Kane 457 User manual

KANE457
Quick Reference Guide
ON / OFF
Turns the analyser ON / OFF
BACKLIGHT
Switches backlight & torch light ON /
OFF
PUMP
Turns the pump ON / OFF
Hold button to zero pressure
SEND / ENTER
Send readings to printer
(Press button for 1 second.)
Send readings to memory
(Hold button down for 2+ secs.)
Stock No. 19294-2 July 2014
© Kane International Ltd

Battery charger
connection
Flue Gas Inlet
Watertrap Drain
with Red Screw
Plug
Flue probe temperature (T1)
Inlet temperature (T2)
Pressure connection
P1
Pressure connection
P2 (differential)
Fit Spigot to Hose before
connecting to Analyser

1. BEFORE USING ANALYSER CHECK THE FOLLOWING:
Particle filter is not dirty or wet.
Water trap and flue probe hose are empty of water
Water trap and red screw plug are fitted correctly to the analyser
Flue probe hose is connected properly to the flue gas inlet
Flue probe temperature plug is connected into T1 temperature connection
Please read the Safety Warnings in the User Manual
2. FRESH AIR PURGE
Position the flue probe in fresh air, then press the “On/Off” button. The analyser auto-
calibrates for approximately 90 seconds. When complete…
Select “Ratio” on the dial. In fresh air the CO reading = 0ppm
Select “O2/Eff” on the dial. In fresh air the O2 reading = 20.9%
Select “Status” on the dial to view the following…
STATUS display
BAT
11 : 46 : 29
15 / 05 / 13
CAL 283
- Battery status.If less than 1 bar recharge or replace, (see section 10)
- Current time. Can be set via the “Menu”, (see section 11)
- Current date. Can be set via the “Menu”, (see section 11)
- Number of days until re- calibration is required
Note: Boiler inlet air temperature can either be…
a) Set automatically by the flue probe during the fresh air purge, or
b) Continuously measured if a thermocouple is plugged into the T2 socket
3. COMBUSTION TESTS
Select “Ratio” on the dial to check that the analyser is set for the correct fuel. To change
fuel select MENU / SETUP / SET FUEL then use scroll and enter, (see section 11).
Position the flue probe as per the boiler manufacturer’s instructions; typically the tip of
the flue probe is inserted to the centre of the flue. The readings will stabilise after 60
seconds assuming the boiler conditions are stable.
The rotary switch can be used to display the following information…
RATIO display
NAT GAS
R 0.0001
COP 12
CO2% 8.8
- Fuel type can be changed via “Menu”, (see section 11)
- CO/CO2 ratio
- Carbon Monoxide, (ppm)
- Carbon Dioxide, (%)
Press SEND to print a full combustion test. (Also sends to PC if Bluetooth fitted).
Hold SEND for 2+ seconds to log a full combustion report.

O2/EFF display
O2% 5.4
TFC 55.1
TIC 17.2
EfC% 98.3
- Oxygen left after combustion. Should be 20.9% in fresh air.
- Flue temperature, (C)
- Inlet temperature. Normally set by flue probe during fresh air purge.
- Condensing boiler efficiency (EfC). Can be changed via “Menu”
Press SEND to print a full combustion test. (Also sends to PC if Bluetooth fitted).
Hold SEND for 2+ seconds to log a full combustion report.
AUX display: a user defined display
O2% 20.9
COP 00
11 : 55 : 02
BAT 59
- The default AUX (auxiliary) display is shown
The parameters on lines 1, 2, 3 and 4 can be set independently
To customise the AUX display select MENU / SCREEN / AUX.
They remain the AUX parameters until changed again by the user.
Press SEND to print a full combustion test. (Also sends to PC if Bluetooth fitted).
Hold SEND for 2+ seconds to log a full combustion report.
4. PRESSURE TEST (Also see section 9)
Select “Prs”. The pump stops. Press the PUMP button to auto-zero the pressure
sensor. Using the black connectors and manometer hose connect to P1 for single
pressure or P1 and P2 for differential pressure.
PRS display
PRESSURE
P -0.04
mbar
12 : 56 : 29
- Defaults to smoothing ‘off’ on start-up. Can be changed via “Menu”.
- Defaults to ‘low’ resolution on start-up. Can be changed via “Menu”.
- Pressure units can be changed via “Menu”.
- Displays time to enable manually timed tests.
Press SEND to print a pressure test. (Also sends to PC if Bluetooth fitted).
Hold SEND for 2+ seconds to log a pressure report.
5. LET-BY and TIGHTNESS TESTING (Also see section 9)
Select “Tightness”. The pump stops. Press the PUMP button to auto-zero the pressure
sensor. Select “yes” or “no” for the let-by test by using or , then press . Connect
from the test point to P1 using a black connector and manometer hose. Adjust the gas
pressure as you would with a “U” tube manometer. Press to start either the let-by
test or the stabilisation period…
LET BY
P1 10.35
P2 10.35
TIME 59
- Let-by test display.
- Pressure at the start of the let-by test
- Real time pressure reading
- Let-by default time is 1 minute. Can be changed via “Menu”.

