Kennedy KEN-594-4820K User manual

QUALI Y GUARAN EE & WARRAN Y
KENNEDY TOOLS carry a one year manufacturer’s warranty.
KENNEDY TOOLS are designed & manufactured
to the highest standards & specifications.
Assuring the quality and performance required by all sectors of industry.
KENNEDY TOOLS are fully guaranteed against
faulty materials & workmanship.
hould they be found to be defective, they will either be repaired or replaced
free of charge (fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
Lock Lock Link Draw lides Lid tays Castors ( et of 4) Draw Liner*
Cabinet/Chest
Order Code Order Code Order Code Order Code Order Code Order Code
Order Code
SP -567 SP -567 SP -567 SP -567 SP -567 SP -567
KEN- 594-4820K -1510K -7400K -7060K -4820K - -6610K
KEN- 594-4840K -1520K -7410K -7040K - -6920K -6610K
KEN- 594-4860K - 1510K -7400K -7060K -4860K - -6610K
KEN- 594-4880K - 1520K -7410K -7040K - -6920K -6610K
* Note: Draw liner size is 583 x 405mm and can be cut to size.
ROLLER CABINE & OOL CHES SPARES
KEN-594-4820K
KEN-594-4840K KEN-594-4880K
KEN-594-4860K
INS RUC ION MANUAL
ROLLER CABINE S
& OOL CHES S
Please retain this information for future reference.
ORDER CODES
KEN-594-4820K 4-DRAWER EX RA HEAVY DU Y OOL CHES - RED
KEN-594-4840K 7-DRAWER EX RA HEAVY DU Y ROLLER CABINE - RED
KEN-594-4860K 9-DRAWER X/LARGE EX RA HEAVY DU Y OOL CHES - RED
KEN-594-4880K 13-DRAWER X/LARGE EX RA HEAVY DU Y ROLLER CABINE - RED
Kennedy Tools continually strives to improve its products. pecifications may change without prior notice.
KENNEDY OOLS
Wigston, Leicester, England, LE18 2FS. www.kennedy-tools.co.uk
Kennedy is a registered trade mark of The Kennedy Group Ltd.
© The Kennedy Group Ltd. 03/18
HE ENVIRONMEN
Always dispose of unwanted tools, accessories and packaging materials in an environmentally
friendly manner.

Lid
Gas strut
Lock
Drawer
TO EMOVE D AWE S:
The ball bearing slides have black retaining
clips. To remove the drawer, the retaining clips
need to be released by pushing the lever up
(right hand side of the drawer) and down (left
hand side of the drawer) simultaneously and
pulling the drawer out. ee Fig. 1
TO EINSTALL D AWE S:
Pull the slides out and insert a slide on to each
side of the drawer. Push the drawer gently in
until it is completely inserted. The retaining clips
will now be in place. Pull the drawer fully out to
check that it will be held.
CASTO S:
The roller cabinet is fitted with four heavy duty
castors consisting of two swivel castors with
brakes and two fixed castors. If you need to
replace a castor, the bottom drawer will need to
be removed t o e n able the scr e w a nd nut
assembly to be assembled.
SIDE HANDLE:
The side handle can be fitted either side of the
cabinet but must be fixed on the same side as
the swivel castors.
ASSEMBLY/MAIN ENANCE
• Read, study and understand all warnings and operating instructions before use.
•DO NOT alter the product in any way.
•DO NOT weld lock bars or dollies onto the unit.
•DO NOT mount the roller cabinet or tool chest onto any moving object such as a
truck, van or lorry etc.
LOADING:
•DO NOT load from the top drawer first.
•DO NOT drop tools into the drawers.
•DO NOT completely fill only one drawer.
•DO NOT load a drawer from the front.
• The maximum product weight, including contents must
not exceed 400kg.
USE:
•DO NOT open more than one loaded drawer at a time.
• Apply brakes on swivel castors when not moving unit.
•DO NOT stand on this product.
•DO NOT slam the drawers shut.
MOVEMENT:
• Close the lid and lock drawers before moving.
• DO NOT pull. Push to move.
• Keep the product on a level surface.
•DO NOT tow with power equipment.
KENNEDY oller cabinets and tool chests are designed to help you work safely and
efficiently. Storage equipment can be dangerous if the correct operating procedures are not
followed. Safety procedures and assembly instructions are as follows:
SAFE Y GUIDELINES
3
7
Drawer afety Catches
Heavy Duty Gas trut
Heavy Duty Cabinet Handle
Heavy Duty Chest Handles
Heavy Duty Castors
Ball Bearing Drawer lides
FEA URES
Fig. 1
LUB ICATION:
Lubricate the top and the bottom channels of
the drawer slides at least twice a year with oil.
lide
Chest handle
Flange bolts (4) per handle
Cabinet handle
ocket head cap screws
(2) per handle
Castors (2 swivel & 2 fixed)*
Flat washers (4) per castor
pring washers (4) per castor
Hex head bolts (4) per castor
* Make sure that the handle
is fitted on the same side
as the swivel castors.
