Kohler K-4759T User manual

2-10
K-4759T
11-18
1119274-T01-C
制造商：上海科勒电子科技有限公司
中国上海市宝山区丰翔路1955号 邮编：200444
科勒（中国）投资有限公司

on the product surface. Please ensure sufficient ventilation in your
surroundings to prevent possible damage to electronic components.
1119274-T01-C
2
Kohler Co.
~

- -
Kohler Co.
3
1119274-T01-C

~
1. Match toilet roughing-in requirement and installation tips
1 Distance between installation holes:136-140mm
2 Distance between instalaltion holes and tank front rim:>20mm
3 Distance between instalaltion holes and bowl inner rim:＜70mm
4 Distance between installation holes and tank top rim:460-490mm
5 Bowl inner diameter:370-390mm
6 Reserve place around 1 meter away from the toilet before installation
2.
3.
1
2
3
4
5
It is recommended to use water-resistant socket.Do not use an
extension code with the product.
1119274-T01-C
4
Kohler Co.
~

4.
Kohler Co.
5
1119274-T01-C

5.
1119274-T01-C
6
Kohler Co.

6.
NOTE! For those newly installed plumbing pipes, before the inlet
hose connected to T-valve, must flush for several seconds to clean
the inner side of the pipe, in order to remove the dirt and debris etc.
Inlet Hose
IMPORTANT! Do not plug in the seat untill connect the water supply.
NOTE! Please do not reuse the old hose.
Kohler Co.
7
1119274-T01-C

7. Install the Remote Controller
Choose a mounting location for the remote holder that is easily
accessible while sitting on the seat.
The remote holder can be installed using screws or double-sided
tape. Choose your preferred method for securing the remote holder.
Follow only the instructions for your chosen installation method.
Anchors may not be needed for installation to certain materials.
Use the appropriate mounting hardware for your particular installation
surface.
Position the remote holder at the desired mounting location with
the rectangular indent toward the bottom (as shown).
Using a pencil, mark the two mounting hole locations. Set the
holder aside.
Drill a 3.5mm hole
at each of the marked locations.
Drill a 6mm hole at each of
the marked locations. Install the wall anchors into the holes.
Install Using Screws
NOTE:
For installation to stud or other wood surface:
For installation using wall anchors:
Remote Holder
Anchors
Screws
Remote
Controller
Caps
Double-sided Tape
1119274-T01-C
8
Kohler Co.

Install the Remote Holder (cont.)
Install Using Double-Sided Tape
Position the remote holder over the mounting holes so the
rectangular indent is toward the bottom.
Secure the remote holder with the screws.
Install the caps to cover the screws.
Position the remote into the holder with the user preset icons
facing up.
Remove the paper from the tape squares.
Press the remote holder into place.
Position the remote into the holder with the user preset icons facing
up.
Kohler Co.
9
1119274-T01-C

8.
Clip
Plug in the power cord and press the power button located at the
right side of the seat while top indicator starts to flash. Then the tank
begins water filling action. The indicator stops flashing to indicate
the water filling action is completed.
senor area
Press “POWER”
icon