When complete adjust the gas pressure if necessary then press to start the
stabilisation period…
STABIL’N
P1 20.00
mbar
TIME 59
- Stabilisation display.
- Real time pressure reading
- Stabilisation default time is 1 minute. Can be changed via “Menu”.
When complete adjust the gas pressure if necessary then press to start the tightness
test…
TIGHTN’S
P1 20.33
P2 20.33
TIME 119
- Tightness test display.
- Pressure at start of tightness test
- Real time pressure reading
- Tightness default time is 2 minute. Can be changed via “Menu”.
When complete the display will show…
LOG 06
P1 20.33
P2 20.26
PRINT
- Let-by and tightness test are automatically stored as a log number
- Pressure at start of tightness test
- Pressure at end of tightness test
- The test can be printed immediately or later from the memory
Note: The analyser’s memory can store up to 20 tightness tests. Tightness tests are logged
automatically therefore the tightness section of the memory will be full after the 20th
tightness test is complete. Before the 21st tightness test can be performed the
tightness section of the memory must be cleared. To do this select MENU / REPORT /
TIGHTN’S / DEL ALL / YES then press .
6. DIFFERENTIAL TEMPERATURE
Select “Diff Temp” to measure flow, return and differential temperatures
DIFF TEMP display
TEMP
T1C 60.1
T2C 47.0
TC 13.1
- Pump automatically switches off when dial is moved to Diff Temp
- Use the T1 connection for the flow temperature sensor
- Use the T2 connection for the return temperature sensor
- Real time temperature difference
Press SEND to print a differential temperature test. (Also sends to PC if Bluetooth fitted).
Hold SEND for 2+ seconds to log a differential temperature report.

7. AMBIENT TESTS
ROOM AIR TESTING
Select “Room Test” for CO and CO2 investigations. Tests can be 15 or 30 minutes and
can be stopped at any time by pressing the PUMP key. Please refer to user manual.
ROOM AIR display
COp 02
CO2P 600
TEST 14
LOG 01
- Real time CO reading (ppm)
- Real time CO2 reading, (ppm)
- Test 00 = start. To stop the Room CO test press the PUMP button
- The complete Room CO test is automatically stored as a log number
Ambient CO2 & CO ideal for 'walk around' testing.
COp 8
CO2P 900
COx 14
CO2x 985
- Real time CO reading, (ppm)
- Real time CO2 reading, (ppm)
- Maximum CO reading (ppm)
- Maximum CO2 reading (ppm)
Timed LOG
Select logging period from 4 to 24 hours to take 240 sets of readings
COp 9
CO2P 800
COv 11
CO2v 950
- Real time CO reading, (ppm)
- Real time CO2 reading, (ppm)
- Average CO reading (ppm)
- Average CO2 reading (ppm)
ZERO
Follow the instructions on the screen. 60 second ambient zero is followed by a true zero.
ZEROING
CO2p 0
TIME 59
-
60 second countdown

8. OTHER DISPLAY CODES
-PO- = Pump Off
-OC- = Open Circuit on temperature input
9. FOR BEST PRESSURE SENSOR ACCURACY
1) Switch the analyser on for 5 minutes to let the temperature stabilise.
2) Zero the pressure sensor when the analyser in the exact position that it will be
used.
10. MANO-MODE
A limited mode for pressure and temperature only that avoids the 90 second countdown
.
With the KANE457 switched off, press and hold down / and then press
and release / . Release / after MANO_MOD is displayed on
top line.
The KANE457 will now operate as a fixed display thermometer/pressure meter with the
pump off and inhibited. The readings can be printed but not stored.
11. TO FULLY CHARGE NiMH RECHARGEABLE BATTERIES
1) The analyser must be switched on.
2) Connect the charger and switched it on; charging indicator illuminates.
3) Switch the analyser off; the display will show “BATTERY CHARGING”.

