Kenwood TYPE FGP20 Quick guide

TYPE FGP20
instructions and recipe ideas

English 2 - 10
´¸∂w
11 - 91

7
9
1
2
3
4
5
6
8
1

safety
lRead these instructions carefully and retain for future
reference.
lRemove all packaging and any labels including the protective
film from the cutting blades.
lIf the cord is damaged it must, for safety reasons, be
replaced by KENWOOD or an authorised KENWOOD
repairer.
lTake care the cone blades and end of the pusher
blade are very sharp, handle with care.
lSwitch off and wait until the blades have completely stopped
before removing the lid.
lSwitch off and unplug:
before fitting or removing parts;
when not in use;
before cleaning.
lNever use your fingers to push food down the feed tube.
Always use the pusher supplied.
lNever use a damaged appliance. Get it checked or repaired:
see ‘service and customer care’.
lNever let the power unit, cord or plug get wet.
lDo not let excess cord hang over the edge of a table or
worktop or touch hot surfaces.
lNever leave the appliance on unattended.
lMisuse of your appliance can result in injury.
lNever use an unauthorised attachment.
lAppliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved.
lChildren should be supervised to ensure that they do not play
with the appliance.
2

lThis appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
lOnly use the appliance for its intended domestic use.
Kenwood will not accept any liability if the appliance is subject
to improper use, or failure to comply with these instructions.
3
before plugging in
•Make sure your electricity supply is
the same as the one shown on the
underside of the appliance.
Important - UK only
•The wires in the cord are coloured as
follows:
Blue = Neutral
Brown = Live.
•The appliance must be protected by a
3A approved (BS1362) fuse.
Note:
•For non-rewireable plugs the fuse
cover MUST be refitted when replacing
the fuse. If the fuse cover is lost then
the plug must not be used until a
replacement can be obtained. The
correct fuse cover is identified by colour
and a replacement may be obtained
from your Kenwood Authorised Repairer
(see Service).
•If a non-rewireable plug is cut off it
must be DESTROYED IMMEDIATELY.
An electric shock hazard may arise if
an unwanted non-rewireable plug is
inadvertently inserted into a 13A socket
outlet.
•This appliance conforms to EC
Regulation 1935/2004 on materials and
articles intended to come into contact
with food.
before using for the first time
Wash the parts: see ‘care and cleaning’.
key
1pusher with support blade
2lid with feed tube
3cutting cone
Actual cones in pack may vary. Optional
cones available include:
Spaghetti (2 X 2mm)
Linguine (2 X 4mm)
Tagliatelle (2 X 9mm)
Flat blade (Pappardelle) - width
of ribbon determined by width of
food
4cone holder
5power unit
6On/Off switch
7container
8container platform
9cord storage
•Refer to the “service and customer
care” section to obtain additional cutting
cones.
to assemble your
spiralizer
1 Insert the cone holder 4.
2 Fit the desired cutting cone 3. The lid
cannot be fitted if the cone holder or
cone are not located correctly. Ensure
that the cone sits flush with the holder.
3 Fit the lid and align the on the lid with
the on the body. Turn clockwise
until the aligns with the 1.
4 Place the container under the cutting
cone.

