Kemppi Minarc 150 User manual

Käyttöohje • Suomi
Bruksanvisning • Svenska
Bruksanvisning • Norsk
Brugsanvisning • Dansk
Operating manual • English
Gebrauchsanweisung • Deutsch
Gebruiksaanwijzing • Nederlands
Manuel d’utilisation • Français
Manual de instrucciones • Español
Instrukcja obsługi • Polski
Инструкции по эксплуатации • По-русски
1910150
0901
FI
SV
NO
DA
EN
DE
NL
FR
ES
PL
RU
MINARC™
150, 151
150 VRD
120 AU, 150 AU

EN
OPERATING MANUAL
English
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
CONTENTS
1. PREFACE .......................................................3
1.1 Introduction .........................................................................................................3
1.2 Safety instructions..........................................................................................3
2. BEFORE YOU START USING THE UNIT .......7
2.1 Unpacking..............................................................................................................7
2.2 Placing the unit.................................................................................................8
2.3 Serial number......................................................................................................8
2.4 Main components ..........................................................................................8
2.5 Connecting to power supply mains .............................................9
2.6 Filler materials and equipment..........................................................9
3. USE .............................................................. 10
3.1 Welding processes ......................................................................................10
3.2 Operating functions..................................................................................10
3.3 Welding selections......................................................................................12
3.4 Welding selections......................................................................................12
3.5 Storing.....................................................................................................................13
4. MAINTENANCE .......................................... 13
4.1 Daily maintenance......................................................................................13
4.2 Troubleshooting............................................................................................14
5. DISPOSAL ................................................... 14
6. ORDERING NUMBERS ............................... 15
7. TECHNICAL DATA ...................................... 15
8. WARRANTY POLICY................................... 17
2
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
1. PREFACE
1.1 INTRODUCTION
Congratulations on having purchased a KEMPPI product. Properly installed
and used KEMPPI products should prove to be productive machines
requiring only a small amount of regular maintenance.
This manual is arranged to give you a good understanding of the equipment
and its safe use. There is also information on both servicing the unit as well as
its technical data. Read the instructions before taking the machine into use or
servicing it for the rst time. Additional information on Kemppi products and
their use can be obtained from Kemppi or a Kemppi dealer.
The specications and designs presented in this manual are subject to
change without prior notice.
NOTE! Items in the manual that require particular attention in order to minimise
damage and personal harm are indicated with this symbol. Read these sections
carefully and follow their instructions.
1.2 SAFETY INSTRUCTIONS
Kemppi welding devices conform to international safety standards. Safety
is an important issue in equipment design and manufacturing. Therefore,
Kemppi welding solutions are unparalleled in safety. There are, however,
always certain hazards involved in using welding equipment. Therefore, to
ensure your personal safety and the safety of your working environment,
carefully read the safety instructions below and respect them.
Use of personal protective equipment
• Thearcanditsreectingradiationdamageunprotectedeyes.Shield
your eyes and face appropriately before you start welding or observe
welding. Also note the dierent requirements for the darkness of the
screen in the mask as the welding current changes.
• Thearcradiationandspattersburnunprotectedskin.Alwayswear
protective gloves, clothing and footwear when welding.
• Alwayswearhearingprotectioniftheambientnoiselevelexceedsthe
allowable limit (e.g., 85 dB(A)).
General operating safety
• Exercisecautionwhenhandlingpartsheatedinwelding.Forexample,
the tip of the welding torch, the end of the welding rod and the work
piece will heat during gouging to a burning temperature.
3
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
• Neverwearthedeviceontheshoulderduringweldingandnever
suspend it by the carrying strap during welding.
• Donotexposethemachinetohightemperatures,asheatmaycause
damage to the machine.
• Keepthetorchcableandearthingcableasclosetoeachotheras
possible throughout their length. Straighten any loops in the cables. This
minimisesyourexposuretoharmfulmagneticelds,whichmayinterfere
withapacemaker,forexample.
• Donotwrapthecablesaroundthebody.
• Inenvironmentsclassiedasdangerous,onlyuseS-markedwelding
devices with a safe idle voltage level. These work environments include,
forexample,humid,hotorsmallspaceswheretheusermaybedirectly
exposedtothesurroundingconductivepieces.
Spatter and re safety
• Weldingisalwaysclassiedashotwork,sopayattentiontoresafety
regulations during welding and after it.
• Rememberthatrecanbreakoutfromsparksevenseveralhoursafter
the welding work is completed.
