Kimo tk110 User manual

PERFOMS A MEASUREMENT
➢Turn on the device by pressing on «On/Off/Esc».
The device displays its name «TK110» or «TK112».
●Put the probe to the required location.
The device displays the temperature measurement with the type of thermocouple below.
If the used thermometer is the TK112 with two connected probes, the device will display the two measures.
➢Press on «OK» to display the delta between the two temperatures.
Thermocouple thermometer
TK 110 – TK 112
DESCRIPTION OF THE DEVICE
OK key
Hold/min/max key
Select key
Backlight key On/Off/Esc key
[e-mail]
DigiParts GmbH

ADJUST THE DEVICE
Select the type of thermocouple:
The device is on and displays the measurement:
➢Press on «Select ».
«PROBE» blin s on screen.
➢Press on «OK».
The type of thermocouple currently used blin s on screen.
➢Press on «Select » until the required type of thermocouple appears: K T J or S.
➢Press on «OK» to validate.
«PROBE» blin s on screen.
➢Press on «On/Off/Esc » to return to the measurement display.
●De ice drop-down menu
1x
SEL.
PROBE
(K)
2x
SEL.
AUTO
OFF
OFF
SEL.
BEEP
OFF
3x 4x SelectSelect
SEL.
UNIT
°C
Select Select
Select
PROBE
SEL.
(K)/(T)/(J)...
OK
SEL.
PROBE
(K)
OK
On/Off/
Esc
PROBE
SEL.
(K)
25.3
(J) °C
SEL.
PROBE
(J)
Once the measurement is frozen:
➢Press once on « Hold/min/max ».
●If the device is a «TK110» or a «TK112» with one connected probe, the device displays the maximum value measured since the last
questioning at the top of the screen and the minimum value measured since the last questioning at the bottom of the screen.
●If the device is a «TK112» with two connected probes, the device display the maximum value of the probe T1 measured since the last
questioning at the top of the screen and the minimum value of the probe T1 since the last questioning at the bottom of the screen.
➢Press again on «Hold/min/max » if the device is a «TK112» with two connected probes.
The device displays the maximum value of the probe T2 measured since the last questioning at the top of the screen and the minimum value
of the probe T2 since the last questioning at the bottom of the screen.
➢Press on «On/Off/Esc » to return to the measurement display.
DISPLAY THE MINIMUM AND THE MAXIMUM
During a measurement:
➢Press on «Hold/min/max».
«Hold» appears on screen and the measurement is frozen.
➢Press on « On/Off/Esc» to exit the hold function.
The device returns to the measurement display.
FREE E THE MEASUREMENT
[e-mail]
DigiParts GmbH

Acti ate or deacti ate the keys beep:
The device is on and displays the measurement.
➢Press on «Select » until « BEEP» blinks on screen.
➢Press on «OK».
«OFF» or «ON» blin s on screen.
➢Press on «Select » to activate the keys beep «ON» or deactivate it «OFF ».
➢Press on «OK» to validate.
«BEEP» blin s on screen.
➢Press on «On/Off/Esc» to return to the measurement display.
Adjust the auto shut-off!:
The device is on and displays the measurement.
➢Press on «Select » until «AUTO OFF» blinks on screen.
➢Press on «OK».
The time before device auto shut-off blin s at the bottom of the screen.
➢Press on «Select» until the required time before auto shut-off appears: 15 30 45 60 75 90 105 120 minutes or OFF.
➢Press on «OK» to validate.
«AUTO OFF» blin s on screen.
➢Press on «On/Off/Esc» to return to the measurement display.
OK
25.3
(J) °C
SEL.
AUTO
OFF
30mn
AUTO
OFF
15/ 30mn...
AUTO
OFF
OFF
OK
Select
SEL.
AUTO
OFF
OFF
On/Off/
Esc
OK On/Off/
Esc
SEL.
BEEP
ON
BEEP
SEL.
OFF
BEEP
SEL.
OFF / ON
OK
SEL.
BEEP
OFF
Select
25.3
(J) °C
Select the measuring unit :
The device is on and displays the measurement.
➢Press on « Select» until «UNIT» blinks on screen.
➢Press on « OK ».
The unit currently used blin s on screen.
➢Press on «Select» until the required unit appears: °C or °F.
➢Press on «OK» to validate the unit selection.
«UNIT» blin s on screen.
➢Press on «On/Off/Esc» to return to the measurement display.
UNIT
SEL.
°C
Select
SEL.
UNIT
°C
SEL.
UNIT
°F
OK
76.9
(J) °F
UNIT
SEL.
°C / °F
On/Off/
Esc
OK
[e-mail]
DigiParts GmbH

➢Remove the front part at the back of the device.
➢Change the old batteries by AAA LR03 1.5V batteries.
➢Replace the front.
CHANGE THE BATTERIES
The device is on.
➢Press on «Backlight»: to activate the device backlight.
➢Press again on this key to deactivate the backlight.
ACTIVATE THE BACKLIGHT
Adjust the alarm:
This function allows to activate a temperature alarm on the channel 1 when the device reaches and exceeds a previously defined threshold.
This threshold will be between -200 and +1760°C following the thermocouple type of the probe.
The device is on and displays the measurement.
➢Press on «Select» until «AL 1» blinks.
➢Press on « OK».
The first digit blin s.
➢Press on «Select» to select the first digit value depending on the thermocouple type of the probe : - 0 1 or off.
●If «off» is selected the alarm is deactivated. Press on «OK» to validate «AL 1» blinks on screen.
●If - 0 or 1 is selected press on «OK ». The following digit blinks press on «Select» to select its value then press on « OK » to
validate. Perform the same procedure to select the value of the following digits (Press on «On/Off/Esc» to return to the following
digit). Press on «OK» when the first digit is adjusted « AL 1» blinks on screen.
➢Press on «On/Off/Esc » to return to the measurement display.
Once returned to KIMO required waste collection will be assured in the respect of the environment in accordance to 2002/96/CE guidelines relating to WEEE
NTang – portable-TK110-TK112 – 10/06/14 – RCS (24) Périgueux 349 282 095 Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
