Kenwood MULTIPRO COMPACT User manual

TYPE: FDP30
instructions
istruzioni
instrucciones
Bedienungsanleitungen
gebruiksaanwijzing
Instrukcja obsługi
instruções

English 2 - 10
Nederlands 11 - 20
Français 21 - 30
Deutsch 31 - 40
Italiano 41 - 50
Português 51 - 60
Español 61 - 70
Dansk 71 - 79
Svenska 80 - 88
Norsk 89 - 97
Suomi 98 - 106
Türkçe 107 - 115
Česky 116 - 124
Magyar 125 - 134
Polski 135 - 145
Eλληνικά 146 - 156
Slovenčina 157 - 166
Українська 167 - 177
ÝY
ovt – ouv

1
2
3
1
6
5
4
11
12
13
14
15
2
3
4
5
6
9
7
8
16
17
18
a
b
c
d
e
10 Plastic blender
A - standard
attachments
B - optional
attachments

11/12 14/15
13

b
a
b
a
c
a
b
16 17
19
18

007
Safety
O
Read these instructions carefully and retain for future reference.
ORemove all packaging and any labels.
OIf the plug or cord is damaged it must, for safety reasons, be
replaced by Kenwood or an authorised Kenwood repairer in
order to avoid a hazard.
ODO NOT touch the sharp blades. The blades and discs are
very sharp, handle with care. Always hold by the finger grip
at the top, away from the cutting edge, when handling
the sharp cutting blades, emptying the bowl and during
cleaning.
ODO NOT process hot ingredients.
OBe careful if hot liquid is poured into the food processor
or blender as it can be ejected out of the appliance due to
sudden steaming.
ONever leave the appliance unattended when it is operating.
ODo not exceed the maximum capacities stated in the
recommended usage chart.
ODo not operate your appliance for longer than the
times specified below without a rest period. Processing
continuously for longer periods can damage your appliance.
Function/Attachment Maximum
Operation Time Rest Period Between
Operations
Blender 60 secs Unplug the
appliance and
allow to cool
down for 15
minutes
Heavy mixtures in the
bowl (e.g. Dough) 60 secs
Mini Chopper/Mill 30 secs
Grinding Mill 60 secs
ODo not lift or carry the processor by the handle - or the handle
may break resulting in injury.
OAlways remove the knife blade before pouring contents from
the bowl.
OKeep hands and utensils out of the processor bowl and
blender goblet whilst connected to the power supply. If food
needs to be pushed down use a suitable utensil such as a
spatula.
OAlways switch off the appliance and disconnect from
the supply if it is left unattended and before assembling,
disassembling or cleaning.
ONever use your fingers to push food down the feed tube.
Always use the pusher supplied.
ONever fit the blade assembly to the power unit without the
goblet or mill jar/lid fitted.
OCAUTION: Before removing the lid from the bowl, blender or
mill from the power unit:
2
English

3
O
switch off;
O
wait until the attachment/blades have completely stopped;
O
be careful not to unscrew the blender goblet or mini
chopper/mill jar from the blade assembly.
ODo not use the lid to operate the processor, always use the
on/off speed control.
OThis appliance will be damaged and may cause injury if the
interlock mechanism is subjected to excessive force.
ONever use an unauthorised attachment.
ONever use a damaged appliance. Get it checked or repaired:
see ‘Service and customer care’.
ONever let the power unit, cord or plug get wet.
ODo not let excess cord hang over the edge of a table or
worktop or touch hot surfaces.
OChildren should be supervised to ensure that they do not play
with the appliance.
OThis appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
OAppliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved.
OOnly use the appliance for its intended domestic use.
Kenwood will not accept any liability if the appliance is subject
to improper use, or failure to comply with these instructions.
OMisuse of your processor, blender or mill can result in injury.
OThe maximum rating is based on the mini chopper/mill
attachment that draws the greatest load. Other attachments
may draw less power.
Blender
O DO NOT process hot ingredients.
O SCALD RISK: Hot ingredients must be allowed to cool to
room temperature before placing in the goblet or before
blending.
O Always take care when handling the blade assembly and avoid
touching the cutting edge of the blades when cleaning.
O Only operate the blender with the lid in place.
O Only use the goblet with the blade assembly supplied.
O Never run the blender empty.
O Smoothie recipes - never blend frozen ingredients that have
formed a solid mass during freezing, break it up before adding
to the goblet.
Mill Attachments
O Never fit the blade assembly to the power unit without the jar/
lid fitted.
O Never unscrew the jar/lid while the mill is fitted to your
appliance.

