Knight Cubit System User manual

knightgroup.co.nz
Tools Required: Powered Screwdriver
Assembly Instructions
Cubit System

Assembly Instructions
knightgroup.co.nz
Cubit System
Recommended
2 Person Assembly
Thank you for purchasing Knight product, please carefully read the assembly instructions prior to installment to gain a complete
understanding of the product. It provides you with important information about the safety, use, installation and maintenance.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS REGARDING
THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
SAFETY
• The product must be used in a safe manner. Inappropriate use may cause damage to the product and/or cause bodily harm to
the user or persons nearby.
• Don’t locate furniture in direct sunlight or near air-conditioning inlet or heating radiator.
• Don’t put high-temperature or frozen objects on furniture.
• Safely carry product to location of assembly.
• Retain this operation manual and pass it on to any future owner.
SET UP AND INSTALLATION
• Assemble the product according to the assembly instructions.
• To prevent possible scratches or damage, assemble the product on a soft surface such as a blanket, carpet or packaging.
• Place the product a safe distance from window frames, radiators, furniture etc. so that persons cannot become trapped.
It is recommended that this product is assembled by 2 people.
Any questions contact Knight on 0800 143 143
Due to continuous improvement of our products, our assembly instructions may not be in complete accordance with the product
and we apologise in advance.

Assembly Instructions
knightgroup.co.nz
Cubit System
Parts
Tools
Electric Driver
Sqaure
8 x M8x16
2 x Legs 2 x Rails
20 x ST5x23 4 x ST5x70
Allen Key

Page 1
Assembly Instructions
knightgroup.co.nz
Page 1
Assembly Instructions
Step 1
Cubit System
8 x M8x16
M8x16
Allen Key

Page 2
Assembly Instructions
knightgroup.co.nz
Page 2
Assembly Instructions
Step 2
Cubit System
20 x ST5x23 4 x ST5x70
ST5x23
ST5x23
ST5x23
ST5x23
ST5x70
ST5x70
Worktop Alignment with Frame:
Please note when installing the worktops,
they will need to over hang at the front
by 5mm to allow for the screen bracket
gap of 10mm between the two worktops.

Page 3
Assembly Instructions
knightgroup.co.nz
Page 3
Assembly Instructions
Cubit System (Wire Basket Install)
6 x ST5x23 1 x Wire Basket

Page 4
Assembly Instructions
knightgroup.co.nz
Page 4
Assembly Instructions
Cubit System
Complete
Adding Additional Users:
To add additional users to the 2 person Cubit System
illustrated in these assembly instructions please refer to the
assembly instructions for the ‘Cantilever Leg and Rail Set’.
Active25 Screens:
To add Active25 Screens to Cubit System please refer to the
assembly instructions for ‘Active25 System Screens’.
Assembly instructions available online at knightgroup.co.nz
under resources.