5 Cut the foods to fit the feed tube and
attach to the blade on the end of the
pusher.
6 Place the pusher in the food tube
ensuring the groove on the pusher
aligns with the rib in the feed tube.
7 Switch on and hold the pusher in
position to guide the food down the
feed tube.
hints & tips
•Use spiralized vegetables to replace
pasta and noodles.
•Use firm fruits and vegetables without
stones, seeds or hollow centres.
•Do not use soft, juicy or overripe foods
as they will fall apart when spiralized.
•Many important vitamins and nutrients
are found in the skin of fruit and
vegetables, so only remove if inedible.
•Select vegetables that are as straight as
possible.
•Cut the end of the food to create a flat
surface to ensure it can be attached to
the end of the pusher. Uneven ends will
make it difficult to secure to the end of
the pusher causing poor results.
•Ensure that the diameter of the food
is more than 5 cm so that it can be
attached securely to the end of the
pusher.
•You will be left with a cone shaped end
pieces at the end of spiralizing. These
pieces can be sliced and used.
•Lightly steam, blanch, boil or stir fry the
spiralized food.
4
Food item Preparation Comments
Apples • Use small apples (diameter to fit
feed tube).
• Trim end so flat.
• No need to core or remove
seeds as core will be retained on
end of pusher.
• Spiralized apple will turn brown
quickly so use immediately or
add lemon juice.
• Use in salads and dessert
recipes.
Beetroot • Remove leaves.
• No need to peel fresh beetroot,
just wash the skin before
spiralizing.
• Cooked beetroot is too soft and
will not spiralize well.
• Eat raw in salads.
Broccoli Stems • Trim the stems. • When cooking broccoli save the
stems and spiralize them.
Carrots • Choose large straight carrot and
trim ends flat.
• Lightly steam, blanched, boil or
stir fry.
Celeriac • Peel and cut to fit the feed tube.
Courgettes • Choose large straight courgettes
and cut off the top and bottom
ends.
Parsnip • Choose large straight parsnips
and cut off the top and bottom
ends.

5
Food item Preparation Comments
Swede/Turnip • Peel and cut to fit the feed tube. • Lightly steam, blanched, boil or
stir fry.
Butternut Squash • Use the non bulbous end
without the hollow centre and
seeds.
• Peel and cut to fit the feed tube.
Kohlrabi • Peel and trim to fit the feed tube.
Daikon Radish or
Mooli
• Peel and trim to fit the feed tube. • Good alternative to rice.
Jerusalem
Artichokes
• Wash and trim to fit the feed
tube.
• Place in water with a small
amount of lemon juice straight
after processing to prevent
discolouration.
Pears • Choose firm small pears.
• Cut to fit the feed tube.
• Spiralized pear will turn brown
quickly so use immediately or
add lemon juice.
• Use in salads and dessert
recipes.
Sweet Potato/
Potato
• Wash the skins.
• Cut to fit the feed tube
• Place in water straight after
processing to stop the strands
discolouring.
care and cleaning
• Always switch off and unplug before
cleaning.
• Handle the cone blades and pusher
blade with care - they are extremely
sharp. Use a brush to clean the blades.
• Some foods may discolour the plastic.
This is perfectly normal and will not
harm the plastic or affect the flavour of
your food. Rubbing with a cloth dipped
in vegetable oil may help remove the
discolouration.
• Store the cones in the container after
use.
power unit
• Wipe with a damp cloth, then dry.
• Do not immerse the power unit in water.
• Push excess cord into the back 9of the
power unit.
• Wash the removable parts by hand, then
dry.
• Alternatively they can be washed in your
dishwasher.
service and customer
care
•If you experience any problems
with the operation of the
appliance, before calling
for assistance refer to the
troubleshooting guide or visit
www.kenwoodworld.com.
UK
If you need help with:
•using your appliance
•servicing or repairs

Zcall Kenwood Customer Care on 023
9239 2333.
Have your model
number (e.g. TYPE FPG20) and
date code (5 digit code e.g.
13L35) ready. They are on the
underside of the power unit.
•spares and attachments
Z call 0844 557 3653.
other countries
• If you experience any problems with
the operation of your appliance,
before requesting assistance refer
to the “troubleshooting guide”
section in the manual or visit
www.kenwoodworld.com.
• Please note that your product is
covered by a warranty, which complies
with all legal provisions concerning any
existing warranty and consumer rights
in the country where the product was
purchased.
• If your Kenwood product malfunctions
or you find any defects, please send it
or bring it to an authorised KENWOOD
Service Centre. To find up to date
details of your nearest authorised
KENWOOD Service centre visit
www.kenwoodworld.com or the website
specific to your Country.
• Designed and engineered by Kenwood
in the UK.
• Made in China.
IMPORTANT INFORMATION FOR
CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE
WITH THE EUROPEAN DIRECTIVE
ON WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT (WEEE)
At the end of its working life, the product
must not be disposed of as urban waste.
It must be taken to a special local authority
differentiated waste collection centre or to a
dealer providing this service.
Disposing of a household appliance
separately avoids possible negative
consequences for the environment and
health deriving from inappropriate disposal
and enables the constituent materials to
be recovered to obtain significant savings
in energy and resources. As a reminder
of the need to dispose of household
appliances separately, the product is
marked with a crossed-out wheeled
dustbin.
guarantee - UK only
If your appliance goes wrong within one
year from the date you bought it, we will
repair it (or replace it if necessary) free of
charge provided:
• you have not misused, neglected or
damaged it;
• it has not been modified (unless by
Kenwood);
• it is not second-hand;
• it has not been used commercially;
• you have not fitted a plug incorrectly;
and
• you supply your receipt to show
when you bought it.
This guarantee does not affect your
statutory rights.
6

