Kogan SMARTERHOME KASGSHT24BA User manual

KOGAN SMARTERHOME™ 2400W
GLASS PANEL HEATER
KASGSHT24BA & KASGSHT24WA

•Read all instructions fully before using the product for the first time and retain for
reference. If passing this product on to a new owner, include a copy of this guide.
•Do not leave this unit unattended while it is in use.
•Some parts of this product can become very hot and cause burns. Particular
attention must be given when children and vulnerable people are present. Keep
children and pets at a safe distance from the unit.
•This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•This heater is not equipped with a device to control the room temperature. Do not
use this heater in small rooms when occupied by persons not capable of leaving a
room on their own, unless constant supervision is provided.
•In order to avoid overheating and potential fire hazard, ensure the heater is not
covered. In particular, do not use it for drying clothes.
•Do not attempt to repair this product yourself. If the product or its power supply
experiences any malfunction or damage, stop using it immediately and contact
Kogan.com to arrange a repair.
•If the power cable is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
•Do not handle the element with bare hands. If it is inadvertently touched, remove
finger marks with a soft cloth and methylated spirits or alcohol: otherwise, the
marks will burn into the element causing premature heater failure.
•This product is suitable for indoor use only.
•Do not use this heater in the immediate surroundings of a bath, shower or
swimming pool.
•Do not touch the plug with wet or damp hands.
•Do not run the power cable under carpeting. Do not cover the power cable with
rugs, runner or similar coverings. Arrange the power cable away from foot traffic
and where it will not be tripped over.
•Do not wind the power cable around the unit.
•Do not insert or allow foreign objects to enter any ventilation or opening on the
heater, as this may result in electric shock, fire or damage to the heater.
•Where possible, avoid the use of an extension cable as this may overheat and
cause a fire. However, if you have to use an extension cable, ensure it is suitable for
SAFETY & WARNINGS

the purpose, has been tested for outdoor use and preferably has an RCD device
fitted or attached.
•Always ensure that the heater is plugged into a suitable socket.
•Do not position directly above or below an electrical socket.
•Always use on a dry, suitably strong, stable, flat and level surface.
•Always unplug the unit and ensure that the unit has cooled completely before
moving, cleaning or storing.
•This heater is intended for domestic use only and should not be used commercially
for contract purposes. Any alternative use, not recommended by Kogan.com, may
result in fire, electric shock or injury to persons.
•Check exterior walls for areas of damage before installing the heater.
•Check exterior walls for communication and electrical cables and pipelines. Should
any service lines be present in the immediate vicinity do not install your heater, find
an alternative location to install this product.
•Do not remove any of the warning stickers or signs from the product.
•This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•When the appliance is not in use and before cleaning, unplug the appliance from
the outlet firstly.
•WARNING: In order to avoid overheating, do not cover the heater.
•The heater must not be located immediately below a socket outlet.
•Do not use this heater if it has been dropped.
•Do not use if there are visible signs of damage to the heater.
•Use this heater on a horizontal and stable surface, or attach it to the wall.
•WARNING: Do not use this heater in small rooms when they are occupied by
persons not capable of leaving the room on their own, unless constant supervision
is provided.
•WARNING: To reduce the risk of fire, keep textiles, curtains, or any other
flammable material a minimum distance of 1 metre from the air outlet.
•The heater is to be installed so that switches and other controls cannot be
touched by a person in the bath or shower.

1
Setting button
8
Timer indicator
2
Up button
9
Temperature (°C) indicator
3
Down button
10
LED number display
4
Power button
11
LED screen on-off button
5
Heating element working indicator
12
Low/High heating selection
6
Low heating indicator
13
Wi-Fi Indicator (solid when connected;
otherwise, flashing)
7
High heating indicator
•Power Input：220-240V~50-60Hz
•Power Consumption: 1200-2400W
OVERVIEW
Air Outlet Control Display
Switch
Leg

Leg Installation
Remove the heater and all accessories from the packing.
1. Place the heater on a flat, dry and clean surface. Install the legs as illustrated:
2. Turn the heater right-side up and ensure it sits firmly on its legs.
A. Make sure there is no breakage or crack on the power cord before its first use.
B. Make sure that the rating power on product is same with your local power and the
socket with safety grounding equipment or replace the socket for safety use.
INSTALLATION

Wall Mount Installation
Drill holes at each side on the wall and insert the plastic expanded plugs within. Attach the
bracket to the wall with screws.
Note:
The heater MUST be installed with the minimum required distance at the four sides of
the heater.
Air Outlet
Minimum 1000mm
Minimum
100mm Minimum
100mm
Minimum 100mm
Floor

Place the heater onto the bracket, ensuing that the holes align.
Tighten screws on the top of bracket to secure.
To remove the heater from the bracket, pull it 5mm outward and then move it 10mm to the
left.

