JVC Studio Kit KA-F5602U User manual

KA-F5602U
KA-F5603U
INSTRUCTIONS
STUDIO KIT
STUDIO SDI KIT
For Customer Use:
Enter below the Serial No. which is
located on the cabinet. Retain this
information for future reference.
Model No. KA-F5602U/KA-F5603U
Serial No.
F.f
ft
m
30
1035
15
10
7
2
1.5
5
4
1.2
5.5 10
C16
11
8
MACRO
PROMPTER
OUTPUT RM DCINPUT
BREAKER
Thank you for purchasing this JVC product.
Before operating this unit, please read the
instructions carefully to ensure the best
possible performance.
LWT0176-001A
Japanese
This instructions book is made from 100 %
recycled paper.
*Illustration with optional lens
and viewfinder attachments.
English
VICTOR COMPANY OF JAPAN, LIMITED
Printed in Japan
LWT0176-001A
is a registered trademark owned by VICTOR COMPANY OF JAPAN, LTD.
is a registered trademark in Japan, the U.S.A., the U.K. and many other countries.
© 2004 VICTOR COMPANY OF JAPAN, LIMITED
®
®
KA-F5602U/KA-F5603U
STUDIO KIT/STUDIO SDI KIT

2
1. Read all of these instructions.
2. Save these instructions for later use.
3. All warnings on the product and in the operating instructions should be adhered to.
4. Unplug this appliance system from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
5. Do not use attachments not recommended by the appliance manufacturer as they may cause hazards.
6. Do not use this appliance near water – for example, near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool, etc.
7. Do not place this appliance on an unstable cart, stand, or table. The appliance
may fall, causing serious injury to a child or adult, and serious damage to the
appliance.
Use only with a cart or stand recommended by the manufacturer, or sold with the
appliance.
Wall or shelf mounting should follow the manufacturer’s instructions, and should
use a mounting kit approved by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
8. Slots and openings in the cabinet and the back or bottom are provided for
ventilation, and to insure reliable operation of the appliance and to protect it from overheating, these
openings must not be blocked or covered. The openings should never be blocked by placing the
appliance on a bed, sofa, rug, or other similar surface.This appliance should never be placed near or
over a radiator or heat register.This appliance should not be placed in a built-in installation such as a
bookcase unless proper ventilation is provided.
9. This appliance should be operated only from the type of power source indicated on the marking label.
If you are not sure of the type of power supplied to your home, consult your dealer or local power
company. For appliance designed to operate from battery power, refer to the operating instructions.
10. This appliance system is equipped with a 3-wire grounding type plug (a plug having a third (grounding)
pin).This plug will only fit into a grounding-type power outlet.This is a safety feature. If you are unable
to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the grounding plug.
11. For added protection for this product during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning and power-line surges.
12. Do not allow anything to rest on the power cord. Do not locate this appliance where the cord will be
abused by persons walking on it.
13. Follow all warnings and instructions marked on the appliance.
14. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
15. Never push objects of any kind into this appliance through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any
kind on the appliance.
16. Do not attempt to service this appliance yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
17. Unplug this appliance from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the appliance.
c. If the appliance has been exposed to rain or water.
d. If the appliance does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions as improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to
restore the appliance to normal operation.
e. If the appliance has been dropped or the cabinet has been damaged.
f. When the appliance exhibits a distinct change in performance – this indicates a need for service.
18. When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer that have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
19. Upon completion of any service or repairs to this appliance, ask the service technician to perform
routine safety checks to determine that the appliance is in safe operating condition.
S3125A
3
English
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR
ATTENTION: POUR EVITER TOUT RISQUE D’ELECTROCUTION
NE PAS OUVRIR LE BOITER.
AUCUNE PIECE INTERIEURE N’EST
A REGLER PAR L’UTILISATEUR.
SE REFERER A UN AGENT QUALIFIE EN CAS DE PROBLEME.
Le symbole de l’éclair à l’intérieur d’un triangle
équilatéral est destiné à alerter l’utilisateur sur la
présence d’une “tension dangereuse” non isolée
dans le boîtier du produit. Cette tension est suffisante
pour provoquer l’électrocution de personnes.
Le point d’exclamation à l’intérieur d’un triangle
équilatéral est destiné à alerter l’utilisateur sur la
présence d’opérations d’entretien importantes au
sujet desquelles des renseignements se trouvent
dans le manuel d’instructions.
*Ces symboles ne sont utilisés qu’aux Etats-Unis.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
INFORMATION
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
●Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
●Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
CHANGES OR MODIFICATIONS NOT APPROVED
BY JVC COULD VOID USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
NOTE:
The rating plate (serial number plate) is on this unit.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
THIS DEVICE COMPLIES WITH PART 15 OF THE
FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE
MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFER-
ENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
This unit should be used with 12 V DC only.
CAUTION:
To prevent electric shocks and fire hazards, DO
NOT use any other power source.
AVERTISSEMENT:
POUR EVITER LES RISQUES
D’INCENDIE OU D’ELECTROCUTION, NE
PAS EXPOSER L’APPAREIL A
L’HUMIDITE OU A LA PLUIE.
Cet appareil ne doit être utilisé sur 12 V en
courant continu.
ATTENTION:
Afin d’éviter tout resque d’incendie ou
d’électrocution, ne pas utiliser d’autres
sources d’alimentation électrique.
REMARQUE:
La plaque dıidentification (numéro de série) se
trouve sur l’appareil.
SAFETY PRECAUTIONS (FOR USA AND CANADA)
Cet appareil numérique de la Class B est
conforme à la norme NMB-003 du Canada.
This Class B digital apparatus complies with
Canadian ICES-003.
INFORMATION (F0R CANADA)
RENSEIGNEMENT (POUR CANADA)

