JHCTech KGEC-6310-S001 User manual

用户手册
User’s Manual
KGEC-6310
Ver.: A0.1
Date：2020-10-22

User’s Manual
Version Note
No.
Ver.
Note
Date
Writer
1
A0.1
first publish
20201022
Echo Guo

User’s Manual
I
Copyright
The documentation and the software included with this product are copy- righted 2020 by Shenzhen JHC
Technology Development Co.,Ltd. All rights are reserved. Shenzhen JHC Technology Development
Co.,Ltd. reserves the right to make improvements in the products described in this manual at any time
without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Shenzhen JHC Technology Development Co., Ltd .
Information provided in this manual is intended to be accurate and reliable. However,
Shenzhen JHC Technology Development Co., Ltd . assumes no responsibility for its use, nor for any
infringements of the rights of third parties, which may result from its use.

User’s Manual
II
Product Warranty (2 years)
JHC warrants to you, the original purchaser, that each of its products will be free from defects in materials
and workmanship for 2 years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons other than
repair personnel authorized by JHC, or which have been subject to misuse, abuse, accident or improper
installation.
JHC assumes no liability under the terms of this warranty as a consequence of such events.
Because of JHC.s high quality-control standards and rigorous testing, most of our customers never need to
use our repair service. If a JHC product is defective, it will be repaired or replaced at no charge during the
warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement
materials, service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU speed, JHC products
used, other hardware and software used, etc.) Note anything abnormal and list any onscreen messages
you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any helpful
information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise authorization) number
from your dealer. This allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement Order Card and a
photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer.

User’s Manual
III
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications
when shielded cables are used for external wiring. We recommend the use
of shielded cables. This kind of cable is available from JHC. Please
contact your local supplier for ordering information. Test conditions for
passing included the equipment being operated within an industrial enclosure.
In order to protect the product from being damaged by ESD (Electrostatic
Discharge) and EMI leakage, we strongly recommend the use of
CE-compliant industrial enclosure products.
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Technical Support and Assistance
Step 1. Visit the JHC web site at www.jhctech.com.cn where you can find the latest information about the
product.
Step 2. Contact your distributor, sales representative, or JHC’s customer service center for technical
support if you need additional assistance. Please have the following information ready before you
call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, application software, etc.)
- A complete description of the problem
- The exact wording of any error messages

User’s Manual
1
CONTENTS
General Information ................................................................................... 4
1.1 Introduction............................................................................................................................. 5
1.2 Features ................................................................................................................................... 5
1.3 Specifications ........................................................................................................................... 7
1.3.1 General..........................................................................................................................................7
1.3.2 Display...........................................................................................................................................7
1.3.3 Ethernet ........................................................................................................................................7
1.3.4 Power Consumption .....................................................................................................................7
1.4 Environmental Specifications................................................................................................... 7
1.5 Order information ................................................................................................................... 8
1.6 Mechanical Specifications........................................................................................................ 9
Hardware Installation ................................................................................13
2.1 Introduction........................................................................................................................... 14
2.2 Switches ................................................................................................................................. 14
2.2.1 CLEAR/COMS -Clear CMOS Data.................................................................................................14
2.2.2 AT/ATX Power on mode selection...............................................................................................15
2.3 I/O/Button/LED Indication.................................................................................................... 15
2.3.1 Ethernet Connector ....................................................................................................................16
2.3.2 USB..............................................................................................................................................17
2.3.3 HDMI...........................................................................................................................................18
2.3.4 DVI-D...........................................................................................................................................18
2.3.5 Power input.................................................................................................................................19
2.3.6 COM ............................................................................................................................................20

User’s Manual
2
2.3.7 DIO ..............................................................................................................................................20
2.3.8 SATA.............................................................................................................................................21
2.3.9 SATA Power .................................................................................................................................21
2.3.10 Mini PCIe...................................................................................................................................21
2.3.11 mSATA .......................................................................................................................................22
2.3.12 M.2............................................................................................................................................24
2.3.13 LED ............................................................................................................................................24
2.4 Installation............................................................................................................................. 25
2.4.1 HDD/SSD installation ..................................................................................................................25
2.4.2 Mini PCIe installation..................................................................................................................26
2.4.3 mSATA installation.......................................................................................................................28
2.4.4 M.2 module installation..............................................................................................................29
BIOS Setup.................................................................................................30
3.1 BIOS Description ..................................................................................................................... 31
3.1.1 Entering the Setup Utility ...........................................................................................................31
3.2 BIOS parameter settings.......................................................................................................... 32
3.2.1 BIOS Navigation Keys ..................................................................................................................33
3.2.2 Main Menu .................................................................................................................................33
3.2.3 Advanced Menu..........................................................................................................................35
3.2.4 Chipset Menu..............................................................................................................................42
3.2.5 Security menu.............................................................................................................................49
3.2.6 Boot menu ..................................................................................................................................50
3.2.7 Save & Exit menu........................................................................................................................51
3.3 Updating the BIOS................................................................................................................... 52
Driver Installation ......................................................................................53
4.1 Follow the sequence below to install the drivers: .................................................................... 54