• Protecttheenvironmentfromweldingsplatter.Removeammable
materials,suchasammableuids,fromtheweldingvicinityandsupply
the welding site with adequate re ghting equipment.
• Inspecialweldingjobs,bepreparedforhazardssuchasreorexplosion
when welding container type work pieces.
• Neverdirectthesparksprayorcuttingsprayofagrindertowardthe
weldingmachineorammablematerials.
• Bewareofhotobjectsorsplatterfallingonthemachinewhenworking
above the machine.
• Weldinginammableorexplosivesitesisabsolutelyforbidden.
General electric safety
• Onlyconnecttheweldingmachinetoanearthedelectricnetwork.
• Notetherecommendedmainsfusesize.
• Donottaketheweldingmachineinsideacontainer,vehicleorsimilar
work piece.
• Donotplacetheweldingmachineonawetsurfaceanddonotworkon
a wet surface.
• Donotallowthemainscabletobedirectlyexposedtowater.
• Ensurecablesorweldingtorchesarenotsquashedbyheavyobjectsand
thattheyarenotexposedtosharpedgesorahotworkpiece.
4
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
• Makesurethatfaultyanddamagedweldingtorchesarechanged
immediately as they can be lethal and may cause electrocution or re.
• Rememberthatthecable,plugsandotherelectricdevicesmaybe
installed or replaced only by an electrical contractor or engineer
authorised to perform such operations.
• Turnotheweldingmachinewhenitisnotinuse.
Welding power circuit
• Insulateyourselffromtheweldingcircuitbyusingdryandundamaged
protective clothing.
• Nevertouchtheworkpieceandweldingrod,weldingwire,welding
electrode or contact tip at the same time.
• Donotputtheweldingtorchorgroundcableontheweldingmachine
or other electric equipment.
Welding fumes
• Ensureproperventilationandavoidinhalingthefumes.
• Ensuresucientsupplyoffreshair,particularlyinclosedspaces.Youcan
alsoensurethesupplyofcleanandsucientbreathingairbyusinga
fresh-airmask.
• Takeextraprecautionswhenworkingonmetalsorsurface-treated
materials containing lead, cadmium, zinc, mercury or beryllium.
Transportation, lifting and suspension
• Neverpullorliftthemachinebytheweldingtorchorothercables.
Always use the lift points or handles designed for that purpose.
• Onlyuseatransportationplatformdesignedfortheequipment.
• Trytotransportthemachineinanuprightposition,ifpossible.
• Neverliftagascylinderandtheweldingmachineatthesametime.
There are separate provisions for gas cylinder transportation.
• Neveruseaweldingmachinewhensuspendedunlessthesuspension
device has been designed and approved for that particular purpose.
• Donotexceedthemaximumallowedloadofsuspensionboomsorthe
transportation trolley of welding equipment.
• Itisrecommendedthatthewirecoilberemovedduringliftingor
transportation.
Environment
• Theweldingpowersourceisnotsuitableforuseinrainorsnow,
although it can be used and stored outdoors. Protect the equipment
against rain and strong sunlight.
5
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
• Alwaysstorethemachineinadryandcleanspace.
• Protectthemachinefromsandanddustduringuseandinstorage.
• Therecommendedoperatingtemperaturerangeis-20to+40°C.The
machine’soperationeciencydecreasesanditbecomesmoreproneto
damageifusedintemperaturesinexcessof40°C.
• Placethemachinesothatitisnotexposedtohotsurfaces,sparksor
spatter.
• Makesuretheairowtoandfromthemachineisunrestricted.
• EMCclassicationofthisproductisclassAinaccordancewith
electromagneticcompatibilitystandardsCISPR11andIEC60974-10,and
therefore the product is designed to be used in industrial environment
only.
WARNING: This class A equipment is not intended for use in residential locations
where the electrical power is provided by a public low-voltage supply system. In
those locations it may be dicult to ensure the electromagnetic compatibility
due to conducted and radiated disturbances.
• Arcweldingequipmentalwayscauseelectromagneticdisturbance.
To minimize the harmful eects of this, use the equipment strictly
according to the operating manual and other recommendations.
Gas bottles and pneumatic devices
• Adheretotheinstructionsforhandlingpneumaticdevicesandgas
bottles.
• Makesurethatgasbottlesareusedandstoredinproperlyventilated
spaces.Aleakinggasbottlemayreplacetheoxygenintheinhaledair,
causing suocation.