4
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
This unit should be used with 12 V DC only.
CAUTION:
To prevent electric shocks and fire hazards, do NOT
use any other power source.
CAUTION
To prevent electric shock, do not open the cabinet. No user
serviceable parts inside. Refer servicing to qualified service
personnel.
Note:
The rating plate (serial number plate) is on this unit.
SAFETY PRECAUTIONS (FOR EUROPE)
5
English
This equipment is in conformity with the provisions and protection requirements of the corre-
sponding European Directives. This equipment is designed for professional video appliances
and can be used in the following environments:
5Residential (including both of the location type class 1 and 2 found in IEC 1000-2-5)
5Commercial and light industrial (including, for example, theatres)
5Urban outdoors (based on the definition of location type class 6 in IEC 1000-2-5)
This apparatus is designed for rack mounting or is used close to other apparatus.
In order to keep the best performance and furthermore for electromagnetic compatibility we
recommend to use cables not exceeding the following lengths:
Caution:
5Where there are strong electromagnetic waves or magnetism, for example near a radio or
TV transmitter, transformer, motor, etc., the picture and sound may be disturbed. In such a
case, please keep the apparatus away from the sources of the disturbance.
Port Cable Length
RM Exclusive Cable 100 meters
PROMPTER OUTPUT Coaxial Cable 5 meters
DC INPUT Exclusive Cable 5 meters
SDI OUTPUT Coaxial Cable 5 meters

6
Thank you for purchasing this
KA-F5602U / KA-5603U Studio Kit.
This product is a kit meant for converting JVC’s KY-F560 video camera into a studio camera.
Model designation may differ depending on whether the Studio Kit is equipped with a SDI
(Serial Digital Interface) terminal.
Model
KA-F5602U
KA-F5603U
Main Features
●Equipped with analog 26P camera connector
Connecting to Remote Control Unit RM-P210, which is sold separately, this unit could be
controlled from up to a distance of 100 m away. In this case, power for the camera is
provided by the remote control unit and thus there is no requirement for a separate power
supply for the camera.
●Multi-system output
From the 26P camera connector, besides the composite signal, another video signal
which could be either RGB component, Y/Cb/Cr component, or YC separate signal could
be outputted. (Selectable by menu switch.)
●Possible to install VF-P400 4-inch Viewfinder
●Equipped with intercom terminal
With the use of headset, communications with remote control unit operator is possible.
●Equipped with prompter output terminal
Prompter video from the remote control unit could be outputted in the form of composite
signal.
●H phase and SC phase could be adjusted during synchronization. (Using menu screen)
●Equipped with SDI output terminal (Only for KA-F5603U)
Camera video is output as serial digital video signal (SMPTE259M-compliant).
SDI Output Terminal
Nil
Yes
7
English
Accessories ........................................................................................................ 8
Related Products used in Conjunction with this Unit .......................................... 8
Precautions ......................................................................................................... 9
Regarding Gain-lock Signal and adjustment of System Phase .......................... 9
Part Names and Functions ............................................................................... 10
System .............................................................................................................. 13
Installation Procedures ..................................................................................... 14
Mounting KY-F560 Camera on this Unit ........................................................... 14
Mounting the Lens onto the Camera ................................................................ 16
Mounting this Unit onto the Tripod.................................................................... 16
Mounting VF-P400 4-inch Viewfinder on this Unit ............................................ 17
Connecting to Remote Control Unit RM-P210 .................................................. 18
Notes to be taken when operating RM-P210.................................................... 20
“SYSTEM” Menu Screen .................................................................................. 21
“DISPLAY” Menu Screen .................................................................................. 22
Specifications ................................................................................................... 23
Contents
Getting Started
Installation
Menu Screen
Others
Connecting RM-P210

8
Getting Started
Accessories
PROMPTER
OUTPUT RM DCINPUT
BREAKER
䡵Studio Kit main body 䡵Screw - 1 piece: Use for securing KY-F560
camera on the Studio Kit.
Relay board
䡵Instructions (this booklet)
Related Products used in Conjunction with this Unit
●Color video camera......................... KY-F560
●4-inch Viewfinder ............................ VF-P400
●Remote Control Unit ....................... RM-P210
●Intercom Headset ........................... KA-310U
●26 Pin Camera Cable ..................... VC-P110 (5 m)
VC-P112 (20 m)
VC-P113 (50 m)
VC-P114 (100 m)
●Use the undermentioned AC power supply if the Remote Control Unit RM-P210 is not in-
use.
AC Power Supply............................ AA-P250
Please refer to page 13 ‘System’ for details.
Select either one.
9
English
Precautions
䢇In order to ensure that this unit could serve
you longer, avoid storing or using it at the
following places.
䡵Extremely hot or cold places
䡵Places with strong vibration
䡵Dusty places
䡵High humidity places
䡵In the vicinity of strong noise sources
䢇Do not subject this unit to strong vibration
or impact when installing or moving it.
䢇Do not plug in or plug out the camera ca-
ble connector when this unit has been pow-
ered on.
䢇Use only the designated power supply. Use
either RM-P210 or AA-P250.
䢇To reduce power consumption, turn off the
power when not in-use.
䢇When transceiver or mobile phone is used
near this unit, noises may be introduced
into the intercom speaker or the screen.
This is not a malfunction.
Moving this unit with the supporting tripod
attached may cause it to detach and drop
if there is sudden external impact or
vibration. This may cause injuries. Please
remove this unit from the tripod before
moving it.
Caution
䢇Earthing the INTERCOM G(GND) terminal
is recommended as noises may be induced
depending on the intercom headset used.
䢇Use only the specified standard length
camera cable. Otherwise, the cable com-
pensation may be insufficient.
Regarding Gain-lock Signal and adjustment of System Phase
When using RM-P210 Remote Control Unit
with this system, Gain-lock signal could be
input into either KY-F560 Camera or RM-
P210.
However, if Gain-lock signal is applied to both
KY-F560 and RM-P210, screen images will
appear jerky.
Please carry out the System Phase
adjustment via the machine where Gain-lock
signal has been input.
In addition, the first priority will be given to
RM-LP55 when connecting it.
䡵When Gain-lock signal is input into RM-
P210
Please adjust the phase by adjusting RM-
P210’s H and SC.
Use RM-LP55 to adjust the phase if it is
connected to this system.
䡵When Gain-lock signal is input into KY-
F560
Please adjust the phase by adjusting KY-
F560’s H and SC.
(Adjustment should be done through KY-F560
even if RM-P210 is connected).
Use RM-LP55 to adjust the phase if it is
connected to this system.

