Klip Xtreme Melodik User manual

KWH-050
Melodik

I. Introduction
Thank you for purchasing the KWH-050 headphones with wireless technology.
We encourage you to read this quick installation guide thoroughly to get the most
out of this wireless device.
Main features
• Enjoy up to10 hours of music**
• Bluetooth®v5.0 that delivers a stable wireless connection and greater range*
• Lightweight design that fits perfectly
• Rotatable earcups provide flexibility
• Hands-free mode enables mobility
• MicroSD™ card slot to listen to your music in different formats
• Padded earpads for all day comfort
* Range estimate is based on an area free and clear of obstacles and interference, and within the
line of sight between devices.
** Depending on the volume level and type of music file being played.
Package content
• Foldable headphones with Bluetooth®wireless technology
• Micro-USB charging cable
• 3.5mm auxiliary cable
• Quick installation guide
II. Product components
English
8
1
2 3
7
6
5
4

1. MicroSD™ (TF) memory card slot
2. Power button: on/off/redial/reject call
3. Micro-USB charging port
4. 3.5mm auxiliary input port audio cable
5. LED indicator:
• The LED lights up blue and then blinks blue and red when the headphones are
powered on.
• The LED blinks blue and red with voice prompt to indicate that the
headphones are ready for pairing mode.
• The LED turns off and headphones chime when the wireless connection has
been established.
• The LED glows solid red while charging.
• The LED turns off when fully charged.
6. : Volume -/previous song
7. : Multifunction button: Play/pause/answer or end a call/mode
8. : Volume +/next song
III. Basic operation
Charge your headphones
• Plug the supplied Micro-USB cable into the USB port of your computer or to a
5VDC USB adapter to fully charge the battery.
• Make sure that the headphones are fully charged before using them for the first
time.
• The headphones’ battery must be initially charged for at least 3 hours. Thereafter,
the battery will take 2.5 hours to recharge.
• While the headphones are being charged, the LED glows red.
• When the battery has reached full capacity, the red LED turns off.
IV. Auxiliary wired connection
• Plug one end of the supplied 3.5mm cable to your headphones and the other
end to the 3.5mm auxiliary port on your input source.
• Set the desired volume on the input source. The volume controls on the
headphone will not operate when they are not connected to an external wired
audio source.

I. Using the wireless headphones
•If the headphone is off, press and hold the power button for 3 seconds to turn it
On.
•Once the headphone is paired to your mobile device (as per previous BT pairing
instructions) above.
• Select your favorite multi-media platform to start enjoying the music.
Note: Make sure that the two devices, phone and headphone are at a distance of
at most 10m from each other for optimal functionality.
2. Answering and ending a call
• When there is an incoming call, you will hear a ring
• Press the multifunction button to pick it up. You may also press the answer
button on your smartphone to take the call.
• To end a call, simply press again the multifunction button. Likewise, you may also
finish the call directly using the end key on your smartphone.
• To reject or ignore an incoming call, press, and hold the power button for about
1.5 seconds.
• If you want to redial the last number called, press the power button twice.
V. Advanced operation
Note: Before installing this product, please make sure your device is Bluetooth®
compatible.
Pairing the headphones with your mobile device
1. Press and hold the power button on the headphones to turn on the device.
2. Next, set your Bluetooth®mobile device to “discover” the wireless headphone.
3. Place the headphones and your phone not more than three feet from each
other.
4. Press the multifunction button for 3 seconds, the LED indicator will blink blue
and red. You’ll hear a voice prompt when the headphones are ready to enter the
pairing mode.
5. On your mobile phone, tap the newly discovered audio device (KWH-050)
being displayed in the Bluetooth®list.
6. When the mobile device asks if you want to pair with it, click Yes or OK to
accept.
7. If you have a lower Bluetooth®version, you may be prompted to enter the
passkey 0000 (4 zeros).
8. If pairing is successful, the LED will turn off and you will hear chime from the
headphones. If after 60 seconds the pairing process fails, please repeat steps 1
through 7 described above.
9. You only need to pair the headphones with your phone once, as it will reconnect
with memorized devices automatically.

