Keysight U1117A User manual

Keysight U1117A IR-to-Bluetooth Adapter
Operating Instructions
The Keysight U1117A Infrared (IR)-to-Bluetooth®1adapter is designed to be used with the
Keysight U1200 Series handheld meters. The U1117A adapter enables you to connect the
handheld meter to the Keysight U1115A remote logging display or Windows PC/Android
devices/iOS devices via the Keysight mobile application/PC application software for a total
wireless remote connectivity solution of up to 100-metres2.
Figure 1. Keysight wireless remote connectivity solution
Standard Shipped Items Checklist
The following items are included when you make a purchase:
- U1117A IR-to-Bluetooth adapter
- Two 1.5 V AAA batteries
- Operating Instructions (this sheet)
1
The Bluetooth
®
word mark and logos are registered trademark owned by Bluetooth SIG, Inc and any
use of such marks by Keysight is under license. Other trademark and trade names are those of their
respective owners.
2Only
applicable when connected to any dongle with Bluetooth Class 1 classication.
Keysight U1200
Series handheld
meters
U1117A IR-to-
Bluetooth adapter
U1177A IR-to-
Bluetooth adapter
Windows PC
Android devices
iOS devices
U1115A remote logging
display
Keysight PC Application Software
Keysight Handheld Meter
Logger
Keysight Mobile Application
Keysight Mobile Meter
Keysight Mobile Logger
1

Product Characteristics
Radio specication Frequency: 2402 MHz ~ 2480 MHz
Transmit power: 17 dBm ± 3 dB
Temperature Operating condition: –20 °C to 55 °C
Storage condition: –40 °C to 70 °C
Relative Humidity (R.H.) Operating condition: Up to 80% at 40 °C (non-condensing)
Storage condition: Up to 95% at 40 °C (non-condensing)
Dimension (W x L x H) 39.0 mm × 71.0 mm × 37.0 mm
Weight 60 g with batteries
Battery Type - Lithium 24–LF (ANSI) and FR03 (IEC)
- Alkaline 24 A (ANSI/NEDA) and LR03 (IEC)
- Zinc Chloride 24 D (ANSI/NEDA) and R03 (IEC)
Battery Lifespan Lithium batteries: 30 hours
Alkaline batteries: 20 hours
Power Consumption Maximum 561 mVA for two 1.5 V AAA batteries
Warranty Three months (Does not cover normal wear and tear of me-
chanical parts and batteries)
Bluetooth Bluetooth SPP prole, Class 1 device, range up to 100 m
Compatibility Keysight Handheld Meter/Display:
- Keysight U1200 Series Handheld Meters
- Keysight U1115A Remote Logging Display
Keysight PC Application Software:
- Keysight Handheld Meter Logger
Keysight Mobile Application:
- Keysight Mobile Meter
- Keysight Mobile Logger
Hardware Devices:
- iPhone
- iPad
- iPod Touch
- Android smartphone/tablet
- Windows PC (with Bluetooth-enabled)
2

Regulatory The U1117A complies with the requirements of the
following product standards:
- EMC
- EN 301 489–1V1.9.2
- EN 301 489–17:V2.2.1
- EN 55022:2010
- EN 55024:2010
- RF (Bluetooth)
- EN 300 328 V1.7.1
- RF (Health)
- EN 62311:2008
- Safety
- EN 60950–1:2006+A11:2009+A12:2011
- India Equipment Type Approval (ETA) Certicate No:
NER-ETA/923
- COFETEL Certicate No: RCPKEU115-0020, registered
under Keysight Technologies Mexico S de RL de CV
“This telecommunication equipment conforms to the NTC
technical requirement”
- Canada IC: The device contains transmitter IC: 5123A–BGTWT11IA
- To comply with FCC and Industry Canada RF radiation exposure limits for
general population, the antenna(s) used for this transmitter must be
installed such that a minimum separation distance of 20 cm is
maintained between the radiator (antenna) and all persons at all times
and must not be colocated or operating in conjunction with any other
antenna or transmitter.
- “La operación de este equipo está sujeta a las siguientes dos
condiciones: (1) es posible que este equipo o dispositivo no cause inter-
ferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier
interferencia, incluyendo la que pueda causar su operación no deseada.”
- “Este produto está homologado pela Anatel de acordo com os procedi-
mentos regulamentados para avaliação da conformidade de produtos
para telecomunicações e atende aos requisitos técnicos aplicados, inclu-
indo os limites de exposição da Taxa de Absorção Especica referente a
campos elétricos, magnéticos e eletromagnéticos de radiofrêquencia.
O máximo valor medido da Taxa de Absorção Especica referente à ex-
posição localizada no corpo é de 0,00137 W/kg.”.
Complies with
IMDA Standards
(N5464-19)
3

- “Este equipamento opera em caráter secundário, isto é, não tem direito a
proteção contra interferência prejucidial, mesmo de estações do mesmo
tipo, e não pode causar interferência a sistemas operando em caráter
primário”.
Manter distância mínima de 10 cm do corpo humano. Para maiores in
formações, consulte o site da ANATEL www.anatel.gov.br
- The radio module certied by Japanese Radio Law is integrated inside.
- NCC Warning Statement:
- Article 12
Without permission, any company, rm or user shall not alter the fre-
quency, increase the power, or change the characteristics and func-
tions of the original design of the certied lower power
frequency electric machinery.
- Article 14
The application of low power frequency electric machineries
shall not affect the navigation safety nor interfere a legal
communication, if an interference is found, the service will be
suspended until improvement is made and the interference no
longer exists.
- According to FCC part 15:21, changes or modications not expressly
approved by the manufacturer for compliance could void the user’s
authority to operate the equipment.
- According to FCC part 15.105(b):
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy, and if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
4