10
Part Names and Functions
Getting Started
INTERCOM
INCOM MIC
INCOM LEVEL
ON
OFF
MAXMIN
DYNAMIC
CARBON
PUSH
CALL
VF
9
8
12367
4
5
0
1[RM] RM Multi-pin Connector (26 Pin)
Connect to Remote Control Unit RM-P210
by using the 26 pin camera cable.
In addition, power is supplied to the this
unit and the camera via this connector
from the remote control unit.
2[INTERCOM] Intercom Input Terminal
(XLR 5 Pin)
Input terminal for intercom headset. JVC
Headset KA-310U can be connected here.
3[INCOM LEVEL] Intercom Receiver
Volume
Use for adjusting the intercom headset re-
ceiver volume level.
4[INCOM MIC] Intercom Mic [ON/OFF]
Switch
[ON/OFF] switch for intercom headset
microphone. Set it to [ON] if the headset
microphone is to be used.
Note
Besides Composite video signal, other
types of camera video signals which
could be output from the output terminal
of RM-P210 include RGB component,
Y/Cb/Cr component and YC separate
signal. The output signal could be se-
lected using the “OUTPUT” item under
the “SYSTEM” menu screen on the KY-
F560. (☞page 21)
!
#@
11
English
9Relay Board
This board is meant for connecting to KY-
F560 camera. This is to be inserted into
the slot at the rear of KY-F560.
0[SDI OUT] SDI Output Terminal...Only
for KA-F5603U
Camera video is output in the form of SDI
signal.
![VF] Viewfinder Terminal (6 Pin)
Use for connecting cable from the View-
finder.
@Viewfinder Holder
Use for mounting the VF-P400 4-inch
Viewfinder.
#Lens Cable Clamp
This clamp is meant for securing the lens
cable.
Part Names and Functions (continued)
Caution
To avoid causing malfunction, please do
not touch this terminal except when con-
necting cable to it.
5[INCOM MIC] Intercom Mic [CARBON/
DYNAMIC] Switch
Use for selecting the type of intercom
headset microphone to be used.
[CARBON] :Choose this setting if car-
bon type microphone is to
be used.
[DYNAMIC] :Choose this setting if dy-
namic type microphone is
to be used.
If JVC Headset KA-310U is to be used,
choose the [CARBON] setting.
6[CALL] Call Button
Press this button to send call signal to the
remote control unit operator if intercom
headset is not in-use.
When this button is pressed and held
down, call signal is being sent to the re-
mote control unit and its [TALLY] button
indicator will blink. Once the [CALL] but-
ton is released, call signal will not be sent
and the [TALLY] button indicator of the re-
mote control unit will go off.
7[CALL] Indicator
If the remote control unit is connected, it
will light up during the duration when 6
[CALL] button is being pressed and held
down. The indicator will go off once the
[CALL] button is released.
8Camera Mounting Frame
Remove this frame for the mounting of KY-
F560 camera.

12
Part Names and Functions (continued)
$[PROMPTER OUTPUT] Prompter
Output Terminal (BNC)
Signal (prompter video signal) inputted
into the [AUX] input terminal of the remote
control unit will be outputted from this ter-
minal via the RM multi-pin connector.
Composite signal will be outputted. Video
monitor will be connected here.
%[DC INPUT] DC Power Input Terminal
(XLR 4 Pin)
Apply DC power to this terminal if Remote
Control Unit RM-P210 is not going to be
connected. For DC power supply, use AA-
P250.
^[BREAKER] Breaker Switch
Breaker switch will trip and cut off the
power if the power consumed is higher
than the rated capacity. If the breaker
switch trips, confirm that there are no ab-
normalities and that the power consump-
tion does not exceed the rated wattage. If
no abnormalities are detected, press the
breaker switch before turning the power
ON again to put this unit in the operating
status. If this unit still does not function
properly, consult your JVC-authorized
dealer.
&Screw Holes for Mounting Tripod
PROMPTER
OUTPUT RM
BREAKER
DC INPUT
$
%^
&
Getting Started
13
English
PROMPTER
OUTPUT RM DCINPUT
MACRO
CALLTALLY
INTERCOM
LEVEL
FULLAUTO F1
SHUTTER
GAIN
F2
F3 MENU/SHUTTER GAIN PAINT AUTO
BR
W.BAL
AUTO
MANU
WHITE MASTERBLACK
POWER
I
O
IRIS
STEP
SHUTTER
MENU
PUSH-ON
DOWN UP
VARIABLE
PUSH-ON
HIGH
LOW
B
A
PRESET
CLOSE OPEN
MID
DOWN UP
F4
BARS
REMOTE CONTROL UNIT RM-P210
COLORVIDEO CAMERA KY-F560
BREAKER
System
SDI compatible
video equipment
●Please refer to KY-F560 instruction manual for details on the lens and lens remote control.
●The 26 Pin camera cable used should be less than 100 m.
●Power is supplied via the 26 Pin camera cable by the Remote Control Unit RM-P210 if it is
in-use. If the Remote Control Unit RM-P210 is not in-use, please use AC power adapter
AA-P250.
Installation
Viewfinder VF-P400
AC power adapter AA-P250
VC-710 (5 m)
Headset KA-310U
Color video camera
KY-F560
SDI output (only KA-F5603U)
[INTERCOM] connector
[DC INPUT] connector
RM multi-pin connector
Headset
KA-310U
4P
4P
Remote control unit RM-P210
Tripod
TP-P300
Dolly TP-P205
Monitor
[PROM
PTER
OUTPUT]
connector
Lens
SDI input
Studio kit/Studio SDI kit
KA-F5602U/KA-F5603U
26Pin camera cable
VC-P110 (5 m)
VC-P112 (20 m)
VC-P113 (50 m)
VC-P114 (100 m)