7
troubleshooting guide
Problem Cause Solution
Spiralizer not operating. No power.
Lid not locked correctly.
Check that appliance plugged in.
Check that lid is located correctly.
Lid cannot be fitted. Cone holder or cone not fitted
correctly.
Check that cone holder and cone are
located correctly.
Poor results. Food too soft or juicy.
Food too narrow or small.
Use firm fruits and vegetables without
stones, seeds or hollow centres.
Select food as straight as possible
and ensure diameter at least 5 cm.
Refer to hint and tip section.
Half moon shaped pieces
produced instead of spirals.
Diameter of food processed too
small.
Food rotating in feed tube.
Ensure diameter larger than end of
pusher.
Ensure food is held steady and cannot
rotate.
Food browning quickly. Some food such as apples, pears
and potato will brown quickly after
processing.
Use straight after processing or store
in water.
Add lemon juice to fruit to prevent
browning.

Courgette Salad
Serves: 2 as a main/ 4 as a side
Time: 5 minutes
Ingredients:
Courgette 2
Yellow pepper (remove
stalk and seeds)
1
Red onion (peeled) ½ (Medium – 150g)
Celery 1 stick
Method:
1 Spiralize the courgette using the Flat Blade.
2 Slice the pepper, onion and the celery into 3mm
thick slices.
3 Mix all the ingredients together in a bowl.
4 Cover with your dressing of choice.
Thai In-spiralized Salad
Serves: 2 as a main/ 4 as a side
Time: 10 minutes
Ingredients:
Mooli (Daikon) radish
(peeled)
½ (30cm)
Cucumber 2
Mango (peeled and
de-stoned)
½
Spring onion 4
To Finish:
Sesame seeds 4 tsp
Dried shrimp (optional) 4 tbsp
Fresh coriander (chopped) 4 tbsp
Method:
1 Spiralize the cucumber and mooli radish using
the Linguine Blade.
2 Cut the Mango into small cubes and chop the
spring onions.
3 Mix all the ingredients together in a large bowl.
4 Cover with your dressing of choice and sprinkle
over the sesame seeds, dried shrimp and fresh
coriander.
Beetroot and Celeriac Linguine
with Prawn
Serves: 2 as a main/ 4 as a side
Time: 20 minutes
Ingredients:
Raw beetroot 2
Celeriac ½ (400g)
Fennel ½ bulb
For the marinade:
Lemon ½ juice of
Extra virgin olive oil 5 tbsp
Fennel seeds ½ tsp
Seasoning To taste
To finish:
Tiger prawns 20
Spinach 200g
Method:
1 Peel and trim off the top and bottom of the
beetroot and celeriac.
2 Spiralize the beetroot and celeriac using the
Linguine Blade.
3 Place the spiralized beetroot and celeriac into a
large bowl.
4 Remove the core and finely chop the fennel and
add to the bowl.
5 Add the lemon juice.
6 Fry the vegetables, fennel seeds and seasoning
in olive oil over a medium heat.
7 Cook for 5 minutes and then add the prawns
and cook until they have turned pink.
8 Add the spinach and mix thoroughly. Serve.
8
recipes (the Spaghetti and Tagliatelle blade can also be
used in recipes where the Linguine blade is recommended.)