3. Music playback
• Briefly press the play/pause button to reproduce, pause and stop audio
playback.
• Press briefly the +and –buttons to go to the next or previous track.
• Press and hold the +and –buttons to increase or decrease the volume level on
the headphones.
• When listening to music playback will pause to allow the call to go through.
• As soon as you hang up, music playback will resume automatically.
VI. Troubleshooting
Problem Solution
The device is not
turning on The battery level might be low. Please recharge the
battery.
Batteries are not
being charged
Check that the source device is ON, or adapter is
correctly used. Check that the Micro-USB cable is
securely connected.
Problem Solution
The device is not
pairing
Place the wireless headphones and Bluetooth®device not
more than three feet away from each other.
The device can't
connect to the
Bluetooth®mode
Confirm that the headphones are under pairing mode.
Confirm that the Bluetooth®function is turned on in your
source device. Input code "0000" when requested.
There is no sound
when playing music
Confirm that the connection with the Bluetooth®device is
set for profile A2DP. Confirm that volume controls on
both, the wireless headphones and the source device are
set to the appropriate levels.
Sound is distorted
when playing music
Check that no other devices using the 2.4GHz
wavelength are nearby, and that there are no obstacles
blocking the signal path.
Can't use the
hands-free mode Confirm that the wireless headphones and Bluetooth®
device are connected using the profile HFP or HSP. If the
Bluetooth®device is connected in profile A2DP, it may be
necessary to change connection profiles (depending on
the specifications of the Bluetooth®device).

Headphone
MPN KWH-050
Form factor
Driver unit
DC Input
Maximum power output
Frequency
Impedance
Sensitivity
Microphone
Form factor
Directivity
Frequency
Impedance
Sensitivity
Volume control
Connectivity
Connection type
Wireless RF frequency
Wireless range
Buttons
Memory card slot
Over-the-ear
Ф40mm
5V
24mW (12mWx2)
2.402-2.480GHz
32Ω
110 ± 3dB (S.P.L at 1kHz)
Built-in
Omnidirectional
20Hz-20kHz
2.2KΩ
-42dB±3dB
Yes
Bluetooth® V5.0, 3.5mm auxiliary-in, microSD™
2.402—2.480GHz
Up to 49ft*
: Volume+/next song,
: Multifunction button : Play/pause/mode
: Volume-/previous song
Power button: On/o/answer/hang up/redial/reject call
Yes
Technical specications
Precautions
• Do NOT drop, hit or shake the device.
• Do NOT disassemble, repair or modify the headphones yourself.
• Do not use cleaning products that contain benzene, solvents or alcohol.
• Do NOT expose the headphones to excessive heat or to direct sunlight for long
periods of time.
Battery
Battery type
Battery charging time
Battery run time
Battery standby time
Special features
Notications type
Foldable
Swivel capsules
Additional information
Cable length
Dimensions (LxWxH)
Weight
Warranty
Built-in rechargeable lithium battery 3.7VDC, 400mAh
2 to 3 hours
Bluetooth® on - 50%: Up to 10 hours**
Bluetooth® on: Up to 8 hours**
24 hours
Tones
Yes
Yes
4.9ft – charging and audio cables
6.2x2.8x7.2in
6.1oz
One year
* Range estimate is based on an area free and clear of obstacles and interference, and within the
line of sight between devices.
** Depending on the volume level and type of music file being played.

• Do NOT store the device in a place with high humidity or dust.
• Do NOT place heavy objects on top of the headphones.
• Do NOT use near a microwave oven or wireless LAN products.
FCC statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Notes

I. Introducción
Gracias por preferir los audífonos KWH-050 con tecnología inalámbrica. Te
recomendamos leer detenidamente esta guía de instalación rápida para aprovechar
al máximo este dispositivo inalámbrico.
Características principales
• Disfruta hasta 10 horas de música**
• Bluetooth®v5.0 que ofrece una conexión inalámbrica estable y de mayor alcance*
• Diseño liviano que se encaja perfectamente
• Las almohadillas giratorias brindan flexibilidad
• Modo de manos libres para estilos de vida activos
• Ranura para tarjetas microSD™ proporciona flexibilidad para escuchar tu música
almacenada en diferentes formatos
• Almohadillas acolchadas para comodidad todo el día
*El cálculo de alcance se basa en un área libre de obstáculos e interferencias y dentro de la línea
de visión entre los dispositivos.
**Depende del nivel de volumen y del tipo de archivo de música que se reproduce.
Contenido del empaque
• Audífonos plegables con tecnología inalámbrica Bluetooth®
• Cable de carga Micro-USB
• Cable auxiliar de 3,5mm
• Guía de instalación rápida
II. Componentes del producto
Español
8
1
2 3
7
6
5
4