14
2. Mounting the Lens onto the Camera.
3. Mounting this Unit onto the Tripod.
4. Mounting VF-P400 4-inch Viewfinder on this Unit.
Slot cover
Camera mounting bracket
Screw ı
Camera mounting frame
1.
2.
Screw Å
Installation
1. Mounting KY-F560 Camera on this Unit.
2.
Loosen 2 screws ıof this unit and pull
out the camera mounting frame.
1.
Preparations to be done on KY-F560 cam-
era.
●If the lens is attached to KY-F560 cam-
era, remove and place it aside.
●Attached the camera mounting bracket
at the bottom of the camera.
●Remove 2 screws Åfrom the rear of
the camera and take out the slot cover.
Installation Procedures
Mounting KY-F560 Camera on this Unit
15
English
Screw Ç
Mounting bracket
Camera mounting frame
Screw ı
Lever
Screw Ç
4.
3.
5.
Relay board
Slot
Mounting KY-F560 Camera on this Unit (continued)
3.
Place the camera on top of the camera
mounting frame and use the screw Çpro-
vided to secure the camera to the base of
the frame.
Use the camera mounting bracket screw
hole to secure the camera.
4.
After the camera mounting frame is in-
serted into this unit, secure it by screwing
back the 2 screws ıwhich were taken
out earlier in above-mentioned step
2.
.
5.
Insert this unit’s relay board into the slot
at the rear of the camera and secure it by
screwing back the 2 screws Åwhich were
taken out earlier in above-mentioned
step
1.
.
Notes
●Please remove the camera lens mount
cap before hand.
●Before inserting the camera mounting
frame into this unit, turn the lens secure
lever located in front of
the camera clockwise to
move it to a lower posi-
tion. If the lever remains
at the upper position, it
may hit this unit when the
frame is being inserted.
Note
Ensure that the relay board is inserted
all the way in.

16
Mounting the Lens onto the Camera
Please refer to KY-F560 instruction manual on mounting the lens.
●When using the under-mentioned types of lens, lens cable ECE-R22 which is sold sepa-
rately must be used. (Please consult your local JVC authorized service agent for details of
the cable to be used.)
S17 x 6.6 BRM(FUJINON)
YH16 x 7K12U(CANON)
●Use the cable clamp to secure the lens cable to this unit.
Mounting this Unit onto the Tripod
Mount and fix this unit onto the tripod using the mulitple screw holes provided beneath it. Use
the appropriate screw holes for mounting this unit such that it could be balanced properly on
top of the tripod.
Screw holes
Cable clamp
Lens cable
Installation
ECE-R22
Lens cable
17
English
Mounting VF-P400 4-inch Viewfinder on this Unit
1.
Loosen the viewfinder lock lever by turning it anti-clockwise.
2.
Slide the viewfinder forward along the viewfinder holder guide on top of this unit.
3.
Turn the viewfinder lock lever clockwise to lock it.
4.
Plug the viewfinder cable connector into this unit’s viewfinder terminal.
VF-P400 4-inch
Viewfinder
Lock lever
Viewfinder holder
Viewfinder terminal
1.
3.
2.
4.
Viewfinder Cable
Note
When “ASPECT RATIO” item under the “SYSTEM” menu screen of KY-F560 is set to
“16:9”, images will appear vertically elongated in the View Finder VF-P400.

18
CALLTALLY
INTERCOM
LEVEL
FULLAUTO F1
SHUTTER
GAIN
F2
F3 MENU/SHUTTER GAIN PAINT AUTO
BR
W.BAL
AUTO
MANU
WHITE MASTER BLACK POWER
I
O
IRIS
STEP
SHUTTER
MENU
PUSH-ON
DOWN UP
VARIABLE
PUSH-ON
HIGH
LOW
B
A
PRESET
CLOSE OPEN
MID
DOWN UP
F4
BARS
REMOTECONTROL UNIT RM-P210
BREAKER
F.f
ft
m
30
1035
15
10
7
2
1.5
5
4
1.2
5.5 10
C16
11
8
MACRO
PROMPTER
OUTPUT RM
MENU
AW BARS
SET
LENS
REMOTE
GENLOCKIN VIDEOOUT
DCIN
POWER
SEEINST
INTERCOM
INCOM MIC
INCOM LEVEL
ON
OFF
MAXMIN
DYNAMIC
CARBON
PUSH
CALL
VF
Connecting to Remote Control Unit RM-P210
Headset
KA-310U
Headset
KA-310U
26 Pin
camera
cable
RM Multi-pin
connector
[INTERCOM] terminal
Remote control unit RM-P210
Monitor
[PROMPTER OUTPUT] terminal
Connection
Switch off RM-P210 power supply before attempting the connection.
●Connect this unit’s RM multi-pin connector and RM-P210 using the 26 Pin camera cable.
Length of the camera cable should not be longer than 100 m.
●If intercom headset is to be used, plug the Headset KA-310U into the [INTERCOM] termi-
nal.
●Prompter video (RM-P210 [AUX VIDEO INPUT] terminal’s input signal) from RM-P210
could be verified by connecting this unit’s [PROMPTER OUTPUT] terminal located in front
of it to a monitor using BNC cable.
26 Pin camera cable
VC-P110 (5 m)
VC-P112 (20 m)
VC-P113 (50 m)
VC-P114 (100 m)
Note
Power for this unit and the camera is supplied by RM-P210 via the 26 Pin camera cable.
Setting
䡵Menu screen setting
●Composite video signal is always output at the RM multi-pin connector.In addition, another
type of video signal which could be either RGB component, Y/Cb/Cr component or YC
separate signal could be outputted. The output signal could be selected using the “OUT-
PUT” item under the “SYSTEM” menu screen.
●If the output signal is RGB component, option to superimpose SYNC signal onto the G
signal could be selected through the “SYNC ON G” item under the “SYSTEM” menu screen.
Connecting RM-P210
19
English
䡵Switch setting
●Set the [CARBON/DYNAMIC] switch according to
the type of intercom headset microphone to be
used. (If JVC Headset KA-310U is connected,
choose the [CARBON] setting.))
●Set the [INCOM MIC ON / OFF] switch depending
on whether headset microphone will be used. If the
switch is set to [ON], then the headset microphone
could be used.
[CARBON/DYNAMIC]
switch
[INCOM MIC ON/OFF] switch
Rear view of
this unit
Operation
GENLOCKIN VIDEO OUT
DCIN
POWER
SEEINST
INTERCOM
INCOM MIC
INCOM LEVEL
ON
OFF
MAXMIN
DYNAMIC
CARBON
PUSH
CALL
VF
[CALL]
Indicator
[CALL] button
[INCOM LEVEL]
volume
GENLOCKIN VIDEO OUT
DCIN
POWER
SEEINST
INTERCOM
INCOM MIC
INCOM LEVEL
ON
OFF
MAXMIN
DYNAMIC
CARBON
PUSH
CALL
VF
●When this unit’s [CALL] button is pressed and held
down, call signals will be sent to the remote control
unit operator and the [TALLY] button indicator of
the remote control unit will blink.
During this duration, the [CALL] indicator of this unit
will light up. The Viewfinder’s [TALLY] lamp will also
blink when call signals are received from the re-
mote control unit.
●The headset reception volume could be adjusted
by [INCOM LEVEL] volume.
Note
After the power is turned on, the camera remote control unit takes about 30 seconds to
be ready to communicate with this unit.
Connecting to Remote Control Unit RM-P210 (continued)
●Turn the [POWER] switch of the camera remote control unit to [ON]. After the [POWER]
switch is turned on, camera remote control unit could be operated after about 30 seconds.
Note
●If both this unit (including the camera) and the remote control unit have the same func-
tional switches, the remote control unit switches will be accorded higher priority.
●If local Remote Control Unit (RM-LP55 or RM-LP57) is used simultaneously, the local
remote control unit will be accorded higher priority.
●When synchronization signal is added to both the camera and the camera remote con-
trol unit, pictures will be distorted. (☞page 9 ‘Regarding Gain-lock Signal and adjust-
ment of System Phase’)
●If external synchronization signal is present when the power is turned on, pictures may
appear jerky for a few seconds. This is not a malfunction.
●When using the remote control unit, refer to its instruction manual for details.