4
O Do not touch the sharp blades – Keep the blade assembly
away from children.
O Never remove the mill until the blades have completely
stopped.
O The appliance will not work if the mill is incorrectly fitted.
O Do not process hot ingredients in the mill allow to cool down
to room temperature before processing.
Mini Chopper/Mill
O The processing of spices is not recommended as they may
damage the plastic parts.
Grinding Mill
O Do not process dried turmeric root as it is too hard and may
damage the blades.
Slicing/Grating Discs
O The discs are very sharp; handle with care when fitting,
removing and cleaning.
O Always hold by the finger grip away from the cutting edge
when handling the sharp cutting blades, emptying the bowl
and during cleaning.
O Never use your fingers to push food down the feed tube. Only
use the pusher supplied.
O Before removing the lid, switch off wait until the cutting disc
has completely stopped.
Cleaning
O Wipe the power unit with a damp cloth, then dry. Ensure that
the interlock area is clear of food debris.
O Do not immerse the power unit or blade assemblies in water.
O The bowl, lid, pusher and all attachments/tools apart from
the blade assemblies are suitable for both handwashing and
dishwashing.
O The blade assemblies should be brushed clean and rinsed
under running water.
Before plugging in
O Make sure your electricity supply is the same as the one shown on the underside of your appliance.
O This appliance conforms to EC Regulation 1935/2004 on materials and articles intended to come into
contact with food.
Before using for the first time
1 Remove the plastic blade covers from the knife blade. Take care the blades are very sharp. These
covers should be discarded as they are to protect the blade during manufacture and transit only.
2 Wash the parts see ‘Care and Cleaning’.

5
Key
Processor
1Pusher
2Feed tube
3Lid
4Bowl
5Detachable drive shaft
6Power unit
7Speed/pulse control
8Safety interlocks
9Cord storage (at back)
Attachments
Not all of the attachments listed below may be
included with your food processor. Attachments
are dependent upon the model variant. Visit
www.kenwoodworld.com for information on how
to buy an attachment not included in pack.
10 Plastic Blender (if supplied)
aBlade assembly
bSealing ring
cGoblet
dFiller cap
eLid
AStandard Attachments
11 Knife blade
12 Dough tool
13 Emulsifying disc
14 Slicing/grating disc
15 Slicing/grating disc (if supplied)
BOptional Attachments
16 Citrus juicer (if supplied)
17 Plastic mini chopper/mill (if supplied)
18 Grinding mill (if supplied)
To Use Your Food Processor
Illustrations – 
1 Fit the detachable drive shaft onto the power
unit.
2 Then fit the bowl by aligning the on the
bowl with the on the power unit, turn
clockwise until it locks .
3 Fit an attachment over the bowl drive shaft.
OAlways fit the bowl and attachment onto the
processor before adding ingredients.
4 Fit the lid - ensuring the top of the drive
shaft/tool locates into the centre of the lid.
ODo not use the lid to operate the processor,
always use the on/off speed control.
5 Plug in, switch on and select a speed. (Refer
to the recommended usage chart).
OThe processor will not operate if the bowl
or lid are not fitted correctly into the
interlock. Check that the feed tube and
bowl handle are situated to the right front
hand corner.
OUse the pulse (P) for short bursts. The pulse
will operate for as long as the control is held
in position.
6 Reverse the above procedure to remove the
lid, attachments and bowl.
OAlways switch off and unplug before
removing the lid.
Important
OYour processor is not suitable for crushing
or grinding coffee beans, or converting
granulated sugar to caster sugar.
OWhen adding almond essence or flavouring
to mixtures avoid contact with the plastic as
this may result in permanent marking.
Using The Attachments
Refer to recommended usage chart
for each attachment.
10 Plastic Blender (if supplied)
To Use Your Blender
Illustrations – 
1 Fit the sealing ring into the blade
assembly - ensuring the seal is located
correctly in the grooved area.
OLeaking will occur if the seal is damaged or
incorrectly fitted.
2 Hold the underside of the blade assembly
and insert the blades into the goblet - turn
anti-clockwise until it is secure. Refer to
the graphics on the underside of the blade
assembly as follows:
- Unlocked position
- Locked position
3 Put your ingredients into the goblet.
4 Fit the lid onto the goblet and turn clockwise
until it clicks. Fit the filler cap.
5 Place the blender onto the power unit, align
the on the blender with the on the
power unit and turn clockwise to lock .
OThe appliance will not operate if the blender
is incorrectly fitted to the interlock.
Hints and Tips
OWhen making mayonnaise, put all the
ingredients, except the oil, into the blender.
Remove the filler cap. Then, with the
appliance running, add the oil slowly through
the hole in the lid.

