John Lewis alex single wardrobe User manual

alex single wardrobe
Instruction manual
Important
retain for future reference
please read carefully

2
Important
Retain for future reference: Read carefully
Please read the instructions and warnings carefully before use to ensure safe and satisfactory operation of
this product.
Your child’s safety is your responsibility. If you have a query with this product or require replacement
parts, please contact your nearest John Lewis department store.
Lay out the parts on a soft level surface and compare to the part/fixing checklist on pages 2 and 3. Do not
discard any packaging until you are sure that you have all the parts.
Keep children clear during assembly as pack contains small parts which may present a choking hazard.
You will need the following tools to complete assembly:
Flat-headed screwdriver and Cross point screwdriver.
Hardware
A x 1
C x 2 (45mm)
F x 6
H x 17
G x 4
E x 6 (40mm)
J x 2
I x 12
M x 3
L x 2
B x 1 (30mm)
D x 6 (30mm)
K x 2
N x 1

3
Topper x 1
Base x 1
Wardrobe Top x 1
Side Panel x 2 (L & R)
Door x 1
Door Stop x 2
Rear Crossbar x 1
Wooden Parts
Clothes Rail x 2
Back Panel x 1

4
K x 2
Topper
Topper
Wardrobe Top
L x 2
Assembly 1
Assembly 2

5
Assembly 3
Assembly 4
Wardrobe Top
Rear Crossbar
Base
Door Stop
I x 5
(each side)
Base
I x 2
G x 2
Door Stop
Door Stop
Wardrobe Top

6
E x 3
G x 1
D x 3
C x 1
J x 1
Rear Crossbar
Wardrobe Side
Wardrobe Top
Base
Assembly 6
Assembly 5

7
G x 1
D x 3
C x 1
J x 1
Assembly 7

8
Assembly 8
E x 3
H x 17
Back Panel
NOTE: When fitting the Back Panel, push into the corner so
that the side and top edges contact the rebate evenly all the
way around the frame of the wardrobe. This will ensure that
the frame is square.

9
Assembly 11
Assembly 9
Assembly 10
Door
Door
M
F x 2
B x 1
Clothes Rail
Repeat for remaining hinges
A

10
1
2
Door
Wardrobe Side
Use screws 1 and 2 to secure and adjust
the fit of the doors.
Tightening or loosening screw 1 will move the
door closer to, or further away from the
frame at that point.
Assembly 13
Assembly 12
1. The narrow part of the front screw
fits into the slot in the metal plate on
the Wardrobe side.
2. The slot in the hinge fits under the
rear screw head. (you may need to
loosen the screw first)
Once the doors are correctly
positioned within the frame,
tighten screw 2 fully and ensure
that the doors are secure before
use.
1
2

11
The wardrobe is supplied with a fixing kit which will secure it and help to guard against accidental tipping.
WARNING : Installation only to be carried out by a competent person.
Check the suitability of the wall before fitting.
1. Place wardrobe against the wall where it is to be fitted. Mark the wall 25mm (1”) down from the top
surface.
2. Using the 25mm screw, washer and the appropriate wall fixing attach the fabric strap to the marked
position.
3.Attach the fabric strap to the wardrobe top using the 15mm screw and the washer.
Before use, ensure that the strap is securely fixed to both the wall and the wardrobe.
1
23
3
The type of wall fixing you will require depends on the construction of the wall. See below for details.
If in doubt, seek professional advice.
Wood: If fixing to wood make
sure that it isn’t chipboard as
screws can easily pull away
the core structure.
Brick or masonry: Use
the wall plug, provided
you are sure that your
wall is sound.
Cavity wall: Special toggle
wall plugs needed.
Seek expert advice.
Washer x 2
Fabric strap
Plastic wall plug
(For brick or masonry wall use only)
Screw (25mm)Screw (15mm)
Assembly 14

JLPAW
09/16
Care and maintenance
Your furniture may be cleaned by wiping with a damp cloth and drying with a soft clean
cloth.
Do not use abrasives, bleach, alcohol or ammonia-based household polishes.
Take care when handling or moving the furniture. Careless handling may cause damage.
Safety notes
Warning: Do not leave your child unattended.
Keep children clear during assembly as pack contains small parts which may present a
choking hazard.
All assembly fixings should always be tightened properly. Care should be taken that no
screws are loose because a child could trap parts of their body, or clothing (e.g. strings,
necklaces, ribbons, dummies, etc) which could pose a risk of strangulation.
Ensure that the wall strap is used to securely attach the wardrobe to the wall to prevent
tipping.
Only use the wardrobe on a stable and level surface.
Any additional or replacement parts can only be obtained from the manufacturer or the
distributor.
John Lewis Partnership
171 Victoria Street
London
SW1E 5NN
www.johnlewis.com