• Beforeuse,makesurethatthegasbottlecontainsgassuitableforthe
intended purpose.
• Alwaysxthegascylindersecurelyinanuprightposition,againsta
cylinderwallrackorpurpose-madecylindercart.
• Nevermoveaprotectivegasbottlewhentheowadjusterisinplace.
Put the valve cover in place during transportation.
• Alwaysclosethegascylindervalveafteruse.
Disclaimer
While every eort has been made to ensure that the information contained
in this guide is accurate and complete, no liability can be accepted for any
errors or omissions. Kemppi reserves the right to change the specication of
the product described at any time without prior notice. Do not copy, record,
reproduce or transmit the contents of this guide without prior permission
from Kemppi.
6
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
1.3 PRODUCT INTRODUCTION
Kemppi Minarc is a manual metal arc welding machine, small in size, suitable
for industry, site and repair welding. The unit uses one phase connection
voltage and it is manufactured for two dierent mains voltages: 230 V (Minarc
150) and 110 V (Minarc 151).
MInarc 150VRD is equipped with so called Voltage Reduction Device (VRD)
function. VRD maintains open circuit voltage under 35 V.
Minarc 150AU and 120AU for mains voltages 240 V and with VRD function are
onmarketonlyforAustraliaandNewSealand.
Minarctoleratesagreatuctuationofinputvoltageandisthussuitable
for work on sites using generator as well as to be used with long power
cables. Inverter technology has been used when designing the unit. Power
regulation in power source is done with IGBT transistors. Welding and
earth cables are supplied with the unit. They are equipped with suitable
connections for the unit electrode holder, earth clamps and connections.
Minarc can also be used for TIG welding. TIG arc is started by scratching.
Ordering numbers of additional equipment for TIG welding can be found in
chapter 5. Ordering numbers.
2. BEFORE YOU START USING THE UNIT
2.1 UNPACKING
The equipment is packed in durable packages, designed specially for them.
Nevertheless,alwaysbeforeusingtheequipment,makesureitwasnotdamaged
during transportation. Also check that you have received what you ordered and
thatthereareinstructionsforit.NOTE!Thepackagingmaterialoftheproductsis
suitable for recycling.
7
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
2.2 PLACING THE UNIT
Place the unit on horizontal, solid and clean surface. Shield it from heavy rain and
scorching sun. Make sure that cooling air circulates freely.
2.3 SERIAL NUMBER
Serial number of the unit is marked on the rating plate of the unit. The serial
numbermakesitpossibletotraceproductmanufacturingseries.Youmight
need the serial number when placing spare parts orders or when planning
maintenance.
2.4 MAIN COMPONENTS
Connect welding cable and earth cable to their connections on the power source.
Mainscableandwallplugarealreadyinstalled.(Note!Minarc151(110V)is
delivered without a plug).
Parts of the unit
1. Body of machine
2. Main power switch
3. Selector switch for welding process
4. Welding current regulator
5.Signallightmachine'ON',(VRD:'VRDsafeON').
6. Signal light for overheating
7. Electrode holder and welding cable
8. Earth cable and clamp
8
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
1
2 3
4
5
678
2.5 CONNECTING TO POWER SUPPLY MAINS
Theunithasamainscableandawallplug(Note!Minarc151(110V)is
deliveredwithoutaplug).Youcanndfuseandcablesizesintheendof
these instructions in Technical data.
2.6 FILLER MATERIALS AND EQUIPMENT
Seealso2.4.Maincomponents.Youcanuseallelectrodesintendedfor
welding with DC. Suitable electrode sizes for the unit are listed in the end of
these instructions in Technical data.
1. Use welding specications given on electrode package.
2. Check that you have selected the correct welding process before starting
to weld.
3. Check that welding cable and earth cable connections are tight. If a
connection is slack, it will result in voltage drop that will cause the
connection to heat.
4. Mount the electrode rmly in holder.
9
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
3. USE
NOTE! It is forbidden to weld in places where there is a danger of re or
explosion!
3.1 WELDING PROCESSES
3.1.1 Manual Metal Arc welding (MMA)
In manual metal arc (MMA) the welding ller material is melted from the
electrode to the weld pool. Rate of welding current is selected on the basis of
electrode size used and welding position. Arc forms between electrode tip
and welding piece. The melting electrode coating forms gas and slag, which
protects the weld pool. Slag solidied over the weld is removed after welding
e.g. with a chipping hammer.