6
OThick mixtures, e.g. pâtés and dips, may need
scraping down. If the mixture is difficult to
process, add more liquid.
OThe processing of spices is not
recommended as they may damage the
plastic parts.
OTo blend dry ingredients - cut into pieces,
remove the filler cap, then with the appliance
running, drop the pieces down one by one.
Keep your hand over the opening. For best
results empty regularly.
11 Knife Blade
Follow the instructions under ‘to use your food
processor’.
Hints and Tips
OFor coarser textures use the pulse control.
OCut food such as meat, bread, vegetables
into cubes approximately 2cm.
OBiscuits should be broken into pieces
and added down the feed tube whilst the
appliance is running.
OTake care not to over-process.
OWhen making pastry use fat straight from
the fridge cut into 2cm cubes.
OFor best results when processing sticky
fruit/ingredients such as dates, use 'Pulse'
first to break down the ingredients and then
continue processing on maximum speed.
12 Dough Tool
Use for yeasted dough mixes.
Follow the instructions under ‘to use your food
processor’.
Hints and Tips
ODo not process for longer than 60 seconds.
OPlace the dry ingredients in the bowl and
add the liquid down the feed tube whilst the
appliance is running. Process until a smooth
elastic ball of dough is formed.
ORe-knead by hand only. Re-kneading in the
bowl is not recommended as it may cause the
processor to become unstable.
13 Emulsifying Disc
Follow the instructions under ‘to use your food
processor’.
Hints and Tips
OEnsure the bowl and tool are clean and free
from grease before use.
OMayonnaise - Place the egg and seasonings
into the bowl and mix for a few seconds.
With the machine running gradually add the
oil down the feed tube in a steady stream.
14 – 15 Discs
To Use The Cutting Discs
1 Fit the drive shaft and bowl onto the power
unit.
2 Holding by the centre grip, place the disc
onto the drive shaft with the appropriate side
uppermost.
3 Fit the lid.
4 Put the food in the feed tube.
5 Switch on and push down evenly with the
pusher 1- never put your fingers in the
feed tube.
Hints and Tips
OUse fresh ingredients
ODo not cut food too small. Fill the width
of the feed tube fairly full. This prevents
the food from slipping sideways during
processing.
OWhen slicing or grating: food placed
upright comes out shorter than food placed
horizontally.
OThere will always be a small amount of waste
on the disc or in the bowl after processing.
16 Citrus Juicer (if supplied)
aCone
bSieve
To use the citrus juicer
1 Fit the drive shaft and bowl onto the power
unit.
2 Fit the sieve into the bowl - ensuring the sieve
handle is locked into position directly over
the bowl handle.
3 Place the cone over the drive shaft turning
until it drops all the way down.
4 Cut the fruit in half. Then switch on and press
the fruit onto the cone.
OThe citrus juicer will not operate if the sieve
is not locked correctly.
Hints and Tips
OFor best results store and juice the fruit
at room temperature and hand roll on a
worktop before juicing.
OTo help with juice extraction move the fruit
from side to side when juicing.
OWhen juicing large quantities, empty the
sieve regularly to prevent the build up of
pulp and seeds.