Download the “Kogan SmarterHome™” app from the Play Store (Android) or App Store
(iOS).
If you do not have a Kogan SmarterHome™ account, register or sign in with a verification
code sent by SMS.
To Register
1. Tap to enter registration page.
2. The system automatically recognises your country/area. You can also select your
country code manually. Enter your mobile phone number/email address and tap
“Next”.
3. If you choose the mobile phone number option, then enter the verification code in
the message sent to you by SMS. Set a password as prompted and press “Confirm”
to finish your registration.
APP INSTALLATION

Add Device Through Network
1. Power the SmarterHome™device on and follow the product-specific instructions
to enter the Wi-Fi-connect mode.
2. Open Kogan SmarterHome™ app and tap “+” in the upper right to add a new
device through the network.
3. Ensure the device’s indicator light rapidly flashes and tap “Confirm light is rapidly
flashing”.
4. Select Wi-Fi network (note: Network must be 2.4GHz band) and enter the
password.
The device will commence the pairing process and connect to the app.
5. After successfully configuring the devices, the device will be shown on the home
page. Tap to enter its control page.

Heating Level
Heating
Hi
Lo
Child-lock
Increase temp.
ECO
Button child-lock
Settings
Set temp.
Area temp.
ECO
ModeON/OFF
Button count down
°C/F
Schedule
Note:
•When device is online, it can be controlled.
•When device is offline, it displays “Offline” and cannot be remotely powered
on.
Decrease temp.

Note: You will need to have set up a Google Home account prior to linking your Kogan
SmarterHome™ device.
1. Select “Menu” and then “Home Control”.
2. In the “Home Control” screen, select the “+” icon in the bottom right.
3. A list will appear showing actions and a search function to access more apps: from
here, install the SmarterHome™app.
Login to App
Add Device
Select Device
4. Log into your SmarterHome™ account with your email address or mobile number.
5. Once linked, it will show the devices linked to your account: You can assign them
to rooms. You will be prompted to authorise apps to sync.
6. Click “Done” and then it will give you a list of commands available.
7. When successfully linked, you will see it on your “Home Control” screen at the
bottom of the app screen. You can now control your Kogan SmarterHome™
devices through Google Home.
GOOGLE HOME CONTROL

Set Up New Device Add and Manage Device
Assign Room Update Home Control

Note: You will need to have set up an Alexa account prior to linking your Kogan
SmarterHome™ device.
1. Select “Menu” and then “Skills”.
2. Search for the app and enable it.
3. Login to your SmarterHome™account with your email address or mobile number.
4. Select “Discover Devices” and the app will begin searching.
5. When successfully linked, you will see a list of connected Kogan SmarterHome™
devices. You can now control your Kogan SmarterHome™devices through Alexa
with your voice.
Alexa Account Setup
Search App in All Skills
Enable App
ALEXA

Login to App
Discover Devices
Setup Device

Turn On
1. Connect the heater to a power socket and turn on the main switch: the heater will
be in standby.
2. Press the power buttons to begin heating operation: the display will show the
current ambient temperature.
3. Press the setting button and the heater will enter temperature setting mode. Use
the up and down buttons to select the desired temperature.
Temperature Setting
1. Press the setting button first to enter the temperature setting mode. Use the up
and down buttons to select the desired temperature (5–45°C).
The selected temperature will be set when there is no input for 5 seconds.
Timer Setting
With a timer set, the heater will turn off automatically once the set time has been reached.
1. Press the setting button twice to enter the timer setting mode. Use the up and
down buttons to select the desired timer (in hours).
2. The current timer setting will be accepted when there is no input for 5 seconds.
High/Low Heat Mode Selection
1. During operation:
•The heating level button on the remote will toggle between high and low heat
mode.
•The up button on the heater and the remote will toggle between high heat
mode and turning the heating off.
•The down button on the heater and the remote will toggle between low heat
mode and turning the heating off.
2. During operation, the relevant heating indicator will be illuminated.
OPERATION

Child-Lock Function
1. In heating mode, press and hold both up and down buttons for 3 seconds and the
child lock function will be enabled. After 5 seconds, the display will show the
ambient temperature.
2. To remove the child lock, press and hold both up and down buttons for 3 seconds
again.
Display Buttons Activation
During operation, the display buttons will not be illuminated. Touch the panel below the
display and they will come on.
Eco Function (Night Mode)
In heating mode, press 1 and 3 for 3 seconds (press ECO on Remote Control), ECO function
runs. In this mode, display shows only some indicator (5 or 6 or 7 or 8, depending on which
setting has been done before ECO runs)
Celsius/Fahrenheit Display
Press and hold both the setting and up buttons for 10 seconds.
Open Window Detection
•If the temperature decreases by 3°C or more in 2 minutes, the Open Window
detection will take effect and the heater will stop heating. The temperature
indicator will flash.
•To restore normal operation, use the power button to turn the heater off, then turn
it on again after a few seconds.
Wi-Fi Reset
During operation, press and hold the setting button for 3 seconds.
Wi-Fi will now be reset, and the Wi-Fi indicator light will be on.
Turn Off
Press the power button to turn the heater off.

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