12. USING THE MENUS
Select “Menu” on the rotary switch and navigate using the function buttons…
= Scroll up = Scroll down
= Enter
COMBUSTION MENU
MAIN MENU SUB MENU OPTIONS / COMMENTS
SETUP SET FUEL NAT GAS, L OIL (28/35 sec), PROPANE, BUTANE, LPG, PELLETS
(Wood)
N C G EfN = nett efficiency, EfG = gross efficiency, EfC = condensing efficiency
SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00
SET DATE Uses DD-MM-YY format
OUTPUT KMIRP1 or KMIRP2 or BLUETOOTH or XML DATA
PASSKEY 1111
REPORT COMB’N Stored combustion tests, VIEW, DEL ALL or EXIT (max = 99 tests)
SCREEN CONTRAST Factory setting is 04
AUX Enables users to customise the parameters on the AUX display
User can set any parameter on lines 1, 2, 3 and 4
HEADER Sets printout header, 2 lines, 20 characters per line
SERVICE CODE Password protected for authorised service agents. Leave set to 0000.
To EXIT each Sub MENU select EXIT.
To EXIT the MENU move the rotary switch to any position other than “Menu”.
Any changes that have not been “entered” will be ignored.
TEMP + PRESS. MENU
SETUP PASSKEY 1 1 1 1
SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00
SET DATE Uses DD-MM-YY format
EXIT

MAIN MENU
SUB
MENU OPTIONS / COMMENTS
PRESSURE SMOOTH OFF = normal response.
ON = slower (damped) response
RESOLVE LOW = e.g. 0.01mBar resolution.
HIGH = displays to an extra decimal place
PS UNITS mBar, mmH2O, Pa, kPa, PSI, mmHg, hPa, InH2O
TIME
LET BY = Set duration of let-by test in minutes.
Default = 1 minute
STABIL’N = Set duration of stabilisation in minutes.
Default = 1 minute
TIGHTN’S = Set duration of tightness test in minutes.
Default = 2 minute
EXIT
REPORT PRESSURE
Stored pressure tests, VIEW, DEL ALL or EXIT
(max = 20 tests)
TIGHTN’S Stored let-
by and tightness tests, VIEW, DEL ALL or EXIT,
(20 tests)
TEMP
Stored differential temperature tests, VIEW, DEL ALL or EXIT
(20 tests)
SCREEN CONTRAST
Factory setting is 04
AUX
Enables users to customise the parameters on the AUX
display
User can set any parameter on lines 1, 2, 3 and 4
HEADER Sets printout header, 2 lines, 20 characters per line
SERVICE CODE Password protected for authorised service agents.
Leave set to 0000.

AMBIENT MENU
SETUP PASSKEY 1 1 1 1
SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00
SET DATE Uses DD-MM-YY format
EXIT
REPORT ROOM AIR Stored Room AIR tests, VIEW, DEL ALL or EXIT
(max = 20 tests)
AMBIENT Stored Amb CO2 & CO tests, VIEW, DEL ALL or EXIT,
(20 tests)
TIMED Stored Timed Logs, VIEW, DEL ALL or EXIT (20 tests)
SCREEN CONTRAST
Factory setting is 04
AUX Enables users to customise the parameters on the AUX display
User can set any parameter on lines 1, 2, 3 and 4
HEADER Sets printout header, 2 lines, 20 characters per line
SERVICE CODE Password protected for authorised service agents.
Leave set to 0000.