7
17 Mini Chopper/Mill (if supplied)
aJar
bSealing ring
cBlade assembly
1Put the ingredients into the jar.
2Fit the sealing ring into the blade assembly.
3Turn the blade assembly upside down. Lower
it into the jar, blades down.
4Screw the blade assembly onto the jar until
finger tight. Refer to the graphics on the
underside of the blade assembly as follows:
- Unlocked position
- Locked position
5Place the mill onto the power unit and turn
clockwise to lock in position.
6Select Maximum speed or use the pulse (P).
Hints and Tips
OBaby food/purée - allow cooked food to
cool down to room temperature before
processing in the mill.
OFor best results the main bowl is
recommended when chopping herbs.
18 Grinding Mill (if supplied)
aMill lid
bGrinding mill blade assembly
1 Place your ingredients into the blade
assembly.
2 Fit the lid and turn clockwise to lock.
3 Place the mill onto the power unit and turn
clockwise to lock.
4 Select maximum speed or use the pulse (P).
Hints and Tips
OFor optimum performance when processing
spices do not process more than 50g at a
time.
OWhole spices retain their flavour for a much
longer time than ground spices so it is best
to grind a small quantity fresh at a time to
retain the flavour.
OTo release the maximum flavour and
essential oils whole spices are best roasted
prior to milling.
ODo not process dried turmeric root in the mill
as it is too hard and may damage the blades.
OCut ginger and coconut into small pieces
before processing.
OFor best results the main bowl is
recommended when chopping herbs.
Care and Cleaning
O
Always switch off and unplug before cleaning.
OHandle the blade and cutting discs with care
- they are extremely sharp.
OSome foods may discolour the plastic. This is
perfectly normal and will not harm the plastic
or affect the flavour of your food. Rub with a
cloth dipped in vegetable oil to remove the
discolouration.
Power Unit
OWipe with a damp cloth, then dry. Ensure
that
the interlock area

is clear of food debris.
ODo not immerse the power unit in water.
OStore excess cord in the storage area at the
back of the power unit .
Cleaning Instructions - Refer
to the relevant illustration 19 .
Service and Customer Care
OIf you experience any problems with the
operation of your appliance, before requesting
assistance refer to the ‘Troubleshooting
Guide’ section in the manual or visit
www.kenwoodworld.com.
OPlease note that your product is covered
by a warranty, which complies with all legal
provisions concerning any existing warranty
and consumer rights in the country where the
product was purchased.
OIf your Kenwood product malfunctions or you
find any defects, please send it or bring it to
an authorised KENWOOD Service Centre.
To find up to date details of your nearest
authorised KENWOOD Service centre visit
www.kenwoodworld.com or the website
specific to your Country.
ODesigned and engineered by Kenwood in the
UK.
OMade in China.
IMPORTANT INFORMATION FOR CORRECT
DISPOSAL OF THE PRODUCT IN ACCORDANCE
WITH THE EUROPEAN DIRECTIVE ON WASTE
ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE)
At the end of its working life, the product must
not be disposed of as urban waste. It must be
taken to a special local authority differentiated
waste collection centre or to a dealer providing
this service.

