1000 Series FAQ
Resetting the Code / Combination
From a Lost Code
Important: There is no procedure for finding an unknown
combination from the front of the lock. A lost combination must be
cleared by removing the combination chamber from the lock
housing, then a new combination can be set.
1. Remove the back plate from the front lock housing by removing
the six back plate screws.
2. Lift the chamber linkage (A) off of the control shaft (B) by
prying up with a small flat blade screwdriver (see figure 1).
3. Remove the shaft bushing (C).
4. Remove the combination chamber (D) by removing the two
Phillips head screws (E) at each end of the combination chamber.
5. Remove the chamber cover (A) marked Ilco Unican (see figure
2) by gently tapping the lip of the chamber cover at the control
shaft end of the chamber (A) (see figure 3) with a screwdriver to
detach it from the staked joints (B).
6. Lay the chamber on its side as shown in figure 4.
7. With tweezers, or other tool, slide the "e" ring (B) off the
unlocking slide stud (A) (see figure 4), then gently lift the end of
the unlocking slide (C) over the unlocking slide stud (A).
Note: The unlocking slide (C) is under spring tension and will be
easier to lift if pushed to the left to ease tension. Swing the
unlocking slide (C) sufficiently to clear the gears (D), no further
than shown in figure 5.
8. Depress the lockout slide (E). The gears (D) are now free to
rotate (see figure 6).
9. Turn each gear (D) so that the gear pockets (F) are aligned as
in figure 6.
For a larger view
of these images,
click here
http://www.kaba-ilco.com/access_control/support/pbl_faq/resetting_code_combination/1000_series.asp (1 of 2) [5/21/2004 11:11:14 AM]

Access Control - 1000 Series PBL FAQ
10. Return the unlocking slide (C) over the unlocking slide stud
(A) while making certain the five toes (G) are engaged in the five
gear pockets (F). It may be necessary to adjust each gear slightly
to make proper alignment between toes and gear pockets (see
figures 6 & 7). Resecure the "e" ring (B) on the unlocking slide
stud (A). Your chamber will now resemble figure 7. and is ready
for reassembly into the lock housing.
REASSEMBLY
1. Resecure the chamber cover (A). Make sure the staked joints
(B) on both end plates fit through both slots on the back cover
(see figure 2).
2. Resecure the shaft bushing (C) with flat side facing up (see
figure 1).
3. Secure the combination chamber (D) with the two Phillips head
screws (E) you removed earlier (see figure 1).
4. Resecure the chamber linkage (A) onto the control shaft (B)
(see figure 1).
5. Resecure the back plate and secure it with the six back plate
screws.
SETTING THE COMBINATION
Do not attempt to set a combination until the complete unit has
been reassembled. Perform the following steps in the order shown.
1. Turn the outside knob once clockwise to the stop position and
then release.
2. Enter the new combination.
3. Turn the outside knob clockwise to the stop position, make sure
the latch is fully retracted, then release the knob.
4. Repeat steps 2 & 3 before closing your door to confirm code
setting.