User’s Manual
3
4.2 Installation:............................................................................................................................. 54
4.3 CPU TEMP LED driver............................................................................................................... 55
4.4 Utility Software Reference ...................................................................................................... 55
SYSTEM RESOURCE ....................................................................................56
5.1 WDT and GPIO ........................................................................................................................ 57

User’s Manual
4
General Information
1
CHAPTER

User’s Manual
5
1.1 Introduction
The KGEC-6310 is a new edge controller by JHC, and the mainboard and sub-board are designed with
an all-in-one architecture without connection. The KGEC-6310 is equipped with Intel® Whiskey lake-
U CPU, support for 2* DDR4 2400Mhz, up to 32GB, and the 9th generation Intel® UHD Graphics.
The KGEC-6310 provides rich IO interfaces, including 1*HDMI, 1*DVI-D, 4*LAN, 2*USB3.1，
2*USB2.0, 2*COM, 1*8-bit DIO. A variety of expansion options, 1*Mini PCIe with PCIe X1+USB
signal, with dual SIM card slot, support for dual 4G LTE/Wifi/BT/GPS; 1*M.2 E-Key 2230 with PCIe
X1+USB2.0 signal for extending the Wifi/BT module. 1*2.5" HDD SATA bay, 1* full mSATA
(SATA+USB)forstorage.DC 12~24V widepower input, support wall mounting and Din-Rail mounting.
Adopt active and passive cooling design, fan wind speed can be intelligently controlled. BIOS
optimized and support real-time system, Ubantu Preemt-RT, optional support INTime. The extension
module and the host are designed with easy disassembly, and the extension quantity is flexible. Different
extension modules can be selected for different application scenarios, which are very suitable for
Machine Vision, CNC control, Motion control and so on.
1.2 Features
Intel® Whiskey lake-U CPU
CPU active and passive cooling design
Intelligent temperature control fan, silent and dustproof
DVI-D/HDMI the display signal can be extended without attenuation
3* I210 AT network chips, Optional support for a variety of real-time industrial Ethernet protocols
1*I219LM support to iAMT12.0
BIOS optimization and support high real-time system INTime and Ubantu preemt-RT
1*Mini PCIe with SIM slot，1*M.2 2230 E-Key
Support software development platform (optional)
DC 12~24V, Wide power supply
Support wall mounting and Din-Rail mounting

User’s Manual
6
Model No.
Specification
KGEC-6310-S001
KGEC-
6310-S002
KGEC-
6310-S003
KGEC-
6310-S004
CPU
Intel®Core
I3-8145U
Intel®
Core I5-
8265U
Intel®
Core I7-
8565U
Intel®
Celeron
4305U
Mermory
2*DDR4 Up to
32GB
2*DDR4 Up
to 32GB
2*DDR4 Up
to 32GB
2*DDR4 Up
to 32GB
LAN
4
4
4
4
USB3.1
2
2
2
2
USB2.0
2
2
2
2
COM
2
2
2
2
DIO
8-bit DIO
8-bit DIO
8-bit DIO
8-bit DIO
HDMI
1
1
1
1
DVI-D
1
1
1
1
Mini PCIe
1
1
1
1
M.2
1
1
1
1
mSATA
1
1
1
1
2.5”SATA3.0
1
1
1
1
Power input
DC 12-24V
DC 12-24V
DC 12-24V
DC 12-24V
Table 1.1: Features

User’s Manual
7
1.3 Specifications
1.3.1 General
CPU: Intel® Whiskey lake-U CPU
System Memory: 2*DDR4, 2400MHz, up to 32GB
Watchdog Timer: 255-level interval timer, setup by software
USB: 2*USB3.1, Type A, 2*USB2.0 Type A
Serial Ports: 2*RS232/422/485 with TVS isolated (DB9)
DIO：8-bit isolated (1*10pin phonenix)
Expansion Interface:
1*Mini PCIe with PCIe X1+USB signal, 1*SIM slot, support 1*4G/LTE/Wifi/BT/GPS
1*M.2 E-key 2230 with PCIe X1+USB2.0 signal
Storage:
1*2.5" HDD/SSD bay,
1*mSATA (SATA+USB)
1.3.2 Display
Chipset: Intel Gen. 9th Intel UHD Graphics
Display Memory: Shared system memory
Resolution: HDMI: max. res. 4096*2160@60Hz, DVI-D: max. res. 2560x1600@60Hz
1.3.3 Ethernet
Chipset: 3*Intel I210AT PCIe Gig. Ethernet,1*Intel I219LM PCIe Gig.Ethernet
Speed: 10/100/1000 Mbps
Interface: 4*RJ45
1.3.4 Power Consumption
Input Voltage:
DC 12-24V，2*2-pin Phoenix
Power Consumption: TDP（12V/2.64 A I3-8145U 4GB ）
Power Adapter: AC/DC power adapter, DC12V/5A 60W
1.4 Environmental Specifications
Operating temperature: -20～60℃
Relative humidity: 10~90% @ 40°C (non-condensing)

