JWA CHINON 68716 User manual

1
Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please refer to your receipt
ASSEMBLY INSTRUCTION
CHINON
ITEM CODE 68716
SOFA TABLE

Allow 15 min For 1 person Additional tool
required
2
PRE-ASSEMBLY PREPARATION
Before you start:
1. Choose aclean, level, spacious assembly area.Avoid hard surfaces that may
damage the product
2. Take care when lifting.Product should be assembled as near as possible to the
point of use
3. Ensure that you have all required contents for complete assembly
4. Always read the assembly instructions carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over tighten the screws and bolts as this may damage the threads
7. Assembly is to be carried out by acompetent adult(s) ONLY
8. During assembly, children should be kept away from the product due to possible
risk to injury.
9. Do not use this item if any components are missing or damaged.
10. Please keep the instructions for future reference.

3
PARTS LIST
1Top Panel x 1
2Middle Panel x 1
3Lower Panel x 1
5Frame x 1
6Frame x 1
4Bars x 3

4
STEP 1:
•Prepare a surface with a protective blanket or cardboard.
• Place frame(5) flat on the surface, as shown below.
• Insert the 3x bars(4) onto frame(5).
•Cap the frame with frame(6), as shown below.
• Secure with 2x bolt(A) per connection. Fasten with allen
key(C).
• Fasten only until the bolt is tight in the thread, do not fully
fasten for now.

5
STEP 2:
• Insert the top panel(1) into the frame, as shown below.
• Secure with 12x screw(B) fasten with a phillips head screw
driver.

STEP 3:
6
• Insert the middle panel(2) into the frame, as shown below.
• Secure with 8x screw(B) fasten with a phillips head screw
driver.
•Then insert the lower panel(3), secure with 4x screw(B),
fasten with a phillips head screw driver.
STEP 4:
• Attach the 4x footstickers(D) as shown above.
•With a 2nd person rotate the table to the correct way up.
• Place the table on a level surface.
• Push down on the corners of the table to level it out. Do not
lean beyond your own balance.
• Once levelled turn the table back on its side and fasten all
the bolts.

7
ASSEMBLY IS COMPLETE

8
SAFETY BRACKETS
INSTRUCTIONS
1. Attach one Mounting Plate to the wall with the Large Screws. Make sure to
attach the Mounting Plate into a stud. If mounting into brick or masonry you
will need to acquire wall anchors.
2. Attach the second Mounting Plate to the furniture frame with the Short
Screws.
3. Move the furniture to its final position. Thread a Wall Strap through the both
Mounting Plates and tighten until snug. Do not over tighten.
4. Make sure that the Mounting Plates are firmly attached to the wall and
furniture and that the Wall Strap is snug.

9
PRODUCT CARE:
As our timber is supplied from sustainable forests there will be natural
variations in surface texture and grain like knots, mineral streaks and sap
runs that may affect the finish. These differences in character are not
defects, but distinctions that make each piece of furniture unique
Our furniture is built to last. Following these steps for basic care should
protect your investment for years to come
•Dust frequently with a clean damp lint-free cloth. This will help
remove abrasive build up which can damage a finish over time
•Do not place hot objects on any furniture surface. Always use a hot plate or
placemat. Laminate and lacquer finishes on table tops provide added scratch
and heat resistance to our furniture, but they can still be damaged without
proper care
•Avoid exposing your furniture to strong sunlight, heat outlet, open windows
or dampness. Prolonged exposure to direct sunlight can fade the finish of
your furniture, while extreme temperature and humidity changes can cause
cracking or splitting
•Do not expose your furniture to any liquids. Never allow water to sit on your
furniture. Alcohol, nail polish and perfume are also dangerous as they will
dissolve the lacquer finish on contact and may require professional repairs
•Do not allow plastic to come in direct contact with your furniture. Chemicals
in the plastic of placemats etc. may soften and mark the finish if left in
contact with the furniture for a period of time