20
Notes to be taken when operating RM-P210
When using RM-P210 menu to carry out the setting of KY-F560, some items of RM-P210
menu setting may not be consistent with the operations of KY-F560.
RM-P210 Menu
Connecting RM-P210
Operation of KY-F560
No
4G
4K
5B
Item
䡵“PROCESS”
screen
“KNEE POINT”
(KNEE POINT setting
when AUTO KNEE is
off)
“GAMMA LEVEL”
(GAMMA CURVE
Correction)
䡵“OPERATION”
screen
“V. GAIN STEP”
(VARIABLE GAIN
STEP SETTING)
KNEE point may vary as follows:
NORMAL : 100 % (Maximum level)
–10 : 80 % (Minimum level)
Level will change by 5 % with every
2-step adjustment on the minus side.
Setting the plus side (1 to 10) will not
change the KNEE point.
Level will change (switch to next level)
with every 2-step adjustment.
(–5 ~NORMAL ~5)
With 0.1 dB setting, turning of RM-
P210 [VARIABLE GAIN] knob will
cause the gain level to change at 0.2
dB step.
With 1.0 dB setting, gain level will
change at 1.0 dB step.
~
~
Variable Value
10
NORMAL
–10
10
NORMAL
–10
0.1 dB
1.0 dB
~~
~~
21
English
“SYSTEM” Menu Screen
When KY-F560 camera is mounted on this unit, new menu screens and menu items are
added to the original KY-F560 menu screen.
The additional new menu screens and menu items will be explained here.
Please refer to KY-F560 instruction manual for details on menu screen setting.
The following additional items are added to the “SYSTEM” menu screen.
The settings in bold are factory settings.
Menu Screen
Item
“OUTPUT”
“SYNC ON G”
Function/Variables
From RM multi-pin connector, besides the composite signal, an-
other type of output video signal could be outputted. The addi-
tional output signal is selected here.
“Y/Cb/Cr” :Y/Cb/Cr component signal will be outputted.
“RGB” : RGB component signal will be outputted.
Option to superimpose SYNC signal onto the G signal
could be selected under the item “SYNC ON G”.
“Y/C” : YC separate signal will be outputted.
Option to superimpose SYNC signal onto the G signal of the RGB
component signal is selected here.
This item could only be set when “RGB” has been selected under
the “OUTPUT” item.
“ON” :SYNC signal will be superimposed.
“OFF” : SYNC signal will not be superimposed.

22
“DISPLAY” Menu Screen
Additional new “DISPLAY” menu screens are added.
The settings in bold are factory settings.
Item
“CHARACTER”
“F NO.”
“SAFETY ZONE”
“CENTER MARK”
“TALLY”
Function/Variables
To select whether characters will be displayed in the viewfinder.
“OFF” : Characters will not be displayed.
“ON” :Characters will be displayed.
Whether to display characters could be selected
individually at the next item.
Even if this item is set to “ON”, no character will be displayed if
the individual character item is set to “OFF”.
To select whether to display the lens iris F value on the view-
finder.
“OFF” : Will not be displayed.
“ON” :Will be displayed.
To select whether to display safety zone and its style on the view-
finder.
“OFF” : Will not be displayed.
“NORMAL” :Safety zone with aspect ratio of 4:3 will be displayed.
“16:9” : Safety zone with aspect ratio of 16:9 will be displayed.
To select whether to display the centre mark when the display of
safety zone has been selected.
“OFF” : Will not be displayed.
“ON” :Will be displayed.
To select whether viewfinder [TALLY] lamp will be turned on when
signal is applied to the [TALLY] terminal located at the rear of the
Remote Control Unit RM-P210.
“OFF” : Lamp will not be turned on.
“ON” :Lamp will be turned on.
Menu Screen
23
English
Specifications
Dimensions (Unit: mm)
INTERCOM
INCOM MIC
INCOM LEVEL
ON
OFF
MAXMIN
DYNAMIC
CARBON
PUSH
CALL
VF
95
57.5
160
180.3
156
185.1
204.3
25
16.5
146.6
Others
RM Multi-pin connector : Composite video signal output
(Either Y/Cb/Cr, RGB or YC separate output signal could be
selected)
PROMPTER output : PROMPTER video signal output (composite signal)
SDI output : Serial digital video signal (SMPTE259M-compliant)
0.8 V(p-p), 75 ¸Unbalanced (only for KY-F5603U)
Operating temperature range : –5 °C to 40 °C (Humidity below 80 %)
Allowable storage temperature : –20 °C to 60 °C
Power supply voltage : DC12 V
Power consumption : KA-F5602U Max. 17 W (KY-F560, VF-P400, lens in-use)
KA-F5603U Max. 18 W (KY-F560, VF-P400, lens in-use)
Dimensions:(W) 156 mm x (H) 180.3 mm x (D) 185.1 mm (Exclude
protruded part.)
Mass : Approx. 1.8 kg
Accessories : Screw .......................................... x 1
Instructions .......................................... x 1
Specifications and appearance of this unit are subject to change for further improvement
without prior notice.