3.1.2 TIG welding
In DC TIG welding, the arc between tungsten electrode and the welding
piece melts the welding piece, thus forming a weld pool. Arc and electrode
are shielded by an inert shielding gas (Argon). If necessary, ller is used. Filler
wire is fed into the weld pool from the outside of the arc. The ller wire and
the welding current level are decided according to the base material type
and thickness, joint form and welding position.
3.2 OPERATING FUNCTIONS
See also 2.4. Main components and 3.4. Welding selections.
1.Signallight,machine'ON',(VRD:'VRDsafeON')
2. Welding process selecting switch
3. Welding current adjuster
4. Signal light for overheating
5. Suitable electrodes; reference values for welding current
6.S-mark(See1.2SafetyInstruction)
10
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
ON
ICS TM
A
10
20
40
60
80 100
120
140
M
I N A R C
ø 1,6 ø 2,0 ø 2,5 ø3,25
Fe-Rutile 30-60 40-80 50-110 80-140
Fe-Basic 30-55 50-80 80-110 110-140
1
3
2
4
5
6
Main switch and signal light
When you turn the main switch to position I, signal light is lit and the unit is
ready for welding. Signal light is always on, when the unit is connected to the
mains and the main switch is in position I.
NOTE! Always start and stop the machine from the main switch, never use the
plug as a switch!
Signal light VRD safe ON (1)
The machine is equipped with an OCV reduction circuit. The signal light is lit
when the circuit is activated and the unit is in working order.
Welding process selector, MMA / TIG
Switch is used for selecting either MMA or TIG welding, depending on
welding target.
VRD: When you have switched the unit to TIG welding, VRD is constantly
active,thusreducingterminalvoltageto30V.Thisfacilitatesarccut-owhen
you stop welding.
Regulating welding current
Welding current rate is regulated steplessly with an adjusting potentiometer.
Signal light for overheating
A yellow signal light of overheating is lit, when thermostat has tripped due
to the unit’s overheating. Fan will cool the unit and after the signal light goes
o, the unit is again ready for welding.
11
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
3.3 WELDING SELECTIONS
3.3.1 Manual Metal Arc welding (MMA)
Select welding parameters according to ller manufacturer’s
recommendations.
1. Selectpolarity(+or-)ofweldingcurrentcableandreturncurrentcable
according to ller.
2. Select MMA welding with the switch .
3. Select suitable welding current by adjusting potentiometer.
3.3.2 DC TIG welding
Select welding parameters according to ller manufacturer’s
recommendations.
1. ConnectTIGtorchto-poleandearthcableto+pole
2. Select TIG welding with the switch .
3. Select suitable welding current by adjusting potentiometer.
3.4 WELDING SELECTIONS
NOTE! Welding fumes may be dangerous to your health, see that there is ample
ventilation during welding! Never look at the arc without face shield made for arc
welding! Protect yourself and your surroundings from the arc and hot spatter!
3.4.1 Earthing
Ifpossible,alwaysxearthcableclampdirectlyontheweldingpiece.
1. Clean connection surface of earth clamp from paint and rust.
2. Connect the clamp carefully so that contact surface is as large as
possible.
3. Finally check that the clamp sits tight.
3.4.2 Welding
See also 3.1. Welding processes and 3.4. Welding selections.
NOTE! It is recommended that you try welding and rate of welding current rst
on something else than the actual work piece.
Youcanstartweldingafterhavingmadethenecessaryselections.Arcislit
by scratching the welding piece with electrode. Length of arc is regulated by
holding electrode tip at a suitable distance from welding piece. Suitable arc
length is usually about half the diameter of the electrode core wire. When
12
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
arcislitmovetheelectrodeslowlyforwardstiltingittoappr.10-15°pulling
angle. If necessary, adjust current value.
ShieldinggasisusedinDCTIGwelding.Yourdealerwillgiveyouadviceon
choosing gas and equipment. Open the gas valve on the TTM 15V TIG torch.
Whengasstartstoow,arcislitbylightlyscratchingworkpiecewiththetip
of the tungsten electrode. When arc is lit, its length is regulated by holding
the tip of the tungsten electrode at a suitable distance from the work piece.
Movethetorchforwardsfromthestartingpoint,usuallyinappr.10-15°
pushing angle forwards. If necessary, regulate current rate. Stop welding by
lifting the torch o the welding piece and by closing the gas valve on the
torch.