1. Ranura para tarjeta de memoria microSD™ (TF)
2. Botón de alimentación: Encender/apagar/rediscar/rechazar llamada
3. Puerto de carga Micro-USB
4. Cable auxiliar de 3,5mm
5. Luz LED de estado:
• El LED se ilumina de color azul y después parpadea en azul y rojo cuando los
audífonos están encendidos.
• El LED parpadea de color azul y rojo con un aviso para indicar que los audífonos
están listos para el modo de emparejamiento.
• El LED se apaga y los audífonos emiten un sonido cuando la conexión
inalámbrica se establece.
• El LED brilla de color rojo mientras se carga la batería.
• El LED se apaga cuando los audífonos están completamente cargados.
6. : Volumen -/pista anterior
7. : Botón multifunción: Reproducir/pausa/ contestar o terminar una llamada/
modo
8. : Volumen +/próxima pista
III. Funcionamiento básico
Carga de los audífonos
• Conecta el cable Micro-USB suministrado al puerto USB de tu computadora o a
un adaptador USB 5VDC para cargar completamente la batería.
• Cerciórate de que los audífonos están totalmente cargados antes de usarlos por
primera vez.
• La batería de los audífonos se debe cargar por 3 horas mínimo. Desde entonces,
tomará 2,5 horas recargarla.
• Mientras se carga la batería el LED se ilumina de color rojo.
• Una vez que la batería alcanza el nivel de carga plena se apaga el indicador LED
rojo.
IV. Conexión alámbrica auxiliar
• Conecta un extremo del cable auxiliar 3,5mm suministrado a tus audífonos y el
otro extremo al puerto auxiliar de 3,5mm en la fuente de entrada.
• Establece el volumen deseado en la fuente de entrada. Los controles de volumen
en los audífonos no operarán cuando los audífonos no están conectados a una
fuente de audio alámbrica externa.

V. Funcionamiento avanzado
Nota: Antes de instalar este producto, verifica que tu dispositivo es compatible con
Bluetooth®.
Cómo emparejar los audífonos con el dispositivo móvil
1. Mantén oprimido el botón de alimentación en los audífonos para encenderlos.
2. A continuación, programa la función Bluetooth®en tu teléfono inteligente para
“detectar” los audífonos inalámbricos.
3. Ubica los audífonos y el teléfono a no más de un metro de distancia entre sí.
4. Presiona el botón multifunción por 3 segundos, el indicador LED parpadeará en
azul y rojo. Escucharás un aviso de voz cuando los audífonos estén listos para
entrar en modo de emparejamiento.
5. En tu teléfono móvil selecciona el dispositivo de audio recién descubierto
(KWH-050) que aparece exhibido en la lista de Bluetooth®.
6. Cuando el teléfono te pregunte si deseas emparejarlo haz clic en Sí u OK para
aceptar.
7. En caso de contar con una versión de Bluetooth®inferior, es posible que te pida
ingresar la contraseña 0000 (4 ceros).
8. Cuando el proceso de emparejamiento concluye satisfactoriamente, el LED
parpadea de color azul y escuchas un tono de los audífonos. Si después de 60
segundos no logras emparejar el dispositivo repite los pasos 1 al 7 descritos
arriba.
9. Solo necesitas emparejar los audífonos con el teléfono una vez y luego se
reconectará automáticamente a los dispositivos memorizados.
I. Utilización de los audífonos inalámbricos
• Si los audífonos están apagados, mantén oprimido el botón de alimentación por 3
segundos para encenderlos.
• Una vez que los audífonos se emparejan con tu dispositivo móvil (por
instrucciones previas de emparejamiento Bluetooth®arriba).
• Escoge tu plataforma multimedia favorita para empezar a disfrutar la música.
Nota: Asegúrate de que los dos dispositivos, teléfono inteligente y audífonos
estén a una distancia de máximo 10m entre sí para óptimo funcionamiento.
2. Contestar y finalizar una llamada desde tu teléfono móvil
• Cada vez que recibas una llamada escucharás un timbre.
• Oprime el botón multifunción para contestar. También puedes presionar el
botón de contestar en tu teléfono inteligente para contestar la llamada.
• Para finalizar una llamada, oprime el botón multifunción una vez más. Del mismo
modo, puedes concluir la llamada directamente utilizando el comando de tu
dispositivo móvil.
• Para rechazar o ignorar una llamada mantén presionado el botón de alimentación.
• Si deseas marcar al último número discado oprime el botón de alimentación dos
veces.
