LC SERIES
MODELS LCLX, LCMX
OPERATING INSTRUCTIONS
The following instructions cover lock operations for LC Series locks. The lock models are
battery powered (PowerSaverTM technology). See back page for Battery Replacement
instructions.
SUPER MASTER CONTROL
The Super Master Combination is a six-digit combination used to reset the lock to the
factory default combination (50 25 50) in the event the user combination(s) are lost. See
the Super Master Operations sheet (P/N 394.101).
LOCK MODES
A maximum of two users can exist in a lock. A lock can operate in either Single Mode or
Dual Custody Mode.
• Single Mode E
Single Mode defaults to having only a Manager User (User 1) in the lock. A second
user (User 2) can then be added by the Manager User (User 1). (See section on
Manager User Operations.)
In Single Mode only one valid user combination is required to open the lock - the Manager
User (User 1) combination or the User 2 combination.
Note: Default lock status from the factory is Single Mode with an opening
combination of “50 25 50” for the Manager User (User 1).
•Dual Custody Mode EE
Dual Custody Mode defaults to two users in the lock - User 1 and User 2.
Both user combinations are required to open the lock - the User 1 combination and the
User 2 combination.
Note: Manager User Operations are not available in Dual Custody Mode.
LOCK OPERATION & RESPONSES
• Each keystroke generates a green flash
G
with a beep 88
88
8.
• To cancel entry, press .
• The completion of a step within an operation is indicated by a green flash
G
with a beep 88
88
8.
• The successful completion of an operation is indicated by two green flashes
with beeps.
G
88
88
8
G
88
88
8
• An error is indicated by five green flashes with beeps.
G
88
88
8
G
88
88
8
G
88
88
8
G
88
88
8
G
88
88
8
• A low battery is indicated by 5 series of three green flashes with beeps
G
88
88
8
G
88
88
8
G
88
88
8after a lock opening.
(See Battery Replacement on back page.)

OPEN/CLOSE THE CONTAINER
1. • For Single Mode EE
EE
E(Factory combination is “50 25 50”.)
Enter Manager User (User 1) or User 2 combination.
G
88
88
8
• For Dual Custody Mode EE
EE
EEE
EE
E
Enter User 1 or User 2 combination.
G
88
88
8
Enter the second combination.
G
88
88
8
Wrong Try Penalty: 5 wrong tries = 3 min. lockout
Each additional wrong try = 3 min. lockout
Green flashes with beeps
G
88
88
8will occur during the lockout.
2. Immediately rotate the container handle to retract bolt works before green
G
lights flash with beeps 88
88
8. Open the container door. To close and lock the
container, close the door and rotate the container handle back to locked position.
CHANGE COMBINATION
WARNING: Super Master Control will be permanently lost if you do not change
the default Super Master Combination prior to changing any User combinations.
See Super Master Operations sheet (P/N 388.105).
Caution: Before changing combination, open the container door to allow testing
with the new combination. Record new combination and store it in a secure
place.
1. • For User 1 (Manager User in Single Mode)
Press . Press .
G
88
88
8
• For User 2
Press . Press .
G
88
88
8
2. Enter current combination. (Factory combination is “50 25 50”.)
G
88
88
8
3. Enter new six-digit combination.
G
88
88
8
4. Enter new combination again for verification.
G
88
88
8
G
88
88
8
5. Open the lock with the new combination before closing container.
CHANGE LOCK MODE (SINGLE / DUAL CUSTODY)
Note: Changing the lock mode will reset the combination(s) to “50 25 50”.
1. Press . Press .
G
88
88
8
2. • If changing from Single to Dual Custody Mode
Enter Manager User (User 1) combination.
G
88
88
8
G
88
88
8
• If changing from Dual Custody to Single Mode
Enter User 1 or User 2 combination.
G
88
88
8
Enter the second combination.
G
88
88
8
G
88
88
8

Manager User Operations
These operations are only available in Single Mode and can only be performed by the
Manager User (User 1). All Manager User Operations involve management of User 2.
User 2 can have a lock access status of “Enabled” or “Disabled”. If “Enabled”, User 2
can open the lock. When User 2 is added to the lock, the default lock access status is
“Enabled”. The Manager User (User 1) has the authority to change the lock access
status for User 2 and can temporarily “Disable” lock access for the user.
ADD USER 2
1. Press . Press .
G
88
88
8
2. Enter Manager User (User 1) combination.
G
88
88
8
G
88
88
8
Note: User 2 is added to the lock as “Enabled” with a factory combination of “50 25 50”.
User 2 can change the User 2 combination while Enabled, but only the Manager User
(User 1) can change the lock access status.
DELETE USER 2
1. Press . Press .
G
88
88
8
2. Enter Manager User (User 1) combination.
G
88
88
8
G
88
88
8
ENABLE USER 2
1. Press . Press .
G
88
88
8
2. Enter Manager User (User 1) combination.
G
88
88
8
G
88
88
8
Note: If you try to enable User 2 when already enabled, you will get an error indication.
DISABLE USER 2
1. Press . Press .
G
88
88
8
2. Enter Manager User (User 1) combination.
G
88
88
8
G
88
88
8
Note: If you try to disable User 2 when already disabled, you will get an error indication.

Document Number 384.120 Rev. C2 - 01/02
www.kaba-mas.com
749 W. Short Street, Lexington, KY 40508
Phone [phone] or [phone] FAX [phone]
Battery Replacement
Read all instructions before attempting to replace the battery in an LC Series
lock.
To replace the battery, you must
first remove the keypad
assembly. To do so, insert the
blade of a flat head screwdriver
under the keypad housing at a
point about 15 degrees to the
right of 6 o’clock on the face of
the keypad (below the Enter
key). (See Figure 1.) There is a
small indentation on the back
edge of the keypad housing that
will allow the screwdriver to
easily be inserted at this point.
Pry the keypad assembly from
the face of the safe being
careful not to damage the cable
connection from the safe to the
keypad assembly. (See Figure
2.)
Remove the old battery and
replace with a new 9-Volt
battery. (See Figure 2.) Reattach
the keypad being careful not to
pinch the battery cable
between the keypad housing
and the mounting bracket.
Test the operation of the lock
before closing the container. If
the combination is entered
successfully, one green flash
displays to indicate the lock is
ready to open. Then rotate the
container handle to retract the
bolt. If the test is successful, the
lock and container are now
ready for use.
Note: If the lock does not operate successfully, carefully remove the keypad, check
the cable connection, and verify that all mounting screws are securely tightened.
Insert Blade of
Screwdriver
Under Keypad
Housing
Figure 1
Battery Clip
Cable
Connection
Figure 2
Battery