8
Recommended Usage Chart
Do not operate your appliance for longer than the times specified below without a rest period.
Do not exceed the maximum capacities stated in the chart below.
Processing continuously for longer periods can damage your appliance.
Processing information supplied is for guidance only and will vary depending on the exact recipe and
ingredients being processed.
Do not process hot ingredients
Tool/
Attachment
Function
(Secs)
All in one cake mixes 2 10 1.2kg total
weight
Pastry - rubbing fat into flour
Adding water to combine pastry
ingredients
2
1 – 2
10
10 – 20
300g flour
weight
Chopping fish and lean meat
Pâtés and terrines
2 10 – 30 400g max
lean beef
Chopping vegetables Pulse 5 – 10 100
– 250g
Chopping nuts 2 30 – 60
100g – 200g
Herbs 2 20 – 30 30 – 50g
Pureeing soft fruit, cooked fruit and
vegetables
2 10 – 30 500g
Blending in the bowl
Do not process hot ingredients.
Do not exceed the maximum mark on the bowl.
Thick soup mixes (450ml liquid to 750g
ingredients)
Process vegetables with 200ml water
until finely chopped.
Add the remaining water until
incorporated.
1 – 2
1
30 – 60
5
1.2 litre
Thin soup mixes (500ml liquid to 500g
ingredients) Start on 1 and
increase to 2
30 – 60 1 litre
Milk and liquid recipes 15 – 30 500 ml
Mayonnaise 2 60 – 80 4 egg yolks
Whipping cream (Processing times may
vary, depending on fat content of cream)
1 15 – 20 250ml
Yeasted mixes 2 60 340g flour
weight
550g total
weight
Grating and slicing firm food items -
cheese, carrots, potatoes and foods of a
similar texture
2–
Do not fill
above the
maximum 1.2L
marked on
the bowl
Slicing softer food items - cucumbers and
tomatoes
1–
Use to squeeze the juice from citrus fruits
e.g.oranges, lemons, limes and grapefruits.
1––

9
Recommended Usage Chart
Tool/
Attachment
Function
(Secs)
Cold liquids and drinks
(Add ice/frozen ingredients to goblet
last)
230 – 60
1.2 litre
Milkshake/Cold milk based mixtures 2 15 – 30 1 litre
Ice crushing Pulse 30 – 40 6 ice cubes
(125g)
Batter mix
(Add liquid ingredients first)
1
2
10
50
1 litre
Nuts 2 10 – 30 50g
Coee beans 2 30 50g
Uncooked meat (beef steak) cut into 2cm
cubes
2 5 100g
Processing spices
Black peppercorns, cardamom seeds,
cumin seeds, coriander seeds and fennel
seeds
2
30 – 60
50g
Grinding coee beans 2 50g
Chopping nuts Pulse – 50g
Processing garlic cloves, fresh chillies and
root ginger
Pulse – 30g
Fresh coconut 2/Pulse 30 – 60 40g

10
Troubleshooting Guide
Problem Cause Solution
The processor will not
operate.
No Power.
Bowl not fitted to power
unit correctly.
Bowl lid not locked on
correctly.
Check processor is plugged in.
Check bowl is located correctly and the
handle is situated towards the right front
hand corner.
Check that the lid interlock is located
correctly into the handle area.
The processor will not work if the bowl
and lid are fitted incorrectly.
If none of the above check the fuse/circuit
breaker in your home.
Detachable drive shaft 
not fitted to power unit.
Fit the detachable drive shaft onto the
power unit before fitting the bowl. The
bowl tools and attachments will not operate
unless the drive shaft is fitted.
Blender or mill will not
operate
Blender or mill not locked on
correctly.
Blender or mill not
assembled correctly.
Blender or mill will not operate if fitted
incorrectly to the interlock.
Check blade assembly is fully tightened into
the goblet/jar
Processor stops during
processing
Processor overloaded/
maximum capacities
exceeded.
Lid unlocked.
Check maximum capacities stated in the
recommended usage chart.
Check lid is locked correctly.
Blender or multi mill
leaking from blade
assembly base.
Seal missing
Seal incorrectly fitted
Seal damaged.
Check seal is fitted correctly and not
damaged. To obtain a replacement seal see
‘Service and customer care’.
Unit unstable/heavy
vibrations and movement.
Sticky fruit/ingredients such
as dates being processed.
Speed selected too low.
For best results use 'Pulse' first to break
down the ingredients and then continue
processing on maximum speed.
Poor performance of
tools/attachments
Refer to hints in relevant ‘Using the attachment’ section. Check
attachments are assembled correctly.
