Knight Team Table User manual

Tools Required:
Assembly Guide
Powered Screwdriver, mm and mm Allen Key.
Team Table

Page 1
Assembly Guide
Team Table
WARNING: FAILURE TO COMPLY WITH OR OBSERVE
ALL ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS
AND WARNINGS REGARDING THE USE OF THIS
PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
IMPORTANT NOTES!
Prior to installment, use or maintenance of the desk
frame, any installer and any user of the desk must study
this assembly and operation manual carefully, so as to
gain a complete understanding of its content.
WARNING
!
1
10
2
3
12
11
13
15
14
6
4
8
5
97
COMPONENTS
Leg x
Adjustable Foot x
Leg Cable Cover x
Rail Lengths x
Rail Widths x
 Way Connector x
 Way Connector Cap x
 Way Connector x
 Way Connector Cap x
 Rail Spacer Bracket x
 Slot Nut x
 Table Top x
SCREWS
 Mxmm Dome Head x
 Mxmm Dome Head x
 Mxmm Cap Head x
 Gxmm Self Tapping x
Please Note: Table top may have pre-drilled holes on the underside, these holes
may not ailgn to your specific frame. If this is the case, the frame will need to be
aligned to the top and new holes drilled separately and screws provided used.

Page 2
Assembly Guide
Team Table
Step 1
Slide the  way and  way connectors over each leg, and
securely lock into place using Mxmm cap head bolts.
Step 3
Securely connect legs to rails lengths using the Mxmm
dome head bolts.
Step 4
Securely connect legs to rails widths using the Mxmm
dome head bolts.
Step 2
Loosely connect the Mxmm dome head bolt and slot nut
through the rail spacer bracket. Slide brackets onto rails, space
evenly and fully tighten in place. Rails 800mm or longer require
1 bracket, 1600mm or longer rails require 2 brackets.
800mm
1600mm

Page 3
Assembly Guide
Team Table
Step 5
Ensure the worksurface is centered over the frame. Pre-drill
holes in the worksurface. Fully tighten all Gxmm self
tapping screws through each leg and rail spacer bracket into
the worksurface.
Completed
Step 6
Conceal any power box cables using the magnetic leg cable
covers.
Optional
Loosely connect the Mxmm dome head bolt and slot nut
through the metal rail spacer bracket. Slide brackets onto rails,
space evenly and fully tighten in place. Rails 800mm or longer
require 1 bracket, 1600mm or longer rails require 2 brackets.
Please Note: Table top may have pre-drilled holes on the underside, these holes may not
ailgn to your specific frame. If this is the case, the frame will need to be aligned to the top
and new holes drilled separately and screws provided used.