User’s Manual
8
Storage temperature: -40 ~ 85°C (-40 ~ 185°F)
Vibration loading during operation:
5grms/5~500Hz/random/in working (SSD); 1grms/5~500Hz/random/in working (HDD)
Shock during operation:
50g peak acceleration(11ms duration)(SSD); 20g peak acceleration(11ms duration)(HDD）
EMC/ Certification: CE/FCC Class B
1.5 Order information
Model No.
CPU
Introduction
KGEC-6310/S001
Intel®Core I3-8145U
Edge controller, Dual-ch DDR4 2*SO-DIMM, 4*LAN, 2*USB3.1,
2*USB2.0, 2*COM,8-bit DIO, 1*Mini PCIe, 1*M.2, 1*DVI-D, 1*HDMI,
1*mSATA, 1*2.5”SATA3.0, DC 12~24V
KGEC-6310/S002
Intel®Core I5-8265U
Edge controller, Dual-ch DDR4 2*SO-DIMM, 4*LAN, 2*USB3.1,
2*USB2.0, 2*COM,8-bit DIO, 1*Mini PCIe, 1*M.2, 1*DVI-D, 1*HDMI,
1*mSATA, 1*2.5”SATA3.0, DC 12~24V
KGEC-6310/S003
Intel®Core I7-8565U
Edge controller, Dual-ch DDR4 2*SO-DIMM, 4*LAN, 2*USB3.1,
2*USB2.0, 2*COM,8-bit DIO, 1*Mini PCIe, 1*M.2, 1*DVI-D, 1*HDMI,
1*mSATA, 1*2.5”SATA3.0, DC 12~24V
KGEC-6310/S004
Intel®Celeron 4305U
Edge controller, Dual-ch DDR4 2*SO-DIMM, 4*LAN, 2*USB3.1,
2*USB2.0, 2*COM,8-bit DIO, 1*Mini PCIe, 1*M.2, 1*DVI-D, 1*HDMI,
1*mSATA, 1*2.5”SATA3.0, DC 12~24V
PA-60DC12
AC/DC adapter,DC 12V/5A 60W

User’s Manual
9
1.6 Mechanical Specifications
The KGEC-6310 edge controller is assembled by the splice of The OSBC (single-board computer ECM-
I909) and the Sub-card (ECB-256) of JHC, and installed in the universal aluminum rectangular profile
housing.
ECM-I909 Front
Picture 1.1: ECB-I909 Front
ECM-I909 Rear
Picture 1.2: ECB-I909 Rear

User’s Manual
10
ECB-256 Front
Picture 1.3: ECB-256 front
ECB-256 Rear
Picture 1.4: ECB-256 rear

User’s Manual
11
KGEC-6310 Front Panel
Picture 1.5: KGEC-6310 Front Panel
KGEC-6310 Rear Panel
Picture 1.6: KGEC-6310 Rear Panel

User’s Manual
12
KGEC-6310 Dimension：
Unit: mm
Picture 1.7 KGEC-6310 Dimension

User’s Manual
13
Hardware Installation
2
CHAPTER

User’s Manual
14
2.1 Introduction
The following sections show the internal switch settings and the external connectors and pin assignments
for applications.
2.2 Switches
The KGEC-6310 edge controller has a number of switches inside the chassis that allows you to configure
your system to suit your application. The table below shows the function of each of the board’s switches:
Switcher
Name
Description
CLEAR/CMOS
Clear CMOS Data Setting
3-Pin switch
AT/ATX
Set Power-on mode at AT or ATX
3-Pin switch
2.2.1 CLEAR/COMS -Clear CMOS Data
Picture 2.1: CLEAR/COMS
If you encounter the followings
a) CMOS data becomes corrupted.
b) You forget the supervisor or user password.
You can reconfigure the system with the default values stored in the ROM BIOS.
To load the default values stored in the ROM BIOS, please follow the steps below.
1. Power-off the system and unplug the power cord.
2. Dial the dip switch to CLEAR mode, stay for 5~6 seconds, and then revert to CMOS mode;
4. Power-On the computer, press the Del key to enter the BIOS setting and reload the optimal default value;
5. Save and exit the Settings.

User’s Manual
15
2.2.2AT/ATX Power on mode selection
Picture 2.2: AT/ATX
The KGEC-6310 provides an AT/ATX SW, which users can set Power-on mode by it. When you dial it at
AT, it means power on byAC Power; When you dial it at ATX, it means power on by Power button.
2.3 I/O/Button/LED Indication
KGEC-6310 Front：
Picture 2.3: KGEC-6310 Front
The front panel contains the I/O interface：
1*DC-in Power: 2*2pin phoenix DC12~24V
2*USB3.1 Type A, 2*USB2.0 Type A
1*HDMI,1*DVI-D
4*LAN:RJ45
