Kennedy KEN-594-4825K User manual

QUALITY GUARANTEE & WARRANTY
KENNEDY TOOLS carry a one year manufacturer’s warranty.
KENNEDY TOOLS are designed & manufactured
to the highest standards & specifications.
Assuring the quality and performance required by all sectors of industry.
KENNEDY TOOLS are fully guaranteed against
faulty materials & workmanship.
Should they be found to be defective, they will either be repaired or replaced
free of charge (fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
ROLLER CABINET & TOOL CHEST SPARES
KEN-594-4865K
KEN-594-4825K KEN-594-4845K
KEN-594-4885K
INSTRUCTION MANUAL
ROLLER CABINETS
& TOOL CHESTS
Please retain this information for future reference.
ORDER CODE
KEN-594-4825K 3-DRAWER EXTRA HEAVY DUTY TOOL CHEST - RED
KEN-594-4845K 7-DRAWER EXTRA HEAVY DUTY CABINET - RED
KEN-594-4865K 6-DRAWER X/LARGE EXTRA DUTY TOOL CHEST - RED
KEN-594-4885K 10-DRAWER X/LARGE EXTRA DUTY CABINET - RED
Kennedy Tools continually strives to improve its products. Specifications may change without prior notice.
KENNEDY TOOLS
P.O. Box 14, Wigston, Leicester, England, LE18 1AT.
THE ENVIRONMENT
Always dispose of unwanted tools, accessories and packaging materials in an environmentally
friendly manner.
KEN-594-4845K
KEN-594-4865K
KEN-594-4885K
KEN-594-4825K
Cabinet/Chest
Order Code
Order
Code
Order
Code
Order
Code
Order Code Order Code Order CodeOrder
Code
Order
Code
Lock Lock
Line
Lock
Line
Draw Slides Lid Stays Directional
casters
Universal
casters
with brake
Armrest
SPR-567-9501K
SPR-567-9501K
SPR-567-9504K
SPR-567-9504K
SPR-567-9506K
SPR-567-9506K SPR-567-9520K
SPR-567-9506K
SPR-567-9506K
SPR-567-9505K
SPR-567-9505K
SPR-567-9502K
SPR-567-9502K
SPR-567-9503K
SPR-567-9506K SPR-567-9509K
SPR-567-9509K
SPR-567-9507K SPR-567-9508K
SPR-567-9508K
KEN-594-4825K_4885K_Instructions.indd 1KEN-594-4825K_4885K_Instructions.indd 1 04/09/2020 11:1104/09/2020 11:11

TO REMOVE DRAWERS:
The ball bearing slides have black retaining
clips. To remove the drawer, the retaining clips
need to be released by pushing the lever up
(right hand side of the drawer) and down (left
hand side of the drawer) simultaneously and
pulling the drawer out. See Fig. 1
TO REINSTALL DRAWERS:
Pull the slides out and insert a slide on to each
side of the drawer. Push the drawer gently in
until it is completely inserted. The retaining clips
will now be in place. Pull the drawer fully out to
check that it will be held.
CASTORS:
The roller cabinet is fitted with four heavy duty
castors consisting of two swivel castors with
brakes and two fixed castors. If you need to
replace a castor, the bottom drawer will need
to be removed to enable the screw and nut
assembly to be assembled.
SIDE HANDLE:
The side handle can be fitted either side of the
cabinet but must be fixed on the same side as
the swivel castors.
• Read, study and understand all warnings and operating instructions before use.
• DO NOT alter the product in any way.
• DO NOT weld lock bars or dollies onto the unit.
• DO NOT mount the roller cabinet or tool chest onto any moving object such as a
truck, van or lorry etc.
LOADING:
• DO NOT load from the top drawer first.
• DO NOT drop tools into the drawers.
• DO NOT completely fill only one drawer.
• DO NOT load a drawer from the front.
• The maximum product weight, including contents must
not exceed 400kg.
USE:
• DO NOT open more than one loaded drawer at a time.
• Apply brakes on swivel castors when not moving unit.
• DO NOT stand on this product.
• DO NOT slam the drawers shut.
MOVEMENT:
• Close the lid and lock drawers before moving.
• DO NOT pull. Push to move.
• Keep the product on a level surface.
• DO NOT tow with power equipment.
KENNEDY Roller cabinets and tool chests are designed to help you work safely and
efficiently. Storage equipment can be dangerous if the correct operating procedures are not
followed. Safety procedures and assembly instructions are as follows:
SAFETY GUIDELINES
3
7
Drawer Safety Catches
Heavy Duty Gas Strut
Heavy Duty Cabinet Handle
Heavy Duty Chest Handles
Heavy Duty Castors
Ball Bearing Drawer Slides
Fig. 1
LUBRICATION:
Lubricate the top and the bottom channels of
the drawer slides at least twice a year with oil.
FEATURES
ASSEMBLY/MAINTENANCE
side handle
heavy duty side handle
M6*12 bolt 4pcs
cap 8pcs
ST5.5*18 screw 8pcs
bumper 4pcs
5*2 swivel caster with brake 2pcs
M8*20 bolt 16pcs
ball bearing slides
5*2 fixed caster 2pcs
drawer
gap strut
lid
KEN-594-4825K_4885K_Instructions.indd 2KEN-594-4825K_4885K_Instructions.indd 2 04/09/2020 11:1104/09/2020 11:11
