TM840 DMR Mobile Quick User Guide

TM840 DMR Mobile Quick User Guide
Quick User Guide
TM840
DMRMobile
We are very grateful for your purchasing KIRISUN DMR Mobile
produced by Kirisun Communications Co., Ltd.
We believe KIRISUN DMR Mobile, which always incorporates the
latest technology, can bring great convenience to your life and work.
We also believe that the quality and function of KIRISUN DMR Mobile
can meet your demands for reliable communication.

TM840 DMR Mobile Quick User Guide
2

TM840 DMR Mobile Quick User Guide
1
1 Safety Information
zThe government bans on operation the radio transmitter without permission in the jurisdiction
scope. Illegal operation will punished with fine or arrest. This product can only be maintained
by the professional technicians.
zSafety: It’s very important for users to realize the generally dangerous of using the radio.
zWarning: Please turn off the radio when you are refueling in the explosive atmosphere (such
as gas, dust and smog, etc.) or park at the gas station.

TM840 DMR Mobile Quick User Guide
2
2 First Use
2.1 Unpacking and Checking
Please unpack carefully and check all the items listed in the following table before discarding the
packing material. If any damage or loss occurs during shipment, please contact your dealer.
2.1.1 Standard Accessories
No. Material Quantity
1 Mobile 1
2 Hand Microphone 1
3 Fixed Bracket 1
4 Power Supply Line 1
5 Fuse 2
6 Microphone Hanger, with two ST4*16 tapping screws 1

TM840 DMR Mobile Quick User Guide
3
7 Plastic handle screw, contain matching flat washer and spring
washer 2
8 ST4.8*20 Self-tapping screws 6
9 Certificate of Approval 1
10 Quick User Guide 1

TM840 DMR Mobile Quick User Guide
4

TM840 DMR Mobile Quick User Guide
5
2.2 Preparing Your Mobile for Use
2.2.1 Installing your Mobile
1）Using six ST4.8*20 self-tapping self-drilling screws to fasten the bracket at the suitable place
inside the vehicle.
2）Using two Plastic handle screw to fasten the mobile on the bracket.
3）Connect the Power Supply Cable
First, arrange the 5 meter power cable (First, find that if there is a hole on the thermal baffle can
cross the power line. If there don’t have one, please drill a hole use the suitable drill bit and put on
rubber hole. Then let the power line through the thermal baffle into the engine compartment), and
connect the engine battery or other power supply to the open end (the power supply can’t exceed
16 Volt). Attention that the red line connect positive pole, the black line connect the negative pole.
Put in the suitable protective tube (random provided, please apply the protective tube from the
suppliers if you change it in the late, avoid causing other damage), put the plug insert the power
interface socket at the tail of turn-table.
4）Connect the Antenna

TM840 DMR Mobile Quick User Guide
6
5）Connect the hand Microphones
Install hand microphone
Put the direction indicative plane of the hand microphone plug on the top and insert it into the
microphone interface of the mobile. Then clockwise rotate the self-lock cover on the microphone
plug until the self-lock cover against the card slot. At this moment, please press down a little bit
and continue rotate in clockwise until it can’t be rotated.
Uninstall hand microphone
Anticlockwise rotate the self-lock cover on the hand microphone until you can’t be rotated, then
pull the plug out.
Install Microphone Hanger Clip
Using two ST4*16 tapping screw to install the microphone Hanger clip at the place where it is
convenient for your use (the microphone and the microphone line should install at the place
doesn’t impact the safe drive), put the hand microphone hang on the microphone hanger.

TM840 DMR Mobile Quick User Guide
7
3 Product Overview
3.1 Control Parts Introduction

TM840 DMR Mobile Quick User Guide
8
No. Part Name No. Part Name
1 Volume Control Knob 11 PTT Key(Hand Microphone)
2 Microphone/Programming Cable Interface 12 Emergency Button
3 The Menu/Ok Button 13 Hook off Key
4 Up Key 14 Dial Key
5 Down Key 15 P1~P4 (Programmable Keys)
6 Return Button 16 LCD Display
7 On/Off Button 17 Antenna Connector
8 LED Indicator 18 Power Cable Connector
9 Speaker 19 GPS Antenna Connector
10 Microphone 20 26 Pin Connector

TM840 DMR Mobile Quick User Guide
9
3.2 Programmable Buttons
For the convenience of users to operate the radio according to their own habits, the following buttons
can be programmed as short cuts to radio functions by dealer.
P1 to P4 can be programmed to “long press” and short press.
Note：
Short Press：Pressing and releasing rapidly.
Long Press: Pressing and holding for the programmed duration. (This time can be set via the
programming settings)
No. Shortcut Keys Description
1 None No function. The error alert will be heard when the key
pressed.
2 High/Low Toggles power level between high and low.
3 Monitor Press monitor key to enter to “carrier squelch” mode when the
current channel is with CTC/DCS, thus the radio will unmute