24
MEMO
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................
............................................................................................

スタジオキット
スタジオSDIキット
取扱説明書
KA-F5602U
KA-F5603U
型
名
私たちは環境・資源をたいせつにしています。
この取扱説明書はエコマーク認定の再生紙
(古紙100%)を使用しています。
お買い上げありがとうございます。
●ご使用の前にこの「取扱説明書」と「安全上のご注意」
を良くお読みのうえ、正しくお使いください。
特に、「安全上のご注意」は必ずお読みいただき安全
にお使いください。お読みになったあとは、保証書と
一緒に大切に保管し、必要なときにお読みください。
●製造番号は品質管理上、重要なものです。お買いあげ
の際は本機に製造番号が正しく記載されているか、ま
たその製造番号と保証書に記載されている製造番号が
一致しているかを、お確かめください。
イラストは、別売のレンズ・
ビューファインダーを取り付
けた例です。
F.f
ft
m
30
1035
15
10
7
2
1.5
5
4
1.2
5.5 10
C16
11
8
MACRO
PROMPTER
OUTPUT RM DCINPUT
BREAKER
Japanese
プロシステムカンパニー
〒192-8620 東京都八王子市石川町2969-2 電話(0426) 60-7245
お客様ご相談センター
携帯電話・PHS・FAXなどからのご利用は
フリーダ イヤ ル
0120 – 2828 – 17
〒113-0033 東京都文京区本郷3丁目14-7ビクター本郷ビル
(03)5684-9311
[代表]
(03)5684-9317
FAX
電話
© 2004 VICTOR COMPANY OF JAPAN, LIMITED
KA-F5602U/KA-F5603U
スタジオキット/スタジオSDIキット

26
このたびは
スタジオキット KA-F5602U/KA-F5603U を
お買い上げいただきありがとうございます。
この商品は、当社カラービデオカメラKY-F560をスタジオカメラとして使用するためのキッ
トです。
SDI(SerialDigitalInterface)出力端子の有無により型名が異なります。
型名 SDI出力端子
KA-F5602U なし
KA-F5603U あり
主な特長
●アナログ26Pカメラコネクター装備
別売のリモートコントロールユニットRM-P210に接続し、最大100mまでの範囲で本機
をコントロールできます。この場合、カメラへの電源はリモートコントロールユニットから
供給されますので、カメラ用として別電源を用意する必要はありません。
●多系統な出力
26Pカメラコネクターからはコンポジット信号の他、RGBコンポーネント、Y/Cb/Crコン
ポーネントまたはYCセパレート信号のいずれかを出力します。(メニュースイッチにて選
択します。)
●4型ビューファインダーVF-P400装着可能
●インカム端子装備
ヘッドセットを使用することにより、リモートコント−ロールユニットのオペレーターと
のコミニュケーションが可能となります。
●プロンプタ−出力端子装備
リモートコントロールユニットからのプロンプタービデオをコンポジット信号で出力しま
す。
●同期結合時のH位相やSC位相調整ができます。(メニュー画面にて)
●SDI出力端子装備(KA-F5603Uのみ)
カメラ映像をシリアルデジタルビデオ信号(SMPTE259M準拠)で出力します。
Japanese
27
はじめに
付属品をご確認ください ............................................................................. 28
本機を使用するための関連商品 ................................................................. 28
正しくお使いいただくためのご注意 ......................................................... 29
ゲンロック信号およびシステム位相調整について .................................. 29
各部の名称と働き ........................................................................................ 30
取付
システム ........................................................................................................ 33
取り付けの手順 ............................................................................................ 34
本機にKY-F560カメラを取り付ける ...................................................... 34
カメラにレンズを取り付ける ..................................................................... 36
本機を三脚に取り付ける ............................................................................. 36
本機に4型ビューファインダーVF-P400を取り付ける ........................ 37
RM-P210接続
リモートコントロールユニットRM-P210を接続する .......................... 38
RM-P210操作時のご注意......................................................................... 40
メニュー画面
"SYSTEM"メニュー画面 ............................................................................ 41
"DISPLAY"メニュー画面 ........................................................................... 42
その他
保証とアフターサービス ............................................................................. 43
仕様 ............................................................................................................... 44
目次