NOTE! Always x the gas cylinder so that it stays steadily in upright position
either in specially made wall rack or cylinder trolley. Always close the cylinder
valve after having nished welding.
3.5 STORING
Store the unit in a clean and dry place. Shield it from rain, and in
temperaturesexceeding+25°Cfromdirectexposuretosun.
4. MAINTENANCE
NOTE! Be careful when handling electrical cables!
In maintaining the unit, take into consideration the rate of use and the
environment it is used in. When the unit is used properly and serviced
regularly, you will avoid unnecessary disturbances in use and production.
4.1 DAILY MAINTENANCE
Perform the following maintenance daily:
• CleanelectrodeholderandTIGtorch’sgasnozzle.Replacedamagedor
worn parts.
• CheckTIGtorch’selectrode.Replaceorsharpen,ifnecessary.
• Checktightnessofweldingandearthcablesconnections.
• Checkconditionofmainsandweldingcablesandreplacedamaged
cables.
• Seethatthereisenoughspaceinfrontofandbackoftheunitfor
ventilation.
13
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
4.2 TROUBLESHOOTING
Problem Cause
The main switch indicator will not light up No electricity connected to the machine
• Check the mains supply fuses.
• Check the mains cable and plug.
Poor welding result Several factors aect the welding quality.
• Check that the earthing clamp is rmly attached, the point of
attachment is clean and that the cable and its connectors are
intact.
• Check that the shielding gas ows out of the torch tip.
• Check that the electric voltage is not irregular or too low/high.
Overheating indicator lit The device has overheated.
• Ensure that cooling air has unrestricted ow.
• If the machine’s duty cycle has been exceeded, wait for indicator
to turn o.
• Too low or high supply voltage.
If the machine’s malfunction is not eliminated with these measures, contact
KEMPPI service.
5. DISPOSAL
Donotdisposeofelectricalequipmentwithnormalwaste!
In observance of European Directive 2002/96/EC on waste electrical
and electronic equipment, and its implementation in accordance with
national law, electrical equipment that has reached the end of its life must
be collected separately and taken to an appropriate environmentally
responsible recycling facility.
The owner of the equipment is obliged to deliver a decommissioned unit
to a regional collection centre, per the instructions of local authorities
or a Kemppi representative. By applying this European Directive you will
improve the environment and human health.
14
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
6. ORDERING NUMBERS
Item Ordering number
Minarc 150 welding machine
(includes earth- and welding cables) 6102150
Minarc 150 welding machine (Denmark)
(includes earth- and welding cables) 6102150DK
Minarc 151 welding machine
(includes earth- and welding cables) 6101151
Minarc 120AU welding machine
(includes earth- and welding cables) 6102120AU
Minarc 150AU welding machine
(includes earth- and welding cables) 6102150AU
Minarc 150VRD welding machine
(includes earth- and welding cables) 6102150VRD
Earth cable and clamp 6184015
Welding cable and electrode holder 6184005
Carrying strap 9592162
Optional: TIG torch TTM15V, 4 m 6271432
7. TECHNICAL DATA
Minarc 150, 150 VRD Minarc 151
Mains voltage 1 ~ phase 50/60 Hz 230V ± 15 % 110V ± 15 %
Rated power
35 % ED MMA 140 A/7,5 kVA 140 A/7,5 kVA
100 % ED MMA 100 A/5,1 kVA 100 A/5,1 kVA
35 % ED TIG 150 A/5,0 kVA 150 A/5,0 kVA
100 % ED TIG 110 A/3,3 kVA 110 A/3,3 kVA
Primary current
35 % ED I1max 31 59
100 % ED I122 39
Connection cable H07RN-F, 3G2,5 (2,5 mm, 3 m) H07RN-F, 3G6 (6 mm, 2 m
Recommended fuse, slow 16 A 32 A
15
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
Welding range
MMA 10 A/20,5 V - 140 A/25,6 V 10 A/20,5 V - 140 A/25,6 V
TIG 5 A/10 V - 150 A/16 V 5 A/10 V - 150 A/16 V
Welding current control stepless stepless
Open-circuit voltage 85 V, (VRD 30 V) 85V
Idle power <10W <10 W
Power factor 0,60 0,60
Eciency 80 % 80 %
Electrode sizes to be welded, diameter Ø 1,5-3,25 mm Ø 1,5-3,25 mm
External dimensions
length 320 mm 320 mm
width 123 mm 123 mm
height with handle 265 mm 265 mm
Weight without connection cable 4,0 kg 4,4 kg
Weight with connection cable 4,6 kg 5,2 kg
Temperature class B (130 °C) B (130 °C)
Operating temperature range -20...+40°C -20...+40°C
Storage temperature range -40...+60°C -40...+60°C
Degree of protection IP23S IP23S
EMC class A A
Norms EN/IEC 60974-1 EN/IEC 60974-1
EN/IEC 60974-10 EN/IEC 60974-10
The products meet conformity requirements for CE marking.