TM840 DMR Mobile Quick User Guide
10
when receiving carrier.
4 Squelch Off To always unmute the speaker no matter whether carrier is
present or not. (Analog mode).
5 Squelch Level Adjust the signal stress required for the radio to unmute.
6 Scan Toggles scan on or off. To receive signal from other channels
7 LCD Brightness Adjust the brightness level by entering to "LCD Brightness".
8 LCD Backlight Type To adjust off time of LCD backlight in this option.
9 Repeater/Talkaround Toggle between using a repeater and communicating directly
with another radio.
10 Zone Selection To change the current call zone.
11 Home Screen To quickly return to the home screen.
12 Nuisance Delete To temporarily ignore unwanted channel activity.
13 Scramble/Encryption Toggles scramble/encryption on or off.
14 Contacts Provides directly access to the contact list
15 Message Selects the message menu. Only works on digital mode.

TM840 DMR Mobile Quick User Guide
11
16 Call log Selects the call log menu. Only valid in digital mode.
17 Monitor Channel On/off monitor channel. Exit monitor channel function when
pressing PTT.
18 Permanent Monitor
Channel
On/off permanent monitor channel. Don’t exit monitor channel
function when pressing PTT.
19 Sending Interrupt To interrupt other user to initiating a call at the current channel.
20 Public Address1
Allows the user to toggle the audio routing from incoming audio
or radio microphone to the connected external public address
(PA) speaker at rear port 1.
21 Public Address2
Allows the user to toggle the audio routing from incoming audio
or radio microphone to the connected external public address
(PA) speaker at rear port 2.
22 External
Alarm/Speaker/Light
When the mobile received emergency call/alarm, call alert or
private call and without operation during the programmed time,
the valid level will output from GPIO. The level can drive the

TM840 DMR Mobile Quick User Guide
12
external alarm device (light or speaker) connected to GPIO to
alarm.
4 Basic Operation
4.1 Powering On/Off the Radio
In the power off status, long press the Radio On-Off button to power on the mobile. The power
on screen will be shown, backlight will light and the power on alert will be heard.
In the power on status, long press Radio On-Off button until power off screen is shown to power
off the mobile.
4.2 Selecting a Zone
A Zone is a group of channels exhibiting the same property, allowing users quickly switch from a
channel group to a different channel group. The radio can be set to have up to 248 zones, each with
a maximum of 128 channels.
You may select a zone through the following way:

TM840 DMR Mobile Quick User Guide
13
1）Press key to enter the main menu in home screen.
2) Access to zone item by or , then press to select.
3) All the zones are listed here. The current zone is indicated by .
4) Press or key to required zone and press to select.
5) This display shows "Zone Selected "and return to selected zone screen.
4.3 Selecting a Channel
Pressing or key to select channel on home screen.
4.4 Adjusting the Volume
After the radio power on, rotate the volume knob clockwise to increase radio volume or
counter-clockwise to decrease the volume.
4.5 Making a Call
You can initiate a call by following method.

TM840 DMR Mobile Quick User Guide
14
When a call is initiated, the red LED lights on. The call type (private call icon , group call icon ),
alias or ID and outgoing call icon is displayed on the LCD
4.5.1 Initiate a Call to the Default Contact
In the home screen, hold down the PTT key to initiate a call to the default contact which has be set
for the current channel in CPS software. The contact can be set to private call, group call, or all call
by CPS.
4.5.2 Selecting a Contact and Initiate a Call
You can also make a call via contacts. Enter contact list menu and select one specific contact, then
hold down PTT to initiate a call.
4.5.3 Manual Dial and Initiate a Call
You can also make a call by "Manual Dial". Enter the "Contacts" menu and then enter "Manual Dial"
sub-menu, directly enter contacts’ ID number, and press PTT key to initiate a call.
4.6 Receiving and Answering the Call

TM840 DMR Mobile Quick User Guide
15
When a call is received in the standby mode:
Green LED indicator lights on. The call type (private call icon , group call icon ), alias or ID and
incoming call icon is displayed on the LCD.
You can hold down PTT to call back to current contact within the hang time duration.
Note:
To receive a group call, your radio must be configured as part of that group. (Dealer set it via CPS).
You cannot respond to an All Call.

TM840 DMR Mobile Quick User Guide
16
5 Menu Bar