Front View
LED Indicator and Slide Switch
Low battery — LED red ashing
1. Bluetooth disconnected — LED green ashing
2. Bluetooth connected — LED solid green
3. Bluetooth power off — LED off
Slide switch
Operation
- Do not open the plastic case unnecessarily. Doing so may cause
damage to the plastic case.
- Keep the adapter away from getting wet.
- Ensure the adapter is turned OFF and the battery cover is removed when
replacing the batteries.
- The batteries must be recycled or disposed properly after depletion.
- If the LED is not lighted when turned on, replace the batteries with new
specied batteries.
- The adapter can only be used with Keysight handheld meters.
Install and Replace the Batteries
Make sure you turn off the U1117A before installing or replacing
the batteries.
To avoid the U1117A being damage from battery leakage:
- Always remove dead batteries immediately.
- Always remove the batteries and store them seperately if the adapter is
not going to be used for a long period.
1. Slide the battery cover
away from adapter’s
body.
2. Insert the batteries. 3. Reverse the sliding
position to close the
battery cover.
5

Turn On the U1117A
Set the slide switch to On.
Congure the U1117A
The U1117A is designed to be used straight from the box without any conguration. How-
ever, if your hardware requires special conguration, you may setup the U1117A
using the U1117A Conguration Utility— downloadable at
www.keysight.com/nd/U1117A
Set the slide switch to Setup.
Reset the U1117A
1. Open the battery cover. Then, set the
slide switch to Setup.
2. Use a at-blade screwdriver to push the
button located in the hole for around three
seconds.
6

Connect Your U1117A Adapter to the Keysight Handheld Meter
Snap the optic side of the U1117A to the handheld meter’s IR communication port.
Install the U1117A to PC via Bluetooth
- Before you begin, make sure the Bluetooth connection on your PC
is enabled.
- It is recommended to use brand new batteries before running any
operations that are critical or require a longer duration.
- In some cases, the Bluetooth Device Manager will create two COM
ports. Use the COM port with the “Outgoing” label only.
- A yellow exclamation mark may appear when the wireless iAP prole
for iOS devices and serial protocol prole (SPP) for Windows PC or
Android devices is detected. In this case, pairing is successful.
1. Set the U1117A slide switch to On.
2. From your PC (Windows 7), go to Start > Devices and Printers.
3. Click Add a device.
4. Select Keysight U1117A-XXXXXX—the XXXXXX represents U1117A device ID and click
Next.
5. Type the default Bluetooth pairing code “1234” and click Next.
6. Once pairing is successful, a notication window will appear. Click Close.
7. The U1117A-XXXXXX is now added and connected successfully to your PC.
Connect a Meter to the Keysight Handheld Meter
Logger via the U1117A
Before you begin, make sure you download the Keysight Handheld Meter Logger at
www.keysight.com/nd/hhmeterlogger
1. Open the Keysight Handheld Meter Logger.
2. On the Connected Instruments List (at the bottom), select the U1117A-XXXXX and
click Connect to establish the multimeter connection.
3. The multimeter will remain connected until the connection is disconnected or the
U1117A is turned off.
7

Connect a Meter to the Keysight U1115A Remote
Logging Display via the U1117A
For details, refer to the U1115A Remote Logging Display Operating Instructions at
www.keysight.com/nd/U1115A.
Connect a Meter Remotely via the Keysight Mobile
Application (Keysight Mobile Apps)
You can now turn your Android and iOS devices into a remote measurement, control and re-
porting devices using both the Keysight Mobile Meter and Keysight Mobile Logger
—available on the Google Play and App Store. These Mobile Apps allow you to wirelessly con-
trol your Keysight handheld meter with your Android devices and iOS devices via the Keysight
U1117A adapter.
All Keysight handheld meters are supported, with the exception of the Keysight U1240 Series,
which requires an additional Keysight U1179A IR Connectivity Bracket for compability with
the Keysight U1117A adapter. Visit the URLs below for more information on the Keysight Mo-
bile Apps: www.keysight.com/nd/hhmeterapp
Maintenance
If any part of the adapter is worn out or damaged, replace it with a new U1117A adapter.
Assistance
For technical assistance, contact your nearest Keysight Sales Ofce or visit the Keysight
website at www.keysight.com/nd/assist for further information.
Simplied EU Declaration of
Conformity
Hereby, Keysight Technologies Malaysia Sdn.Bhd
declares that the radio equipment type U1117A,
IR-to-Bluetooth® Adaptor (Class 1) is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://regulations.about.keysight.com/DoC/
Postal Address for product regulations enquiries:
Keysight Technologies Deutschland GmbH
Postbox 1320, 71003 Boeblingen, GERMANY.
8
U1117-90103
www.keysight.com
©Keysight Technologies 2014-2019
Printed in Malaysia
November 2019
1852-14-7510
(01) 07898956006022