13. Printouts
KANE457 V 1.00G
SERIAL NO. 000000000
YOUR COMPANY NAME &
PHONE NUMBER HERE
KANE457 V 1.00G
SERIAL NO. 000000000
YOUR COMPANY NAME &
PHONE NUMBER HERE
KANE457 V 1.00G
SERIAL NO. 000000000
YOUR COMPANY NAME &
PHONE NUMBER HERE
DATE 01/07/14 PRESSURE DIFF TEMP
TIME 12:00:08
DATE 01/07/14 DATE 01.07/14
COMBUSTION TIME 12:00:08 TIME 12:00:08
FUEL NAT GAS PRS mbar -0.037 T1
o
C 60.1
O2 % 5.4 T2
o
C 47.0
CO2 % 8.8 ∆T
o
C 13.1
CO ppm 12 Customer
FLUE
o
C 55.1
INLT
o
C 17.2 Appliance Customer
NETT
o
C 37.9
Ref. Appliance
EFF (C) 98.3
LOSSES 1.7 Ref.
XAIR % 34.8
-----------------------------------------------------
C a l . d u e o n 0 1 / 0 7 / 1 5
----------------------------------------------------- KANE457 V 1.00G
SERIAL NO. 000000000
YOUR COMPANY NAME &
PHONE NUMBER HERE
CO/CO2 0.0001
KANE457 V 1.00G
SERIAL NO. 000000000
YOUR COMPANY NAME &
PHONE NUMBER HERE
PRS mbar 0.00
Customer ROOM AIR TEST
Appliance LOG 01 LOG 01
DATE 01/07/14 DATE 01/07/14
Ref. TIME 12:00:08 TIME 12:00:08
TEST CO ppm CO2 ppm LET BY TEST
0 0 0
1 0 222 PRS-1 mbar 10.12
KANE457 V 1.00G
SERIAL NO. 000000000
YOUR COMPANY NAME &
PHONE NUMBER HERE
2 0 192 PRS-2 mbar 10.11
3 0 177 LET-BY MINS 1:00
4 0 178
5 0 183 TIGHTNESS TEST
6 0 189
7 0 192 PRS-1 mbar 20.12
AMBIENT CO/CO2 8 0 200 PRS-2 mbar 20.10
15
0
235
∆PRS
mbar
-0.02
DATE 01/07/14 STABIL’N MINS 1:00
TIME 12:00:08 MAXIMUM CO 0 TIGHTN’S MINS 2:00
MAXIMUM CO2 235
CO ppm 0 Customer
CO2 ppm 223 Customer
MAXIMUM CO 0 Appliance
MAXIMUM CO2 223 Appliance
Ref.
Customer Ref.
Appliance
Ref.


PRODUCT REGISTRATION
Please complete, detach and return to: Kane International Ltd
Kane House, Swallowfield, Welwyn Garden City, Hertfordshire, AL7 1JG
Your Details
Name:
Job Title:
Company Name:
Company Address 1:
Address 2:
Town/City:
County:
Postcode:
Country:
Phone Number:
Fax Number:
Mobile Number:
Email Address:
Product Details
Note: Proof of Purchase may be required for warranty claims.
Date Purchased:
as numbers (28.01.14):
Purchased From:
Model Number: KANE457
Product Serial Number:
Located on the rear product
label beneath the protective
rubber sleeve

Why did you buy a Kane Product?
Made in the UK Previous Owner
Value for Money Our Fixed Price Servicing Programme
Kane Brand Dealer Recommendation
Not your Decision Other:
What brand was your previous analyser?
How did you hear about Kane?
Magazine Advert Trade Counter
Training School Previous Owner
Personal Recommendation Internet Search
Exhibition Other:
Which do you read most often?
Often Sometimes Hardly Ever
Registered Gas Engineer
Gas Installer
P.H.P.I.
P.H.A.M. News
Heating Ventilating & Plumbing
Heating & Plumbing Monthly
Your feedback is important to us, please add any additional comments you would
like to make with regard to your recent Kane purchase:
Thank you for completing this survey.
All the information we have collected is confidential.
We do not sell or share data with any other company or organisation.


Thank you for buying this
analyser.
Before use, please register on
our website
www.kane.co.uk
Scan the QR code to go directly to
Register your Product on-line
or complete, detach and return
the Product Registration form in
this manual.
Other manuals for 457
2
Table of contents
Other Kane Measuring Instrument manuals
