Assembly Instructions and Parts List

22-1/2” Bed Extension for JWL-1221VS Lathe

Stock No. 719201

Read and understand the entire owner's manual that accompanied your JWL-1221VS

lathe before attempting assembly or operation of accessories.

WARNING: This product can expose you to chemicals including lead and cadmium which are known to the

State of California to cause cancer and birth defects or other reproductive harm. For more information go to

http://www.p65warnings.ca.gov.

WARNING: Drilling, sawing, sanding or machining wood products generates wood dust and other

substances known to the State of California to cause cancer. Avoid inhaling dust generated from wood

products or use a dust mask or other safeguards for personal protection.

Wood products emit chemicals known to the State of California to cause birth defects or other reproductive

harm. For more information go to http://www.p65warnings.ca.gov/wood.

Inspect contents for shipping damage. Report any

damage or part shortages to your distributor. Do

not discard shipping materials until accessory is set

up and functioning properly.

Shipping contents

1 Bed extension

2 Socket head screws, 5/16x1

2 Lock washers, 5/16x1

2 Flat washers, 5/16x1

1 Positioning plate

1 Pan head screw, 1/4x1/2

Tools required for assembly

6mm hex key (“Allen wrench”)

Cross point screwdriver

Assembly

(Parts in brackets refer to index numbers in the

exploded view.)

1. Use the pan head screw [1] to attach plate [2]

to end of bed extension [3] where the beds will

meet.

2. Place bed extension against lathe bed and

hold in place with the plate [2].

3. Insert two socket head screws [6], lock

washers [5] and flat washers [4]. Align beds as

closely as possible, then snug the screws but

do not fully tighten yet.

4. Move tailstock over the seam of lathe bed and

bed extension and align the clamping nut in

the center where the beds meet. (Shift bed

extension as needed until tailstock can slide

onto it). Tighten tailstock clamping lever – this

will properly align and make flush the beds.

5. Tighten both socket head screws [6].

6. Unlock tailstock, and slide it back and forth

across seam to verify smooth travel.

JET

427 New Sanford Road

LaVergne, Tennessee 37086 Part No. M-719201

Ph.: 800-274-6848 Revision A2 11/2018

Specifications

Stock number .............................................................................................................................................. 719201

Assembled dimensions ...................................................................... 572 x 229 x 216 mm (22.5”L x 9”W x 8.5”H)

Net weight ...................................................................................................................................... 19 kg (41.89 lb)

Shipping dimensions ..................................................................... 640 x 288 x 277 mm (25.20” x 11.33” x 10.90”)

Shipping weight ................................................................................................................................ 22 kg (48.5 lb)

Specifications were current at time of publication, but because of our policy of continuous improvement, JET

reserves the right to change specifications at any time and without prior notice, without incurring obligations.

# 719201 Bed extension (22-1/2”) for JWL-1221VS lathe

Index No Part No Description Size Qty

1 ................. TS-081F032 ................ Phillips Pan Head Machine Screw ............................... 1/4”-20x1/2” ..................... 1

2 ................. JWL1221VS-502 ......... Plate ............................................................................. ........................................ 1

3 ................. JWL1221VS-503 ......... Extension Bed .............................................................. ........................................ 1

4 ................. TS-0680031 ................ Flat Washer .................................................................. 5/16” ................................ 2

5 ................. TS-0720081 ................ Lock Washer ................................................................ 5/16” ................................ 2

6 ................. TS-0208061 ................ Socket Head Cap Screw .............................................. 5/16”-18x1” ...................... 2