28
はじめに
付属品をご確認ください
PROMPTER
OUTPUT RM DC INPUT
BREAKER
スタジオキット本体 スクリュー1本:KY-F560カメラをスタジオ
キットに固定するために使用
します。
中継ボード
取扱説明書(本書)
本機を使用するための関連商品
●カラービデオカメラ ........................... KY-F560
●4型ビューファインダー .................... VF-P400
●リモートコントロールユニット ......... RM-P210
●インターカム用ヘッドセット ........... KA-310U
●26Pinカメラケーブル ...................... VC-P110(5m)
VC-P112(20m)
VC-P113(50m)
VC-P114(100m)
●リモートコントロールユニットRM-P210を使用しない場合、AC電源は下記のものを使用
してください。
AC電源 ................................................ AA-P250
※詳細は33ページの「システム」をご覧ください。
いずれかを
選択します。
Japanese
29
正しくお使いいただくためのご注意
本機を長い間ご使用いただくために、次の
ような場所での使用および保管は避けてく
ださい。
極端に暑い所や寒い所
激しい振動のある所
ほこりの多い所
湿気の多い所
強いノイズの発生源の近く
設置、移動時に強い振動や衝撃を与えない
でください。
本機に電源を入れた状態で、カメラケーブル
コネクターを抜き差ししないでください。
電源は指定された電源をお使いください。
RM-P210より供給またはAA-P250
節電のため、使用しないときは電源を切っ
てください。
トランシーバーや携帯電話を本機の近くで
使用すると、インカムのスピーカーにノイ
ズが入ったり画面にノイズが出ることがあ
りますが、これは故障ではありません。
本機を三脚に取り付けたまま
移動すると、本機や三脚に衝
撃・振動が加わった場合に、固
定部が外れ本機が落下し、けが
や事故の原因となることがあ
ります。移動は必ず本機を三脚
より外してから行なってくだ
さい。
注意
インカム使用時、接続システムによっては、
誘導ハムの影響を受けるため本機の
INTERCOMG(GND)端子を大地アースに
接続することをおすすめします。
カメラケーブルは、指定された標準の長さ
のものを使用してください。それ以外はカ
メラケーブル補償が不十分となります。
ゲンロック信号およびシステム位相調整について
RM-P210リモートコントロールユニットと
のシステムで使用した場合、ゲンロック信号
はKY-F560カメラおよびRM-P210のどち
らからでも入力できます。
ただし、KY-F560とRM-P210の両方にゲ
ンロック信号を入力すると、画面が乱れます。
システム位相調整は、ゲンロック信号が入力
された機器側で行なってください。
また、RM-LP55接続時は、RM-LP55が最優
先となります。
RM-P210にゲンロック信号を入力した
場合
RM-P210のH、SC調整で位相を調整してく
ださい。このシステムでRM-LP55を接続し
ている場合は、RM-LP55で位相を調整して
ください。
KY-F560にゲンロック信号を入力した
場合
KY-F560のH、SC調整で位相を調整してく
ださい。(RM-P210を接続していても、KY-
F560で調整してください。)
RM-LP55を接続している場合は、RM-
LP55で位相を調整してください。

30
各部の名称と働き
はじめに
INTERCOM
INCOM MIC
INCOM LEVEL
ON
OFF
MAXMIN
DYNAMIC
CARBON
PUSH
CALL
VF
9
8
12367
4
5
0
1
[RM]RMマルチピンコネクター(26ピン)
26ピンカメラケーブルを用いて、リモー
トコントロールユニットRM-P210と接
続します。
また、このコネクターを介して、リモート
コントロールユニットから本機およびカ
メラに電源が供給されます。
メモ
カメラ映像信号はコンポジット信号の
他にRGBコンポーネント、Y/Cb/Crコ
ンポーネント、YCセパレート信号のい
ずれかをRM-P210の出力端子から出
力します。出力信号は、KY-F560の
"SYSTEM"メニュー画面の"OUTPUT"
項目で選択します。(☞41ページ)
2[INTERCOM]インターカム入力端子
(XLR5ピン)
インターカム用ヘッドセットの入力端子
です。当社製ヘッドセットKA-310Uを接
続できます。
3[INCOMLEVEL]インターカム用レシー
バーボリューム
インターカム用ヘッドセットのレシー
バー音量を調節するボリュームです。
4[INCOMMIC]インターカム用マイク
[ON/OFF]スイッチ
インターカム用ヘッドセットのマイクの
[ON/OFF]スイッチです。ヘッドセットの
マイクを使用する場合、[ON]に設定して
ください。
!
#@
Japanese
31
5[INCOMMIC]インターカム用マイク
[CARBON/DYNAMIC]スイッチ
インターカム用ヘッドセットのマイク型
式を選択します。
[CARBON] : カーボン型マイクの場
合、この設定にします。
[DYNAMIC] : ダイナミック型マイクの
場合、この設定にします。
※当社製ヘッドセットKA-310U接続時
には、[CARBON]に設定してください。
6[CALL]コールボタン
インターカム用ヘッドセットを用いない
で、リモートコントロールユニットのオペ
レーターにコール信号を送るとき、このボ
タンを押します。
このボタンを押しているいる間、リモート
コントロールユニットにコール信号を送
り、リモートコントロールユニットの
[TALLY]ボタンが点滅します。ボタンか
ら指を離すと、コール信号の送信を止め、
リモートコントロールユニットの
[TALLY]ボタンが消灯します。
7[CALL]インジケーター
リモートコントロールユニット接続時、
6[CALL]ボタンを押している間、点灯し
ます。[CALL]ボタンから指を離すと、消灯
します。
8カメラ取り付け用フレーム
このフレームを外して、KY-F560カメラ
を取り付けます。
9中継ボード
KY-F560カメラと接続すためのボード
です。KY-F560背面部のスロット部に取
り付けます。
0[SDI]SDI出力端子…KA-F5603Uのみ
カメラ映像をSDI信号で出力します。
各部の名称と働き(つづき)
![VF]ビューファインダー端子(6ピン)
ビューファインダーからのケーブルを接
続します。
@ビューファインダーホルダー
4型ビューファインダーVF-P400を取
り付けます。
#レンズケーブルクランプ
レンズケーブルを固定するためのクラン
プです。
ご注意
故障を防ぐため、ケーブルを接続するとき
以外は、この端子に触れないでください。

