Knight Agile Desk Electric 2 Column User manual

knightgroup.co.nz
Agile Desk - Electric 2 Column
Tools Required: Powered Screwdriver
Assembly Instructions - Single Sided, Double Sided, Returns

knightgroup.co.nz
Assembly Instructions
Page 2
Assembly Instructions
Agile Desk - Electric 2 Column
Contents
Electric 2 Column Single Sided Desk Page 4
Electric 2 Column Single Sided Desk with Desk Hung Screen Page 14
Electric 2 Column Single Sided Desk with Cable Tray Page 22
Electric 2 Column Double Sided Desk Page 27
Electric 2 Column Double Sided Desk with Screen Page 42
Electric 2 Column Double Sided Desk with Cable Tray Page 47
Electric 2 Column Return Right Hand Page 54
Electric 2 Column Return Right Hand Single Sided Desk Page 58
Electric 2 Column Return Right Hand Double Sided Desk Page 61
Electric 2 Column Return Left Hand Page 64
Electric 2 Column Return Left Hand Single Sided Desk Page 68
Electric 2 Column Return Left Hand Double Sided Desk Page 71
Electric 2 Column Digital Handset Functions Page 74

knightgroup.co.nz
Assembly Instructions
Page 3
Assembly Instructions
Agile Desk - Electric 2 Column
IMPORTANT!
Please carefully read the assembly manual and direction for use prior to
instalment, use and maintenance of the table frame to gain a complete
understanding of its contents. It provides you with important information about
the safety, use, installation and maintenance of the table.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY, SAFETY
AND OPERATION INSTRUCTIONS REGARDING THE USE OF THIS PRODUCT MAY
RESULT IN SERIOUS BODILY INJURY.
SAFETY
• The table must be used in a safe manner. Inappropriate use may cause
damage to the table and/or cause bodily harm to the user or persons nearby.
• Do not tamper with electrical components as this may lead to serious bodily
harm.
• Only connect the electric table frames to the prescribed mains power
voltage.
• Do not use the table frame to lift people.
• Please retain this operation manual and pass it on to any future owner.
USAGE
• The height-adjustable table is designed for use in dry work environments only.
• The table height is infinitely adjustable within its height range so that it can
be set to the user’s most ergonomic working height. The user should seek
professional help to establish their optimum working height.
• The table has been designed as a devise to elevate the users work surface
and associated office peripherals. Do not use the table frame for any other
purposes than that which it has been designed for. Any other use is at user’s
own risk!
• Do not crawl, lie or move around under the table frame, and do not sit or
stand on the table frame.
• CHILDREN should only use the table when supervised by adults.
• Liability: The manufacturer accepts under no circumstances warranty claims
or liability claims for damages arising from improper use or handling of the
table frame other than that described in this operation manual.
SET UP AND INSTALLATION
Assemble the table frame according to the following pages in this assembly
instructions guide.
• Place the table in a safe distance from window frames, radiators, furniture etc.
so that persons cannot become trapped.
• Level the table with the adjustable feet ensuring that the table is stable.
• Check that no cables can get jammed.
• Connect the table to the 110 or 230 VAC power outlet.
The table is now ready for use.
MAINTENANCE
• The table does not require any maintenance by the user
• The table is only to be cleaned with a wrung cloth.
TECHNICAL DATA
DESK
Height Range: 680-1130mm includes worktop
Speed: 22mm/s
Weight Rating: 120kg
WORKSTATION/DESK & RETURN
Height Range: 680-1130mm includes worktop
Speed: 22mm/s
Single Motor
Weight Rating: 100kg
Input Voltage: 100-240V AC 50-60Hz
Output Voltage: 24V DC 2.0A
Duty Cycle: 10% 2min on 18min off

knightgroup.co.nz
Assembly Instructions
Page 4
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Parts
1 x L&R Leg Pair 1 x Cross Rail 1 x Drive Shaft
4 x Levelling Foot
1 x L&R Support Bar Pair2 x Foot 2 x Leg Rail Pair
8 x M8x10 6 x ST5.0x23 2 x ST3.9x28 x M8x25
1 x Handset1 x Power Supply1 x Power Cord

knightgroup.co.nz
Assembly Instructions
Page 5
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Step 1
4 x M8x10

knightgroup.co.nz
Assembly Instructions
Page 6
Assembly Instructions
Step 2
Agile Desk - Electric 2 Column Single Sided
4 x M8x10

knightgroup.co.nz
Assembly Instructions
Page 7
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Step 3
4 x Levelling Foot 8 x M8x25
IMPORTANT!
REFER TO PAGE 14 FOR INSTALL
OF SCREEN

knightgroup.co.nz
Assembly Instructions
Page 8
Assembly Instructions
Worktop Length
1200mm 1125mm
1500mm 1425mm
1800mm 1725mm
2100mm 2025mm
Agile Desk - Electric 2 Column Single Sided
Step 4
Length

knightgroup.co.nz
Assembly Instructions
Page 9
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
1 x Drive Shaft
Step 5

knightgroup.co.nz
Assembly Instructions
Page 10
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Step 6
6 x ST5.0x23

knightgroup.co.nz
Assembly Instructions
Page 11
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Step 7
2 x ST3.9x12
A

knightgroup.co.nz
Assembly Instructions
Page 12
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Step 8

knightgroup.co.nz
Assembly Instructions
Page 13
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided
Completed

knightgroup.co.nz
Assembly Instructions
Page 14
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Parts
2 x M8x25 4 x ST5.0x23 2 x Stabilizing BracketSSD Screen Brackets
L/R Pair

knightgroup.co.nz
Assembly Instructions
Page 15
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Step 1

knightgroup.co.nz
Assembly Instructions
Page 16
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Step 2
348348
90.0°90.0°
348
90.0°

knightgroup.co.nz
Assembly Instructions
Page 17
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Step 3

knightgroup.co.nz
Assembly Instructions
Page 18
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Step 4
2 x M8x25

knightgroup.co.nz
Assembly Instructions
Page 19
Assembly Instructions
90.0°
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Step 5
4 x ST5.0x23 2 x Stabilizing
Bracket

knightgroup.co.nz
Assembly Instructions
Page 20
Assembly Instructions
Agile Desk - Electric 2 Column Single Sided with Hung Screen
Step 6
90.0°90.0°
