspection Connectors
• Patch panel inspection
• 250 or 400 magnification
• Uses MTS-8000 large screen (10.4”)
• Comparison with 3 other images on the same
screen
Alternatively
OVF-1 ball pen-sized separate visual fault
locator
Built-in 635 nm Visual Fault Locator
• Universal push/pull for all 2.5/1.25 mm
connector types
Insertion Loss Measurements
• Power meter integrated in MTS-8000
mainframe
• Multi-wavelength laser source with CW or
modulated signals
• Easy loss measurements of a jumper or
patch cord OTS-55 SMART Optical Talkset
• ≥ 45 dB dynamic range
• Wavelength of operation: 1550 nm
