Kohler K-4108 User manual

Features
•In-line heater provides continuously heated water for consistent
comfort.
•Front and rear wash modes provide warm water for cleansing.
•Adjustable water temperature and water pressure.
•Choose oscillating or pulsating spray.
•Touchscreen remote control with two programmable user
presets.
•Stainless steel wand with UV-light self-sanitization.
•Heated seat with five temperature settings.
•LED lighting illuminates the bowl to serve as a night-light.
•Warm-air drying system with adjustable air speed and
temperature.
Codes/Standards
•Carbon filter for odor control.
•Quiet-Close™lid closes slowly and quietly without slamming. ASME A112.4.2/CSA B45.16
UL 1431
•Quick-Release™hinges allow seat to be unlatched from toilet
for easy removal and convenient cleaning; no tools required. CSA C22.2 No. 64
CSA C22.2 No. 68
•Grip-Tight bumpers hold seat firmly in place.
•Ergonomically designed for comfortable seating. KOHLER®Intelligent Toilet and C3®
Cleansing Seat Three-Year Limited
Warranty
Material
•Plastic
Installation See website for detailed warranty information.
•Fits most elongated toilets.
Available Colors/Finishes
•Requires a dedicated circuit electrical outlet.
Included Components
Additional Components:
Remote
Supply hose
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-25-2019 08:24 - US/CA
C3®-230
Elongated Cleansing Toilet Seat
K-4108

17-1/8" (435 mm)
Notes
Required Electrical Service Install this product according to the installation
guide.
One dedicated circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI). Outside North America,
this device may be known as a Residual Current Device (RCD). Connect the seat to a cold water supply of
drinking quality water at a pressure of 20 psi - 80
psi (139 kPa - 551 kPa).
120 V, 15 A, 60 Hz
Technical Information Do not install this seat in a location where: (1)
water might be splashed on the product or (2)
All product dimensions are nominal.
ElongatedSeat shape type: excessive moisture, high humidity levels, or
condensation is present. This will avoid damage
to the electronic components.
Closed-frontSeat front type:
5-1/2" (139 mm)Seat-mounting holes:
Do not use an extension cord with this product.
46" (1168 mm)Power cord length:
To avoid possible product malfunction, do not
plug in the seat until instructed to do so.
Locate the recepticle at least 6" (152 mm) above
the floor, and within a 32" (813 mm) radius
measured 2" (51 mm) from the bowl ledge.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-25-2019 08:24 - US/CA
C3®-230
Elongated Cleansing Toilet Seat
K-4108
