Knight Agile Round User manual

knightgroup.co.nz
Tools Required: Powered Screwdriver
Assembly Instructions
Agile Round Desk

Page 1
Assembly Instructions
knightgroup.co.nz
Agile Round Desk
Parts:
Tools:
8x M8x20
12x ST5.0x23*
2x ST3.5x16
4x M6x12
1 x HEX KEY
• To prevent possible scratches or damage, assemble the product
on a soft surface such as a blanket, carpet or packaging.
Recommended
2-person Step
Item Description Quantity
A Worktop (optional) 1
B Support bar 2
C Pre-assembled frame 1
DFoot 2
E Handset 1
F Controller cable 1
G Power cord 1
A
B
B
C
D
D
E
F
G
*Supplied when purchased with worktop.
DESK TECHNICAL DATA
• Height Range: 640mm - 1290mm
• Speed: ~30mm/s
• Max load: 140kg
• Input Voltage: 100-240V AC 50-60Hz
• Output Voltage: 24V DC
• Duty Cycle: 10% 2min on 18min off

Page 2
Assembly Instructions
knightgroup.co.nz
Step 1
Step 3
Step 2
Step 4
Page 2
Assembly Instructions
Worktop Length
1200mm 1125mm
1500mm 1425mm
1800mm 1725mm
Tighten the screws and fix support bars in place with
4x M6x12.
Slide on worktop support bars.Unfold the frame.
Loosen frame and adjust length to suit worktop.
Agile Round Desk
4x M6x12
C
B
B
Be careful with the cable.

Page 3
Assembly Instructions
knightgroup.co.nz
Page 3
Assembly Instructions
Step 8Step 7
Step 6Step 5
Connect cables and attach handset with 2x ST3.5x16.
Handset can be attached left or right hand.
Tighten up the frame.Fix worktop to frame with 12x ST5.0x23.
Attach the feet using 8x M8x20
Agile Round Desk
12x ST5.0x23
2x ST5.0x23 8x M8x20
A
G
E
F
D
D
Place left or right hand.

Page 4
Assembly Instructions
knightgroup.co.nz
Page 4
Assembly Instructions
Please carefully read the assembly manual and direction for use
prior to installment, use and maintenance of the table frame to
gain a complete understanding of its contents. It provides you
with important information about the safety, use, installation and
maintenance of the table.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY,
SAFETY AND OPERATION INSTRUCTIONS REGARDING THE USE OF
THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
SAFETY
• The table must be used in a safe manner. Inappropriate use may
cause damage to the table and/or cause bodily harm to the user
or persons nearby.
• Do not tamper with electrical components as this may lead to
serious bodily harm.
• Only connect the electric table frames to the prescribed mains
power voltage
• Do not use the table frame to lift people.
• Retain this operation manual & pass it on to any future owner.
USAGE
• The height-adjustable table is designed for use in dry work
environments only.
• Table is height adjustable so that it can be set to the user’s most
ergonomic working height. The user should seek professional help
to establish their optimum working height.
• The table has been designed as a devise to elevate the users
work surface and associated office peripherals. Do not use the
table frame for any other purposes than that which it has been
designed for. Any other use is at user’s own risk!
• Do not crawl, lie or move around under the table frame, and do
not sit or stand on the table frame.
• CHILDREN should only use the table when supervised by adults.
• In the event of the occurrence of jarring sounds during operation,
STOP using the table and please contact the dealer.
• Liability: The manufacturer accepts under no circumstances
warranty claims or liability claims for damages arising from
improper use or handling of the table frame other than that
described in this operation manual.
SET UP AND INSTALLATION
• Assemble the table frame according to the assembly instructions.
• Place the table in a safe distance from window frames, radiators,
furniture etc. so that persons cannot become trapped.
• Level the table with the adjustable feet ensuring that the table is
stable.
• Check that no cables can get jammed.
• Connect the table to the 110 or 230 VAC power outlet.
• The table is now ready for use.
Important
Completed
Agile Round Desk

Page 5
Assembly Instructions
knightgroup.co.nz
Page 5
Assembly Instructions
Handset manual
Agile Round Desk
Display
screen Home key
Memory
key
Up & down
key
OPERATION
• Up & down key - Keep touch key to adjust desk height until
you reach optimum height.
• Display screen - Shows current height of desk
• Memory key - After setting memory key desk height will
auto adjust to the chosen setting.
• How to set memory key - Adjust desk to preferred height
using up & down key. Touch a memory key for 5 seconds
until you hear a beep to save setting
• Home key - Auto adjusts desk height to 72cm. This height
is the standard optimum height when sitting.
Handset locks automatically after 30 seconds of no use.
To unlock handset touch up or down key.
ADDITIONAL SETTINGS
Press home key until you hear a second beep.
Use the up and down keys to navigate then press the home
key to make your selection.
A = Sensitivity of downwards anti collision
Up & down keys to navigate to selection
1 - High sensitivity
2 - Standard sensitivity
3 - Low sensitivity
4 - Off
Press M2 to make selection.
Press M2 again to save selection and return home screen.
B = CM or IN display
Up & down keys to navigate to selection
1 - CM
2 - IN
Press M2 to make selection.
Press M2 again to save selection and return home screen.
C = Home height setting
Up & down keys to adjust height
Press M2 to make selection.
Press M2 again to save selection and return home screen.
D = Minimum height setting
Up & down keys to adjust height
Press M2 to make selection.
Press M2 again to save selection and return home screen.
E = Maximum height setting
Up & down keys to adjust height
Press M2 to make selection.
Press M2 again to save selection and return home screen.
F = Sensitivity of upwards anti collision
Up & down keys to navigate to selection
1 - High sensitivity
2 - Standard sensitivity
3 - Low sensitivity
4 - Off
Press M2 to make selection.
Press M2 again to save selection and return home screen.
ERROR CODES
ER1 = Motor stop
Power off and restart. If fault still exists there is a motor problem.
ER2 = Synchro error beyond 15mm
Power off and restart. If handset display RST (down key unlocked)
keep touching down key to the lowest number.
ER3 = Cable fault
Motor cable is off or broken. Power off and restart.
ER4 = Communication fault
Check cables for handset and controller. Power off and restart.
ER5 = Overload protection
There is too much weight on desk. Lighten load, power off and restart.
Hot = Overload power protection
Will auto recover after 5 min.