Minarc 120AU Minarc 150AU
Mains voltage 1 ~ phase 50/60 Hz 240 V + 10 % ... - 20 % 240 V + 10 % ... - 20 %
Rated power
ED MMA 50 % 110 A/5,5 kVA 35 % 140 A/7,5 kVA
ED MMA 100 % 80 A/3,9 kVA 100 % 100 A/5,1 kVA
ED TIG 50 % 120 A/3,5 kVA 35 % 150 A/5,0 kVA
ED TIG 100 % 80 A/2,2 kVA 100 % 110 A/3,3 kVA
Primary current
35 % ED I1max 24 A 30
100 % ED I1e 17 22
Connection cable H07RN-F, 3G1,5 (1,5 mm, 3 m) H07RN-F, 3G6 (2,5 mm, 2 m
Recommended fuse, slow 10 A 15 A
16
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
Welding range
MMA 10 A/20,5 V - 110 A/24,4 V 10 A/20,5 V - 140 A/25,6 V
TIG 5 A/10 V - 120 A/15 V 5 A/10 V - 150 A/16 V
Welding current control stepless stepless
Open-circuit voltage 30V 30 V
Idle power <30W <30 W
Power factor 0,60 0,60
Eciency 80 % 80 %
Electrode sizes to be welded, diameter Ø 1,5-2,5 mm Ø 1,5-3,25 mm
External dimensions length 320 mm 320 mm
width 123 mm 123 mm
height with handle 265 mm 265 mm
Weight without connection cable 4,0 kg 4,0 kg
Weight with connection cable 4,6 kg 4,6 kg
Temperature class B (130 °C) B (130 °C)
Operating temperature range -20...+40°C -20...+40°C
Storage temperature range -40...+60°C -40...+60°C
Degree of protection IP23S IP23S
EMC class A A
Norms AS 1674.2 AS 1674.2
AS/NZS 3652 AS/NZS 3652
WTIA Tech note 22 WTIA Tech note 22
EN/IEC 60974-1 EN/IEC 60974-1
EN/IEC 60974-10 EN/IEC 60974-10
The products meet conformity requirements for CE marking.
17
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

EN
8. WARRANTY POLICY
Kemppi Oy provides a warranty for products manufactured and sold by the
company if defects in materials or workmanship occur. Warranty repairs are to
be carried out only by an authorised Kemppi Service Agent. Packing, shipping,
andinsuranceareattheorderer’sexpense.
The warranty starts on the date of purchase. Spoken promises not included in
the terms of warranty are not binding on the warrantor.
Limitations of the warranty
The following conditions are not covered under the terms of warranty:
defectsarisingfromnormalwearandtear,non-compliancewithoperation
and maintenance instructions, overloading, negligence, connection
to incorrect or faulty supply voltage (including voltage surges outside
equipment specications), incorrect gas pressure, anomalies or failures in
the electric network, transport or storage damage, and re or damage due to
forces of nature. This warranty does not cover direct or indirect travel costs,
daily allowances, or accommodation related to warranty service.
The warranty does not cover welding torches and their consumables, feeder
drive rolls,
and feeder guide tubes. Direct or indirect damage caused by a defective
product is not covered under the warranty.
The warranty becomes void if modications are made to the machine that
arenotapprovedbythemanufacturerorifnon-originalsparepartsareused
in repairs. The warranty is also voided if repairs are carried out by a repair
agent not authorised by Kemppi.
Undertaking warranty repairs
Warranty defects must be reported to Kemppi or an authorised Kemppi
Service Agent without delay.
Before a warranty repair is undertaken, the customer must present proof
of warranty or otherwise prove the validity of the warranty in writing. The
proof must indicate the date of purchase and the manufacturing number of
the unit to be repaired. The parts replaced under the terms of this warranty
remain the property of Kemppi and must be returned to Kemppi if requested.
After a warranty repair, the warranty of the machine or equipment, repaired
or replaced, shall be continued to the end of the original warranty period.
18
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901