32
各部の名称と働き(つづき)
$[PROMPTEROUTPUT]プロンプター
出力端子(BNC)
リモートコントロールユニットの[AUX]
入力端子に入力された信号(プロンプター
ビデオ信号)をRMマルチピンコネクター
を介して、この端子から出力します。
コンポジット信号で出力します。ビデオモ
ニタ−に接続します。
%
[DCINPUT]DC電源入力端子(XLR4ピン)
リモートコントロールユニットR M -
P210を接続しない場合、この端子にDC
電源を入力します。電源は、AA-P250を
使用してください。
^[BREAKER]ブレーカースイッチ
消費電力が容量オーバーしたとき、ブレー
カーが切れます。ブレーカーが切れた場合
は、何か異常があって定格電力を越えてい
ないかを確認した後、異常がなければブ
レーカーを押し、次に電源を再投入してく
ださい。それでも、正常動作しない場合は、
お買い上げ販売店または最寄りのビク
ターサービス窓口にご相談ください。
&三脚取り付け用ネジ孔
PROMPTER
OUTPUT RM
BREAKER
DC INPUT
$
%^
&
はじめに
Japanese
33
PROMPTER
OUTPUT RM DCINPUT
AC power adapter
AA-P250
VC-710 (5 m)
4P
4P
Headset
KA-310U
Headset
KA-310U
Color video camera
KY-F560
Remote control unit
RM-P210
26Pin camera cable
VC-P110 (5 m)
VC-P112 (20 m)
VC-P113 (50 m)
VC-P114 (100 m)
Viewfinder
VF-P400
Tripod
TP-P300
Dolly
TP-P205
Monitor
Lens
[DC INPUT] connector
[INTERCOM] connector
RM multi-pin connector
[PROMPTER
OUTPUT]
connector
SDI input
Studio kit / Studio SDI kit
KA-F5602U/KA-F5603U
MACRO
CALLTALLY
INTERCOM
LEVEL
FULLAUTO F1
SHUTTER
GAIN
F2
F3 MENU/SHUTTER GAIN PAINT AUTO
BR
W.BAL
AUTO
MANU
WHITE MASTERBLACK
POWER
I
O
IRIS
STEP
SHUTTER
MENU
PUSH-ON
DOWN UP
VARIABLE
PUSH-ON
HIGH
LOW
B
A
PRESET
CLOSE OPEN
MID
DOWN UP
F4
BARS
REMOTE CONTROL UNIT RM-P210
COLORVIDEO CAMERA KY-F560
BREAKER
SDI output (only KA-F5603U)
システム
SDI入力対応
ビデオ機器
●レンズおよびレンズリモコンはKY-F560取扱説明書をご覧ください。
●26Pinカメラケーブルは、100m以内でお使いください。
●リモートコントロールユニットRM-P210を使用したとき、電源は26Pinカメラケーブル
を介してRM-P210から供給されます。リモートコントロールユニットRM-P210を使用
しない場合、電源はAA-P250ACpoweradapterを使用してください。
取付

34
取り付けの手順
1.本機にKY-F560カメラを取り付けます。
2.カメラにレンズを取り付けます。
3.本機を三脚に取り付けます。
4.本機に4型ビューファインダー(VF-P400)を取り付けます。
本機にKY-F560カメラを取り付ける
1.
KY-F560カメラに対する取付の準備作
業を行います。
●KY-F560カメラにレンズが付いてい
る場合は、レンズを外しておきます。
●カメラ取付ブラケットは、カメラの底面
に取り付けた状態にします。
●カメラ背面部のスクリューÅ2本を外
し、スロットカバーを外します。
2.
本機のスクリューı2本をゆるめ、カメラ
取付用フレームを引き出します。
スロットカバー
カメラ取付ブラケット
スクリューı
カメラ取付用フレーム
1.
2.
スクリューÅ
取付
Japanese
35
5.
本機の中継ボードをカメラ背面のスロッ
ト部に挿入し、上記手順
1.
で外したスク
リューÅ2本を用いてカメラに固定しま
す。
メモ
●カメラのレンズマウントキャップは
事前に取りはずしてください。
●カメラ取付フレームを本機に挿入す
るとき、カメラ前面部のレンズ固定用
レバーを時計方向に回
し、レバーを下側の位置
にしてください。レバー
が上側にあると、フレー
ムを挿入したとき、レ
バーが本機にぶつかり
挿入できなくなります。
メモ
中継ボードは奥まで確実に挿入してくだ
さい。
3.
カメラ取付用フレームにカメラを置き、本
機に付属のスクリューÇを用いてフレー
ム底面部にカメラを固定します。
カメラ底面部の取付ブラケットのネジ孔
を用いて固定します。
4.
カメラを取り付けたフレームを本機に挿
入し、上記手順
2.
でゆるめたスクリュー
ı2本を用いて本機に固定します。
スクリューÇ
取付ブラケット
カメラ取付用フレーム
スクリューı
スクリューÇ
4.
3.
5.
中継ボード
スロット部
本機にKY-F560カメラを取り付ける(つづき)
レバー

36
カメラにレンズを取り付ける
レンズの取付方法は、KY-F560取扱説明書をお読みください。
●下記のズームレンズを使用する場合は、別売のレンズケーブルECE-R22が必要です。(ケー
ブルの詳細は、最寄りのビクターサービス窓口にご相談ください。)
S17x6.6BRM(FUJINON)
YH16x7K12U(CANON)
●レンズケーブルは本機のケーブルクランプに固定してください。
本機を三脚に取り付ける
本機底面部のネジ孔を使って三脚に取り付けます。複数のネジ孔を備えていますので、本機の
バランスがとれる位置のネジ孔を使って三脚に取り付けてください。
ネジ孔
ケーブルクランプ
取付
ECE-R22レンズケーブル レンズケーブル
Japanese
37
本機に4型ビューファインダーVF-P400を取り付ける
1.
ビューファインダーのロックレバーを反時計方向に回してロックレバーをゆるめます。
2.
ビューファインダーを本機上面部のビューファインダーホルダーのガイドに沿わせて、前
方にスライドさせます。
3.
ビューファインダーのロックレバーを時計方向に回して固定します。
4.
ビューファインダーケーブルのコネクターを本機のビューファインダー端子に接続しま
す。
4型ビューファインダー
VF-P400
ロックレバー
ビューファインダーホルダー
ビューファインダー端子
1.
3.
2.
4.
ビューファインダー
ケーブル
メモ
KY-F560の"SYSTEM"メニュー画面の"ASPECTRATIO"項目を"16:9"に設定したと
き、ビューファインダーVF-P400には縦長の映像が表示されます。
Other manuals for Studio Kit KA-F5602U
1
This manual suits for next models
1
Table of contents
Other JVC Camera Accessories manuals

JVC
JVC WR-MG200U User manual

JVC
JVC WR-DV75U User manual

JVC
JVC KA-DV350U User manual

JVC
JVC CARRYING BAG CB-V77U User manual

JVC
JVC Marine Case WR-MG100 User manual

JVC
JVC CamiFlex FG-CAM-F4/U User manual

JVC
JVC CB-A260 User manual

JVC
JVC WR-GX001 User manual

JVC
JVC KA-ZH215U User manual

JVC
JVC KA-790G User manual
